Search Results (89)

For the precise description of gas physical processes in high-voltage direct current (HVDC) transmission, an advanced and robust numerical framework for the simulation of transient particle densities in the course of corona discharges is developed in this work. The aim is the scalable and consistent modeling of the space charge density under realistic conditions. The core component of the framework is a discontinuous Galerkin method that ensures the conservative properties of the underlying hyperbolic problem. The space charge density at the electrode surface is imposed as a dynamic boundary condition via Lagrange multipliers. To increase the numerical stability and convergence rate, a homotopy approach is also integrated. For the experimental validation, a measurement concept was realised that uses a subtraction method to specifically remove the displacement current component in the signal and thus enables an isolated recording of the transient ion current with superimposed voltage stresses. The experimental results on a small scale agree with the numerical predictions and prove the quality of the model. On this basis, the framework is transferred to hybrid HVDC overhead line systems with a bipolar design. In the event of a fault, significant transient space charge densities can be seen there, especially when superimposed with new types of voltage waveforms. The framework thus provides a reliable contribution to insulation coordination in complex HVDC systems and enables the realistic analysis of electrohydrodynamic coupling effects on an industrial scale. Full article

This paper presents a comprehensive review of High-Voltage Direct-Current (HVDC) systems, focusing on their technological evolution, fault characteristics, and advanced signal processing techniques for fault detection. The paper traces the development of HVDC links globally, highlighting the transition from mercury-arc valves to Insulated Gate Bipolar Transistor (IGBT)-based converters and showcasing operational projects in technologically advanced countries. A detailed comparison of converter technologies including line-commutated converters (LCCs), Voltage-Source Converters (VSCs), and Modular Multilevel Converters (MMCs) and pole configurations (monopolar, bipolar, homopolar, and MMC) is provided. The paper categorizes HVDC faults into AC, converter, and DC types, focusing on their primary locations and fault characteristics. Signal processing methods, including time-domain, frequency-domain, and time–frequency-domain approaches, are systematically compared, supported by relevant case studies. The review identifies critical research gaps in enhancing the reliability of fault detection, classification, and protection under diverse fault conditions, offering insights into future advancements in HVDC system resilience. Full article

A cable accessory is a critical component in constructing high-voltage direct current (HVDC) power grids, and it is typically composed of multiple materials. Due to the discontinuity of the insulation medium, it is prone to failure. This study focuses on a two-layered composite insulation medium simplified from HVDC cable accessories, and its surface potential decay (SPD) characteristics are related to the space charge transport characteristics. Previous studies on surface charge migration have been limited and primarily focused on single-layered insulation materials. However, the actual insulation structure is mostly composite. Therefore, it is of great practical significance to explore the surface charge migration characteristics of two-layered structures. This study presents a bipolar charge transport model after pre-depositing surface charges to investigate the surface charge migration characteristics of an ethylene–propylene–diene monomer (EPDM)/polyethylene (PE) two-layered polymer film. The effects of charge injection and trap related to nano-doping, local defects, and thermal aging on the surface potential decay (SPD) and space charge distribution in EPDM/PE were analyzed. The results show that the increase in the electron injection barrier slows surface charge dissipation and inhibits charge accumulation at the interface. An increase in the trapping coefficient leads to a higher surface potential in the stable state and a greater space charge density. During the early depolarization stage, the SPD rate is weakly dependent on the trap depth, with charge migration primarily governed by the external electric field. Full article

Converter stations are pivotal in high-voltage direct current (HVDC) systems, enabling power conversion between an alternating current (AC) and a direct current (DC) while ensuring efficient and stable energy transmission. Fault detection in converter stations is crucial for maintaining their reliability and operational safety. This paper focuses on image-based detection of five common faults: metal corrosion, discoloration of desiccant in breathers, insulator breakage, hanging foreign objects, and valve cooling water leakage. Despite advancements in deep learning, existing detection methods face two major challenges: limited model generalization due to diverse and complex backgrounds in converter station environments and sparse supervision signals caused by the high cost of collecting labeled images for certain faults. To overcome these issues, we propose InvMOE, a novel fault detection algorithm with two core components: (1) invariant representation learning, which captures task-relevant features and mitigates background noise interference, and (2) multi-task training using a mixture of experts (MOE) framework to adaptively optimize feature learning across tasks and address label sparsity. Experimental results on real-world datasets demonstrate that InvMOE achieves superior generalization performance and significantly improves detection accuracy for tasks with limited samples, such as valve cooling water leakage. This work provides a robust and scalable approach for enhancing fault detection in converter stations. Full article

When a line-commutated converter–high-voltage direct current (LCC-HVDC) transmission system with large-scale integration of renewable energy encounters HVDC-blocking events, the sending-end power system is prone to transient overvoltage (TOV) risks. Renewable energy units that are connected via power electronic devices are susceptible to large-scale cascading disconnections due to electrical endurance and insulation limitations when subjected to an excessively high TOV, which poses a serious threat to the safe and stable operation of the system. Therefore, the prediction of TOV at renewable energy stations (RES) under DC blocking (DCB) scenarios is crucial for developing strategies for the high-voltage ride-through of renewable energy sources and ensuring system stability. In this paper, an approximate analytical expression for the TOV at RES under DCB fault conditions is firstly derived, based on a simplified equivalent circuit of the sending-end system that includes multiple DC transmission lines and RES, which can take into consideration the multiple renewable station short-circuit ratio (MRSCR). Building on this, a knowledge-embedded enhanced deep neural network (KEDNN) approach is proposed for predicting the RES’s TOV for complex power systems. By incorporating theoretical calculation values of the TOV into the input features, the task of the deep neural network (DNN) shifts from mining relationships within large datasets to revealing the correlation patterns between theoretical calculations and real values, thereby improving the robustness of the prediction model in cases of insufficient training data and irrational feature construction. Finally, the proposed method is tested on a real-world regional power system in China, and the results validate the effectiveness of the proposed method. The approximate analytical expression for the TOV at RES and the KEDNN-based TOV prediction method proposed in this paper can provide valuable references for scholars and engineers working in the field of power system operation and control, particularly in the areas of overvoltage theoretical calculation and mitigation. Full article

Cross-linked polyethylene (XLPE) is applied in most advanced high-voltage direct-current (HVDC) power cable insulations, which are produced via dicumyl peroxide (DCP) technology. The electrical conductivity of insulation material can be increased by cross-linking byproducts from the DCP process. Hence, currently much attention is being paid to a new process to produce cross-linking byproduct-free XLPE. The cross-linking in situ between ethylene–glycidyl methacrylate copolymer and 1,5-disubtituted pentane via reactive compounding is a substitute for DCP. The reaction potential energy information of the eighteen reaction channels was obtained at the B3LYP/6-311+G(d,p) level. Results demonstrated that epoxy groups and 1,5-disubtituted reactive groups can react in situ to realize the XLPE-based network structure via covalent linking, and epoxy ring openings yielded ester. 1,5-disubtituted pentane played a cross-linker role. The reactivity of the carboxyl group was stronger than that of the sulfydryl or hydroxyl group. The reaction channel RTS1 was more kinetically favorable due to the lower reaction Gibbs energy barrier height of 1.95 eV. The cross-linking network construction of the new XLPE insulation without byproducts opens up the possibility of DCP substitution, which is beneficial to furthering the design of thermoplastic insulation materials for power cables in the future. Full article

This paper examines the modeling approaches used to analyze the electric field distribution in high-voltage direct-current gas-insulated systems (HVDC-GISs) used for the acceleration grid power supply (AGPS) of neutral beam injectors (NBIs). A key challenge in this context is the degradation of dielectric performance due to radiation-induced conductivity (RIC), a phenomenon specific to the harsh radioactive environments near fusion reactors. Traditional models for gas conductivity in HVDC-GISs often rely on constant or nonlinear conductivity formulations, which are based on experimental data but fail to capture the effects of external ionizing radiation that triggers RIC. To address this limitation, a more advanced approach, the drift–diffusion recombination (DDR) model, is used, as it more accurately represents gas ionization and the influence of radiation fields. However, this increased accuracy comes at the cost of higher computational complexity. This paper compares the different modeling strategies, discussing their strengths and weaknesses, with a focus on the capabilities in evaluating the charge accumulation and the RIC phenomenon. Full article

The use of multi-terminal high voltage direct current (HVDC) power transmission systems is being adopted in many new links between different generation and consumption areas due to their high efficiency. In these systems, cable energization must be performed at the rated voltage. Healthy energizations at the rated voltage result in large inrush currents, especially in long cables, primarily due to ground capacitance. State-of-the-art protection functions struggle to distinguish between transients caused by switching and those associated with ground faults, leading to potential unwanted tripping of the protection systems. To prevent this, tripping is usually blocked during the energization transient, which delays fault detection and clearing. This paper presents a novel method for prompt discrimination between healthy and faulty energizations. The proposed method outperforms conventional protection functions as this discrimination allows for earlier and more reliable tripping, thus avoiding extensive damage to the cable and the converter due to trip blocking. The method is based on the transient analysis of the current in the cable shields, therefore, another technical advantage is that high voltage-insulated measuring devices are not required. Two distinct tripping criteria are proposed: one attending to the change in current polarity, and the other to the change in current derivative sign. Extensive computer simulations and laboratory tests confirmed the correct operation in both cases. Full article

Polypropylene (PP) is regarded as a recyclable material for high-voltage direct current (HVDC) cable insulation due to its high melting point and electrical resistivity. This work focuses on the effect of the β-nucleating agent content on the electrical tree growth characteristics in isotactic PP (iPP) insulation. The results demonstrate that adding β-nucleating agents promotes the growth of β-crystals while limiting the α-crystal content. The crystallinity improves with the reduction in the average size of spherulites due to the addition of a β-nucleating agent with 0.1 wt% content. Electrical tree experiments show that the electrical tree growth rate declines as the nucleating agent content rises from 0 to 0.1 wt%. Meanwhile, the expansion coefficient increases with higher nucleating agent content. Continuous increases in the nucleate agent content result in the upward growth rate of electrical trees. When the nucleating agent content is below 0.1 wt%, the α–β-crystal interface introduced by the agent suppresses carrier migration and limits impact ionization, leading to the slower growth rate of the electrical tree. Further addition of the nucleate agent induces a β–β-crystal interface with weak coupling in carriers. It is concluded that β-nucleating agent-modified PP with 0.1 wt% content has potential application in HVDC cable insulation. Full article

The insulation of high-voltage direct-current (HVDC) cables experiences a short period of voltage polarity reversal when the power flow is adjusted, leading to sever field distortion in this situation. Consequently, improving the insulation performance of the composite insulation structure in these cables has become an urgent challenge. In this paper, SiC-SR (silicone rubber) and TiO₂-SR nanocomposites were chosen for fabricating HVDC cable accessories. These nanocomposites were prepared using the solution blending method, and an electro-acoustic pulse (PEA) space charge test platform was established to explore the electron transfer mechanism. The space charge characteristics and field strength distribution of a double-layer dielectric composed of cross-linked polyethylene (XLPE) and nano-composite SR at different concentrations were studied during voltage polarity reversal. Additionally, a self-built breakdown platform for flake samples was established to explore the effect of the nanoparticle doping concentration on the breakdown field strength of double-layer composite media under polarity reversal. Therefore, a correlation was established between the micro electron transfer process and the macro electrical properties of polymers (XLPE/SR). The results show that optimal concentrations of nano-SiC and TiO₂ particles introduce deep traps in the SR matrix, significantly inhibiting charge accumulation and electric field distortion at the interface, thereby effectively improving the dielectric strength of the double-layer polymers (XLPE/SR). Full article

Crosslinked polyethylene (XLPE) is an important polyethylene modification material which is widely used in high-voltage direct current (HVDC) transmission systems. Low-density polyethylene (LDPE) was used as a matrix to improve the thermal and electrical properties of XLPE composites through the synergistic effect of a crosslinking agent and nanopore structure molecular sieve, TS-1. It was found that the electrical and thermal properties of the matrices were different due to the crosslinking degree and crosslinking efficiency, and the introduction of TS-1 enhanced the dielectric constants of the two matrices to 2.53 and 2.54, and the direct current (DC) resistivities were increased to 3 × 10¹² and 4 × 10¹² Ω·m, with the enhancement of the thermal conductivity at different temperatures. As the applied voltage increases, the DC breakdown field strength is enhanced from 318 to 363 kV/mm and 330 to 356 kV/mm. The unique nanopore structure of TS-1 itself can inhibit the injection and accumulation in the internal space of crosslinked polyethylene composites, and the pore size effect of the filler can limit the development of electron impact ionization, inhibit the electron avalanche breakdown, and improve the strength of the external applied electric field (breakdown field) that TS-1/XLPE nanocomposites can withstand. This provides a new method for the preparation of nanocomposite insulating dielectric materials for HVDC transmission systems with better performance. Full article

Mass-impregnated (MI) cables have been used for many years as cables in high-voltage direct current (HVDC) systems. In line commutated converter (LCC) HVDC systems, polarity reversal for power flow control can induce significant electrical stress on MI cables. Furthermore, the mass oil and kraft paper comprising the impregnated insulation have significantly different coefficients of thermal expansion. Load fluctuations in the cable lead to expansion and contraction of the mass, creating pressure within the insulation and causing redistribution of the impregnant. During this process, shrinkage cavities can form within the butt gaps. Since the dielectric strength of the cavities is lower than that of the surrounding impregnation, cavitation phenomena in impregnated paper insulation are considered a factor in degrading insulation performance. Consequently, this study analyzes the electrical conductivity of thermally aged materials and investigates the transient electric field characteristics within the cable. Additionally, it closely analyzes the formation and dissolution of cavities in MI cables during polarity reversal based on a numerical model of pressure behavior in porous media. The conductivity of the impregnated paper indicates that it has excellent resistance to thermal degradation. Simulation results for various load conditions highlight that the interval of load-off time and the magnitude of internal pressure significantly influence the cavitation phenomenon. Lastly, the study proposes stable system operation methods to prevent cavitation in MI cables. Full article

Charging potential appears when a conductor insulated to the ground is exposed to an electrostatic field. A modified measurement method based on a non-contact electrometer is presented in this article. This system is appropriate for measuring the charging potential of a conductor near high-voltage direct-current (HVDC) overhead lines. Compared with the contact measurement method, the modified method is hardly affected by the internal resistance of the electrometer, which helps ensure measurement accuracy in the electrostatic field. In contrast with the traditional non-contact electrometer, the electric field generated by HVDC lines and the space charges around the electrometer probe are shielded using a grounding cage. The effectiveness of the modified measurement method was verified via experiments. The impacts of the structure and position of the measurement system on the measured charging potential are discussed. Full article

To enhance the direct current (DC) dielectric properties of cross-linked polyethylene (XLPE) for high-voltage (HV) cable insulation, the polyethylene molecular chain is modified by grafting bismaleimide ethane (BMIE), which creates carrier deep traps within the polymer material. Compared to the traditional modified molecule maleic anhydride (MAH), BMIE has a significantly higher boiling point than the production temperature of XLPE. Additionally, it does not release bubbles during the production process and, thus, preserves the dielectric properties. It was proved by infrared spectroscopy and a gel content test that BMIE was successfully grafted onto the polyethylene molecular chain and had no effect on the crosslinking degree of the polymer while reducing the amount of crosslinker, thereby reducing the influence of the by-products of the decomposition of dicumene peroxide (DCP) on the electrical resistance of polymers. The analysis of DC breakdown field strength, current density, and space charge distribution at various temperatures demonstrates that grafting BMIE can greatly enhance the dielectric properties of insulation. Polar groups in the BMIE molecule create deep trap energy levels in XLPE-g-BMIE, and these trap energy levels contribute to the formation of a charged layer near the electrode, which is shielded by Coulomb potential. As a result, the charge injection barrier increases. Additionally, the presence of these polar groups reduces the mobility of charge carriers through trap-carrier scattering, effectively suppressing the accumulation of space charge within the material. First-principle calculations also confirm that bound states can be introduced as carrier traps by grafting BMIE onto polyethylene molecules. The agreement between experimental results and simulation calculations indicates that grafting BMIE to enhance the dielectric properties of polyethylene is a new and feasible research direction in the exploitation of materials for HVDC cables. Full article

Large and remote offshore wind farms (OWFs) usually use voltage source converter (VSC) systems to transmit electrical power to the main network. Submarine high-voltage direct current (HVDC) cables are commonly used as transmission links. As they are liable to insulation breakdown, fault location in the HVDC cables is a major issue in these systems. Exact fault location can significantly reduce the high cost of submarine HVDC cable repair in multi-terminal networks. In this paper, a novel method is presented to find the exact location of the DC faults. The fault location is calculated using extraction of new features from voltage signals of cables’ sheaths and a trained artificial neural network (ANN). The results obtained from a simulation of a three-terminal HVDC system in power systems computer-aided design (PSCAD) environment show that the maximum percentage error of the proposed method is less than 1%. Full article
