Large-scale hydro-steel structures (LS-HSSs) are vital to hydraulic engineering, supporting critical functions such as water resource management, flood control, power generation, and navigation. However, due to prolonged exposure to severe environmental conditions and complex operational loads, these structures progressively degrade, posing increased risks over time. The absence of effective structural health monitoring (SHM) systems exacerbates these risks, as undetected damage and wear can compromise safety. This paper presents an advanced SHM framework designed to enhance the real-time monitoring and safety evaluation of LS-HSSs. The framework integrates the finite element method (FEM), multi-sensor data fusion, and Internet of Things (IoT) technologies into a closed-loop system for real-time perception, analysis, decision-making, and optimization. The system was deployed and validated at the Luhun Reservoir spillway, where it demonstrated stable and reliable performance for real-time anomaly detection and decision-making. Monitoring results over time were consistent, with stress values remaining below allowable thresholds and meeting safety standards. Specifically, stress monitoring during radial gate operations (with a current water level of 1.4 m) indicated that the dynamic stress values induced by flow vibrations at various points increased by approximately 2 MPa, with no significant impact loads. Moreover, the vibration amplitude during gate operation was below 0.03 mm, confirming the absence of critical structural damage and deformation. These results underscore the SHM system’s capacity to enhance operational safety and maintenance efficiency, highlighting its potential for broader application across water conservancy infrastructure. Full article

This research focuses on improving flood management of the Malwathu Oya River in Anuradhapura Historical City, Sri Lanka, by designing an efficient gate system for the weir of Halpan Ela in the Malwathu Oya River. Frequent flooding threatens agriculture, infrastructure, and public safety in this region. This research aims to enhance water level control in the upper reach of Halpan Ela Anicut by evaluating rainfall patterns, tank spillway efficiency, and gate operation challenges. Historical data on rainfall and tank spillage were analyzed. Flow simulations revealed significant pressure differences, with the existing gate structure showing an upstream pressure of 114,492.5 Pa at a maximum flow of 1740 m³/s, compared to 105,406 Pa for the new flap gate system at the same flow rate. This represents a pressure difference of 9 kPa, equivalent to a 0.9 m water head. Despite the system’s estimated cost of USD 0.1 million, the potential reduction in river flood damage, which currently exceeds USD 0.2 million annually, demonstrates its value. This research emphasizes the effectiveness of the flap gate system in reducing flood risks in Anuradhapura City compared to the existing gate type, though it is only a part of a broader flood mitigation strategy. Full article

Pre-release is the discharge from a reservoir before a flood to enhance flood control capability. Its success depends on the performance of rainfall forecasting. However, there is little information regarding the causal relationship between its performance and the success of pre-release. Therefore, the rainfall forecast required for pre-release at 326 multi-purpose reservoirs in Japan is shown quantitatively in this paper. In our analysis, pre-release was simulated based on tentative rainfall forecasts made using observed rainfall data from a period of 17 years (2006 to 2022) with some processing. Then, outputs were evaluated in terms of two risks: not avoiding emergency spillway gate operation and no recovery of water use capacity. The results of five elements were reached: (1) the characteristics of situations requiring pre-release, the required (2) forecast length and (3) spatial resolution, the required accuracy of (4) the rainfall amount, and (5) the position of rainfall zone. For (1), pre-release is required nationwide in typhoons or stationary fronts at a frequency of four instances per year. For (2) and (3), assuming perfect accuracy, the current specifications of rainfall forecast in Japan: forecast length of 84 h or more and the combined use of 5 km and 20 km spatial resolution are generally effective in themselves. For (4) and (5), possible uncertainties in the rainfall amount and the position of rainfall zone needs to be decreased by one digit for avoiding emergency spillway gate operations, while excessive pre-release tends not to result in no recovery of water use capacity. Full article

The paper demonstrates a simulation optimization framework for enhancing the real-time flood control with gated spillways at places where no flood forecasting data are available. A multiobjective modeling scheme is presented for the flood management in a gated spillway in which the operator may specify the priorities on floods based on their different return periods. Two different operation strategies were devised. Both operating strategies employ ten-stage policies, which rely on the reservoir water level as the input data. The second strategy benefits from both the observed reservoir water level and the flood peak. The optimal values of the models’ parameters were obtained using a genetic algorithm. This is a novel approach because none of its policies needs flood forecasting data, thus, making them adaptable to any flood with any return period. To evaluate the performances of the proposed models, the flood control through a gated spillway of the Karkheh reservoir was considered, where flood hydrographs with different return periods were routed through the reservoir. Full article

The objective of this research is to introduce a novel framework to quantify the risk of the reservoir system outside the design envelope, taking into account the risks related to flood-protection and hydro-energy generation under unfavourable reservoir element conditions (system element failures) and hazardous situations within the environment (flood event). To analyze water system behavior in adverse conditions, a system analysis approach is used, which is founded upon the system dynamics model with a causal loop. The capability of the system in performing the intended functionality can be quantified using the traditional static measures like reliability, resilience and vulnerability, or dynamic resilience. In this paper, a novel method for the assessment of a multi-parameter dynamic resilience is introduced. The multi-parameter dynamic resilience envelops the hydropower and flood-protection resilience, as two opposing demands in the reservoir operation regime. A case study of a Pirot reservoir, in the Republic of Serbia, is used. To estimate the multi -parameter dynamic resilience of the Pirot reservoir system, a hydrological model, and a system dynamic simulation model with an inner control loop, is developed. The inner control loop provides the relation between the hydropower generation and flood-protection. The hydrological model is calibrated and generated climate inputs are used to simulate the long-term flow sequences. The most severe flood event period is extracted to be used as the input for the system dynamics simulations. The system performance for five different scenarios with various multi failure events (e.g., generator failure, segment gate failure on the spillway, leakage from reservoir and water supply tunnel failure due to earthquake) are presented using the novel concept of the explicit modeling of the component failures through element functionality indicators. Based on the outputs from the system dynamics model, system performance is determined and, later, hydropower and flood protection resilience. Then, multi-parameter dynamic resilience of the Pirot reservoir system is estimated and compared with the traditional static measures (reliability). Discrepancy between the drop between multi-parameter resilience (from 0.851 to 0.935) and reliability (from 0.993 to 1) shows that static measure underestimates the risk to the water system. Thus, the results from this research show that multi-parameter dynamic resilience, as an indicator, can provide additional insight compared to the traditional static measures, leading to identification of the vulnerable elements of a complex reservoir system. Additionally, it is shown that the proposed explicit modeling of system components failure can be used to reflect the drop of the overall system functionality. Full article

This paper presents a real-time flood control model for dams with gate-controlled spillways that brings together the advantages of an optimization model based on mixed integer linear programming (MILP) and a case-based learning scheme using Bayesian Networks (BNets). A BNet model was designed to reproduce the causal relationship between inflows, outflows and reservoir storage. The model was trained with synthetic events generated with the use of the MILP model. The BNet model produces a probabilistic description of recommended dam outflows over a time horizon of 1 to 5 h for the Talave reservoir in Spain. The results of implementing the BNet recommendation were compared against the results obtained while applying two conventional models: the MILP model, which assumes full knowledge of the inflow hydrograph, and the Volumetric Evaluation Method (VEM), a method widely used in Spain that works in real-time, but without any knowledge of future inflows. In order to compare the results of the three methods, the global risk index ($I_r$) was computed for each method, based on the simulated behavior for an ensemble of hydrograph inflows. The $I_r$ values associated to the 2 h-forecast BNet model are lower than those obtained for VEM, which suggests improvement over standard practice. In conclusion, the BNet arises as a suitable and efficient model to support dam operators for the decision making process during flood events. Full article

During the flood discharge in large-scale hydraulic engineering projects, intense flow-induced vibrations may occur in hydraulic gates, gate piers, spillway guide walls, etc. Furthermore, the vibration mechanism is complicated. For the spillway guide wall, existing studies on the vibration mechanism usually focus on the vibrations caused by flow excitations, without considering the influence of dam vibration. According to prototype tests, the vibrations of the spillway guide wall and the dam show synchronization. Thus, this paper presents a new vibration mechanism of associated-forced coupled vibration (AFCV) for the spillway guide wall to investigate the dynamic responses and reveal coupled vibrational properties and vibrational correlations. Different from conventional flow-induced vibration theory, this paper considers the spillway guide wall as a lightweight accessory structure connected to a large-scale primary structure. A corresponding simplified theoretical model for the AFCV system is established, with theoretical derivations given. Then, several vibrational signals measured in different structures in prototype tests are handled by the cross-wavelet transform (XWS) to reveal the vibrational correlation between the spillway guide wall and the dam. Afterwards, mutual analyses of numeral simulation, theoretical derivation, and prototype data are employed to clarify the vibration mechanism of a spillway guide wall. The proposed mechanism can give more reasonable and accurate results regarding the dynamic response and amplitude coefficient of the guide wall. Moreover, by changing the parameters in the theoretical model through practical measures, the proposed vibration mechanism can provide benefits to vibration control and structural design. Full article

In this paper, we present a method to assess the influence of the initial reservoir level in hydrological dam safety and risk analysis. Traditionally, in professional practice, the procedures applied are basically deterministic. Several physical processes are defined deterministically, according to the criteria of the designer (usually in the conservative side), although there is a high degree of uncertainty regarding these processes. A relevant variable is the reservoir level considered at the beginning of flood events. Hydrological dam safety assessment methods traditionally assume that the reservoir is initially full when it receives the design flood, thus, staying in the conservative side when designing a new dam. However, the distribution of reservoir levels at the beginning of flood episodes takes more importance for evaluating the real risk for the dams in operation. We analyzed three different scenarios—initial reservoir level equal to maximum normal level, equal to a maximum conservation level, and following the probability distribution from the historical records. To do so, we presented a method applied to a gated-spillway dam located in the Tagus river basin. A set of 100,000 inflow hydrographs was generated through a Monte Carlo procedure, by reproducing the statistics of the main observed hydrograph characteristics—peak flow, volume, and duration. The set of 100,000 hydrographs was routed through the reservoir applying the Volumetric Evaluation Method as a flood control strategy. In order to compare the three scenarios, we applied an economic global risk index. The index combines the hydrological risk for the dam, linked to the maximum water level reached in the reservoir, during the flood routing, and the flood risk in the downstream river reach, linked to the discharge releases from the dam. The results showed the importance of accounting for the fluctuation of initial reservoir levels, for assessing the risk related to hydrological dam safety. Furthermore, a procedure to quantify the uncertainty associated with the effects of initial reservoir level on hydrological dam safety, has been proposed. Full article

Hydrological dam safety assessment methods traditionally assume that the reservoir is full while it receives the design flood. In practice, reservoir management strategy determines the probability distribution of reservoir levels at the beginning of flood episodes. In this study, we present a method to economically assess the influence of reservoir management strategy on hydrological dam safety and downstream flood risk. The method was applied to a gated spillway dam located in the Tagus River basin. A set of 100,000 inflow hydrographs was generated through a Monte Carlo procedure, reproducing the observed statistics of main hydrograph characteristics: peak flow, volume, and duration. The set of 100,000 hydrographs was routed through the reservoir applying the volumetric evaluation method as a flood control strategy. Three different scenarios were studied: Initial reservoir level equal to maximum normal level, equal to a maximum conservation level, and following the probability distribution of initial reservoir levels. In order to evaluate economically the influence of initial variable reservoir level and compare the three scenarios, a global risk index was applied. The index combines the hydrological risk for the dam, linked to the maximum water level experienced in the reservoir while the flood is routed, and the flood risk in the downstream river reach, linked to the discharge releases from the dam. The results highlighted the importance of considering the fluctuation of initial reservoir level for assessing the risk related to hydrological dam safety. Full article

The study presents a method which can be used to define real-time operation rules for gated spillways (named the K-Method). The K-Method is defined to improve the performance of the Volumetric Evaluation Method (VEM), by adapting it to the particular conditions of the basin, the reservoir, or the spillway. The VEM was proposed by the Spanish engineer Fernando Girón in 1988 and is largely used for the specification of dam management rules during floods in Spain. This method states that outflows are lower than or equal to antecedent inflows, outflows increase when inflows increase, and the higher the reservoir level, the higher the percentage of outflow increase. The K-Method was developed by modifying the VEM and by including a K parameter which affects the released flows. A Monte Carlo environment was developed to evaluate the method under a wide range of inflow conditions (100,000 hydrographs) and with return periods ranging from one to 10,000 years. The methodology was applied to the Talave reservoir, located in the South-East of Spain. The results show that K-values higher than one always reduce the maximum reservoir levels reached in the dam. For K-values ranging from one to ten, and for inflow hydrographs with return periods higher than 100 years, we found a decrease in the maximum levels and outflows, when compared to the VEM. Finally, by carrying out a dam risk analysis, a K-value of 5.25 reduced the expected annual damage by 8.4% compared to the VEM, which represents a lowering of 17.3% of the maximum possible reduction, determined by the application of an optimizer based on mixed integer linear programming (MILP method). Full article

Large-scale water resources systems are often managed by an integrated set of hydraulic structures that are vulnerable to wider ranges of discharge and tailwater elevation than envisioned in their original design due to climate change and additional project objectives such as fostering healthy ecosystems. The present physical model study explored the performance of a spillway structure on the Kissimmee River, operated by the South Florida Water Management District, under extreme conditions of drought and flooding with accompanying low and high tailwater levels for both gate-controlled and uncontrolled spillway flow conditions. Maximum scour depths and their locations for two different riprap apron lengths downstream of the spillway stilling basin were measured along with the complex flow fields prior to scour. Effects of tailwater submergence, type of spillway flow and riprap apron length on scour results are interpreted in terms of the measured turbulent kinetic energy and velocity distributions near the bed. Full article
