Ambient monitoring in chemical laboratories and industrial sites that use toxic, hazardous, or flammable materials is essential to protect the lives of workers, material resources, and infrastructure at these sites. In this research paper, we present an innovative approach for developing a low-cost and portable sensor node that detects and warns of hazardous chemical gas and vapor leaks. The system also enables leak location tracking using an indoor tracking and positioning system operating in ultra-wideband (UWB) technology. An array of sensors is used to detect gases, vapors, and airborne particles, while the leak location is identified through a UWB unit integrated with an Internet of Things (IoT) processor. This processor transmits real-time location data and sensor readings via wireless fidelity (Wi-Fi). The real-time indoor positioning system (IPS) can automatically select a tracking area based on the distances measured from the three nearest anchors of the movable sensor node. The environmental sensor data and distances between the node and the anchors are transmitted to the cloud in JSON format via the user datagram protocol (UDP), which allows the fastest possible data rate. A monitoring server was developed in Python to track the movement of the portable sensor node and display live measurements of the environment. The system was tested by selecting different paths between several adjacent areas with a chemical leakage of different volatile organic compounds (VOCs) in the test path. The experimental tests demonstrated good accuracy in both hazardous gas detection and location tracking. The system successfully issued a leak warning for all tested material samples with volumes up to 500 microliters and achieved a positional accuracy of approximately 50 cm under conditions without major obstacles obstructing the UWB signal between the active system units. Full article

As the attention to using hydrogen as a potential energy storage medium for power generation and mobility increases, hydrogen production, storage, and transportation safety should be considered. For instance, hydrogen’s extreme physical and chemical properties and the wide range of flammable concentrations raise many concerns about the current safety measures in processing other flammable gases. Hydrogen cloud accumulation in the case of leakage in confined spaces can lead to reaching the hydrogen lower flammability limit (LFL) within seconds if the hydrogen is not properly evacuated from the space. At Jülich Research Centre, hydrogen mixed with natural gas is foreseen to be used as a fuel for the central heating system of the campus. In this work, the release, dispersion, formation, and spread of the hydrogen cloud in the case of hydrogen leakage inside the central utility building of the campus are numerically simulated using the OpenFOAM-based containmentFOAM CFD codes. Additionally, different ventilation scenarios are simulated to investigate the behavior of the hydrogen cloud. The results show that locating exhaust openings close to the ceiling and the potential leakage source can be the most effective way to safely evacuate hydrogen from the building. Additionally, locating the exhaust outlets near the ceiling can decrease the combustible cloud volume by more than 25% compared to side openings far below the ceiling. Also, hydrogen concentrations can reach the LFL in case of improper forced ventilation after only 8 s, while it does not exceed 0.15% in the case of natural ventilation under certain conditions. The results of this work show the significant effect of locating exhaust outlets near the ceiling and the importance of natural ventilation to mitigate the effects of hydrogen leakage. The approach illustrated in this study can be used to study hydrogen dispersion in closed buildings in case of leakage and the proper design of the ventilation outlets for closed spaces with hydrogen systems. Full article

Hydrogen is considered the next energy to replace fossil fuels, but it must be handled with care given that it is a flammable gas. A barrier wall is an effective way to mitigate the effect of an explosion, and to build a safe barrier wall, research on hydrogen explosions is necessary. Experiments and CFD (computational fluid dynamics) are two commonly used methods, but both are costly to use under any condition. Machine learning can be used to enhance the data from experiments and CFD as the trained model can predict explosion pressure levels very rapidly under various conditions. We propose the prediction of a hydrogen VCE (vapor cloud explosion) with a barrier wall using various machine learning methods. This research uses CFD simulation data from KAERI (Korea Atomic Energy Research Institute) as training data. MLP (multi-layer perceptron), LSTM (long short-term memory), and the Transformer architectures are used to train the hydrogen VCE and are compared. In our research, MLP produces the best score among all learning processes, with an R² value exceeding 0.97, outperforming both LSTM and Transformer in terms of accuracy and speed. The trained machine learning model can be used to build safe barrier walls in hydrogen refueling stations. Evaluating the safe distance from the barrier wall and evaluating the optimal position of the barrier wall are possible usages. Full article

The investigation of hydrogen leakage and diffusion behavior is of great importance for the assessment of safety risks and the establishment of safety regulations for hydrogen refueling stations. However, the uncertainty associated with the location of hydrogen leaks and the complex environment pose challenges in understanding the diffusion characteristics of hydrogen leaks. In this research, a numerical analysis is performed to study the diffusion of hydrogen leaks in both horizontal and vertical directions under three different environments, considering two different sizes of leak holes. The results show that horizontal and vertical hydrogen leaks have different effects on the hydrogen diffusion behavior. The presence of a canopy and obstacles inhibits hydrogen diffusion and dilution, which could be the cause of more severe accidents. Moreover, the size of the leak hole also impacts the scale of the flammable gas cloud. The effect of leaking direction to the canopy is also considered. In comparison with the semi-open space, the pressure on the canopy is higher in an enclosed space. Full article

Accidental leakage from oil–gas storage tanks can lead to the formation of liquid pools. These pools can result in vapor cloud explosions (VCEs) if combustible vapors encounter ignition energy. Conducting accurate and comprehensive consequence analyses of such explosions is crucial for quantitative risk assessments (QRAs) in industrial safety. In this study, a methodology based on the SLAB-TNO model to calculate the overpressure resulting from a VCE is presented. Based on this method, the consequences of the VCE accident considering the gas cloud concentration diffusion are studied. The probit model is employed to evaluate casualty probabilities under varying environmental and operational conditions. The effects of key parameters, including gas diffusion time, wind speed, lower flammability limit (LFL), and environment temperature, on casualty diffusion are systematically investigated. The results indicate that when the diffusion time is less than 100 s, the VCE consequences are significantly more severe due to the rapid spread of the gas cloud. Furthermore, increasing wind speed accelerates gas dispersion, reducing the spatial extent of casualty isopleths. The LFL is shown to have a direct impact on both the mass and diffusion of the flammable gas cloud, with higher LFL values shifting the explosion’s epicenter upward. The environmental temperature promotes gas diffusion in the core area and increases the mass of the combustible gas cloud. These findings provide critical insights for improving the safety protocols in oil and gas storage facilities and can serve as a valuable reference for consequence assessment and emergency response planning in similar industrial scenarios. Full article

Liquid hydrogen storage is an important way of hydrogen storage and transportation, which greatly improves the storage and transportation efficiency due to the high energy density but at the same time brings new safety hazards. In this study, the liquid hydrogen leakage in the storage area of a hydrogen production station is numerically simulated. The effects of ambient wind direction, wind speed, leakage mass flow rate, and the mass fraction of gas phase at the leakage port on the diffusion behavior of the liquid hydrogen leakage were investigated. The results show that the ambient wind direction directly determines the direction of liquid hydrogen leakage diffusion. The wind speed significantly affects the diffusion distance. When the wind speed is 6 m/s, the diffusion distance of the flammable hydrogen cloud reaches 40.08 m, which is 2.63 times that under windless conditions. The liquid hydrogen leakage mass flow rate and the mass fraction of the gas phase have a greater effect on the volume of the flammable hydrogen cloud. As the leakage mass flow rate increased from 5.15 kg/s to 10 kg/s, the flammable hydrogen cloud volume increased from 5734.31 m³ to 10,305.5 m³. The installation of a barrier wall in front of the leakage port can limit the horizontal diffusion of the flammable hydrogen cloud, elevate the diffusion height, and effectively reduce the volume of the flammable hydrogen cloud. This study can provide theoretical support for the construction and operation of hydrogen production stations. Full article

Accidental release from a hydrogen car tank in a confined space like a tunnel poses safety concerns. This Computational Fluid Dynamics (CFD) study focuses on the first seconds of such a release, which are the most critical. Hydrogen leaks through a Thermal Pressure Relief Device (TPRD), forms a high-speed jet that impinges on the street, spreads horizontally, recirculates under the chassis and fills the area below it in about one second. The “fresh-air entrainment effect” at the back of the car changes the concentrations under the chassis and results in the creation of two “tongues” of hydrogen at the rear corners of the car. Two other tongues are formed near the front sides of the vehicle. In general, after a few seconds, hydrogen starts moving upwards around the car mainly in the form of buoyant blister-like structures. The average hydrogen volume concentrations below the car have a maximum of 71%, which occurs at 2 s. The largest “equivalent stoichiometric flammable gas cloud size Q9” is 20.2 m³ at 2.7 s. Smaller TPRDs result in smaller hydrogen flow rates and smaller buoyant structures that are closer to the car. The investigation of the hydrogen dispersion during the initial stages of the leak and the identification of the physical phenomena that occur can be useful for the design of experiments, for the determination of the TPRD characteristics, for potential safety measures and for understanding the further distribution of the hydrogen cloud in the tunnel. Full article

As the applications of hydrogen as a replacement for fossil fuels and energy storage increase, more concerns have been raised regarding its safe usage. Hydrogen’s extreme physical properties—its lower flammability limit (LFL), for instance—represent a challenge to simulating hydrogen leakage and, hence, mitigating accidents that occur due to such leakage. In this work, the OpenFOAM-based CFD simulation package containmentFOAM was validated by different experimental results. As in its original use, to simulate nuclear safety issues, the containmentFOAM package is capable of capturing different phenomena, like buoyant gas clouds and diffusion between gases and air. Despite being widely validated in nuclear safety, this CFD package was assessed with benchmark experiments used to validate hydrogen leakage scenarios. The validation cases were selected to cover different phenomena that occur during the hydrogen leakage—high-speed jet leakage, for example. These validation cases were the hallway with vent, FLAME, and GAMELAN experiments. From the comparison of the experimental and simulation results, we concluded that the containmentFOAM package showed good consistency with the experimental results and, hence, that it can be used to simulate actual leakage cases. Full article

One of China’s ambitious hydrogen strategies over the past few years has been to promote fuel cells. A number of hydrogen refueling stations (HRSs) are currently being built in China to refuel hydrogen-powered automobiles. In this context, it is crucial to assess the dangers of hydrogen leaking in HRSs. The present work simulated the liquid hydrogen (LH2) leakage with the goal of undertaking an extensive consequence evaluation of the LH2 leakage on an LH2 refueling station (LHRS). Furthermore, the utilization of an air curtain to prevent the diffusion of the LH2 leakage is proposed and the defending effect is studied accordingly. The results reveal that the Richardson number effectively explained the variation of plume morphology. Furthermore, different facilities have great influence on the gas cloud diffusion trajectory with the consideration of different leakage directions. The air curtain shows satisfactory prevention of the diffusion of the hydrogen plume. Studies show that with the increase in air volume (equivalent to wind speed) and the narrowing of the air curtain width (other factors remain unchanged), the maximum flammable distance of hydrogen was shortened. Full article

The accidental release of toxic gases leads to fire, explosion, and acute toxicity, and may result in severe problems for people and the environment. The risk analysis of hazardous chemicals using consequence modelling is essential to improve the process reliability and safety of the liquefied petroleum gas (LPG) terminal. The previous researchers focused on single-mode failure for risk assessment. No study exists on LPG plant multimode risk analysis and threat zone prediction using machine learning. This study aims to evaluate the fire and explosion hazard potential of one of Asia’s biggest LPG terminals in India. Areal locations of hazardous atmospheres (ALOHA) software simulations are used to generate threat zones for the worst scenarios. The same dataset is used to develop the artificial neural network (ANN) prediction model. The threats of flammable vapour cloud, thermal radiations from fire, and overpressure blast waves are estimated in two different weather conditions. A total of 14 LPG leak scenarios involving a 19 kg capacity cylinder, 21 tons capacity tank truck, 600 tons capacity mounded bullet, and 1350 tons capacity Horton sphere in the terminal are considered. Amongst all scenarios, the catastrophic rupture of the Horton sphere of 1350 MT capacity presented the most significant risk to life safety. Thermal flux of 37.5 kW/ m² from flames will damage nearby structures and equipment and spread fire by the domino effect. A novel soft computing technique called a threat and risk analysis-based ANN model has been developed to predict threat zone distances for LPG leaks. Based on the significance of incidents in the LPG terminal, 160 attributes were collected for the ANN modelling. The developed ANN model predicted the threat zone distance with an accuracy of R² value being 0.9958, and MSE being 202.9061 in testing. These results are evident in the reliability of the proposed framework for safety distance prediction. The LPG plant authorities can adopt this model to assess the safety distance from the hazardous chemical explosion based on the prior forecasted atmosphere conditions from the weather department. Full article

Adopting proton exchange membrane fuel cells fuelled by hydrogen presents a promising solution for the shipping industry’s deep decarbonisation. However, the potential safety risks associated with hydrogen leakage pose a significant challenge to the development of hydrogen-powered ships. This study examines the safe design principles and leakage risks of the hydrogen gas supply system of China’s first newbuilt hydrogen-powered ship. This study utilises the computational fluid dynamics tool FLACS to analyse the hydrogen dispersion behaviour and concentration distributions in the hydrogen fuel cell room based on the ship’s parameters. This study predicts the flammable gas cloud and time points when gas monitoring points first reach the hydrogen volume concentrations of 0.8% and 1.6% in various leakage scenarios, including four different diameters (1, 3, 5, and 10 mm) and five different directions. This study’s findings indicate that smaller hydrogen pipeline diameters contribute to increased hydrogen safety. Specifically, in the hydrogen fuel cell room, a single-point leakage in a hydrogen pipeline with an inner diameter not exceeding 3 mm eliminates the possibility of flammable gas cloud explosions. Following a 10 mm leakage diameter, the hydrogen concentration in nearly all room positions reaches 4.0% within 6 s of leakage. While the leakage diameter does not impact the location of the monitoring point that first activates the hydrogen leak alarm and triggers an emergency hydrogen supply shutdown, the presence of obstructions near hydrogen detectors and the leakage direction can affect it. These insights provide guidance on the optimal locations for hydrogen detectors in the fuel cell room and the pipeline diameters on hydrogen gas supply systems, which can facilitate the safe design of hydrogen-powered ships. Full article

Contamination of toxic and odorous gases emitted from stacks in buildings located in an urban environment are potential health hazards to citizens. A simulation using the computational fluid dynamic technique may provide detailed data on the flammable region and spatial dispersion of released gases. Concentrations or emissions associated with garage sources and garage-to-house migration rates are needed to estimate potential exposures and risk levels. Therefore, the aim of the study was to use an original mathematical model to predict the most accurate locations for LPG sensors in an underground garage for vehicles powered with LPG. First, the three-dimensional geometry of an underground garage under a multi-family building was reconstructed. Next, two types of ventilation, jet and duct, were considered, and different sources of LPG leakage were assumed. Then, the Ansys Fluent software was applied as a solver, and the same initial value of released LPG (5 kg) was assumed. As a simplification, and to avoid the simulation of choked outflow, the emission from a large area was adopted. The results showed stagnation areas for duct ventilation in which gas remained for both the jet and duct ventilation. Moreover, it was observed that the analyzed gas would gather in the depressions of the ground in the underground garage, for example in drain grates, which may create a hazardous zone for the users of the facility. Additionally, it was observed that for jet ventilation, turbulence appearance sometimes generated differentiated gas in an undesirable direction. The simulation also showed that for blowing ventilation around the garage, and for higher LPG leakage, a higher cloud of gas that increased probability of ignition and LPG explosion was formed. Meanwhile, for jet ventilation, a very low concentration of LPG in the garage was noticed. After 35 s, LPG concentration was lower than the upper explosive limit. Therefore, during the LPG leakage in an underground garage, jet ventilation was more efficient in decreasing LPG gas to the non-explosive values. Full article

To investigate the evolution process of LNG (Liquefied Natural Gas) liquid pool and gas cloud diffusion, the Realizable k-ε model and Eluerian model were used to numerically simulate the liquid phase leakage and diffusion process of LNG storage tanks. The experimental results showed that some LNG flashed and vaporized rapidly to form a combustible cloud during the continuous leakage. The diffusion of the explosive cloud was divided into heavy gas accumulation, entrainment heat transfer, and light gas drift. The vapor cloud gradually separated into two parts from the whole “fan leaf shape”. One part was a heavy gas cloud; the other part was a light gas cloud that spread with the wind in the downwind direction. The change of leakage aperture had a greater impact on the whole spill and dispersion process of the storage tank. The increasing leakage aperture would lead to 10.3 times increase in liquid pool area, 78.5% increase in downwind dispersion of methane concentration at 0.5 LFL, 22.6% increase in crosswind dispersion of methane concentration at 0.5 LFL, and 249% increase in flammable vapor cloud volume. Within the variation range of the leakage aperture, the trend of the gas cloud diffusion remained consistent, but the time for the liquid pool to keep stable and the gas cloud to enter the next diffusion stage was delayed. The low-pressure cavity area within 200 m of the leeward surface of the storage tank would accumulate heavy gas for a long time, forming a local high concentration area, which should be an area of focus for alert prediction. Full article

Process safety helps prevent the unexpected and unplanned release of flammable and toxic chemicals, leading to poisonous gas clouds, fires, and explosions. Vapor cloud explosions (VCEs) are among the most severe hazards to humans and the environment in process facilities. Therefore, process safety demands to use best and reliable techniques to model VCEs in process industries and storage tanks of flammable chemicals. In this regard, the Computational Fluid Dynamics (CFD) models are more appropriate, as these models provide three-dimensional (3D) modeling of all sequences of events in an accident. In this study, CFD is used to model VCE in two industrial accidents: the Amuay refinery disaster (happened in 2012) and the Indian Oil Corporation’s (IOC) Jaipur terminal (2009). This work studies 3D CFD modeling of flammable cloud explosion in the real-time configuration for both accidents. FLACS (FLame ACceleration Simulator), a CFD software, is used to simulate the loss of hydrocarbon containment, cloud formation, and explosion in both industrial case studies. The ignition locations and grid sizes were varied to analyze their influence on explosion overpressure, temperature, vapor velocity, and fuel mass. This work also investigated the effect of geometry complexity on the explosion. Results showed that, as opposed to the coarse grid, the fine grid provides more precision in the analysis. The study also reveals an explosion overpressure of the order 4–15 bar (g) for the given case studies. This study’s results can help perform a qualitative and quantitative risk assessment of the Amuay refinery accident and Jaipur fire. The simulation of different scenarios can help develop and improve safety guidelines to mitigate similar accidents. Full article

Failure of a pipeline carrying gaseous hydrogen can have several effects, some of which can pose a significant threat of harm to people and damage to buildings in its immediate proximity. This paper presents a probabilistic risk assessment procedure for the estimation of damage to people and buildings endangered by high-pressure hydrogen pipeline explosions. Such a procedure provides an evaluation of annual probability of damage to people and buildings under an extreme event using a combination of the conditional probability of damage triggered by an explosion and the probability that the explosion occurs as a consequence of the pipeline failure. The release of hydrogen is simulated using the LimitState:SLAB model and the size of the hydrogen-air cloud in the flammability range is evaluated, then overpressure and impulse generated by the blast are evaluated through the Netherland Organization for Applied Scientific Research (TNO) model, while explosion effects on people and buildings are estimated through Probit equations and pressure–impulse diagrams. As for people, both direct and indirect effects of overpressure events are taken into account. For buildings, a comparison of the damage to different types of buildings (i.e., buildings made of reinforced concrete and buildings of tuff stone masonry) is also made. The probabilistic procedure presented may be used for designing a new hydrogen pipeline network and will be an advantageous tool for safe management of H₂ gas pipelines. Full article
