Search Results (29)

This study presents the results of axial tension (uplift) and compression tests evaluating the capacity of helical piles installed in Shahriyar dense sand using the UTM apparatus. Thirteen pile load experiments involving single-, double-, or triple-helix piles with shaft diameters of 13 mm were performed, including six compression tests and seven tension tests with different pitches (D_h =13, 20, and 25 mm). The tested helical piles with a helix diameter of 51 mm were considered, and the interhelix spacing approximately ranged between two and four times the helix diameter. Through laboratory testing techniques, the Shahriyar dense sand properties were identified. Alongside theoretical analyses of helical piles, the tensile and compressive pile load tests outcomes in dense sand with a relative density of 70% are presented. It was found that the maximum capacities of the compressive and tensile helical piles were up to six and eleven times that of the shaft capacity, respectively. With an increasing number of helices, the settlement reduced, and the bearing capacity increased. Consequently, helical piles can be manufactured in smaller sizes compared to steel piles. Overall, the compressive capacities of helical piles were higher than the tensile capacities under similar conditions. Single-helices piles with a pitch of 20 mm and double-helices piles with a pitch of 13 mm were more effective than others. Therefore, placing helices at the shallower depths and using smaller pitches result in better performance. In this study, when compared to values from the L1–L2 method, the theoretical method slightly underestimates the ultimate compression capacity and both overestimates and underestimates the uplift capacity for single- and double-helical piles, respectively, due to the individual bearing mode and cylindrical shear mode. Full article

Helical piles are widely used in geotechnical engineering, and their rapid installation and service reliability have attracted significant interest from the offshore wind industry. These piles are frequently subjected to cyclic loading in complex marine environments. Although the cyclic bearing behavior of helical piles has been studied, most research has focused on soil properties and loading conditions, with a limited systematic analysis of plate parameters. Moreover, the selection of plate parameters is not explicitly defined. As a crucial preliminary step in the capacity calculation, it is vital for the design of helical piles. To address this gap, the present study combines physical modeling tests and finite element simulations to systematically evaluate the influence of plate parameters on their cyclic bearing behavior. The parameters investigated include the plate depth, the plate diameter, plate spacing, and the number of plates. The results indicate that, under the same embedment conditions, cumulative displacement increases with the plate depth, with a critical embedment depth ratio of H_cr/D = 6 under cyclic loading conditions, but decreases with the number of plates. Axial stiffness increases with the plate depth, diameter, and number of plates, with an increase ranging from 0.5 to 3.0. However, the normalized axial stiffness decreases with these parameters, reaching a minimum value of 1.63. The plate spacing has a minimal influence on cyclic bearing behavior. Additionally, this study examines the evolution of displacement and stiffness parameters over repeated cycles in numerical simulations, as well as the post-cyclic pullout capacity of the helical pile foundation, which varies between −5% and +12%. Full article

This study investigates the application of machine learning (ML) algorithms for seismic damage classification of bridges supported by helical pile foundations in cohesive soils. While ML techniques have shown strong potential in seismic risk modeling, most prior research has focused on regression tasks or damage classification of overall bridge systems. The unique seismic behavior of foundation elements, particularly helical piles, remains unexplored. In this study, numerical data derived from finite element simulations are used to classify damage states for three key metrics: piers’ drift, piles’ ductility factor, and piles’ settlement ratio. Several ML algorithms, including CatBoost, LightGBM, Random Forest, and traditional classifiers, are evaluated under original, oversampled, and undersampled datasets. Results show that CatBoost and LightGBM outperform other methods in accuracy and robustness, particularly under imbalanced data conditions. Oversampling improves classification for specific targets but introduces overfitting risks in others, while undersampling generally degrades model performance. This work addresses a significant gap in bridge risk assessment by combining advanced ML methods with a specialized foundation type, contributing to improved post-earthquake damage evaluation and infrastructure resilience. Full article

For an offshore photovoltaic helical pile foundation, significant horizontal cyclic loading is imposed by wind and waves. To study a fixed offshore PV helical pile’s horizontal cyclic bearing performance, a numerical model of the helical pile under horizontal cyclic loading was established using an elastic–plastic boundary interface constitutive model of the clay soil. This model was compared with a monopile of the same diameter under similar conditions. The study examined the effects of horizontal cyclic loading amplitude, period, and vertical loads on the horizontal cyclic bearing performance. The results show that under horizontal monotonic loading, the bearing capacities of a helical pile and monopile in a serviceability limit state are quite similar. However, as the amplitude of horizontal cyclic loading increases, soil stiffness deteriorates significantly, leading to greater horizontal displacement accumulation for both types of piles. The helical pile’s bearing capacity under horizontal cyclic loadings is approximately 60% of that under monotonic loading. With shorter cyclic loading periods, horizontal displacement accumulates rapidly in the initial stage and stabilizes over a shorter duration. In contrast, longer cyclic loading periods lead to slower initial displacement accumulation, but the total accumulated displacement at stabilization is greater. When vertical loads are applied, the helical pile exhibits more stable horizontal cyclic bearing performance than the monopile. Full article

Screw piles (often referred to as helical piles) are widely used to resist axial and lateral loads as deep foundations. Multi-helix piles experience complex interactions between the plates which depend on the soil properties, pile stiffness, helix diameter, and the number of helix plates among other factors. Design methods for these piles are typically highly empirical and there remains significant uncertainty around calculating the compression capacity. In this study, a database of 1667 3D finite element analyses was developed to better understand the effect of different inputs on the compression capacity of screw piles in clean sands. Following development of the numerical database, various machine learning methods such as linear regression, neural networks, support vector machines, and Gaussian process regression (GPR) models were trained and tested on the database in order to develop a prediction tool for the pile compression capacity. GPR models, trained on the numerical data, provided excellent predictions of the screw pile compression capacity. The test dataset root mean square error (RMSE) of 29 kN from the GPR model was almost an order of magnitude better than the RMSE of 225 kN from a traditional theoretical approach, highlighting the potential of machine learning methods for predicting the compression capacity of screw piles in homogenous sands. Full article

This study examines the current status and future potential of the offshore wind sector. Offshore wind is pivotal in transitioning to a low-carbon society and meeting rising energy demands, despite being capital-intensive. The industry aims to develop larger-scale wind farms in deeper ocean locations, with projections indicating significant cost reductions. To explore deeper ocean areas, specialized foundations like floating platforms moored to the seabed are required. This study proposes helical piles anchored in the seabed as a method to secure mooring lines. Using Plaxis 3D, a parametric examination was conducted on helical piles with two plates: one fixed at the pile’s toe and the other varying in position between 0.5 and 13 m from the seabed surface. Load inclination angles (0, 20, 40, and 60 degrees) were used to simulate mooring line loads. Results indicate the optimal Zh/Z ratios for maintaining load-bearing capacity and stability: 0.12 (10 mm movements), 0.22 (25 mm), and 0.26 (50 mm) for small shaft diameters; and 0.34 (10 mm), 0.38 (25 mm), and 0.46 (50 mm) for large shaft diameters. These findings highlight the importance of specific load inclination angles based on shaft diameter and allowable movement for effective performance. Full article

The bearing capacity of fiber-reinforced plastic (FRP) helical screw piles is determined by the lesser of the breaking load at the bolted joint and the resistance provided by the screw tip area. In this study, compression and tensile tests were performed with the number of bolts and edge distance as variables. It showed similar strength when compared to the failure stress derived from material testing. In addition, considering load resistance performance, the optimal screw cross section was obtained through parametric analysis. Considering the structural behavior of the screw, a prediction equation was presented to design the screw cross-section as a tapered cross-section using a theoretical method. As a result of comparing the screw cross-section with the finite element analysis results, it was confirmed that the design stress and analysis stress showed an error of 1.1 MPa and were within the allowable stress of 80 MPa. Full article

Helical piles are advantageous alternatives in constructions subjected to high tractions in their foundations, like transmission towers. Installation torque is a key parameter to define installation equipment and the final depth of the helical pile. This work applies machine learning (ML) techniques to predict helical pile installation torque based on information from 707 installation reports, including Standard Penetration Test (SPT) data. It uses this information to build three datasets to train and test eight machine-learning techniques. Decision tree (DT) was the worst technique for comparing performances, and cubist (CUB) was the best. Pile length was the most important variable, while soil type had little relevance for predictions. Predictions become more accurate for torque values greater than 8 kNm. Results show that CUB predictions are within $\left[0.71,1.59\right]$ times the real value with a 95% confidence. Thus, CUB successfully predicted the pile length using SPT data in a case study. One can conclude that the proposed methodology has the potential to aid in the helical pile design and the equipment specification for installation. Full article

Adding fibers into cement to form fiber-reinforced soil cement material can effectively enhance its physical and mechanical properties. In order to investigate the effect of fiber type and dosage on the strength of fiber-reinforced soil cement, polypropylene fibers (PPFs), polyvinyl alcohol fibers (PVAFs), and glass fibers (GFs) were blended according to the mass fraction of the mixture of cement and dry soil (0.5%, 1%, 1.5%, and 2%). Unconfined compressive strength tests, split tensile strength tests, scanning electron microscopy (SEM) tests, and mercury intrusion porosimetry (MIP) pore structure analysis tests were conducted. The results indicated that the unconfined compressive strength of the three types of fiber-reinforced soil cement peaked at a fiber dosage of 0.5%, registering 26.72 MPa, 27.49 MPa, and 27.67 MPa, respectively. The split tensile strength of all three fiber-reinforced soil cement variants reached their maximum at a 1.5% fiber dosage, recording 2.29 MPa, 2.34 MPa, and 2.27 MPa, respectively. The predominant pore sizes in all three fiber-reinforced soil cement specimens ranged from 10 nm to 100 nm. Furthermore, analysis from the perspective of energy evolution revealed that a moderate fiber dosage can minimize energy loss. This paper demonstrates that the unconfined compressive strength test, split tensile strength test, scanning electron microscopy (SEM), and mercury intrusion porosimetry (MIP) pore structure analysis offer theoretical underpinnings for the utilization of fiber-reinforced soil cement in helical pile core stiffening and broader engineering applications. Full article

The increasing demand for deep excavations in construction projects emphasizes the necessity of robust support structures to ensure safety and stability. Support structures are critical in stabilizing excavation pits, with a primary focus on enhancing their bearing capacity. This paper employs finite element modeling techniques to conduct a numerical analysis of nails and helical anchors’ bearing capacity. To reinforce the stability of pit walls, selecting an appropriate method for guard structure construction is imperative. The chosen method should efficiently redistribute forces induced by soil mass weight, displacements, and potential loads in the pit vicinity to the ground. Various techniques, including trusses, piles, cross-bracing systems, nailing, and anchorage systems, are utilized for this purpose. The study evaluates numerical models for two guard structure configurations: nailing systems and helical anchorage. It examines the impact of parameters such as displacement, helical helix count, helix diameter variations, and the integration of nailing systems with helices. Comparative analyses are conducted, including displacement comparisons between different nailing systems and helical anchor systems, along with laboratory-sampled data. The research yields significant insights, with a notable finding highlighting the superior performance of helical bracings compared to nailing systems. The conclusions drawn from this study provide specific outcomes that contribute valuable knowledge to the field of deep excavation support structures, guiding future design and implementation practices. Full article

In this paper, numerical simulations of a special energy pile, which constitutes a spiral-injected pipe and one straight discharge pile for Geothermal Heat Pump Systems (SGHEs-P(parallel)), were conducted by Fluent software. The effects of the spiral pitches on the heat transfer rate based on the G-function method and peripheral soil temperature of the pile were investigated under continuous and intermittent operation strategies. The impact of spiral tube sizing on the surface heat transfer coefficients was studied. The results indicated that SGHEs-P may be preferred for office buildings under intermittent operation conditions. For a short period, the temperature profiles and heat transfer efficiency of SGHEs-P were mainly influenced by the fluid type, length of the spiral tube, and spiral pitch. The smaller the spiral pitch, the more uniform the temperature distribution, and the better the heat transfer effect, but the heat transfer per unit depth of pile decreased. The average temperature variation curve of the soil around the energy pile with different spiral pitches was simulated and obtained over time. Meanwhile, the impact of spiral radius, spiral pitch, and spiral tube radius on the convective heat transfer coefficient was also presented. Through data fitting, the formulas for the correction coefficients of spiral radius, spiral pitch, and spiral tube radius on convective heat transfer coefficient were obtained, respectively. Full article

The foundations of particular engineering structures, including marine and jetty structures, mooring systems for submerged platforms or those on the ocean surface, and transmission towers, are subjected to various external loads including compression, uplift, and lateral loads. In such cases, to improve the soil resistance below foundations, pile foundations such as helical piles, anchored piles, and batter piles are commonly preferred, depending on the in situ conditions. Helical piles, increasingly used as an alternative foundation to conventional piles, are placed in the soil body by rotating with torque. This paper deals with the contribution of a helical pile in improving loose sandy soil, and the main purpose is to study the effect of the helix-buried depth on the load-bearing capacity and failure mechanism. The investigated variables include the distance between helixes, the number of helixes, and the diameter of the upper helix. Physical model tests were conducted, and two- and three-dimensional numerical analyses were performed by using the finite element method with an advanced soil model to illustrate the failure mechanisms of helical piles. The aim was to reveal the efficiency of the finite element method in modelling helical piles placed in weak sandy soil. A simplified linear geometry for helixes was established in a two-dimensional finite element model whereas a real geometry for helixes, which was a more realistic approach, was created in a three-dimensional finite element model. The results show that the three-dimensional model indicates better agreement with the physical model compared to the two-dimensional model, and all investigated variables highly affect the load-bearing capacity of helical piles. Full article

Helical piles became a popular foundation technique, and as a result of environmental restrictions, they have become increasingly widely used. However, due to the high cost of experimentation, the influence of the number of helices and their positions on the pile-bearing capacity has not been sufficiently studied. The present study performed compression and lateral load tests on helical piles of the same diameter but with one, two, and three round helices in known sandy soil. The results from the experiments are compared with those from numerical simulations that use the mesh-free RBF method and the Winkler–Fuss approach to model how the pile and ground interact. The results are generalized to suggest an engineering equation that can predict the best pile configuration in sandy soil. Full article

In the past decades, as the world has placed emphasis on green energy, solar energy has become a favorable option. Different piled foundations have been designed to strengthen the structure supporting the solar panels. These piled foundations include rectangular and circular hollow section piles, as well as H-shaped piles. With various environmental loadings, lateral soil displacement will be encountered when large solar panels are installed on the supporting structure at an inclined angle. Presently, helical pipe piles are widely used in solar farms as part of the supporting structure. In this paper, the pile–soil interaction of steel pipe piles and helical pipe piles with wind loads is analyzed using ABAQUS. The Finite Element Method (FEM) models are assessed with varying strength moduli and cohesions of clay. Further, this paper examines the pile soil system, considering different clay stiffnesses, including very soft, soft, firm, stiff, very stiff, and hard. It is found that the helical piles’ horizontal capacity increases with soil strength and Young’s modulus, but the capacity increment rate reacts differently. This study has a guiding effect on the construction of solar farms using the “tracker” solar system. Full article

Helical piles are a new type of pile that has good application prospects, and researchers have carried out an in-depth investigation into their vertical uplift and compressive bearing capacity. However, there is relatively little research on the dynamic bearing characteristics of helical piles. Therefore, the lateral vibration of a helical pile embedded in the viscoelastic foundation is systematically studied in this article. Utilizing the equivalent stiffness method to transform a helical pile into a cylindrical pile of special diameter, the lateral vibration model of the helical pile considering shear deformation is established based on the Winkler foundation model and the Timoshenko beam theory. The analytical solutions for the lateral dynamic displacement, bending moment, and shear force of the helical pile are strictly derived, and the rationality of the present solutions is also verified by comparing them with existing solutions. Based on the present solutions, a parametric study is carried out to investigate the influence of the pile and soil properties on the lateral dynamic response of the helical pile. It is found that the load excitation frequency and pile–soil stiffness ratio have a significant influence on the lateral dynamic displacement, bending moment, and shear force of the helical pile with space and time response. Full article
