Search Results (49)

Search Parameters:
Keywords = helium-ion microscopy

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
19 pages, 13821 KiB
Article
Structure and Electrocatalytic Properties of Sulfur-Containing Multi-Walled Carbon Nanotubes on a Titanium Substrate Modified by a Helium Ion Beam
by Petr M. Korusenko, Egor V. Knyazev, Alexander S. Vinogradov, Ksenia A. Kharisova, Sofya S. Filippova, Ulyana M. Rodionova, Oleg V. Levin and Elena V. Alekseeva
Nanomaterials 2024, 14(23), 1948; https://doi.org/10.3390/nano14231948 - 4 Dec 2024
Cited by 1 | Viewed by 1238
Abstract
In this work, a set of analytical techniques, including scanning electron microscopy (SEM), Raman scattering spectroscopy, X-ray photoelectron spectroscopy (XPS), energy-dispersive X-ray microanalysis (EDX) and cyclic voltammetry (CV), were used to study the impact of high-energy He+ ion irradiation on the structural [...] Read more.
In this work, a set of analytical techniques, including scanning electron microscopy (SEM), Raman scattering spectroscopy, X-ray photoelectron spectroscopy (XPS), energy-dispersive X-ray microanalysis (EDX) and cyclic voltammetry (CV), were used to study the impact of high-energy He+ ion irradiation on the structural and electrochemical characteristics of sulfur-containing multi-walled carbon nanotubes (S-MWCNTs) placed on a titanium substrate. The results indicate that the ion beam treatment of the S-MWCNT system led to an increase in the level of imperfections on the surface structures of the nanotubes due to the formation of point defects on their outer walls and the appearance of oxygen-containing functional groups, including SOx groups, near these defects. At the same time, a significant increase in the sulfur concentration (by 6.4 times) was observed on the surface of the S-MWCNTs compared to the surface of unirradiated nanotubes. This was due to the redeposition of sulfur atoms near the point defects under the action of the ion beam, followed by the subsequent formation of direct S–C chemical bonds. Electrochemical studies demonstrated that the irradiated S-MWCNTs/Ti system exhibit enhanced catalytic activity, with improved oxygen reduction reaction (ORR) performance and a substantial increase in anodic current during the oxidation reaction of hydrogen peroxide under alkaline conditions, highlighting their potential for advanced electrocatalytic applications. Full article
Show Figures

Graphical abstract

13 pages, 2526 KiB
Article
A Novel Nano-Spherical Tip for Improving Precision in Elastic Modulus Measurements of Polymer Materials via Atomic Force Microscopy
by Tianyu Fu, Paul C. Uzoma, Xiaolei Ding, Pengyuan Wu, Oleksiy Penkov and Huan Hu
Micromachines 2024, 15(9), 1175; https://doi.org/10.3390/mi15091175 - 22 Sep 2024
Cited by 1 | Viewed by 2297
Abstract
Micro-nano-scale mechanical properties are vital for engineering and biological materials. The elastic modulus is generally measured by processing the force–indentation curves obtained by atomic force microscopy (AFM). However, the measurement precision is largely affected by tip shape, tip wear, sample morphology, and the [...] Read more.
Micro-nano-scale mechanical properties are vital for engineering and biological materials. The elastic modulus is generally measured by processing the force–indentation curves obtained by atomic force microscopy (AFM). However, the measurement precision is largely affected by tip shape, tip wear, sample morphology, and the contact model. In such research, it has been found that the radius of the sharp tip increases due to wear during contact scanning, affecting elastic modulus calculations. For flat-ended tips, it is difficult to identify the contact condition, leading to inaccurate results. Our research team has invented a nano-spherical tip, obtained by implanting focused helium ions into a silicon microcantilever, causing it to expand into a silicon nanosphere. This nano-spherical tip has the advantages of sub-micro size and a smooth spherical surface. Comparative tests of the elastic modulus measurement were conducted on polytetrafluoroethylene (PTFE) and polypropylene (PP) using these three tips. Overall, the experimental results show that our nano-spherical tip with a consistent tip radius, symmetrical geometric shape, and resistance to wear and contamination can improve precision in elastic modulus measurements of polymer materials. Full article
(This article belongs to the Special Issue Micro/Nanostructures in Sensors and Actuators, 2nd Edition)
Show Figures

Figure 1

12 pages, 5748 KiB
Article
Radiation Effects in Tungsten and Tungsten-Copper Alloys Treated with Compression Plasma Flows and Irradiated with He Ions
by Azamat Ryskulov, Vitaliy Shymanski, Igor Ivanov, Bauyrzhan Amanzhulov, Anastasia Dauhaliuk, Vladimir Uglov, Adilet Temir, Valiantsin Astashynski, Asset Sapar, Anton Kuzmitski and Yerulan Ungarbayev
Materials 2024, 17(18), 4442; https://doi.org/10.3390/ma17184442 - 10 Sep 2024
Cited by 1 | Viewed by 1152
Abstract
The paper presents the results of studying the structure and phase state of tungsten and tungsten-copper alloy after pulsed action of compression plasma flows and irradiation with helium ions. The compression plasma flows were used to modify the surface layer of tungsten, as [...] Read more.
The paper presents the results of studying the structure and phase state of tungsten and tungsten-copper alloy after pulsed action of compression plasma flows and irradiation with helium ions. The compression plasma flows were used to modify the surface layer of tungsten, as well as to create an alloy based on tungsten and copper. Using scanning electron microscopy and X-ray structural analysis, the formation of radiation defects on the tungsten surface was detected in the form of local areas of exfoliation and destruction, which begin to form at helium ion irradiation doses of 2 × 1017 cm−2. It is shown that preliminary plasma treatment of the surface in the melting mode leads to the complete disappearance of surface radiation defects up to a dose of 2 × 1017 cm−2, which may be associated with the formation of a fine-crystalline grain structure, the intergranular boundaries of which serve as effective sinks for primary radiation defects. Full article
(This article belongs to the Special Issue Mechanical Behavior and Radiation Response of Materials)
Show Figures

Figure 1

16 pages, 9074 KiB
Article
Studies of the Morphology of Hematite Synthesized from Waste Iron Sulfate
by Kamila Splinter, Robert Möckel, Gregor Hlawacek and Zofia Lendzion-Bieluń
Molecules 2024, 29(15), 3527; https://doi.org/10.3390/molecules29153527 - 26 Jul 2024
Viewed by 1274
Abstract
Microwave-based reactions have gained traction in recent years due to their ability to enhance reaction rates and yield while reducing energy consumption. Also, according to the conception of ‘waste to materials’, various waste feeds are intensively sought to be tested. The experimental setup [...] Read more.
Microwave-based reactions have gained traction in recent years due to their ability to enhance reaction rates and yield while reducing energy consumption. Also, according to the conception of ‘waste to materials’, various waste feeds are intensively sought to be tested. The experimental setup of this study involved varying pH levels, oxidation agents, and precipitation agents to optimize the synthesis process of iron red based on waste iron sulfate. The selection of oxidation and precipitation agents was found to significantly influence the pigment synthesis process. Various oxidizing agents, including hydrogen peroxide and atmospheric air, were evaluated for their effectiveness in promoting the oxidation of ferrous ions to ferric ions, essential for pigment formation. Additionally, different precipitation agents such as sodium hydroxide and ammonia solution were assessed for their ability to precipitate iron hydroxides and facilitate pigment particle formation. The characterization of synthesized pigments revealed promising results in terms of quality and color properties. Helium Ion Microscopy (HIM) analysis confirmed the formation of well-defined pigment particles with controlled morphology. X-ray diffraction (XRD) studies provided insights into the crystalline structure of the pigments, indicating the presence of characteristic iron oxide phases. By improving this technology, waste iron sulfate can be efficiently transformed into valuable iron pigments, offering a sustainable solution for waste management while meeting the growing demand for high-quality pigments. Full article
Show Figures

Figure 1

10 pages, 1996 KiB
Article
The Influence of the Structural Parameters of Nanoporous Alumina Matrices on Optical Properties
by Ekaterina N. Muratova, Alina A. Ponomareva, Andrey A. Shemukhin, Yuriy V. Balakshin, Aleksandr P. Evseev, Vyacheslav A. Moshnikov, Anton A. Zhilenkov and Olga Yu. Kichigina
Metals 2024, 14(6), 651; https://doi.org/10.3390/met14060651 - 30 May 2024
Viewed by 1087
Abstract
In this work, two types of nanoporous alumina membranes were prepared and tested. Structural features of the samples obtained by using different acids were investigated by scanning electron microscopy (SEM). And further SEM-images were analyzed by different types of fractal dimension estimation methods. [...] Read more.
In this work, two types of nanoporous alumina membranes were prepared and tested. Structural features of the samples obtained by using different acids were investigated by scanning electron microscopy (SEM). And further SEM-images were analyzed by different types of fractal dimension estimation methods. The transmission and scattering of accelerated He+ ions were studied in experiments on the ion irradiation of dielectric channels based on porous alumina. An ion accelerator was used as a source of the He+ beam with an energy of 1.7 MeV. Ion scattering was studied by Rutherford backscattering spectrometry. Helium transition through nanoporous alumina at various angles between the normal to the sample and the beam direction were observed. It is shown that the porous structure of anodic aluminum oxide is excellent as a dielectric matrix of nanocapillaries. Owing to the small angle scattering, it allows for the transportation of the accelerated charged particles through the dielectric capillaries, and, as a result, the localization of high energy ion irradiation effects. Additionally, according to the transmission of UV–V is spectra, the energy gaps of samples obtained were calculated. Full article
Show Figures

Figure 1

12 pages, 5507 KiB
Article
Magnetic Hardening of Heavily Helium-Ion-Irradiated Iron–Chromium Alloys
by Yasuhiro Kamada, Daiki Umeyama, Takeshi Murakami, Kazuyuki Shimizu and Hideo Watanabe
Metals 2024, 14(5), 568; https://doi.org/10.3390/met14050568 - 12 May 2024
Viewed by 1932
Abstract
This study reports on the magnetic hardening phenomenon of heavily helium ion-irradiated iron–chromium alloys. The alloys are important structural materials in next-generation nuclear reactors. In some cases, problems may arise when the magnetic properties of the materials change due to neutron irradiation. Therefore, [...] Read more.
This study reports on the magnetic hardening phenomenon of heavily helium ion-irradiated iron–chromium alloys. The alloys are important structural materials in next-generation nuclear reactors. In some cases, problems may arise when the magnetic properties of the materials change due to neutron irradiation. Therefore, it is necessary to understand the effects of irradiation on magnetism. Helium irradiation was conducted as a simulated irradiation, and the effect of cavity formation on magnetic properties was thoroughly investigated. High-quality single-crystal Fe-x%Cr (x = 0, 10, 20) films, with a thickness of 180–200 nm, were fabricated through ultra-high vacuum evaporation. Subsequently, irradiation of 19 dpa with 30 keV He+ ions was conducted at room temperature. X-ray diffraction measurements and electron microscopy observations confirmed significant lattice expansion and the formation of high-density cavities after irradiation. The magnetization curve of pure iron remained unchanged, while magnetic hardening was noticed in iron–chromium alloys. This phenomenon is believed to be due to the combined effect of cavity formation and changes in the atomic arrangement of chromium. Full article
Show Figures

Graphical abstract

12 pages, 6429 KiB
Article
Improving the Adhesion of Multi-Walled Carbon Nanotubes to Titanium by Irradiating the Interface with He+ Ions: Atomic Force Microscopy and X-ray Photoelectron Spectroscopy Study
by Petr M. Korusenko, Egor V. Knyazev, Olga V. Petrova, Denis V. Sokolov, Sergey N. Povoroznyuk, Konstantin E. Ivlev, Ksenia A. Bakina, Vyacheslav A. Gaas and Alexander S. Vinogradov
Nanomaterials 2024, 14(8), 699; https://doi.org/10.3390/nano14080699 - 17 Apr 2024
Cited by 4 | Viewed by 1826
Abstract
A complex study of the adhesion of multi-walled carbon nanotubes to a titanium surface, depending on the modes of irradiation with He+ ions of the “MWCNT/Ti” system, was conducted using atomic force microscopy and X-ray photoelectron spectroscopy. A quantitative assessment of the [...] Read more.
A complex study of the adhesion of multi-walled carbon nanotubes to a titanium surface, depending on the modes of irradiation with He+ ions of the “MWCNT/Ti” system, was conducted using atomic force microscopy and X-ray photoelectron spectroscopy. A quantitative assessment of the adhesion force at the interface, performed using atomic force microscopy, demonstrated its significant increase as a result of treatment of the “MWCNT/Ti” system with a beam of helium ions. The nature of the chemical bonding between multi-walled carbon nanotubes and the surface of the titanium substrate, which causes this increase in the adhesion of nanotubes to titanium as a result of ion irradiation, was investigated by X-ray photoelectron spectroscopy. It was established that this bonding is the result of the formation of chemical C–O–Ti bonds between titanium and carbon atoms with the participation of oxygen atoms of oxygen-containing functional groups, which are localized on defects in the nanotube walls formed during ion irradiation. It is significant that there are no signs of direct bonding between titanium and carbon atoms. Full article
Show Figures

Figure 1

14 pages, 9835 KiB
Article
Controllable Fabrication of Sub-10 nm Graphene Nanopores via Helium Ion Microscopy and DNA Detection
by Zhishan Yuan, Yanbang Lin, Jieming Hu and Chengyong Wang
Biosensors 2024, 14(4), 158; https://doi.org/10.3390/bios14040158 - 27 Mar 2024
Cited by 3 | Viewed by 3935
Abstract
Solid-state nanopores have become a prominent tool in the field of single-molecule detection. Conventional solid-state nanopores are thick, which affects the spatial resolution of the detection results. Graphene is the thinnest 2D material and has the highest spatial detection resolution. In this study, [...] Read more.
Solid-state nanopores have become a prominent tool in the field of single-molecule detection. Conventional solid-state nanopores are thick, which affects the spatial resolution of the detection results. Graphene is the thinnest 2D material and has the highest spatial detection resolution. In this study, a graphene membrane chip was fabricated by combining a MEMS process with a 2D material wet transfer process. Raman spectroscopy was used to assess the quality of graphene after the transfer. The mechanism behind the influence of the processing dose and residence time of the helium ion beam on the processed pore size was investigated. Subsequently, graphene nanopores with diameters less than 10 nm were fabricated via helium ion microscopy. DNA was detected using a 5.8 nm graphene nanopore chip, and the appearance of double-peak signals on the surface of 20 mer DNA was successfully detected. These results serve as a valuable reference for nanopore fabrication using 2D material for DNA analysis. Full article
Show Figures

Figure 1

11 pages, 8711 KiB
Article
Spectromicroscopy Study of Induced Defects in Ion-Bombarded Highly Aligned Carbon Nanotubes
by Sammar Tayyab, Alice Apponi, Maria Grazia Betti, Elena Blundo, Gianluca Cavoto, Riccardo Frisenda, Nuria Jiménez-Arévalo, Carlo Mariani, Francesco Pandolfi, Antonio Polimeni, Ilaria Rago, Alessandro Ruocco, Marco Sbroscia and Ravi Prakash Yadav
Nanomaterials 2024, 14(1), 77; https://doi.org/10.3390/nano14010077 - 27 Dec 2023
Cited by 3 | Viewed by 1550
Abstract
Highly aligned multi-wall carbon nanotubes were investigated with scanning electron microscopy (SEM), Raman spectroscopy and X-ray photoelectron spectroscopy (XPS) before and after bombardment performed using noble gas ions of different masses (argon, neon and helium), in an ultra-high-vacuum (UHV) environment. Ion irradiation leads [...] Read more.
Highly aligned multi-wall carbon nanotubes were investigated with scanning electron microscopy (SEM), Raman spectroscopy and X-ray photoelectron spectroscopy (XPS) before and after bombardment performed using noble gas ions of different masses (argon, neon and helium), in an ultra-high-vacuum (UHV) environment. Ion irradiation leads to change in morphology, deformation of the carbon (C) honeycomb lattice and different structural defects in multi-wall carbon nanotubes. One of the major effects is the production of bond distortions, as determined by micro-Raman and micro-X-ray photoelectron spectroscopy. We observe an increase in sp3 distorted bonds at higher binding energy with respect to the expected sp2 associated signal of the carbon 1s core level, and increase in dangling bonds. Furthermore, the surface damage as determined by the X-ray photoelectron spectroscopy carbon 1s core level is equivalent upon bombarding with ions of different masses, while the impact and density of defects in the lattice of the MWCNTs as determined by micro-Raman are dependent on the bombarding ion mass; heavier for helium ions, lighter for argon ions. These results on the controlled increase in sp3 distorted bonds, as created on the multi-wall carbon nanotubes, open new functionalization prospects to improve and increase atomic hydrogen uptake on ion-bombarded multi-wall carbon nanotubes. Full article
(This article belongs to the Special Issue Carbon Nanotubes and Nanosheets for Sustainable Solutions)
Show Figures

Figure 1

27 pages, 21549 KiB
Perspective
Dual Nucleosomal Double-Strand Breaks Are the Key Effectors of Curative Radiation Therapy
by Anders Brahme and Yvonne Lorat
Biophysica 2023, 3(4), 668-694; https://doi.org/10.3390/biophysica3040045 - 14 Dec 2023
Cited by 2 | Viewed by 1836
Abstract
Most ionizing radiation produces δ-rays of ≈1 keV that can impart MGy doses to 100 nm3 volumes of DNA. These events can produce severe dual double-strand breaks (DDSBs) on nucleosomes, particularly in dense heterochromatic DNA. This is the most common multiply [...] Read more.
Most ionizing radiation produces δ-rays of ≈1 keV that can impart MGy doses to 100 nm3 volumes of DNA. These events can produce severe dual double-strand breaks (DDSBs) on nucleosomes, particularly in dense heterochromatic DNA. This is the most common multiply damaged site, and their probabilities determine the biological effectiveness of different types of radiation. We discuss their frequency, effect on cell survival, DNA repair, and imaging by gold nanoparticle tracers and electron microscopy. This new and valuable nanometer resolution information can be used for determining the optimal tumor cure by maximizing therapeutic effects on tumors and minimizing therapeutic effects on normal tissues. The production of DDSBs makes it important to deliver a rather high dose and LET to the tumor (>2.5 Gy/Fr) and at the same time reach approximately 1.8–2.3 Gy of the lowest possible LET per fraction in TP53 intact normal tissues at risk. Therefore, their intrinsic low-dose hyper-sensitivity (LDHS)-related optimal daily fractionation window is utilized. Before full p53 activation of NHEJ and HR repair at ≈½ Gy, the low-dose apoptosis (LDA) and LDHS minimize normal tissue mutation probabilities. Ion therapy should thus ideally produce the lowest possible LET in normal tissues to avoid elevated DDSBs. Helium to boron ions can achieve this with higher-LET Bragg peaks, producing increased tumor DDSB densities. Interestingly, the highest probability of complication-free cure with boron or heavier ions requires a low LET round-up for the last 10–15 GyE, thereby steepening the dose response and further minimizing normal tissue damage. In conclusion, the new high-resolution DSB and DDSB diagnostic methods, and the new more accurate DNA-repair-based radiation biology, have been combined to increase our understanding of what is clinically important in curative radiation therapy. In fact, we must understand that we already passed the region of optimal LET and need to go back one step rather than forward, with oxygen being contemplated. As seen by the high overkill and severely high LET in the distal tumor and the increased LET to normal tissues (reminding of neutrons or neon ions), it is therefore preferable to use lithium–boron ions or combine carbon with an optimal 10–15 GyE photon, electron, or perhaps even a proton round-up, thus allowing optimized, fractionated, curative, almost complication-free treatments with photons, electrons, and light ions, introducing a real paradigm shift in curative radiation therapy with a potential 5 GyE tumor boost, 25% increase in complication-free cure and apoptotic–senescent Bragg Peak molecular light ion radiation therapy. Full article
(This article belongs to the Special Issue Biological Effects of Ionizing Radiation)
Show Figures

Graphical abstract

11 pages, 11824 KiB
Article
A Comparative Study of Gallium-, Xenon-, and Helium-Focused Ion Beams for the Milling of GaN
by Shuai Jiang and Volkan Ortalan
Nanomaterials 2023, 13(21), 2898; https://doi.org/10.3390/nano13212898 - 3 Nov 2023
Cited by 8 | Viewed by 2497
Abstract
The milling profiles of single-crystal gallium nitride (GaN) when subjected to focused ion beams (FIBs) using gallium (Ga), xenon (Xe), and helium (He) ion sources were investigated. An experimental analysis via annular dark-field scanning transmission electron microscopy (ADF-STEM) and high-resolution transmission electron microscopy [...] Read more.
The milling profiles of single-crystal gallium nitride (GaN) when subjected to focused ion beams (FIBs) using gallium (Ga), xenon (Xe), and helium (He) ion sources were investigated. An experimental analysis via annular dark-field scanning transmission electron microscopy (ADF-STEM) and high-resolution transmission electron microscopy (HRTEM) revealed that Ga-FIB milling yields trenches with higher aspect ratios compared to Xe-FIB milling for the selected ion beam parameters (30 kV, 42 pA), while He-FIB induces local lattice disorder. Molecular dynamics (MD) simulations were employed to investigate the milling process, confirming that probe size critically influences trench aspect ratios. Interestingly, the MD simulations also showed that Xe-FIB generates higher aspect ratios than Ga-FIB with the same probe size, indicating that Xe-FIB could also be an effective option for nanoscale patterning. Atomic defects such as vacancies and interstitials in GaN from He-FIB milling were suggested by the MD simulations, supporting the lattice disorder observed via HRTEM. This combined experimental and simulation approach has enhanced our understanding of FIB milling dynamics and will benefit the fabrication of nanostructures via the FIB technique. Full article
Show Figures

Figure 1

20 pages, 7513 KiB
Article
Enhanced Release of Calcium Ions from Hydroxyapatite Nanoparticles with an Increase in Their Specific Surface Area
by Urszula Szałaj, Agnieszka Chodara, Stanisław Gierlotka, Jacek Wojnarowicz and Witold Łojkowski
Materials 2023, 16(19), 6397; https://doi.org/10.3390/ma16196397 - 25 Sep 2023
Cited by 14 | Viewed by 3416
Abstract
Synthetic calcium phosphates, e.g., hydroxyapatite (HAP) and tricalcium phosphate (TCP), are the most commonly used bone-graft materials due to their high chemical similarity to the natural hydroxyapatite—the inorganic component of bones. Calcium in the form of a free ion or bound complexes plays [...] Read more.
Synthetic calcium phosphates, e.g., hydroxyapatite (HAP) and tricalcium phosphate (TCP), are the most commonly used bone-graft materials due to their high chemical similarity to the natural hydroxyapatite—the inorganic component of bones. Calcium in the form of a free ion or bound complexes plays a key role in many biological functions, including bone regeneration. This paper explores the possibility of increasing the Ca2+-ion release from HAP nanoparticles (NPs) by reducing their size. Hydroxyapatite nanoparticles were obtained through microwave hydrothermal synthesis. Particles with a specific surface area ranging from 51 m2/g to 240 m2/g and with sizes of 39, 29, 19, 11, 10, and 9 nm were used in the experiment. The structure of the nanomaterial was also studied by means of helium pycnometry, X-ray diffraction (XRD), and transmission-electron microscopy (TEM). The calcium-ion release into phosphate-buffered saline (PBS) was studied. The highest release of Ca2+ ions, i.e., 18 mg/L, was observed in HAP with a specific surface area 240 m2/g and an average nanoparticle size of 9 nm. A significant increase in Ca2+-ion release was also observed with specific surface areas of 183 m2/g and above, and with nanoparticle sizes of 11 nm and below. No substantial size dependence was observed for the larger particle sizes. Full article
(This article belongs to the Topic Advances in Biomaterials)
Show Figures

Figure 1

14 pages, 10031 KiB
Article
TiN-NbN-TiN and Permalloy Nanostructures for Applications in Transmission Electron Microscopy
by Michael I. Faley, Joshua Williams, Penghan Lu and Rafal E. Dunin-Borkowski
Electronics 2023, 12(9), 2144; https://doi.org/10.3390/electronics12092144 - 8 May 2023
Cited by 2 | Viewed by 2831
Abstract
We fabricated superconducting and ferromagnetic nanostructures, which are intended for applications in transmission electron microscopy (TEM), in a commercial sample holder that can be cooled using liquid helium. Nanoscale superconducting quantum-interference devices (nanoSQUIDs) with sub-100 nm nanobridge Josephson junctions (nJJs) were prepared at [...] Read more.
We fabricated superconducting and ferromagnetic nanostructures, which are intended for applications in transmission electron microscopy (TEM), in a commercial sample holder that can be cooled using liquid helium. Nanoscale superconducting quantum-interference devices (nanoSQUIDs) with sub-100 nm nanobridge Josephson junctions (nJJs) were prepared at a distance of ~300 nm from the edges of a 2 mm × 2 mm × 0.05 mm substrate. Thin-film TiN-NbN-TiN heterostructures were used to optimize the superconducting parameters and enhance the oxidation and corrosion resistance of nJJs and nanoSQUIDs. Non-hysteretic I(V) characteristics of nJJs, as well as peak-to-peak quantum oscillations in the V(B) characteristics of the nanoSQUIDs with an amplitude of up to ~20 µV, were obtained at a temperature ~5 K, which is suitable for operation in TEM. Electron-beam lithography, high-selectivity reactive ion etching with pure SF6 gas, and a naturally created undercut in the Si substrate were used to prepare nanoSQUIDs on a SiN membrane within ~500 nm from the edge of the substrate. Permalloy nanodots with diameters down to ~100 nm were prepared on SiN membranes using three nanofabrication methods. High-resolution TEM revealed that permalloy films on a SiN buffer have a polycrystalline structure with an average grain dimension of approximately 5 nm and a lattice constant of ~0.36 nm. The M(H) dependences of the permalloy films were measured and revealed coercive fields of 2 and 10 G at 300 and 5 K, respectively. These technologies are promising for the fabrication of superconducting electronics based on nJJs and ferromagnetic nanostructures for operation in TEM. Full article
(This article belongs to the Special Issue Nanofabrication of Superconducting Circuits)
Show Figures

Figure 1

11 pages, 4279 KiB
Article
Microstructure Evolution and Effect on Deuterium Retention in TiC- and ZrC-Doped Tungsten under He+ Ion Irradiation
by Xiaoyu Ding, Jiahui Fang, Qiu Xu, Panpan Zhang, Haojie Zhang, Laima Luo, Yucheng Wu and Jianhua Yao
Metals 2023, 13(4), 783; https://doi.org/10.3390/met13040783 - 17 Apr 2023
Cited by 6 | Viewed by 2198
Abstract
Combining the advantages of a wet chemical method and spark plasma sintering, carbide-doped materials W-1wt%TiC and W-1wt%ZrC were prepared. Microstructural evolution in W-1wt%TiC and W-1wt%ZrC under irradiation of 5 keV He+ at 600 °C to fluences up to 5.0 × 1021 [...] Read more.
Combining the advantages of a wet chemical method and spark plasma sintering, carbide-doped materials W-1wt%TiC and W-1wt%ZrC were prepared. Microstructural evolution in W-1wt%TiC and W-1wt%ZrC under irradiation of 5 keV He+ at 600 °C to fluences up to 5.0 × 1021 ions/m2 with ion flux of about 8.8 × 1017 ions/m2s was investigated by transmission electron microscopy (TEM). The dislocation loop number density of W-1wt%TiC was higher than that of W-1wt%ZrC, but the average loop size of the W-1wt%TiC was in average smaller. There were no observable helium bubbles in W-1wt%TiC and W-1wt%ZrC, exhibiting higher radiation resistance to He+ compared to pure W. He+ pre-damaged and undamaged W-1wt%TiC and W-1wt%ZrC samples were irradiated by 5 keV D2+ to estimate the D retention in doped W materials. The irradiation damage impact of He+ on deuterium retention was examined by a method of thermal desorption spectroscopy (TDS). Compared with the undamaged samples, it was illustrated that D2 retention of W-1wt%TiC and W-1wt%ZrC increased after He+ pre-irradiation. Full article
Show Figures

Figure 1

10 pages, 387 KiB
Article
Lateral Controlled Doping and Defect Engineering of Graphene by Ultra-Low-Energy Ion Implantation
by Felix Junge, Manuel Auge, Zviadi Zarkua and Hans Hofsäss
Nanomaterials 2023, 13(4), 658; https://doi.org/10.3390/nano13040658 - 8 Feb 2023
Cited by 6 | Viewed by 2752
Abstract
In this paper, the effectiveness of ultra-low-energy ion implantation as a means of defect engineering in graphene was explored through the measurement of Scanning Kelvin Probe Microscopy (SKPM) and Raman spectroscopy, with boron (B) and helium (He) ions being implanted into monolayer graphene [...] Read more.
In this paper, the effectiveness of ultra-low-energy ion implantation as a means of defect engineering in graphene was explored through the measurement of Scanning Kelvin Probe Microscopy (SKPM) and Raman spectroscopy, with boron (B) and helium (He) ions being implanted into monolayer graphene samples. We used electrostatic masks to create a doped and non-doped region in one single implantation step. For verification we measured the surface potential profile along the sample and proved the feasibility of lateral controllable doping. In another experiment, a voltage gradient was applied across the graphene layer in order to implant helium at different energies and thus perform an ion-energy-dependent investigation of the implantation damage of the graphene. For this purpose Raman measurements were performed, which show the different damage due to the various ion energies. Finally, ion implantation simulations were conducted to evaluate damage formation. Full article
(This article belongs to the Special Issue Carbon Nanotubes and Nanosheets for Sustainable Solutions)
Show Figures

Figure 1
