Search Results (18)

The locomotion of fish provides inspiration for designing efficient and agile underwater robots. Potamotrygon motoro propels itself by generating traveling waves along its pectoral fins. Inspired by its graceful swimming stroke, we design and fabricate a robotic fish, where the snap-through instability of elastic curved rods is exploited to produce the undulatory fin motion. In this design, the rotary input of two motors is transformed smoothly and continuously to controllable wave-like fin deformation. By changing the initial fin shape, motor speed, and friction at the releasing end, the propulsion performance and the maneuverability of the robotic fish can be significantly improved. The physical prototype of the robotic fish is fabricated, and its swimming performance is measured. Its maximum swimming speed reaches 0.76 BL/s, and it can achieve small-radius turns with a maximum angular speed of 1.25 rad/s. In contrast to the multi-actuator systems, the proposed dual-motor, elastic-snapping–driven design is featured by simple structural construction, low energy consumption, excellent maneuverability, and superb adaptation to environments. Our robotic fish holds promising applications in such areas as environmental monitoring, underwater inspection, and ocean exploration. The propulsion strategy presented in this work may pave a new way for the design of shape-morphing robots as well as other soft machines at multiple length scales. Full article

Multi-object tracking (MOT) is a critical task in computer vision, with widespread applications in intelligent surveillance, behavior analysis, autonomous navigation, and marine ecological monitoring. In particular, accurate tracking of underwater fish plays a significant role in scientific fishery management, biodiversity assessment, and behavioral analysis of marine species. However, MOT remains particularly challenging due to low visibility, frequent occlusions, and the highly non-linear, burst-like motion of fish. To address these challenges, this paper proposes an improved tracking framework that integrates Interacting Multiple Model Kalman Filtering (IMM-KF) into DeepSORT, forming a self-adaptive multi-object tracking algorithm tailored for underwater fish tracking. First, a lightweight YOLOv8n (You Only Look Once v8 nano) detector is employed for target localization, chosen for its balance between detection accuracy and real-time efficiency in resource-constrained underwater scenarios. The tracking stage incorporates two complementary motion models—Constant Velocity (CV) for regular cruising and Constant Acceleration (CA) for rapid burst swimming. The IMM mechanism dynamically evaluates the posterior probability of each model given the observations, adaptively selecting and fusing predictions to maintain both responsiveness and stability. The proposed method is evaluated on a real-world underwater fish dataset collected from the East China Sea, comprising 19 species of marine fish annotated in YOLO format. Experimental results show that the IMM-DeepSORT framework outperforms the original DeepSORT in terms of MOTA, MOTP, and IDF1. In particular, it significantly reduces false matches and improves tracking continuity, demonstrating the method’s effectiveness and reliability in complex underwater multi-target tracking scenarios. Full article

The rapid advancement of tactile electronic skin (E-skin) has highlighted the effectiveness of incorporating bionic, force-sensitive microstructures in order to enhance sensing performance. Among these, cilia-like microstructures with high aspect ratios, whose inspiration is mammalian hair and the lateral line system of fish, have attracted significant attention for their unique ability to enable E-skin to detect weak signals, even in extreme conditions. Herein, this review critically examines recent progress in the development of cilia-inspired bionic tactile E-skin, with a focus on columnar, conical and filiform microstructures, as well as their fabrication strategies, including template-based and template-free methods. The relationship between sensing performance and fabrication approaches is thoroughly analyzed, offering a framework for optimizing sensitivity and resilience. We also explore the applications of these systems across various fields, such as medical diagnostics, motion detection, human–machine interfaces, dexterous robotics, near-field communication, and perceptual decoupling systems. Finally, we provide insights into the pathways toward industrializing cilia-inspired bionic tactile E-skin, aiming to drive innovation and unlock the technology’s potential for future applications. Full article

Leader–follower modalities and other asymmetric interactions that drive the collective motion of organisms are often quantified using information theory metrics like transfer or causation entropy. These metrics are difficult to accurately evaluate without a much larger number of data than is typically available from a time series of animal trajectories collected in the field or from experiments. In this paper, we use a generalized leader–follower model to argue that the time-separated mutual information between two organism positions can serve as an alternative metric for capturing asymmetric correlations that is much less data intensive and more accurately estimated by popular k-nearest neighbor algorithms than transfer entropy. Our model predicts a local maximum of this mutual information at a time separation value corresponding to the fundamental reaction timescale of the follower organism. We confirm this prediction by analyzing time series trajectories recorded for a pair of golden shiner fish circling an annular tank. Full article

The specific arrangement and distribution of photoreceptors in the retina can vary among different fish species, with each species exhibiting adaptations related to its habitat, behavior, and visual requirements. Poecilia sphenops, a diurnal fish, was the focus of this study. The retinas of a total of eighteen Molly fish were investigated utilizing light and electron microscopy. The retina exhibited a square mosaic pattern of the inner segments of cones. This pattern comprised double cones positioned along the sides of a square, with two types of single cones situated at the center and corners of the square arrangement across the entire retina. The corner cones were slightly shorter than the central ones. Additionally, the outer plexiform layer contained both cone pedicles and rod spherules. The rod spherule consisted of a single synaptic ribbon arranged in a triad or quadrat junctional arrangement within the invaginating free ends of the horizontal and bipolar cell processes. On the other hand, cone pedicles have more than one synaptic ribbon in their junctional complex. The inner nuclear layer consisted of the amacrine, bipolar, Müller, and horizontal cell bodies. Müller cell processes, expressing GFAP, extended across all retinal layers, segmenting the deeper retina into alternating fascicles of optic axons and ganglion cells. The outer and inner plexiform layers showed many astrocyte cell processes expressing GFAP. In conclusion, the current study is the first record of the retinal structures of Molly fish. This study illustrated the mosaic arrangement of photoreceptors and GFAP expression patterns of astrocytes and Müller cells. The presence of three cone types, coupled with a sufficient number of rods, likely facilitates motion awareness for tasks like finding food and performing elaborate mating ceremonies. Full article

Research into how fish and other aquatic organisms propel themselves offers valuable natural references for enhancing technology related to underwater devices like vehicles, propellers, and biomimetic robotics. Additionally, such research provides insights into fish evolution and ecological dynamics. This work carried out a numerical investigation of the most relevant dimensionless parameters in a fish swimming environment (Reynolds $Re$, Strouhal $St$, and $Slip$ numbers) to provide valuable knowledge in terms of biomechanics behavior. Thus, a three-dimensional numerical study of the fish-like lambari, a BCF swimmer with carangiform kinematics, was conducted using the URANS approach with the k-$\omega$-SST transition turbulence closure model in the OpenFOAM software. In this study, we initially reported the equilibrium Strouhal number, which is represented by $S{t}^{\ast }$, and its dependence on the Reynolds number, denoted as $Re$. This was performed following a power–law relationship of $St\propto R{e}^{(-\alpha )}$. We also conducted a comprehensive analysis of the hydrodynamic forces and the effect of body undulation in fish on the production of swimming drag and thrust. Additionally, we computed propulsive and quasi-propulsive efficiencies, as well as examined the influence of the Reynolds number and $Slip$ number on fish performance. Finally, we performed a vortex dynamics analysis, in which different wake configurations were revealed under variations of the dimensionless parameters $St$, $Re$, and $Slip$. Furthermore, we explored the relationship between the generation of a leading-edge vortex via the caudal fin and the peak thrust production within the motion cycle. Full article

Biological fish exhibit remarkable adaptability and exceptional swimming performance through their powerful and flexible bodies. Therefore, designing a continuum flexible body is significantly important for the development of a robotic fish. However, it is still challenging to replicate these functions of a biological body due to the limitations of actuation and material. In this paper, based on a tensegrity structure, we propose a bionic design scheme for a continuum robotic fish body with a property of stiffness variation. Its detailed structures and actuation principles are also presented. A mathematical model was established to analyze the bending characteristics of the tensegrity structure, which demonstrates the feasibility of mimicking the fish-like oscillation propulsion. Additionally, the stiffness variation mechanism is also exhibited experimentally to validate the effectiveness of the designed tensegrity fish body. Finally, a novel bionic robotic fish design scheme is proposed, integrating an electronic module-equipped fish head, a tensegrity body, and a flexible tail with a caudal fin. Subsequently, a prototype was developed. Extensive experiments were conducted to explore how control parameters and stiffness variation influence swimming velocity and turning performance. The obtained results reveal that the oscillation amplitude, frequency, and stiffness variation of the tensegrity robotic fish play crucial roles in swimming motions. With the stiffness variation, the developed tensegrity robotic fish achieves a maximum swimming velocity of 295 mm/s (0.84 body length per second, BL/s). Moreover, the bionic tensegrity robotic fish also performs a steering motion with a minimum turning radius of 230 mm (0.68 BL) and an angular velocity of 46.6°/s. The conducted studies will shed light on the novel design of a continuum robotic fish equipped with stiffness variation mechanisms. Full article

The recoil motions in free swimming, given by lateral and angular rigid motions due to the interaction with the surrounding water, are of great importance for a correct evaluation of both the forward locomotion speed and efficiency of a fish-like body. Their contribution is essential for calculating the actual movements of the body rear end whose prominent influence on the generation of the proper body deformation was established a long time ago. In particular, the recoil motions are found here to promote a dramatic improvement of the performance when damaged fishes, namely for a partial functionality of the tail or even for its complete loss, are considered. In fact, the body deformation, which turns out to become oscillating and symmetric in the extreme case, is shown to recover in the water frame a kind of undulation leading to a certain locomotion speed though at the expense of a large energy consumption. There has been a deep interest in the subject since the infancy of swimming studies, and a revival has recently arisen for biomimetic applications to robotic fish-like bodies. We intend here to apply a theoretical impulse model to the oscillating fish in free swimming as a suitable test case to strengthen our belief in the beneficial effects of the recoil motions. At the same time, we intend to exploit the linearity of the model to detect from the numerical simulations the intrinsic physical reasons related to added mass and vorticity release behind the experimental observations. Full article

Locomotion control of synergistical interaction between fins has been one of the key problems in the field of robotic fish research owing to its contribution to improving and enhancing swimming performance. In this paper, the coordinated locomotion control of the boxfish-like robot with pectoral and caudal fins is studied, and the effects of different control parameters on the propulsion performance are quantitatively analyzed by using hydrodynamic experiments. First, an untethered boxfish-like robot with two pectoral fins and one caudal fin was designed. Second, a central pattern generator (CPG)-based controller is used to coordinate the motions of the pectoral and caudal fins to realize the bionic locomotion of the boxfish-like robot. Finally, extensive hydrodynamic experiments are conducted to explore the effects of different CPG parameters on the propulsion performance under the synergistic interaction of pectoral and caudal fins. Results show that the amplitude and frequency significantly affect the propulsion performance, and the propulsion ability is the best when the frequency is 1 Hz. Different phase lags and offset angles between twisting and flapping of the pectoral fin can generate positive and reverse forces, which realize the forward, backward, and pitching swimming by adjusting these parameters. This paper reveals for the first time the effects of different CPG parameters on the propulsion performance in the case of the synergistic interaction between the pectoral fins and the caudal fin using hydrodynamic experimental methods, which sheds light on the optimization of the design and control parameters of the robotic fish. Full article

Fish of any variety are nowadays being kept captive for several purposes, from recreational to alimentary to research. It is possible that we humans often underestimate or misunderstand the basic, natural needs of the species we use for our purposes. Sociality is likely to play an extensive and fundamental role in the quality of life of animals such as zebrafish. This study aimed to develop a dummy conspecific that included depth and motion illusions in order to assess whether these stimuli could represent a valid alternative to a conspecific in triggering shoaling behaviour in a well-known model in genetics and neuroscience, the zebrafish (Dario rerio). We thus replaced the natural livery of a zebrafish shape with three visual illusions: the Ouchi–Spillmann illusion, which generates an effect of local tilting motion; and another two which should create pictorial cues of tridimensionality. Via a binary shoal choice test, we assessed the time spent close to each of the three artificial dummies compared to neutral control stimuli such as grey ellipses. We found no preference for the illusory patterns, suggesting that the illusion was not perceived or, alternatively, that the perception of the illusion was not enough to elicit recognition of the dummy as conspecific and subsequent social behaviours. Full article

In oviparous marine fishes, the hyperosmotic induction of sperm motility in seawater (SW) is well established, however, the potential function of ion channels in the maintenance of post activated spermatozoon swimming performance remains largely unknown. Here, we investigated the influence of ion channels on the spermatozoon swimming parameters using the gilthead seabream (Sparus aurata) as a model for modern marine teleosts. Our data show that the SW-induced activation of seabream sperm motility requires three concomitant processes, the hyperosmotic shock, an ion-flux independent increase of the intracellular concentration of Ca²⁺ ([Ca²⁺]_i), but not of [K⁺]_i or [Na⁺]_i, and the alkalization of the cytosol. The combination of all three processes is obligatory to trigger flagellar beating. However, the time-course monitoring of sperm motion kinetics and changes in the [Ca²⁺]_i, [K⁺]_i and [Na⁺]_i in SW or in non-ionic activation media, showed that the post activated maintenance of spermatozoa motility is dependent on extracellular Ca²⁺ and K⁺. A meta-analysis of a seabream sperm transcriptome uncovered the expression of multiple ion channels, some of which were immunolocalized in the head and/or tail of the spermatozoon. Selective pharmacological inhibition of these ion channel families impaired the long-term motility, progressivity, and velocity of SW-activated spermatozoa. The data further revealed that some antagonists of K⁺-selective or Ca²⁺-selective channels, as well as of stretch-activated and mechanosensitive channels, altered the trajectory of spermatozoa, suggesting that these ion channels are likely involved in the control of the swimming pattern of the post activated spermatozoon. These combined findings provide new insight into the signaling pathways regulating spermatozoon activation and swimming performance in marine fishes. Full article

This work presents a numerical study of the collective motion of two freely-swimming swimmers by a hybrid method of the deep reinforcement learning method (DRL) and the immersed boundary-lattice Boltzmann method (IB-LBM). An active control policy is developed by training a fish-like swimmer to swim at an average speed of 0.4 $L/T$ and an average orientation angle of 0${}^{\circ }$. After training, the swimmer is able to restore the desired swimming speed and orientation from moderate external perturbation. Then the control policy is adopted by two identical swimmers in the collective swimming. Stable side-by-side, in-line and staggered formations are achieved according to the initial positions. The stable side-by-side swimming area of the follower is concentrated to a small area left or right to the leader with an average distance of 1.35 L. The stable in-line area is concentrated to a small area about 0.25 L behind the leader. A detailed analysis shows that both the active control and passive self-organization play an important role in the emergence of the stable schooling formations, while the active control works for maintaining the speed and orientation in case the swimmers collide or depart from each other and the passive self-organization works for emerging a stable schooling configuration. The result supports the Lighthill conjecture and also highlights the importance of the active control. Full article

Several bio-inspired underwater robots have been demonstrated in the last few years that can horizontally swim using different smart actuators. However, very few works have been presented on robots which can swim vertically, have a payload and resemble a jellyfish-like creature. In this work, we present the design, fabrication, and performance characterization of a new tethered robotic jellyfish, which is based on inflatable soft pneumatic composite (SPC) actuators. These soft actuators use compressed air to expand and contract, which help the robot to swim vertically in water. The soft actuators consist of elastomeric air chambers and very thin steel springs, which contribute to gaining faster motion of the biomimetic robot. A prototype of 220 mm in diameter and consisting of eight actuating units was fabricated and tested underwater in a fish tank. It reached a height of 400 mm within 2.5 s while carrying a dead weight of 100 g when tested at 70 psi (483 kPa) pressure. This high performance (160 mm/s on average speed) suggests that faster motion with a payload can be achieved by using SPC actuators. The inflatable structures help to flap the bell segments as well as in buoyancy effect for rapid vertical motion. The major achievement of this work is the ability to demonstrate a novel use of inflatable structures and biomimetic flapping wings for fast motion in water. The experimental and deduced data from this work can be used for the design of future small unmanned underwater vehicles (UUVs). This work adds a new robot to the design space of biomimetic jellyfish-like soft robots. Such kind of vehicle design might also be useful for transporting objects underwater effectively. Full article

This paper presents mechatronic design and manufacturing of a biomimetic Carangiform-type autonomous robotic fish prototype (i-RoF) with two-link propulsive tail mechanism. For the design procedure, a multi-link biomimetic approach, which uses the physical characteristics of a real carp fish as its size and structure, is adapted. Appropriate body rate is determined according to swimming modes and tail oscillations of the carp. The prototype is composed of three main parts: an anterior rigid body, two-link propulsive tail mechanism, and flexible caudal fin. Prototype parts are produced with 3D-printing technology. In order to mimic fish-like robust swimming gaits, a biomimetic locomotion control structure based on Central Pattern Generator (CPG) is proposed. The designed unidirectional chained CPG network is inspired by the neural spinal cord of Lamprey, and it generates stable rhythmic oscillatory patterns. Also, a Center of Gravity (CoG) control mechanism is designed and located in the anterior rigid body to ensure three-dimensional swimming ability. With the help of this design, the characteristics of the robotic fish are performed with forward, turning, up-down and autonomous swimming motions in the experimental pool. Maximum forward speed of the robotic fish can reach 0.8516 BLs^-1 and excellent three-dimensional swimming performance is obtained. Full article

This work focuses on developing a complete non-linear dynamic model comprising entirely kinematic and hydrodynamic effects of Carangiform locomotion based on the Lagrange approach by adapting the parameters and behaviors of a real carp. In order to imitate biological features, swimming patterns of a real carp for forward, turning and up-down motions are analyzed by using the Kineova 8.20 software. The proportional optimum link lengths according to actual size, swimming speed, flapping frequency, proportional physical parameters and different swimming motions of the real carp are investigated with the designed robotic fish model. Three-dimensional (3D) locomotion is evaluated by tracking two trajectories in a MATLAB environment. A Reaching Law Control (RLC) approach for inner loop (Euler angles-speed control) and a guidance system for the outer loop (orientation control) are proposed to provide an effective closed-loop control performance. In order to illustrate the 3D performance of the proposed closed loop control system in a virtual reality platform, the designed robotic fish model is also implemented using the Virtual Reality Modeling Language (VRML). Simulation and experimental analysis show that the proposed model gives us significant key solutions to design a fish-like robotic prototype. Full article
