Search Results (41)

Titanium dioxide (TiO₂) is a wide-bandgap semiconductor material with broad application potential, known for its excellent photocatalytic performance, high chemical stability, low cost, and non-toxicity. These properties make it highly attractive for applications in photovoltaic energy, environmental remediation, and optoelectronic devices. For instance, TiO₂ is widely used as a photocatalyst for hydrogen production via water splitting and for degrading organic pollutants, thanks to its efficient photo-generated electron–hole separation. Additionally, TiO₂ exhibits remarkable performance in dye-sensitized solar cells and photodetectors, providing critical support for advancements in green energy and photoelectric conversion technologies. Boron-doped diamond (BDD) is renowned for its exceptional electrical conductivity, high hardness, wide electrochemical window, and outstanding chemical inertness. These unique characteristics enable its extensive use in fields such as electrochemical analysis, electrocatalysis, sensors, and biomedicine. For example, BDD electrodes exhibit high sensitivity and stability in detecting trace chemicals and pollutants, while also demonstrating excellent performance in electrocatalytic water splitting and industrial wastewater treatment. Its chemical stability and biocompatibility make it an ideal material for biosensors and implantable devices. Research indicates that the combination of TiO₂ nanostructures and BDD into heterostructures can exhibit unexpected optical and electrical performance and transport behavior, opening up new possibilities for photoluminescence and rectifier diode devices. However, applications based on this heterostructure still face challenges, particularly in terms of photodetector, photoelectric emitter, optical modulator, and optical fiber devices under high-temperature conditions. This article explores the potential and prospects of their combined heterostructures in the field of optoelectronic devices such as photodetector, light emitting diode (LED), memory, field effect transistor (FET) and sensing. TiO₂/BDD heterojunction can enhance photoresponsivity and extend the spectral detection range which enables stability in high-temperature and harsh environments due to BDD’s thermal conductivity. This article proposes future research directions and prospects to facilitate the development of TiO₂ nanostructured materials and BDD-based heterostructures, providing a foundation for enhancing photoresponsivity and extending the spectral detection range enables stability in high-temperature and high-frequency optoelectronic devices field. Further research and exploration of optoelectronic devices based on TiO₂-BDD heterostructures hold significant importance, offering new breakthroughs and innovations for the future development of optoelectronic technology. Full article

Two-dimensional (2D) van der Waals materials have been actively investigated for broadband, high-sensitivity, low-power-consumption photodetection owing to their highly customizable band structures and fast interfacial charge transfers. Studying photocurrent generation mechanisms provides insights into charge carrier dynamics in WSe₂-based detectors, linking spatial factors (e.g., photocurrent generation/collection) with interfacial band alignment. Here, we employ scanning photocurrent microscopy to spatially resolve the processes of photocurrent generation and collection in WSe₂-based composite structures. Photocurrent polarity and magnitude at interface reflects interfacial band alignment and potential gradients at metal–WSe₂ and WSe₂–In₂Se₃ junctions. Strong electric fields at metal–WSe₂ interfaces drive more efficient electron–hole separation and yield higher photocurrents, compared with WSe₂–In₂Se₃ interfaces. The photodetector exhibits broadband detection capabilities from visible to infrared light, achieving a high responsivity of 17.7 A/W and an excellent detectivity of 3.7 × 10¹² Jones, as well as fast response times of <113 µs. Furthermore, object imaging with a resolution better than 0.5 mm was successfully demonstrated, highlighting the potential of this photoresponse for practical imaging applications. This work reveals that photocurrent is distributed with a clear dependence on device configuration, offering a new avenue for optimizing 2D material-based photoelectric devices. Full article

Due to high responsivity and wide spectral sensitivity, metal halide perovskite photodiodes have a wide range of applications in the fields of visible light and near-infrared photodetection. Specific detectivity is an important quality factor for high-performance perovskite-based photodiodes, while one of the keys to achieving high detectivity is to reduce dark current. Here, 3-fluoro phenethylammonium iodide (3F-PEAI) was used to passivate the perovskite surface and form the two-dimensional (2D) perovskite on the three-dimensional (3D) perovskite surface. The as-fabricated passivated perovskite photodiodes with 2D/3D hybrid-dimensional perovskite heterojunctions showed two orders of magnitude smaller dark current, larger open circuit voltage and faster photoresponse, when compared to the control perovskite photodiodes. Meanwhile, it maintained almost identical photocurrent, achieving a high specific detectivity up to 2.4 × 10¹² Jones and over the visible-near-infrared broadband photodetection. Notably, the champion photoresponsivity value of 0.45 A W⁻¹ was achieved at 760 nm. It was verified that the 2D capping layers were able to suppress trap states and accelerate photocarrier collection. This work demonstrates strategic passivation of surface iodine vacancies, offering a promising pathway for developing ultrasensitive and low-power consumption photodetectors based on metal halide perovskites. Full article

Objectives: To design a multifunctional nanozyme hydrogel with antibacterial, photo-responsive nitric oxide-releasing, and antioxidative properties for promoting the healing of infected wounds. Methods: We first developed ultra-small silver nanoparticles (NPs)-decorated sodium nitroprusside-doped Prussian blue (SNPB) NPs, referred to as SNPB@Ag NPs, which served as a multifunctional nanozyme. Subsequently, this nanozyme, together with geniposide (GE), was incorporated into a thermo-sensitive hydrogel, formulated from Poloxamer 407 and carboxymethyl chitosan, creating a novel antibacterial wound dressing designated as GE/SNPB@Ag hydrogel. The physical properties of a GE/SNPB@Ag hydrogel were systematically investigated. Results: After embedding the nanozyme and GE, the resulting GE/SNPB@Ag hydrogel retains its thermosensitive properties and exhibits sustained release characteristics. In addition to its catalase-like activity, the nanozyme demonstrates high photothermal conversion efficiency, photo-induced nitric oxide release, and antibacterial activity. In addition, the hydrogel exhibits favorable antioxidant properties and high biocompatibility. The results of animal experiments demonstrate that the composite hydrogel combined with laser irradiation is an effective method for promoting infected wound healing. Conclusions: In vitro and in vivo studies indicate that the resulting GE/SNPB@Ag hydrogel holds significant potential for the treatment of infected wounds and for further clinical applications. Full article

Wide-bandgap semiconductors like GaN, known for their superior photoresponse and detection capabilities in the ultraviolet range, represent a foundational component in the design of advanced photodetectors, where the integration of materials with distinct spectral sensitivities into heterojunctions is pivotal for next-generation device innovation. A high-performance self-powered dual-mode ultraviolet photodetector based on a (PEA)₂PbI₄/GaN heterojunction was fabricated via spin coating. The device exhibits outstanding UV sensitivity under both positive and negative bias, achieving a responsivity of 1.39 A/W and a detectivity of 8.71 × 10¹⁰ Jones under 365 nm UV illumination. The built-in electric field at the heterojunction interface enables self-powered operation, achieving a rapid rise time of 46.9 ms and a decay time of 55.9 ms. These findings offer valuable insights into the development and application of perovskite and wide-bandgap semiconductor heterojunctions in optoelectronic devices. Full article

Highly sensitive infrared photodetectors are needed in numerous sensing and imaging applications. In this paper, we report on extended short-wave infrared (e-SWIR) avalanche photodiodes (APDs) capable of operating at room temperature (RT). To extend the detection wavelength, the e-SWIR APD utilizes a higher indium (In) composition, specifically In_0.3Ga_0.7As_0.25Sb_0.75/GaSb heterostructures. The detection cut-off wavelength is successfully extended to 2.6 µm at RT, as verified by the Fourier Transform Infrared Spectrometer (FTIR) detection spectrum measurement at RT. The In_0.3Ga_0.7As_0.25Sb_0.75/GaSb heterostructures are lattice-matched to GaSb substrates, ensuring high material quality. The noise current at RT is analyzed and found to be the shot noise-limited at RT. The e-SWIR APD achieves a high multiplication gain of $M~190$ at a low bias of $V_{bias}=-2.5\mathrm{V}$ under illumination of a distributed feedback laser (DFB) with an emission wavelength of 2.3 µm. A high photoresponsivity of $\mathfrak{R}>140\mathrm{A}/\mathrm{W}$ is also achieved at the low bias of $V_{bias}=-2.5\mathrm{V}$. This type of highly sensitive e-SWIR APD, with a high internal gain capable of RT operation, provides enabling technology for e-SWIR sensing and imaging while significantly reducing size, weight, and power consumption (SWaP). Full article

This paper presents the development of a photoelectrochemical sensor for hypochlorous acid (HOCl) detection, employing a phenothiazine-based organic photosensitizer (Dye-PZ). The designed probe, Dye-PZ, follows a D-π-A structure with phenothiazine as the electron-donating group and a cyano-substituted pyridine unit as the electron-accepting group. A specific reaction of the phenothiazine sulfur atom with HOCl enables selective recognition. The covalent immobilization of Dye-PZ onto a titanium dioxide nanorod-coated fluorine-doped tin oxide electrode (FTO/TiO₂) using bromo-silane coupling agent (BrPTMS) resulted in the fabrication of the photoanode FTO/TiO₂/BrPTMS/Dye-PZ. The photoanode exhibited a significant photoresponse under visible-light irradiation, with a subsequent reduction in photocurrent upon reaction with HOCl. The oxidation of the phenothiazine sulfur atom to a sulfoxide diminished the internal charge transfer (ICT) effect. Leveraging this principle, the successful photoelectrochemical sensing of HOCl was achieved. The sensor showed high stability, excellent reproducibility, and selective sensitivity for HOCl detection. Our study provides a novel approach for the development of efficient photoelectrochemical sensors based on organic photosensitizers, with promising applications in water quality monitoring and biosensing. Full article

Near-infrared (NIR) light has many applications in agriculture, transportation, medicine, the military, and other fields. Lead phthalocyanine (PbPc) exhibits excellent near-infrared (NIR) light absorption characteristics and is widely used in NIR-sensitive organic photodetectors. In this work, PbPc-based NIR organic phototransistors (OPTs) with different active layer structures were designed and fabricated. The photo-absorption characteristics of organic films, photosensitive properties, and air stability of the devices were investigated. The results suggested that (i) the bilayer planar heterojunction (PHJ) devices exhibit far better photosensitive performance than the single layer ones due to higher mobility of the formers than the latters; (ii) the bilayer PHJ ones with p-type channel have equivalent photosensitive performance to those with n-type channel owing to equivalent mobility, higher NIR absorption and lower exciton dissociation efficiency of the formers than the latters; (iii) the bilayer PHJ ones with p-type channel possess superior air stability to those with n-type channel thanks to better air stability of pentacene channel layer than C₆₀ channel layer; (iv) the tri-layer PHJ ones perform better than the bilayer PHJ ones with p-type channel and exhibit a high photoresponsivity of 1415 mA/W and a maximum photo-to-dark current ratio of 1.2 × 10⁴, and such an outstanding performance benefits from the virtues of tri-layer PHJ structure including high light absorption, carrier mobility and exciton dissociation efficiency; and (v) the air stability of the tri-layer PHJ ones is better than that of the bilayer PHJ ones with p-type channel, which can be attributed to the passivation of the top-level C₆₀ layer. Full article

In recent years, two-dimensional (2D) layered transition metal dichalcogenides (TMDs) have received significant attention due to their exceptional electrical and optical properties. Among these 2D materials, ReS₂ distinguishes itself through its unique optical and conductance anisotropy. Despite concerted efforts to produce high-quality ReS₂, the unique interlayer decoupling properties pose substantial challenges in growing large-area ReS₂ thin films, with the preparation of single layers proving even more complex. In this work, large-scale continuous monolayer and bilayer ReS₂ films were successfully grown on mica substrates using low-pressure chemical vapor deposition (LPCVD). Photodetectors were fabricated using the prepared high-quality ReS₂ films, and the devices presented stable photoresponse and enhanced response sensitivity. The production of continuous ReS₂ atomic layers heralds promising prospects for large-scale integrated circuits and advances the practical application of optoelectronics based on 2D layered materials. Full article

We present a straightforward and cost-effective method for the fabrication of flexible photodetectors, utilizing tetragonal phase VO₂ (A) nanorod (NR) networks. The devices exhibit exceptional photosensitivity, reproducibility, and stability in ambient conditions. With a 2.0 V bias voltage, the device demonstrates a photocurrent switching gain of 1982% and 282% under irradiation with light at wavelengths of 532 nm and 980 nm, respectively. The devices show a fast photoelectric response with rise times of 1.8 s and 1.9 s and decay times of 1.2 s and 1.7 s for light at wavelengths of 532 nm and 980 nm, respectively. In addition, the device demonstrates exceptional flexibility across large-angle bending and maintains excellent mechanical stability, even after undergoing numerous extreme bending cycles. We discuss the electron transport process within the nanorod networks, and propose a mechanism for the modulation of the barrier height induced by light. These characteristics reveal that the fabricated devices hold the potential to serve as a high-performance flexible photodetector. Full article

PbS films grown on quartz substrates by the chemical bath deposition method were annealed in an O₂ atmosphere to investigate the role of oxygen in the sensitization process at different annealing temperatures. The average grain size of the PbS films gradually increased as the annealing temperature increased from 400 °C to 700 °C. At an annealing temperature of 650 °C, the photoresponsivity and detectivity reached 1.67 A W⁻¹ and 1.22 × 10¹⁰ cm Hz^1/2 W⁻¹, respectively. The role of oxides in the sensitization process was analyzed in combination with X-ray diffraction and scanning electron microscopy results, and a three-dimensional network model of the sensitization mechanism of PbS films was proposed. During the annealing process, O functioned as a p-type impurity, forming p⁺-type PbS layers with high hole concentrations on the surface and between the PbS grains. As annealing proceeds, the p⁺-type PbS layers at the grain boundaries interconnect to form a three-dimensional network structure of hole transport channels, while the unoxidized p-type PbS layers act as electron transport channels. Under bias, photogenerated electron–hole pairs were efficiently separated by the formed p⁺-p charge separation junction, thereby reducing electron–hole recombination and facilitating a higher infrared response. Full article

A quantum dot (QD) thin film of arsenic (III) oxide-hydroxide/polypyrrole (As₂S₃-As₂O₃/Ppy) with a supernova-like shape has been developed for optoelectronic applications across a wide optical range, spanning from ultraviolet (UV) to infrared (IR). The fabrication process involves the polymerization of pyrrole to form Ppy in the presence of NaAsO₂ and K₂S₂O₈. The resulting QD exhibits a remarkable morphology characterized by a supernova-like structure and a porous nature with a particle size of 4 nm. The unique morphology of the QD contributes to its optical properties. The material demonstrates a maximum optical absorbance that extends up to 600 nm. The chemical structure of the composite has been proved using various characterization techniques. The As₂S₃-As₂O₃/Ppy QD thin film holds significant potential for optoelectronic applications, particularly in light detection across multiple optical regions. Its sensitivity has been evaluated through the measurement of photoresponsivity (R), yielding a high value of 0.31 mA/W. This indicates a substantial current density (J_ph) of 0.031 mA/cm² at a wavelength of 340 nm. Additionally, the detectivity (D) of the photodetector has been calculated based on these values, resulting in a detection capability of 6.9 × 10⁷ Jones. This indicates the ability to detect low levels of photons using this photodetector. The highly reproducible nature of this photodetector enables its application in various optoelectronic systems. The As₂S₃-As₂O₃/Ppy QD thin film offers great promise as a versatile optoelectronic application with its wide optical range, excellent sensitivity, and detectivity. Full article

A highly uniform spherical MoO₂-MoO₃/polypyrrole core-shell nanocomposite has been successfully synthesized as an optoelectronic photon sensing material, capable of detecting light in the UV, Vis, and IR domains. The nanocomposite is prepared through the oxidation of pyrrole using Na₂MoO₄, resulting in a uniform spherical morphology that has been confirmed by TEM, theoretical modeling, and SEM analyses. This morphology contributes to its promising optical behavior, characterized by a small bandgap of 1.36 eV. The optoelectronic photosensing capability of the nanocomposite has been evaluated across the UV, Vis, and IR spectra, demonstrating high efficiency. The photoresponsivity R values indicate the ability of the nanocomposite to generate hot electrons in response to incident photons. With an R value of 4.15 mA·W⁻¹ at 440 nm, this optoelectronic device exhibits considerable promise for integration into an advanced technological apparatus. The detection (D) value of 9.30 × 10⁸ Jones at 440 nm further confirms the high sensitivity in the Vis region. The excellent stability of the device can be attributed to the inherent MoO₂-MoO₃ oxide and Ppy polymer materials. This stability has been demonstrated through reproducibility studies and current-voltage measurements under various optical conditions. The combination of stability, efficiency, and sensitivity makes this optoelectronic device well suited for light sensing applications in both industrial and commercial settings. Its promising performance opens up opportunities for advancements in various fields requiring accurate and reliable light detection. Full article

This study achieved the decoration of poly-3-methyl aniline (P3MA) with As₂O₃–As(OH)₃ using K₂S₂O₈ and NaAsO₂ on the 3-methyl aniline monomer. This resulted in a highly porous nanocomposite polymer composite with wide absorption optical behavior, an average crystalline size of 22 nm, and a 1.73 eV bandgap. The photoelectrode exhibited a great electrical response for electroanalytical applications, such as photon sensing and photodiodes, with a J_ph of 0.015 mA/cm² and J_o of 0.004 mA/cm². The variable J_ph values ranged from 0.015 to 0.010 mA/cm² under various monochromatic filters from 340 to 730 nm, which demonstrates high sensitivity to wavelengths. Effective photon numbers were calculated to be 8.0 × 10²¹ and 5.6 × 10²¹ photons/s for these wavelength values, and the photoresponsivity (R) values were 0.16 and 0.10 mA/W, respectively. These high sensitivities make the nanocomposite material a promising candidate for use in photodetectors and photodiodes, with potential for commercial applications in highly technological systems and devices. Additionally, the material opens up possibilities for the development of photodiodes using n- and p-type materials. Full article

Studying the nonlinear photoresponse of different materials, including III-V semiconductors, two-dimensional materials and many others, is attracting burgeoning interest in the terahertz (THz) field. Especially, developing field-effect transistor (FET)-based THz detectors with preferred nonlinear plasma-wave mechanisms in terms of high sensitivity, compactness and low cost is a high priority for advancing performance imaging or communication systems in daily life. However, as THz detectors continue to shrink in size, the impact of the hot-electron effect on device performance is impossible to ignore, and the physical process of THz conversion remains elusive. To reveal the underlying microscopic mechanisms, we have implemented drift-diffusion/hydrodynamic models via a self-consistent finite-element solution to understand the dynamics of carriers at the channel and the device structure dependence. By considering the hot-electron effect and doping dependence in our model, the competitive behavior between the nonlinear rectification and hot electron-induced photothermoelectric effect is clearly presented, and it is found that the optimized source doping concentrations can be utilized to reduce the hot-electron effect on the devices. Our results not only provide guidance for further device optimization but can also be extended to other novel electronic systems for studying THz nonlinear rectification. Full article
