A new compact, wideband, millimeter-wave microstrip crossover—designed without vias—demonstrates effective performance with an insertion loss of 2 dB across a wide frequency range. For Path 1, the operational bandwidth spans 11 GHz (13–24 GHz), while for Path 2, it extends over 10 GHz (12–22 GHz). The overlapping bandwidth, maintaining the 2 dB insertion loss criterion, covers 9 GHz (13–22 GHz). The design introduces two transition mechanisms to achieve optimal scattering parameters for the crossover: a stair-shaped microstrip line (MST) to ground-backed coplanar waveguide (GCPW) for the initial crossed line (Path 1), and vertical coupling between microstrip and coplanar hourglass microstrip patches on a single-layer substrate for Path 2. This innovative approach ensures an insertion loss of approximately 1 dB for both paths across the bandwidth, with a slight increase beyond 20 GHz for Path 2 due to substrate losses. Both crossed lines maintain a return loss of 10 dB across the spectrum, with isolation of approximately 20 dB. This design presents a flat, compact, and via-less configuration, with physical dimensions measuring 6.5 mm × 7.6 mm. The proposed design exhibits excellent scattering parameters, which enhance the efficiency of phased array antenna systems in terms of power transfer between input and output ports, as well as improving isolation between different input ports in the feed network of these systems used in remote sensing. Consequently, this contributes to the increased sensitivity and accuracy of such systems. Full article

A terahertz band (0.1–10 THz) has the characteristics of rich spectrum resources, high transmission speed, strong penetration, and clear directionality. However, the terahertz signal will suffer serious attenuation and absorption during transmission. Therefore, a terahertz antenna with high gain, high efficiency, and wide bandwidth is an indispensable key component of terahertz wireless systems and has become a research hotspot in the field of antennas. In this paper, a high-gain broadband antenna is presented for terahertz applications. The antenna is a three-layer structure, fed by a grounded coplanar waveguide (GCPW), using polytetrafluoroethylene (PTFE) material as the dielectric substrate, and the metal through-hole of the dielectric substrate forms a substrate-integrated waveguide (SIW) structure. The metal fence structure is introduced to reduce the coupling effect between the radiation patches and increase the radiation bandwidth and gain. The center frequency is 0.6366 THz, the operating bandwidth is 0.61–0.68 THz, the minimum value of the voltage standing wave ratio (VSWR) is 1.00158, and the peak gain is 13.14 dBi. In addition, the performance of the designed antenna with a different isolation structure, the length of the connection line, the height of the substrate, the radius of the through-hole, and the thickness of the patch is also studied. Full article

In this paper, a dual-band integrated bandpass filter (DI-BPF) based on a mode composite substrate integrated coaxial line (MCSICL) is proposed for a large frequency ratio. The low-frequency bandpass filter is formed by incorporating an SICL line and a gap into the MCSICL, operating in the fundamental mode of the MCSICL. The high-frequency bandpass filter is formed by introducing grounded vias into the MCSICL, operating in the first high-order mode of the MCSICL. To guide the design, the equivalent circuit models of the low- and high-frequency bandpass filters are built. Based on the equivalent circuit models, the DI-BPF is synthesized for a large frequency ratio. The transitions from the DI-BPF to ground coplanar waveguides (GCPWs) are designed for the low- and high-frequency bandpass filters. The DI-BPF with the transitions is fabricated by the printed circuit board (PCB) process. Measurement results indicate a large frequency ratio of 23.16, with the isolation between the low- and high-frequency bandpass filters exceeding 30 dB from dc to 50 GHz. Full article

This paper presents a novel periodic grounded coplanar waveguide (GCPW) leaky-wave antenna implemented in an Indium Phosphide (InP) process. The antenna is designed to operate in the 220 GHz–325 GHz frequency range, with the goal of integrating it with an InP uni-traveling-carrier photodiode to realize a wireless transmitter module. Future wireless communication systems must deliver a high data rate to multiple users in different locations. Therefore, wireless transmitters need to have a broadband nature, high gain, and beam-steering capability. Leaky-wave antennas offer a simple and cost-effective way to achieve beam-steering by sweeping frequency in the THz range. In this paper, the first periodic GCPW leaky-wave antenna in the 220 GHz–325 GHz frequency range is demonstrated. The antenna design is based on a novel GCPW leaky-wave unit cell (UC) that incorporates mirrored L-slots in the lateral ground planes. These mirrored L-slots effectively mitigate the open stopband phenomenon of a periodic leaky-wave antenna. The leakage rate, phase constant, and Bloch impedance of the novel GCPW leaky-wave UC are analyzed using Floquet’s theory. After optimizing the UC, a periodic GCPW leaky-wave antenna is constructed by cascading 16 UCs. Electromagnetic simulation results of the leaky-wave antenna are compared with an ideal model derived from a single UC. The two design approaches show excellent agreement in terms of their reflection coefficient and beam-steering range. Therefore, the ideal model presented in this paper demonstrates, for the first time, a rapid method for developing periodic leaky-wave antennas. To validate the simulation results, probe-based antenna measurements are conducted, showing close agreement in terms of the reflection coefficient, peak antenna gain, beam-steering angle, and far-field radiation patterns. The periodic GCPW leaky-wave antenna presented in this paper exhibits a high gain of up to 13.5 dBi and a wide beam-steering range from $-60{}^{°}$ to $35{}^{°}$ over the 220 GHz–325 GHz frequency range. Full article

A grounded coplanar waveguide (GCPW), as a millimeter wave special transmission line, can be used to calibrate broadband oscilloscope probes. A method to change the through-hole structure to widen the GCPW is investigated in this paper. The effect of the through-hole array on the band-width of the GCPW is investigated and verified using COMSOL Multiphysics simulation software. Finally, the S-parameters of the fabricated GCPWs are measured by a vector network analyzer, and the results show that they have an insertion loss > −3 dB and return loss < −10 dB in the frequency range of DC to 60 GHz, which satisfies the design requirements. Full article

This article presents the methodology to design a single-fed circularly-polarized antenna with low front-to-back ratio (FBR). A circular-patch (CPatch) antenna has been incorporated within the rectangular-cavity, made of, substrate integrated waveguide (SIW). The size of the CPatch and the SIW cavity has been chosen appropriately, in a manner, that the both resonators dominant mode coincide. This arrangement has been adopted to realize the basic radiating unit with no surface-wave and the significantly lower FBR. The circularly polarization has been excited through shorting the periphery of CPatch radiator to the “one of the two metallic grounds” of this SIW cavity. The patch periphery has been shorted from two distinct points, separated by the quarter wavelength—over center frequency of working band. The antenna has been designed and manufactured over Rogers RT/Duroid 5880 substrate with dielectric constant (ε_r) of 2.2, loss-tangent (tan δ, at 10 GHz) of 0.0009, and substrate height of 0.508 mm. Southwest^® end launcher (SEL) along with SIW-to-GCPW (Grounded Co-Planar Waveguide) transition has been used here to facilitate the measurement of antenna’s electrical and the radiation performance. The designed antenna’s impedance bandwidth and the 3 dB axial-ratio (AR) bandwidth is 9.5% and the 2.3%, respectively. It’s simulated and the measured peak gain, within working frequency band, is higher than 8.5dBic. The proposed antenna’s FBR is antenna is significantly lower than the conventional circularly-polarized antennas. Through comparative study, with work in open literature, it has been demonstrated that the designed antenna, based on proposed method, can a potential candidate for applicable in satellite and in the other spaceborne communication system’s module—at ground and in the space station. Full article

In this paper, a new method for the wireless detection of liquid level is proposed by integrating a capacitive IDC-sensing element with a passive three-port RFID-sensing architecture. The sensing element transduces changes in the liquid level to corresponding fringe-capacitance variations, which alters the phase of the RFID backscattered signal. Variation in capacitance also changes the resonance magnitude of the sensing element, which is associated with a high phase transition. This change in the reactive phase is used as a sensing parameter by the RFID architecture for liquid-level detection. Practical measurements were conducted in a real-world scenario by placing the sensor at a distance of approximately 2 m (with a maximum range of about 7 m) from the RFID reader. The results show that the sensor node offers a high sensitivity of 2.15°/mm to the liquid-level variation. Additionally, the sensor can be used within or outside the container for the accurate measurement of conductive- or non-conductive-type liquids due to the use of polyethylene coating on the sensitive element. The proposed sensor increases the reliability of the current level sensors by eliminating the internal power source as well as complex signal-processing circuits, and it offers real-time response, linearity, high sensitivity, and excellent repeatability, which are suitable for widespread deployment of sensor node applications. Full article

This paper proposes a dual-polarization dipole antenna for a cylindrical phased array working in Ku-band. The dipole antenna is double-layer structured and is composed of two orthogonal butterfly shaped dipole radiators, two ground co-planar waveguide (GCPW) feeding structures and vias. Each dipole is in the shape of a butterfly. The dipole patch is grooved triangularly and one side of it is bent into an N shape, which effectively expands the working frequency band of the antenna. The double-layer structure improves the isolation between the antenna ports. The antenna works between 15 GHz to 16.2 GHz and the isolation between the antenna’s two feeding ports in this band is better than 20 dB. The proposed dipole antenna is applied in a 32-element cylinder array. The simulation and measured results show that the array can scan between −60° to +60° in the azimuth plane with a gain fluctuation less than 2.5 dB. Therefore, the proposed design is an attractive candidate for conformal devices at Ku-band frequencies, and it also has a great potential for application in larger antenna arrays. Full article

For automobile radar systems, the antenna array requires a low sidelobe level (SLL) to reduce interference. A low-SLL and low-cost planar antenna array are proposed in this article for millimeter-wave automotive radar applications. The proposed array consists of six linear series-fed patch arrays, a series distribution network using a grounded co-planar waveguide (GCPW), and a bed of nails. First, a hybrid HFSS-MATLAB optimization platform is set up to easily obtain good impedance matching and low SLL of the linear series-fed patch array. Then, a six-way GCPW power divider is designed to combine the optimized linear sub-array to achieve a planar array. However, since CCPW is a semi-open structure, like a microstrip line, the parasitic radiation generated by the GCPW feeding network will lead to the deterioration of the SLL. To solve this problem, a bed of nails—as an artificial magnetic conductor (AMC)—is designed and placed above the feeding networking to create an electromagnetic stopband in the working band. Its working mechanism has been explained in detail. The feeding network cannot effectively radiate electromagnetic waves into free space. Thus, the parasitic radiation can be suppressed. A low-SLL planar array prototype working at 79 GHz is designed, manufactured, and measured. The measured results confirm that the proposed low-SLL planar array has a −10 dB impedance bandwidth of 3 GHz from 77 to 80 GHz and a maximum peak gain of 21 dBi. The measured SLL is −24 dB and −23 dB in the E-plane and H-plane at 79 GHz, respectively. The proposed low SLL array can be used for adaptive cruise control (ACC) system applications. Full article

In this paper, the pulse wave (PW) rectifier of the Schottky diode is theoretically analyzed using the microwave equivalent circuit. It is found that the duty cycle of PW is inversely proportional to the load resistance of the rectifier when the amplitude of the input pulse is the same. Therefore, a stable high-efficiency rectifier can be designed by changing the value of the load resistance when the duty cycles are different. A grounded coplanar waveguide (GCPW) rectifier for the pulse wave is designed to verify this rule. The rectifier is simulated by ADS software and verified by the measurements. When the duty cycle of PW varies from 0.01 to 1 and the input pulse amplitude is stable at the operation frequency of 2.38 GHz, the measured rectifying efficiency can be maintained at the peak efficiency of 76.1% by adjusting the load resistance. However, when the input signal of the rectifier is the continuous wave (CW), the rectifying efficiency is only 3.9% at the same input power amplitude. The proposed rectifier has a simple structure so that it can obtain a high efficiency and has a compact size of 0.22λ₀ × 0.11λ₀. It can be a good candidate for simultaneous wireless information and power transmission (SWIPT) for low-power electronic devices in the Internet of Things (IoT). Full article

This paper exhibits a high-gain, low-profile dipole antenna array (DAA) for 5G applications. The dipole element has a semi-triangular shape to realize a simple input impedance regime. To reduce the overall antenna size, a substrate integrated cavity (SIC) is adopted as a power splitter feeding network. The transition between the SIC and the antenna element is achieved by a grounded coplanar waveguide (GCPW) to increase the degree of freedom of impedance matching. Epsilon-near-zero (ENZ) metamaterial technique is exploited for gain enhancement. The ENZ metamaterial unit cells of meander shape are placed in front of each dipole perpendicularly to guide the radiated power into the broadside direction. The prospective antenna has an overall size of 2.58 ${\lambda }_g^3$ and operates from 28.5 GHz up to 30.5 GHz. The gain is improved by 5 dB compared to that of the antenna without ENZ unit cells, reaching 11 dBi at the center frequency of 29.5 GHz. Measured and simulated results show a reasonable agreement. Full article

Wireless body area network (WBAN) applications have broad utility in monitoring patient health and transmitting the data wirelessly. WBAN can greatly benefit from wearable antennas. Wearable antennas provide comfort and continuity of the monitoring of the patient. Therefore, they must be comfortable, flexible, and operate without excessive degradation near the body. Most wearable antennas use a truncated ground, which increases specific absorption rate (SAR) undesirably. A full ground ultra-wideband (UWB) antenna is proposed and utilized here to attain a broad bandwidth while keeping SAR in the acceptable range based on both 1 g and 10 g standards. It is designed on a denim substrate with a dielectric constant of 1.4 and thickness of 0.7 mm alongside the ShieldIt conductive textile. The antenna is fed using a ground coplanar waveguide (GCPW) through a substrate-integrated waveguide (SIW) transition. This transition creates a perfect match while reducing SAR. In addition, the proposed antenna has a bandwidth (BW) of 7–28 GHz, maximum directive gain of 10.5 dBi and maximum radiation efficiency of 96%, with small dimensions of 60 × 50 × 0.7 mm³. The good antenna’s performance while it is placed on the breast shows that it is a good candidate for both breast cancer imaging and WBAN. Full article

When designing a microwave circuit involving substrate integrated coaxial lines (SICLs), it is important to know what real crosstalk between SICLs is. A measured crosstalk will be a good reference value in a practical design. In addition, it is also needed to compare and check the crosstalk from the simulation and calculation formula with measured results. However, it is very difficult to measure the crosstalk between SICLs because it is theoretically very low. In this study, for the first time, the crosstalk characteristics of a SICL are evaluated through experimental design and measurements. By adjusting the layout of the structures and implementing controlled experiments, interference caused by the presence of leaks and radiation at the interface and structural transitions is effectively suppressed. The experimental results show that for two parallel SICLs with a length of 30 mm and an interval of 5 mm, the isolation is greater than 80 dB for the measured frequency range of 1–8 GHz, significantly better than the results of the grounded coplanar waveguide (GCPW). Full article

This paper presents the bandwidth enhancement and frequency scanning for fan beam array antenna utilizing novel technique of band-pass filter integration for wireless vital signs monitoring and vehicle navigation sensors. First, a fan beam array antenna comprising of a grounded coplanar waveguide (GCPW) radiating element, CPW fed line, and the grounded reflector is introduced which operate at a frequency band of 3.30 GHz and 3.50 GHz for WiMAX (World-wide Interoperability for Microwave Access) applications. An advantageous beam pattern is generated by the combination of a CPW feed network, non-parasitic grounded reflector, and non-planar GCPW array monopole antenna. Secondly, a miniaturized wide-band bandpass filter is developed using SCSRR (Semi-Complementary Split Ring Resonator) and DGS (Defective Ground Structures) operating at 3–8 GHz frequency band. Finally, the designed filter is integrated within the frequency scanning beam array antenna in a novel way to increase the impedance bandwidth as well as frequency scanning. The new frequency beam array antenna with integrated band-pass filter operate at 2.8 GHz to 6 GHz with a wide frequency scanning from the 50 to 125-degree range. Full article
