This paper investigates the problem of angular momentum control and planning for control moment gyroscope(CMG) arrays in rigid spacecraft attitude control systems using deep reinforcement learning (DRL). Specifically, a DRL-based angular momentum control strategy is proposed for spacecraft attitude control systems employing multiple CMGs as actuators. The twin-delayed deep deterministic policy gradient (TD3) algorithm is used to perform online learning and policy updates based on environmental feedback. This approach eliminates the need for precise mathematical models and iterative parameter tuning. This enables the CMG system to perform angular momentum planning and facilitates rapid and high-precision spacecraft attitude maneuvers and control through angular momentum exchange. Simulations were performed to analyze spacecraft attitude maneuvers and stabilization under various scenarios, focusing on the angular momentum control process of a pyramidal single gimbal CMG (SGCMG) array. The results demonstrate that the proposed method effectively achieves large-angle attitude maneuvers and stable attitude maintenance, both in ideal conditions and in the presence of nonlinear disturbances. During large-angle maneuvers, the spacecraft’s attitude estimation using MRPs converges in less than 1 min, and the convergence accuracy during attitude-holding reaches the order of 10⁻³. Moreover, the approach fully leverages the output characteristics of the CMG system and achieves robust performance and accuracy, even under conditions with significant noise and disturbances. Full article

Continuously rotating gimbals for scanning purposes are widely used in space applications. For high-precision gimbals, it is essential to lock the gimbal before launch and unlock it on orbit. This kind of gimbal puts forward the need for hold down release mechanisms that are able to clear the gap between the rotating and fixed parts at release. Existing technologies either lack the function of gap avoidance after separation or rely more or less on the elastic deformation of the structure or limited spring forces for unlocking, which are either unreliable or complicated. To address this problem, this paper presents the design of a novel non-pyrotechnic heavy-load hold down release mechanism (HDRM) based on shape memory alloy actuator. The proposed HDRM is shock-free and capable of clearing an axial gap of 8 mm for safe rotating at release. The structure and operational principle of the proposed design are straightforward. Detailed tests show the proposed HDRM may withstand a maximum external force of 50 KN with relatively high stiffness under 15 KN of preload, indicating a better performance than existing products. The HDRM demonstrates its promising usage as an alternative to traditional pyrotechnic and non-pyrotechnic HDRMs. Full article

In order to ensure that dual-axis rotational inertial navigation systems (RINSs) maintain a high level of accuracy over the long term, there is a demand for periodic calibration during their service life. Traditional calibration methods for inertial measurement units (IMUs) involve removing the IMU from the equipment, which is a laborious and time-consuming process. Reinstalling the IMU after calibration may introduce new installation errors. This paper focuses on dual-axis rotational inertial navigation systems and presents a system-level self-calibration method based on invariant errors, enabling high-precision automated calibration without the need for equipment disassembly. First, navigation parameter errors in the inertial frame are expressed as invariant errors. This allows the corresponding error models to estimate initial attitude even more rapidly and accurately in cases of extreme misalignment, eliminating the need for coarse alignment. Next, by utilizing the output of a gimbal mechanism, angular velocity constraint equations are established, and the backtracking navigation is introduced to reuse sensor data, thereby reducing the calibration time. Finally, a rotation scheme for the IMU is designed to ensure that all errors are observable. The observability of the system is analyzed based on a piecewise constant system method and singular value decomposition (SVD) observability analysis. The simulation and experimental results demonstrate that this method can effectively estimate IMU errors and installation errors related to the rotation axis within 12 min, and the estimated error is less than 4%. After using this method to compensate for the calibration error, the velocity and position accuracies of a RINS are significantly improved. Full article

Strapdown celestial imaging sensors provide a compact, lightweight alternative to their gimbaled counterparts. Strapdown imaging systems typically require a wider field of view, and consequently longer exposure intervals, leading to significant motion blur. The motion blur for a constellation of stars results in a constellation of trails on the image plane. We present a method that extracts the path of these star trails, and uses a linearized weighted least squares approach to correct noisy inertial attitude measurements. We demonstrate the validity of this method through its application to synthetically generated images, and subsequently observe its relative performance by using real images. The findings of this study indicate that the motion blur present in strapdown celestial imagery yields an a posteriori mean absolute attitude error of less than 0.13 degrees in the yaw axis, and 0.06 degrees in the pitch and roll axes (3 $\sigma$) for a calibrated wide-angle camera lens. These findings demonstrate the viability of low-cost, wide-angle, strapdown celestial attitude sensors on lightweight UAV hardware. Full article

This paper presents AlScN piezoelectric two-axis MEMS mirrors with gimbal-less and gimbaled designs fabricated in a CMOS-compatible manner. Integrated piezoelectric sensors provided feedback signals of the actual mirror positions. The mirror with a diameter of 1.5 mm possessed adjustable optical tilt angles of up to 22.6° @ 30 V, with a high resonance frequency of about 8.2 kHz, while the 3 mm mirror reached 48.5° @ 41 V. The mirror with the gimbaled structure exhibited an excellent field of view and good mechanical decoupling. Additionally, a significant improvement in mirror scanning performance was observed in a vacuum (4 Pa), proving that the optical field of view was magnified by more than a factor of 10. Full article

This study aims at creating low-cost, three-dimensional (3D), freehand ultrasound image reconstructions from commercial two-dimensional (2D) probes. The low-cost system that can be attached to a commercial 2D ultrasound probe consists of commercial ultrasonic distance sensors, a gimbal, and an inertial measurement unit (IMU). To calibrate irregular movements of the probe during scanning, relative position data were collected from the ultrasonic sensors that were attached to a gimbal. The directional information was provided from the IMU. All the data and 2D ultrasound images were combined using a personal computer to reconstruct 3D ultrasound image. The relative position error of the proposed system was less than 0.5%. The overall shape of the cystic mass in the breast phantom was similar to those from 2D and sections of 3D ultrasound images. Additionally, the pressure and deformations of lesions could be obtained and compensated by contacting the probe to the surface of the soft tissue using the acquired position data. The proposed method did not require any initial marks or receivers for the reconstruction of a 3D ultrasound image using a 2D ultrasound probe. Even though our system is less than $500, a valuable volumetric ultrasound image could be provided to the users. Full article

In the UAV electro-optical pod of the two-axis four-gimbal, the characteristics of a coarse–fine composite structure and the complexity of dynamics modeling affect the entire system’s high precision control performance. The core goal of this paper is to solve the high precision control of a two-axis four-gimbal electro-optical pod through dynamic modeling and theoretical study. In response to this problem, we used finite element analysis (FEA) and stress study of the key component to design the structure. The gimbals adopt the aerospace material 7075-t3510 aluminum alloy in order to meet the requirements of an ultralight weight of less than 1 kg. According to the Euler rigid body dynamics model, the transmission path and kinematics coupling compensation matrix between the two-axis four-gimbal structures are obtained. The coarse–fine composite self-correction drive equation in the Cartesian system is derived to solve the pre-selection and check problem of the mechatronic under high-precision control. Finally, the modeling method is substituted into the disturbance observer (DOB) disturbance suppression experiment, which can monitor and compensate for the motion coupling between gimbal structures in real time. Results show that the disturbance suppression impact of the DOB method with dynamics model is increased by up to 90% compared to PID (Proportion Integration Differentiation method) and is 25% better than the traditional DOB method. Full article

A micro-scanner made of stainless-steel is fabricated via laser cutting technology for 3D Lissajous confocal imaging. The multi-gimbaled structure of the device provides two orthogonal torsional modes and three different out-of-plane modes. Torsional modes can be used to achieve 2D scan and all of the out-of-plane modes can be used in changing the focus of the micro-scanner to achieve a 3D scanning pattern. One of the out-of-plane modes along with two orthogonal torsional modes can be employed for scanning a large depth-stack in sparse fashion while another out-of-plane mode can satisfy a much higher scan fill-rate with less field of view (FOV). Simulations of the micro-scanner are obtained using finite element method (FEM) software and compared with the characterization data gathered from Laser Doppler Vibrometer (LDV). Using various out-of-plane modes, the constructed fill patterns are simulated on MATLAB and fill rates compared. Full article

Developing methods for autonomous landing of an unmanned aerial vehicle (UAV) on a mobile platform has been an active area of research over the past decade, as it offers an attractive solution for cases where rapid deployment and recovery of a fleet of UAVs, continuous flight tasks, extended operational ranges, and mobile recharging stations are desired. In this work, we present a new autonomous landing method that can be implemented on micro UAVs that require high-bandwidth feedback control loops for safe landing under various uncertainties and wind disturbances. We present our system architecture, including dynamic modeling of the UAV with a gimbaled camera, implementation of a Kalman filter for optimal localization of the mobile platform, and development of model predictive control (MPC), for guidance of UAVs. We demonstrate autonomous landing with an error of less than 37 cm from the center of a mobile platform traveling at a speed of up to 12 m/s under the condition of noisy measurements and wind disturbances. Full article

Since an existing 3-phase inner rotor torque actuator (TA) has severe torque ripples, it is not appropriate for a gimbal system that requires precise position control. Therefore, a coreless TA is considered to eliminate the core causing torque ripples. In order to compensate for several problems (e.g., problems of production structures and output degradation) when a coreless type is used, the final 2-phase outer rotor is proposed for the low vibration and high power TA in the gimbal system. To control the 2-phase TA applied to such the gimbal system, special inverter control methods, such as bi-directional drive for tilting control and control for output torque improvement, are required. The 2-phase 3-leg inverter is free of DC capacitor voltage unbalance compared to the 2-leg inverter, and is economical because it uses less power switches than the 4-leg inverter. Therefore, the 2-phase 3-leg inverter is applied to drive the 2-phase outer rotor coreless TA of a hybrid gimbal system, and it is verified through simulation. Full article

We present an electromagnetically driven microscanner based on a gimbal-less twist mechanism. In contrast to conventional microscanners using a gimbal-less leverage mechanism, our device utilizes a gimbal-less twist mechanism to increase the scan angle in optical applications requiring a large scanning mirror. The proposed gimbal-less scanner with twist mechanism increases the scan angle by 1.55 and 1.97 times for the slow and fast axes, respectively, under the same force; 3.64 and 1.97 times for the slow and fast axes, respectively, under the same maximum stress, compared to the gimbal-less leverage mechanism. The scanner with a 3-mm-diameter mirror and a current path composed of a single-turn coil was fabricated, and it showed the maximum scan angle of 5° (quasi-static) and 22° (resonant) for the slow and fast axes, respectively. The experimentally estimated crosstalk was as small as 0.47% and 0.97% for the fast and slow axes affected by the other axes, respectively, which was determined using a newly employed methodology based on fast Fourier transform. Full article

Unmanned Aerial Vehicles (UAVs) have shown great potential in agriculture and are increasingly being developed for agricultural use. There are still a lot of experiments that need to be done to improve their performance and explore new uses, but experiments using UAVs are limited by many conditions like weather and location and the time it takes to prepare for a flight. To promote UAV remote sensing, a near ground remote sensing platform was developed. This platform consists of three major parts: (1) mechanical structures like a horizontal rail, vertical cylinder, and three axes gimbal; (2) power supply and control parts; (3) onboard application components. This platform covers five degrees of freedom (DOFs): horizontal, vertical, pitch, roll, yaw. A stm32 ARM single chip was used as the controller of the whole platform and another stm32 MCU was used to stabilize the gimbal. The gimbal stabilizer communicates with the main controller via a CAN bus. A multispectral camera was mounted on the gimbal. Software written in C++ language was developed as the graphical user interface. Operating parameters were set via this software and the working status was displayed in this software. To test how well the system works, a laser distance meter was used to measure the slide rail’s repeat accuracy. A 3-axis vibration analyzer was used to test the system stability. Test results show that the horizontal repeat accuracy was less than 2 mm; vertical repeat accuracy was less than 1 mm; vibration was less than 2 g and remained at an acceptable level. This system has high accuracy and stability and can therefore be used for various near ground remote sensing studies. Full article
