Search Results (65)

The implantable capsule grouting pile is a novel pile foundation technology in which a capsule is affixed to the side of the implanted pile to facilitate grouting and achieve extrusion-based reinforcement. This technique is designed to improve the bearing capacity of implanted piles in coastal areas with deep, soft soil. This study conducted model tests involving multiple grouting positions across different foundation types to refine the construction process and validate the enhancement of bearing capacity. Systematic measurements and quantitative analyses were performed to evaluate the earth pressure distribution around the pile, the resistance characteristics of the pile end, the evolution of side friction resistance, and the overall bearing performance. Special attention was given to variations in the lateral friction resistance adjustment coefficient under different working conditions. Furthermore, an actual case analysis was conducted based on typical soft soil geological conditions. The results indicated that the post-grouting process formed a dense soil ring through the expansion and extrusion of the capsule, resulting in increased soil strength around the pile due to increased lateral earth pressure. Compared to conventional piles, the grouted piles exhibited a synergistic improvement characterized by reduced pile end resistance, enhanced side friction resistance, and improved overall bearing capacity. The ultimate bearing capacity of model piles at different grouting depths across different foundation types increased by 6.8–22.3% compared with that of ordinary piles. In silty clay and clayey silt foundations, the adjustment coefficient η_s of lateral friction resistance of post-grouting piles ranged from 1.097 to 1.318 and increased with grouting depth. The findings contribute to the development of green pile foundation technology in coastal areas. Full article

In order to study the bearing characteristics of pile groups under the coupling of multiple caves, the influence of the interaction between the crossing cave, the underlying inclined cave, the pile-side cave, and the underlying cave on the ultimate bearing capacity, axial force, lateral friction, and load sharing ratio of the pile group was analyzed based on the model test. The research results show the following: (1) Due to the existence of the underlying cave, the Q-S curves of the pile groups are all steep drop types, and they show the characteristics of end-bearing piles. The influence of other caves is not obvious; the existence of beaded caves, lower crossing caves, underlying inclined caves, upper crossing caves, and pile-side caves will reduce the ultimate bearing capacity of the pile group. The reduction in the ultimate bearing capacity is 7.38%, 4.94% for the lower crossing cave, 2.59% for the underlying inclined cave, 2.27% for the upper crossing cave, and 0.74% for the pile-side cave. (2) When the pile body passes through the cave, the axial force changes slightly in the overburden layer, changes greatly in the limestone layer, and remains unchanged in the cave; under the same load level, the axial force of the pile close to the underlying inclined cave and the pile-side cave is smaller than that of the pile farther away. (3) Under the same load level, the lateral friction of the pile foundation shows a decreasing trend in the sand layer and limestone layer. The friction inside the sand layer is small. After entering the lime layer, the lateral friction increases sharply. The lateral friction is approximately 0 within the cave range. After passing through the cave, the lateral friction increases sharply. (4) The underlying inclined cave and the pile-side cave do not affect the position of the peak point of the pile foundation. The existence of the cave makes the pile foundation increase the peak point at the exit of the cave; under the same load level, the lateral friction of the pile close to the underlying inclined cave and the pile-side cave is larger than that of the pile farther away. (5) The existence of beaded caves, lower crossing caves, underlying inclined caves, upper crossing caves, and pile-side caves will increase the proportion of pile end resistance by 6.95%, 4.23%, 0.94%, 0.77%, and 0.62%, respectively. (6) This study systematically analyzed the differences in the degree of influence of different types of caves (including crossing caves, underlying inclined caves, and pile-side caves) on the bearing characteristics of pile foundations under the condition of the existence of underlying caves. It was found that beaded caves > lower crossing caves > underlying inclined caves > upper crossing caves > pile-side caves, which provides a priority decision-making basis for the optimal design of cave treatment schemes in engineering practice. Full article

The NT-CEP pile is an innovative type of pile that builds upon the conventional concrete straight-hole cast-in-place pile. It primarily consists of two components: the main pile and the bearing plate. The key factors influencing its load-bearing capacity include the pile diameter, the cantilever dimensions of the bearing plate, and the slope of the bearing plate’s foot, among others. The pile spacing significantly influences the bearing capacity of NT-CEP pile group foundations. The overall bearing capacity of an NT-CEP pile group foundation is not merely the sum of the ultimate bearing capacities of individual piles; rather, it results from the interactions among the pile bodies, the cap, and the foundation soil. Advancing the design theory of NT-CEP pile groups and enhancing their practical applications in engineering requires an in-depth investigation of how different pile spacings influence the load-bearing performance of pile group foundations. This objective can be achieved by exploring the soil damage mechanisms around side, corner, and central piles. This exploration helps in clarifying the influence of pile spacing on the load-bearing performance. Based on research findings regarding the bearing capacity of single and double pile foundations, this paper utilizes ANSYS finite element simulation analysis to model six-pile and nine-pile groups. Because these arrangements are universally adopted in engineering practice, they are capable of accounting for the pile group effect under various pile spacings and row configurations. The nine-pile group comprises corner piles, side piles, and a center pile, enabling a comprehensive analysis of stress variations among piles at different positions. As six-pile and nine-pile groups represent common pile configurations, studying these two types can provide valuable insights and direct references for optimizing pile foundation design. The study systematically investigates the influence of varying piles spacings on the bearing capacity of NT-CEP pile group foundations. It concludes that, as pile spacing decreases, The displacement of the top of this pile increases. thereby enhancing the group piles effects. Conversely, increasing the spacing between piles represents an effective strategy for elevating the compressive capacity of the NT-CEP pile-group foundation. Larger spacing also increases the vertical load-bearing capacity of the central piles, enhances the lateral friction resistance of corner piles, and heightens the load-sharing proportion between the bearing plate and the pile end. Furthermore, increasing pile spacing raises the ratio of load sharing by the foundation soil for both the CEP nine-pile foundation and the CEP six-pile foundation. The reliability of the simulation study has been verified by a visualization small scale model test of a half cut pile. Full article

In order to study the influence of pile end sediment on the bearing characteristics of bored piles, the on-site bearing capacity test was conducted on a single pile. A mathematical model of bearing capacity and the settlement response of a single pile considering sediment effects and a finite element model of a single pile with pile end sediment were established. In addition, the influence of sediment thickness on the bearing capacity of bored piles was systematically analyzed. The results show that the compaction of sediment at the pile end could significantly improve the ultimate bearing capacity of the single pile. Compared with the single pile that did not consider the compaction of the sediment at the pile end, the load required to reach the ultimate bearing capacity of the pile after compaction of the sediment increases by 900 KN. The settlement of the pile under a maximum vertical load increases with an increase in the thickness of the sediment. The influence of sediment thickness on axial force transmission is mainly reflected in the linear to nonlinear transformation of axial force distribution from low to high during the process of load. The slight decrease in axial force at the bottom of the pile could also be caused by the increase in the thickness of sediment. The increase in sediment layer thickness means that the transfer efficiency of the pile end resistance decreases. However, with an increase in load, the compression effect of the pile end sediment becomes obvious, which will further change the distribution of load between the pile side resistance and the pile end resistance. Full article

The span of pile foundations beneath metro depots typically ranges from 10 to 20 m, exhibiting a notably large span. This structural characteristic results in the pile foundations bearing a more concentrated upper load, while the interstitial soil between the piles bears minimal force. Concurrently, global climate change and enhanced urban greening initiatives have led to a significant increase in rainfall in northwest China, a region traditionally characterized by arid and semi-arid conditions. This climatic shift has precipitated a continuous rise in groundwater levels. Furthermore, the extensive distribution of collapsible loess in this region exacerbates the situation, as the rising groundwater levels induce loess collapse, thereby adversely affecting the mechanical behavior of the pile foundations. In light of these factors, this study utilized the pile foundations of a metro depot in Xi’an as a prototype to conduct static load model tests under conditions of rising groundwater levels. The experimental results reveal that the load–settlement curve of the pile foundations in the absence of groundwater exhibited a steep decline with distinct three-stage characteristics, and the ultimate bearing capacity was determined to be 5 kN. When the groundwater level is situated below the loess stratum, the settlement of both the pile foundations and the foundation soil, as well as the axial force, skin friction, and pile tip force, remains relatively stable. However, when the groundwater level rises to the loess stratum, there is a significant increase in the settlement of the pile foundations and foundation soil. Negative skin friction emerges along the pile shaft, and the bearing type of the pile foundation transitions gradually from a friction pile to an end-bearing pile. The influence range of the pile foundation on the settlement of the foundation soil is approximately three times the pile diameter. Full article

The primary objective of this study is to establish an innovative theoretical framework for analyzing the behavior of an end-bearing pile-supported embankment. This proposed methodology extensively investigates various aspects, including the characteristics of relative slip at the interface between the pile and soil, the distinctive non-uniform deformation patterns typically observed in soft soils, and the substantial influence of pile–soil interaction on the evolution of soil arching phenomena. To precisely capture the frictional relationship and relative displacement within the pile–soil system, we introduce an enhanced ideal elastic-plastic model. Additionally, a deformation function is incorporated to simulate the non-uniform deformation of soft soils, and an improved soil arching model is developed to assess its impact on the overall behavior. The analytical solution is derived through the implementation of a stress and volume deformation continuity condition, and its validity is effectively demonstrated through numerical simulations. The results indicate that under the load of the embankment, relative slip at the pile–soil contact surface is a significant phenomenon and should not be neglected in theoretical calculations. The relative displacement between the pile and soil initially exhibits a linear relationship with depth, and later follows a quadratic function as depth increases. Full article

Pre-drilled composite planted piles are a commonly used construction method, but there is currently limited research on the load-bearing characteristics of piles penetrating boulders. Therefore, a new type of pre-drilled composite planted pile suitable for sites with isolated boulders has been developed. Using transparent soil technology, vertical uplift bearing capacity tests were conducted on pre-drilled piles to investigate the uplift capacity and load transfer mechanism of piles with boulders. Additionally, a discrete–continuous coupled 3D numerical model was employed to analyze the influence of boulder position on the pile’s uplift bearing capacity. The results indicate that the ultimate uplift bearing capacity of piles with boulders in the pile body is approximately twice that of piles without boulders, and this difference decreases with the increase of the distance between boulder and the pile end; under ultimate uplift loading, the pile end of a pile containing boulders contributes approximately 32% of the uplift bearing capacity, whereas the pile end without boulders contributes almost no uplift capacity; the presence of boulders increases the cross-sectional diameter of the pile, providing additional vertical support from the overlying soil, thereby significantly enhancing the ultimate uplift bearing capacity of the pile. Additionally, the boulder also increases the pathways for load transfer to the surrounding soil, further expanding the impact area on the soil surrounding the piles. Parameter analysis of the position of the boulder in the pile body reveals that under various conditions (boulder distances from the pile tip of 0, 50, 100, and 150 mm), both the ultimate uplift bearing capacity and the angle of the sliding failure surface decrease gradually as the depth of boulder decreases. This study provides a novel solution for pile foundation construction in similar boulder strata. Full article

In situ vertical load field tests were carried out on two bored piles used in the Chizhou Highway Bridge across the Yangtze River, both of which were rooted piles. Based on the test results, such as those on the relationship between the load and settlement, axial force distribution, and the relationship between shaft friction and pile–soil relative displacement, the vertical load transfer mechanics of the rooted piles were analyzed. The results showed that the load-carrying curves of the rooted piles vary gradually and also that the rooted piles exhibit the bearing characteristics of friction piles because the loads at the pile tips are less than 15% of the total bearing capacity of the piles. The slope of the axial force distribution curve of the rooted piles first increased at the upper interface and then decreased at the lower interface of the root-reinforced zone. The axial force of the rooted piles decreased faster in soil layers where the piles had roots, which can be explained by the fact that roots share the vertical load with piles and that roots improve the bearing properties of piles. Considering the shaft and end resistance of the roots on the piles, the relationship between load and settlement of the rooted piles was calculated by a three-line model based on the load transfer method. The results calculated from the model were in good agreement with the results from the tests. The results from the tests could inform the design and analysis of rooted piles. Full article

The use of screw piles has grown rapidly, yet their varied configurations and behavior in different soils remain key research areas. This study examines the performance of Toe-wing (Tsubasa) and Spiral screw piles with similar tip areas under similar ground conditions, focusing on how the helix position (W_p) and tip embedment depth (E_d) affect the ultimate pile capacity. In the case of a fixed helix/toe-wing position with increasing pile tip depth, Spiral screw piles exhibited higher load-carrying resistance than toe-wing piles at relative densities of 55%, 80%, and 90% fine sand. Moreover, load-carrying resistance increased as the position of the helix/toe-wing increased (W_p > 0). For a fixed pile tip depth (E_d) and varying helix/toe-wing positions, spiral screw piles showed higher resistance than toe-wing piles when W_p < 90 mm. Moreover, the resistance decreased as the helix moved away (W_p/D_h > 0), and the pile tip acted independently when W_p/D_h > 1.38. Whereas, for toe-wing piles, ultimate pile capacity increased as the toe-wing moved away from the tip up to W_p/D_h = 2.15, then decreased to reflect the independent behavior of the toe-wing and pile tip. Empirical equations are presented to convert installation effort and ultimate capacity from one type to another. Full article

To ensure the connection performance of precast concrete square piles, a screw clamping and welding joint connection is applied to the solid square piles. By conducting full-scale bending performance tests on six solid square pile specimens with cross-sectional side lengths of 300, 450, and 600 mm, including pile bodies, screw clamping joints, screw clamping, and welding joints, the bending load-bearing capacity, deformation capacity, and failure characteristics of the screw clamping–welding joint connection are compared and studied. The results show that the bending failure mode of the pile body specimens is shear failure in the flexural shear section and concrete crushing in the compression zone of the pure bending section; the bending failure mode of the screw clamping joint specimens are the pull-out of steel bar heads at the joint end plate; the bending failure mode of the screw clamping and welding joint specimens are concrete crushing in the compression zone of the pure bending section, steel bar breakage in the tension zone of the flexural shear section, and pull-out of steel bar heads at the end plate. It is worth noting that no significant damage occurred at the joints. The cracks in the pure bending section of the bending specimens mainly develop vertically and are evenly distributed, while some cracks in the flexural shear section develop obliquely towards the loading point, with branching. Compared to the pile body specimens, the cracking moment of the joint specimens is up to 16% higher, the ultimate moment is within 15% lower, and the maximum mid-span deflection is within 25% lower, indicating that the provision of anchorage reinforcement can increase the stiffness and cracking moment of the specimens. Full article

Large-diameter cast-in-place tubular piles offer high efficiency and adaptability for various engineering applications. Despite their widespread use, the bearing behavior of these piles remains complex due to the interactions with the internal soil core, and the related theoretical framework is not yet fully developed. In this study, a simplified load transfer model is proposed based on the pile–soil interaction mechanism of large-diameter tubular piles. Comprehensive load transfer models for the skin friction and end resistance of both the pile body and the soil core are established, supported by a detailed theoretical analysis. A novel three-criteria approach is introduced for the first time to enhance settlement predictions for large-diameter tubular piles by considering the displacement coordination mechanism of the internal soil core, addressing the limitations of traditional two-criteria methods. The proposed methods are validated through two engineering case studies, demonstrating their effectiveness and confirming their rationality and applicability in practical scenarios. Full article

To investigate the effect of combined end-and-shaft post-grouting on the vertical load-bearing performance of bridge-bored piles in the Dongting Lake area of Hunan, two post-grouted piles were subjected to bi-directional O-cell and top-down load tests before and after combined end-and-shaft grouting, based on the Wushi to Yiyang Expressway project. A comparative analysis was conducted on the bearing capacity, deformation characteristics, and load transfer behavior of the piles before and after grouting. This study also examined the conversion coefficient γ values of different soil layers obtained from the bi-directional O-cell test for bearing capacity calculations. Additionally, the characteristic values of the end bearing capacity, obtained from the bi-directional O-cell and top-down load tests, were compared with the values calculated using the relevant formulas in the current standards, which validated the accuracy of existing regulations and traditional loading methods. The results indicate that the stress distribution along the pile shaft differed between the two test methods. In the bi-directional O-cell test, the side resistance developed from the end to the head, while in the top-down load test, it developed from the head to the end. After combined post-grouting, the ultimate bearing capacity of the piles significantly increased, with side resistance increasing by up to 81.03% and end resistance by up to 105.66%. The conversion coefficients for the side resistance in silty sand and gravel before and after grouting are 0.86 and 0.80 and 0.81 and 0.69, respectively. The characteristic values of the end bearing capacity, as measured by the bi-directional O-cell and top-down load tests, were substantially higher than those calculated using the current highway bridge and culvert standards, showing increases of 133.63% and 86.15%, respectively. These findings suggest that the current standard formulas are overly conservative. Additionally, the measured values from the top-down load test may underestimate the actual bearing capacity of piles in engineering projects. Therefore, it is recommended that future pile foundation designs incorporate both bi-directional O-cell testing and combined post-grouting techniques to optimize design solutions. Full article

Utilizing the results of static load tests using the self-balancing method on two large-diameter bored piles from the Huaiyang Left Line Special Bridge Project of the Lianyungang–Zhenjiang Railway, this study aims to investigate the effect of combined tip-and-side post-grouting on the bearing characteristics of post-grouted piles in railway bridges. The difference in bearing performance between individual piles before and after grouting was evaluated using a comparative analysis. The results show that the bearing capacity of the pile foundations is greatly increased by combined tip-and-side post-grouting. In particular, following grouting, a single pile’s maximum bearing capacity rises from 32.99% to 38.42%. The combined post-grouting produces a compressed grout that enhances the mechanical characteristics of the pile–soil contact, resulting in a significant increase in side resistance all the way along the pile. The combined post-grouting also optimizes the performance of the tip resistance, resulting in a more rapid response as the pile tip displacement increases. Additionally, the combined post-grouting modifies the pile shaft’s load transfer mechanism by increasing the tip resistance’s contribution to the pile foundation’s ultimate bearing capacity and moving the bearing’s center of gravity closer to the pile end. Full article

Screw-groove piles, a new type of precast pile, are economically and environmentally friendly and improve the load-bearing performance of piles through a unique screw-groove structure. To reveal the load-transfer characteristics and bearing mechanism of the screw-groove pile, the axial force, load–settlement curve, skin friction, bearing capacity, and response characteristics of the foundation for piles under vertical loading were analyzed. Furthermore, a parameter analysis of the ultimate bearing capacity and material utilization of screw-groove piles was performed using the finite element method. The results demonstrate that the screw-groove pile had an ultimate bearing capacity 1.85 times higher than that of the circular pile, and its material utilization rate was 2.85 times higher. The screw-groove surface end resistance and pile-tip resistance formed a multipoint vertical bearing mode. It efficiently utilized the soil’s shear strength and mobilized a larger volume of surrounding soil to share the load. The screw-groove structure increased the pile–soil interaction surface, thereby increasing the skin friction resistance of the pile. Additionally, increasing the inner radius of the screw groove boosts the pile’s bearing capacity but may reduce material utilization. An optimal screw-groove spacing balances both factors, while excessive groove thickness lowers material use. The pile shows high sensitivity to soil parameters. Full article

The failure zone around the pile tip varies greatly with the different failure patterns considered in research on the end-bearing capacity of piles. In an effort to improve the consideration of the size of the failure zone, a new failure pattern is proposed in the estimation of the end-bearing capacity of driven piles in sand and the failure zone is determined by zero-extension line (ZEL). Considering a failure zone limited below the pile end plane and an equivalent frictional contact condition with the equivalent frictional strength fully mobilized at the failure zone boundary, a more realistic prediction of the end-bearing capacity of piles is achieved. Reasonable values of parameters are obtained through parameter and numerical analysis. It is found that the failure zone is roughly within the range of 40° from the vertical direction. Comparison between the ultimate toe capacity predicted by the proposed method, a method directly using cone penetration test (CPT) data, and a method based on characteristic theory shows that the mixed zero-extension line method considering limited region failure has a better consistency with experimental data. Full article
