Search Results (26)

Effective monitoring of fish passage through river barriers is essential for evaluating fishway performance and supporting adaptive river management. Traditional methods are often invasive, labor-intensive, or too costly to enable widespread implementation across most fishways. Infrared (IR) beam-break counters offer a promising alternative, but their adoption has been limited by high costs and a lack of flexibility. We developed and tested a novel, low-cost infrared beam-break counter—FishTracker—based on open-source Raspberry Pi and Arduino platforms. The system detects fish passages by analyzing interruptions in an IR curtain and reconstructing fish silhouettes to estimate movement, direction, speed, and morphometrics under a wide range of turbidity conditions. It also offers remote access capabilities for easy management. Field validation involved controlled tests with dummy fish, experiments with small-bodied live specimens (bleak) under varying turbidity conditions, and verification against synchronized video of free-swimming fish (koi carp). This first version of FishTracker achieved detection rates of 95–100% under controlled conditions and approximately 70% in semi-natural conditions, comparable to commercial counters. Most errors were due to surface distortion caused by partial submersion during the experimental setup, which could be avoided by fully submerging the device. Body length estimation based on passage speed and beam-interruption duration proved consistent, aligning with published allometric models for carps. FishTracker offers a promising and affordable solution for non-invasive fish monitoring in multispecies contexts. Its design, based primarily on open technology, allows for flexible adaptation and broad deployment, particularly in locations where commercial technologies are economically unfeasible. Full article

Vertical slot fishways (VSFs) are crossing devices that are built on rivers or streams. They were initially designed to help salmons to complete their migratory cycle by crossing permanent obstructions. In order to favor the passage of smaller or benthic species, stones or concrete cylinders, called macro-roughnesses, are often inserted at the bottom of the fishway. To study the effects of macro-roughnesses on the flow inside a VSF, three-dimensional unsteady simulations were carried out using the volume of fluid method to model the free surface. In this paper, kinematic quantities obtained by CFD are used to detail the flow inside a VSF with and without macro-roughnesses. It can provide valuable information about the flow characteristics, especially in areas where the experimental measurements are difficult to implement. Full article

To help fish to bypass dams and other human-made barriers, some fishways have ingeniously incorporated extended tunnel sections. This innovative design not only optimizes the overall structure of the fishway but also significantly reduces disturbances to the surrounding ecosystem. However, the potential challenges posed by long tunnel sections to fish upstream migration remain insufficiently studied and poorly understood. This study conducted in situ experiments utilizing a passive-integrated-transponder (PIT) system to quantitatively assess the effects of dark and natural light environments on the upstream migration behavior of plateau-endemic fishes (Schizothorax macropogon, Schizothorax waltoni, and Schizothorax oconnori) in a vertical-slot fishway. A 655 m section of the fishway was selected for the experiment, with shading cloth used to simulate the dark environment (DE) of tunnel sections, and its removal serving as the natural light environment (NE). The results showed that in the DE, the upstream behaviors of S. macropogon, S. waltoni, and S. oconnori were not hindered. The entry efficiency at the experimental segment (Ee) of all three species exceeded 65% in the DE, which was higher than that in the NE. The passage efficiency (Ep) of S. macropogon and S. waltoni showed no significant difference between the DE and NE, whereas S. oconnori exhibited a significant difference, with an overall Ep of 0% in the NE and 75.0% in the DE. Additionally, the DE caused a temporary disruption to the diel migration rhythms of the three species. The transit speeds (St) of S. macropogon and S. waltoni were both elevated in the DE, with S. waltoni showing a particularly significant increase; its average St in the DE (0.080 m/s) was much higher than in the NE (0.021 m/s). Ridge regression analysis further indicated that the DE was the primary factor influencing the St and had a positive effect on upstream behavior. Moreover, differences in the upstream migration performances of different species under varying light conditions highlighted species-specific sensitivity to light. This study offers key insights for fish passage design in canyon hydropower projects and highlights the potential of tunnel-type fishways in restoring river connectivity. Full article

Fishways are an important solution for mitigating the ecological impacts of river barriers, with their hydrodynamics playing a key role in their effectiveness. Computational fluid dynamics (CFD) is now one of the main tools to predict and characterize flow hydrodynamics, but choosing the most suitable turbulence model is considered one of its main challenges. Although substantial research has been carried out on vertical slot fishways, where the flow is predominantly two-dimensional, studies on pool-type fishways with bottom orifices remain scarce. In this study, three Reynolds averaged Navier–Stokes (RANS) turbulence models (the standard k-ε model, the renormalized group k-ε (RNG) model, and the standard k-ω model) and the large-eddy simulation (LES) model performances were compared to simulating the flow in a pool-type fishway with bottom orifices. ADV and PIV experimental data were used to assess model performance. While all the turbulence models accurately predicted the discharges and flow depths, the LES model outperformed the others in reproducing flow patterns, velocities, and turbulent kinetic energy. The RNG model also showed reasonable agreement with the experimental data. By contrast, the k-ε model delivered the poorest performance, failing to accurately predict the sizes of the recirculation zones and the locations of the recirculation axis and presenting the weakest agreement with the experimental observations. The value of the LES model in studying and characterizing fishway hydrodynamics, particularly concerning turbulence parameters, is highlighted. Full article

Innovating seal structures and optimizing size parameters are effective ways to enhance the leakage characteristics of labyrinth seals (LSs). Inspired by the ecological fishways with high flow resistance on dam sides, a novel bio-inspired staggered labyrinth seal is proposed. The leakage characteristics of both the curved-edged bio-inspired labyrinth seal (CELS) and the straight-edged bio-inspired labyrinth seal (SELS) at different tooth-incline angles are studied numerically and experimentally. The influence of key geometrical parameters on the leakage characteristics and flow field parameters of the CELSs are investigated, and the leakage control mechanism of bio-inspired LSs is revealed via analyzing flow field parameter distribution. The results indicate that, compared to conventional double-sided staggered straight-tooth labyrinth seals, the leakage rate reduction in CELSs is up to 30% when the incline angle is equal to 25°, outperforming that of the SELS in leakage control. This improvement is mainly attributed to the flow path bending and jet contraction effects at the tooth-tip entrance, along with the thermodynamic effects of the high-turbulence dissipation zone adjacent to the tooth top. The optimum leakage characteristics can be achieved when seal clearance h < 0.5 mm, aspect ratio δ < 0.6, and tooth thickness t < 1.5 mm. This work provides new insights into the structural design of high-resistance and low-leakage labyrinth seals. Full article

This study investigates the behavior of chubs (Squalius cephalus) of mid-body length (9.7–15.6 cm) with respect to turbulent flow conditions in a pool representing an experimental vertical slot fishway. Velocity and turbulence were characterized using PIV data. The influence of turbulent flow on fish behavior was assessed through the number of successful fish passage attempts, the associated passage times, and the spatial distribution of fish in the pool. Turbulence conditions were modified by the addition of one or three vertical rigid cylinders inside the pool. The results show that these adaptations may facilitate the passage of chubs. Results provide valuable insights and information to understand the relationship between fish behavior and hydraulic conditions, especially in the context of improving the design of fishways. Full article

Throughout the world, emerging barriers in river systems block longitudinal connectivity for migrating fish, causing significant impacts by precluding them from carrying out vital life cycle activities. Fishways are still the main mitigation solution implemented, where barrier removal is not feasible. Within the multiple technical fish passage devices, the vertical slot fishway (VSF) is considered the most reliable. Early design guidelines, established for cyprinids, indicate that the volumetric dissipation power (P_v) in the pools should be P_v < 150 Wm⁻³, while most frequent slope values range from 10 to 12%. In this study, an experimental approach was conducted to question and debate the validity of these recommendations. For this, the Iberian barbel (Luciobarbus bocagei, Steindachner, 1864) passage performance was assessed in a full-scale fishway that exceeded P_v design guidelines, under different configurations. These varied in discharge (Q) and mean pool water depth (h_m): VSF1 (Q = 81 Ls⁻¹; h_m = 0.55 m); VSF2 (Q = 110 Ls⁻¹; h_m = 0.80 m); and the same design was equipped with a deep notch: DN1 (Q = 71 Ls⁻¹; h_m = 0.55 m); DN2 (Q = 99 Ls⁻¹; h_m = 0.80 m). The slope was set to 15.2% while the head drop per pool was Δh = 0.28 m, which generated a P_v that ranged from 222 in VSF1 to 187 Wm⁻³ in DN2. Passage behaviour was assessed using PIT telemetry and time-to-event analysis to evaluate the barbel upstream passage using standardized metrics: (i) motivation (ii) ascend success, and (iii) transit time. The hydrodynamic scenarios experienced by fish were characterized through a numerical model using computational fluid dynamics (CFD). The results, contrary to what was expected, showed a higher performance in VSF1 confirmed by the ascent analysis and transit time. Although no differences were found in fish motivation, the results indicate that larger fish displayed lower times to perform the first passage attempt. The CFD results show that, although maximum velocities and turbulence (turbulent kinetic energy (TKE) and Reynolds shear stress (RSS)) do not change significantly between configurations, their distribution in the pools is quite different. Regarding TKE, larger volumes with magnitudes higher than 0.05 m²s⁻² were notorious in both DN1 and DN2 configurations compared to VSF1, influencing passage efficiency which is in line with the ascent and transit time metrics results. Overall, the present research undeniably debates the literature design guidelines and reinforces the need to jointly assess species-specific fish passage criteria and fishway hydrodynamics, whereas precaution should be taken when using very general recommendations. Full article

Agricultural drainage canals that connect upstream fish spawning areas to downstream rivers and lakes serve as crucial habitats for migrating fish. However, disconnections, such as drops and chutes, have been constructed in these canals due to agricultural modernization and flood control measures, hindering the movement of fish that find it difficult to ascend in fast-flowing currents. Portable fishways offer a promising solution to reconnect waterbodies in agricultural canals, as they can be easily removed during high water discharges to avoid impeding the canals’ drainage function. In addition to experimental assessments of fishway functionality, employing a hydrodynamic model to explore effective placement strategies for portable fishways is essential to maximize their effectiveness. This study presents a method for determining the best horizontal location of a portable fishway in an agricultural drainage canal using two-dimensional hydrodynamic simulations within the specified cases. The applicability of this method is demonstrated by addressing the positioning challenge of a portable fishway on a chute in an agricultural drainage canal in Japan. The results indicate that the proposed method allows for the selection of a suitable location, considering preferable hydraulic conditions both within the portable fishway and around its entrance. Full article

River artificial fragmentation is arguably the most imperilling threat for freshwater-dependent fish species. Fish need to be able to freely move along river networks as not only spawning grounds but also refuge and feeding areas may be spatially and temporally separated. This incapacity of free displacement may result in genetic depletion of some populations, density reduction and even community changes, which may in turn affect how meta-community balances are regulated, potentially resulting in functional resilience reduction and ecosystem processes’ malfunction. Fishways are the most common and widely used method to improve connectivity for fish species. These structures allow fish to negotiate full barriers, thus reducing their connectivity impairment. Among all technical fishway types, vertical slot fishways (VSF) are considered to be the best solution, as they remain operational even with fluctuating water discharges and allow fish to negotiate each cross-wall at their desired depth. In the present study, we collected both published and original data on fish experiments within VSF, to address two questions, (1) What variables affect fish passage during experimental fishway studies? and (2) What is the best VSF configuration? We used Bayesian Generalized Mixed Models accounting for random effects of non-controlled factors, limiting inherent data dependencies, that may influence the model outcome. Results highlight that fish size, regardless of the species, is a good predictor of fishway negotiation success. Generally, multiple slot fishways with one orifice proved to be the best solution. Future work should be focused on small-sized fish to further improve the design of holistic fishways. Full article

With the development of hydraulic structures, rivers are becoming fragmented, and their connectivity is greatly affected. Important migratory routes through which fish complete their life processes are hindered. In severe cases, it may lead to the extinction of fish species. As facilities commonly used to assist fish upstreaming, fishways are significant for environmental remediation and have received attention from different scholars. This article proposed a new type of fishway, inspired by Tesla valves with obstructing reverse flow characteristics and classic fishway structures. Due to its characteristic of introducing a water-blocking island structure, it was denominated as an island-style fishway. This work studied an island fishway through a combination of physical models and numerical simulations. The results show that this fishway could achieve various flow patterns suitable for fish migration, and the flow rate control was stable. This study also explored the impact of island spacing arrangement on the turbulent structure of the pool chamber. It was found that when the island distance is set at 1.5d, indicators such as flow velocity and turbulent kinetic energy could achieve significant control effects. However, inappropriate d values might cause adverse effects. This research could provide reference ideas for the design of new fishways. Full article

Modified Denil fishways have a centred gabion containing gravel and are intended to enable the free passage of riverbed-oriented species and invertebrates. An experimental plant was built at a small hydropower station which provided a newly arranged Denil fishway and a pool and weir fishway parallel to one another. It was possible to alternately operate the systems for monitoring purposes owing to the parallel design, allowing an appropriate comparison and analysis of the results to be carried out. The primary objective of this study is to qualitatively and quantitatively compare the size selectivity and ascent numbers between the new development and the conventional construction type. An important component of this study is the test to prove the passage of bullheads in the modified Denil fishway using an experimental set-up. The results of this study depict a similar size distribution of ascended fish in both construction types and thus provide no evidence of selectivity for small fish sizes. Likewise, no deficit of the modified Denil fishway compared with the pool and weir fishway could be proven within the scope of a monitoring. The successful passage of bullheads could be demonstrated in the experiment as well as during monitoring. Full article

The reproduction and survival of fish are often negatively affected by the construction of dams and other hydroelectric projects, which cut off their migratory routes. Building effective fish passage facilities that allow fish to pass through dams smoothly alleviates the negative impact of hydroelectric projects on the ecological environment, thus protecting the diversity of aquatic species and preventing the extinction of indigenous fish. Vertical slit fishways are highly effective, but turbulence inside the fishway pools directly affects fish passage. In this study, the large-eddy simulation framework is used to capture the vortex characteristics in the interior of vertical slit fishway pools, and the volume of fluid method is applied to simulate the free surface. The independence of the grid is assessed by the large-eddy simulation quality index, and the simulation results are compared with experimental acoustic Doppler velocimetry data. This work characterizes the vortex flow field inside the vertical slit fishway using the Q-criterion, Omega method, and Liutex vortex identification method. The results show that the vortex structure inside the fishway pool has obvious three-dimensional characteristics and vortex structure varies within the different fishway pool chambers. The analysis and comparison of the three different vortex identification methods show that the vortex structure captured by the Liutex method is more consistent with the actual motion pattern of the fishway water flow. Full article

In recent years, the hydropower development of the lower Mekong River has accelerated, accompanied by habitat loss and fragmentation. We conducted two experiments using video recordings and traps to evaluate the effectiveness of a nature-like rock ramp bypass in the Sesan River in 2019 and 2021. The results show that the fishway provides both upstream and downstream passage for at least 24 non-salmonid species of fish. The vast majority of fish choose to ascend from July to September, especially in August, and hardly between October and November. The fish inside the fishway prefer to move during the daytime (6:00–18:00), especially during August and September. An excessive water depth at the entrance can lower the number of ascending fish, whereas a higher water depth at the exit can cause the opposite result. Nevertheless, the size of fish monitored exhibits a decreasing trend, suggesting the nature-like bypass cannot completely mitigate the impact caused by this impassable Sesan Ⅱ dam. Therefore, a quantitative assessment of the bypass is highly encouraged, whereas the selection of the tracked fish species and experimental period requires considerable deliberation. This study alleviates the dilemma of insufficient fishway evaluation in tropical countries, which can provide researchers with data support on future non-salmonid fishway designs. Full article

The purpose of this study was to allow fish to move upstream past barriers or difficult sections of passage, even on steep stream-type fishways. Therefore, the authors devised a roughness arrangement to raise the water depth in the fishway and reduce its flow velocity. Roughness was used as a group in the arrangement so as to expect afflux effects. Water depth was raised and the flow velocity was reduced around the roughness groups, which allowed fish to hold position and move upstream. Although rapid flow was locally formed in some spots in the fishway, its area was small, enabling the fish to move upstream sufficiently. The experimental results obtained in this study will be applied as a removable stream-type fishway to small channels, head constructions, and so on where fishways cannot be installed due to management. Full article

An understanding of fish movement behavior in response to flow field variables is important for exploring the hydrodynamic strategies of fish in fish passages. In this paper, bighead carps were taken as an example. The fish movement behavior response to water flow field information by means of estimating the energetic expenditure using an IBM approach in an experimental fishway was investigated. Fish swimming velocity, drag force, and energy expenditure were analyzed in varied flow conditions related to hydraulic variables, including velocity (V), turbulent kinetic energy (TKE), and strain rate (SR). The result indicated that the fish will require more energy in high TKE zones. This study provides a reference for optimizing the design of fish passages and fisheries management. This method can be applied to assess the efficiency of fish bypass structures and conduct fish survival studies. Full article
