The compressive capacity of helical anchors constitutes a pivotal performance parameter in geotechnical design. To precisely predict the compressive bearing behavior of helical anchors in aeolian sand, this study integrates in situ testing with finite element numerical analysis to systematically elucidate the non-linear evolution of its load-bearing mechanisms. The XGBoost algorithm enabled the rigorous quantification of the governing geometric features of compressive capacity, culminating in a computational framework for the bearing capacity factor (N_q) and lateral earth pressure coefficient (K_u). The research findings demonstrate the following: (1) Compressive capacity exhibits significant enhancement with increasing helix diameter yet displays limited sensitivity to helix number. (2) Load–displacement curves progress through three distinct phases—initial quasi-linear, intermediate non-linear, and terminal quasi-linear stages—under escalating pressure. (3) At embedment depths of H < 5D, tensile capacity diminishes by approximately 80% relative to compressive capacity, manifesting as characteristic shallow anchor failure patterns. (4) When H ≥ 5D, stress redistribution transitions from bowl-shaped to elliptical contours, with ≤10% divergence between uplift/compressive capacities, establishing 5D as the critical threshold defining shallow versus deep anchor behavior. (5) The helix spacing ratio (S/D) governs the failure mode transition, where cylindrical shear (CS) dominates at S/D ≤ 4, while individual bearing (IB) prevails at S/D > 4. (6) XGBoost feature importance analysis confirms internal friction angle, helix diameter, and embedment depth as the three parameters exerting the most pronounced influence on capacity. (7) The proposed computational models for N_q and K_u demonstrate exceptional concordance with numerical simulations (mean deviation = 1.03, variance = 0.012). These outcomes provide both theoretical foundations and practical methodologies for helical anchor engineering in aeolian sand environments. Full article

In the process of heavy-duty cutting, the reciprocating motion of the sliding guide pair surface is prone to local wear, which seriously affects the overall machining accuracy and service life of the machine tool. This study proposes a biomimetic micro-texture design scheme combining elliptical grooves and shell-shaped grooves on the surface of carp as biomimetic prototypes to enhance the oil film bearing capacity, drag reduction, and wear resistance of guide rail pairs. Based on Fluent fluid simulation research, it has been shown that this texture has a better dynamic pressure lubrication effect. We used response surface methodology to optimize the texture design parameters and further verify the accuracy of the optimal parameters with the NSGA-II genetic algorithm. The results show that under lubricated conditions, the load-bearing pressure of the combined micro-textured guide rail pair increased by 53.79%, the friction coefficient decreased by 39.04%, and the temperature decreased by 15.83%. This texture can still significantly improve drag reduction and wear resistance in a low-oil state. Full article

Under alternating loads, the contact situation for self-aligning roller bearings in the main shaft of a wind turbine is complex. Few methodologies exist for calculating the contact stress of main shaft bearings. We propose a method for calculating the contact stress of main shaft bearings in wind turbines; by simulating alternating loads that affect the turbine’s lifespan with a probability of 99%, analyzing the operational characteristics of the bearings under these loads using the roller slice method, and establishing a load–displacement model, this model serves as the boundary condition for contact stress simulation. We present the approach for building a three-dimensional finite element simulation model of contact stress, followed by model validation. The findings reveal that the maximum stress within the spindle bearing is concentrated in the contact zone, taking on an elliptical configuration. The maximum contact stress, as computed by the proposed method, amounts to 1356.3 MPa, and the bearing’s load-bearing performance adequately fulfills the design requirements. A comparative analysis with the calculation results documented in the existing literature shows that the average discrepancies in the computed outcomes for the roller’s contact with the inner and outer rings are 2.55% and 2.48%, respectively, and this validates the high reliability of the proposed approach. The research conducted in this thesis can further enhance the credibility of the contact stress calculation method for large-scale wind turbine spindle bearings. Full article

The novel forced wave generator (NFWG) is a critical component of the harmonic drive (HD) without a flexible bearing. Tribological design is required to increase the load-carrying capacity and reduce the frictional resistance in the elliptical sliding pairs (ESPs) between the flex spline (FS) and the NFWG. As the thin-walled FS operates under cyclic deformation with large displacement in the HD, this paper investigates the effects of the distribution region, depth, shape, and density of micro-dimple textures on the outer contour surface of the NFWG on the load-carrying capacity and the frictional resistance of the ESPs using the CFD method. The analysis reveals that the load capacity and lubrication performances of the ESPs are significantly enhanced when the micro-dimple textures are fully distributed on the outer contour surface of the NFWG, with a depth of 0.1 mm, a radius of 6 mm, and a distribution density of 3.9%. The results provide a reference for the practical design of ESPs in the HD under extreme mechanical transmission conditions. Full article

An assembled elliptical joint was designed for a lattice wind turbine tower, and four samples were analyzed under static loads. Additionally, finite element analysis software was employed to create 40 models, with the wall thickness of the ball seat and the web being the variable parameters. This enabled the identification of the variation pattern in the ultimate bearing capacity. It was found that the failure parts of the four test pieces were located in the connection area between the tensioned web member and the ball table. Increasing the wall thickness of the ball table and the web member significantly increased the joint’s load-bearing capacity. However, increasing the table wall thickness somewhat reduced the joint’s deformation capacity. Increasing the web member thickness significantly improved the deformation capacity and the energy absorption capacity of the joint. Increasing the table wall and the member web thickness reduced the peak equivalent stress in the ball table area and the press plate, as well as the overall stress level. Finite element simulations showed that the joint’s load-bearing ability was adversely impacted when the table wall thickness exceeded 10 mm. When the web member wall thickness exceeded 5 mm, the joint bearing capacity was less sensitive to the increase in the wall thickness. Full article

Nano Cu precipitation plays a crucial role in significantly improving the performance of the Cu-bearing high-strength low-alloy steel. The final cooling temperature effects the transformation products of austenite during the continuous cooling process, as well as the nano precipitations of steel. This study investigated the microstructure and hardness at different final cooling temperatures (750, 700, 650, 600, 550, and 500 °C) using the MMS-300 thermal simulation experimental machine (Northeastern University, Shenyang, China) and Vickers hardness tester. The changes in microstructure and the phase transformation law of austenite were determined during continuous cooling and then analyzed. The precipitation reaction of nano Cu precipitation during continuous cooling was studied using transmission electron microscopy (TEM), revealing the precipitation state under different final cooling temperature conditions. The results showed that the precipitations led to an increase and then a decrease in the microhardness, and the microhardness reaches its peak at 550 °C. The precipitations changed from spherical to elliptical, and the size gradually increased when the final cooling temperature increased. Full article

High-strength concrete-filled steel tube (CFST) arches have been widely applied in underground engineering, among which there are special-shaped arches such as D-shaped sections. At present, most studies have concentrated on members with square or circular sections, while relatively few studies have been conducted on D-shaped section members. In this study, firstly, D-shaped sections were initially transformed into sections with a part square and part elliptical shape using an equivalent section method. The formulas for the axial compression and pure bending bearing capacities of the basic D-shaped CFST members were deduced using unified theory, and the bearing capacity of the D-shaped members was calculated in a given case. Secondly, numerical simulations of axial compression and pure bending of the basic CFST members with three section types (square, circular, and D-shaped) were carried out using ABAQUS software. To ensure the reliability of the numerical simulations, the concrete damage constitutive model and the elastic–plastic model were adopted to simulate the core concrete and the steel tube, respectively. In the results, the axial compression and pure bending bearing capacities of the D-shaped section obtained via theoretical calculation were 2339.6 kN and 84.8 kN·m, respectively, while the results obtained via numerical simulation were 2335.8 kN and 85.4 kN·m, respectively, which were relatively close. Among the three section types of members, the D-shaped members had the highest axial compression bearing capacity, which was 1.45% and 4.58% higher than those of the circular and square section members, respectively. However, their bending moment bearing capacity was relatively low. The stress distribution of the D-shaped members presented a characteristic where the circular part dominated, and the stress transfer effect of the members was favorable. In practical engineering, when the surrounding rock pressure is high and evenly distributed, D-shaped section arches can be selected, and increasing the proportion of the square area in D-shaped sections can enhance the overall flexural capacity of arches. Full article

The stress analysis of buried pipe culverts is a complex task, and accurately characterizing the deterioration of mechanical properties caused by corrosion poses significant challenges. In this study, the finite element analysis software PLAXIS 3D was employed to construct a numerical simulation model of a pipe culvert. By varying the stiffness and thickness of either the entire structure or specific sections, different degrees of corrosion were simulated to investigate the influence of various cross-sectional shapes on corrosion effects. Multiple experimental controls were set to analyze both the bearing capacity and deformation characteristics under different conditions. The findings reveal that different levels of corrosion have distinct impacts on the deformation behavior of pipe culverts. Overall corrosion has the most significant effect on the overall deformation, while crown and middle corrosion show a similar effect on stiffness-related deformations. In contrast, invert corrosion has minimal impact on the stiffness-related deformation. Corrosion affects circular and elliptical pipe culverts similarly. However, the circular pipe culvert is evidently influenced by overall corrosion more significantly than the elliptical ones due to the combined effects from overall and local corrosion in their deformations. Through finite element numerical simulation, it can be used as a reference for practical engineering design and construction. Full article

This study employs a hybrid numerical-experimental calibration method based on phenomena to determine the fracture parameters of the Modified Mohr–Coulomb (MMC) model. Using a self-developed VUMAT subroutine and the element deletion technique, the fracture process of a wide plate pipeline is thoroughly analyzed. This study investigates the impact of various crack shapes on the fracture response under tensile loading and the influence of surface crack size on the initiation location of a wide plate. These results demonstrate the calibrated MMC fracture model’s accurate prediction of the toughness fracture behavior of X80 pipeline steel. Under equal area conditions of the dangerous section, circular cracks exhibit lower bearing capacity compared to elliptical cracks. Elliptical cracks predominantly propagate in the thickness direction, whereas circular cracks show nearly uniform growth in all directions. Furthermore, when the crack depth is less than half of the wall thickness, the damage accumulation value at the midpoint of the crack front is maximized; conversely, when the crack front is closer to the internal measurement point of the wide plate, the damage accumulation value is maximized. Full article

This paper presents novel configurations for additively manufactured lattice structures, including helical and elliptic designs, in addition to the pyramid base model. Functionally graded versions of the pyramid and elliptic lattice structures are developed by considering desirable relative densities in each layer. The lattice structures were manufactured using Ti-6Al-4V powder in a three-dimensional selective laser melting printer. The averaged porosities are 0.86, 0.91, 0.916, 0.93 and 0.74 for pyramid, functionally graded pyramid, elliptic, functionally graded elliptic and helical, respectively. The mechanical behavior of the lattice structures was characterized through compression tests using a universal testing machine and computationally analyzed using finite element code. The results indicate that the elliptic and functionally graded elliptic lattices have elastic moduli of 0.76 and 0.67 GPa, while the yield strengths are 41.32 and 32.24 MPa, respectively, in comparison to cancellous bone. Moreover, pyramid, functionally graded pyramid, and helical lattices show relatively lower elastic moduli of 0.57, 0.65 and 0.41 GPa and higher yield strengths of 54.1, 52.15 and 61.02 MPa, respectively. This could be an indication that they are fit for cortical bones. All samples have low elastic moduli coupled with high yield strengths. This could reduce or eliminate stress shielding, making them suitable for some load-bearing bio-inspired applications. A comparative study utilizing experimental and numerical models was conducted to evaluate the performance of the proposed designs. Full article

Currently, microscopic research on the tensile fracture properties of recycled brick coarse aggregate concrete has mainly adopted microscopy techniques, which can clearly observe the actual damage situations of each phase material but are unable to individually analyze the effect of a specific material factor on the tensile properties of recycled concrete. This brings much uncertainty to the practical application of recycled concrete. Therefore, this study proposes a cohesive zone model (CZM) for simulating the tensile fracture of recycled brick coarse aggregate (RBCA) concrete. To this end, the study explores the effects of various critical factors on the fracture mode and bearing capacity of recycled brick aggregate concrete, including the replacement rate of recycled brick coarse aggregate, pore structure, interfacial transition zone (ITZ) strength, mortar strength, and volume fraction of brick aggregate. The results indicate that, when the minor to major axis ratio of elliptical pores is 0.5 ≤ K < 1, the following order of influence can be observed: random convex polygonal pores, circular pores, and elliptical pores. Moreover, excessively strengthening the ITZ and mortar does not significantly enhance the tensile performance of RBCA concrete. The distribution location of aggregate has a significant impact on the crack shape of recycled concrete, as does the pore structure, due to their randomness. Therefore, this article also discusses these. These findings contribute to a comprehensive understanding of the tensile properties of recycled brick coarse aggregate and provide insights into optimizing its behavior. Full article

Biaxial compression tests based on an elliptical tunnel were conducted to study the failure characteristics and the meso-crack evolution mechanism of tunnels with different cross-sections constructed in sandstone. The progressive crack propagation process around the elliptical tunnel was investigated using a real-time digital image correlation (DIC) system. Numerical simulations were performed on egg-shaped, U-shaped, and straight-walled arched tunnels based on the mesoscopic parameters of the elliptical tunnel and following the principle of an equal cross-sectional area. The meso-crack evolution and stress conditions of the four types of tunnels were compared. The results show that (1) fractures around an elliptical tunnel were mainly distributed at the end of the long axis and mainly induce slabbing failure, and the failure mode is similar to a V-shaped notch; (2) strain localization is an important characteristic of rock fracturing, which forebodes the initiation, propagation, and coalescence paths of macro-cracks; and (3) the peak loads of tunnels with egg-shaped, U-shaped, and straight-walled arched cross-sections are 98.76%, 97.56%, and 90.57% that of an elliptical cross-section. The elliptical cross-section shows the optimal bearing capacity. Full article

This study explored the axial compression behavior of elliptical concrete-filled steel tubes with encased steel considering spherical-cap gap (GSECFST) composite short columns. We designed 25 composite column specimens by varying the steel tube yield strength (f_ty), steel skeleton yield strength (f_sy), concrete cubic compression strength (f_cu), steel tube thickness (t), steel skeleton sectional area (A_s), the long and short half-axis ratio (a/b), the gap ratio (X_sg), and the slenderness ratio (λ). Based on the nonlinear constitutive models of the materials and the nonlinear contact effect among materials, the ABAQUS 6.20 finite element software established the refined finite element models of these composite short columns. Also, the rationality of the finite element modeling with a spherical-cap gap was verified by comparing it with the existing experimental results. The influence regularity of various parameters on the load (N)-displacement (Δ) curves, bearing capacity, initial stiffness, and ductility of the composite short columns was obtained. In addition, the failure modes, N-Δ process, sectional strain distribution, and gap feature index of the constraint partition model for GSECFST axial compression short columns were revealed. The results showed a weakened interaction between the elliptical steel tube and concrete. Also, the axial compression bearing capacity, initial stiffness, and core concrete ductility were reduced because of the spherical-cap gap. As f_ty, f_sy, f_c, and A_sy increased, the axial bearing capacity, initial stiffness, and ductility of GSECFST composite short columns improved significantly but decreased with increasing of a/b, X_sg, and λ. When the gap ratio of the spherical crown was less than 4%, the outer steel tubes in the mid-span area of the GSECFST composite short columns buckled in the direction of the elliptical short axis under axial compression, and the concrete expanded outward and crushed. The failures were similar to those of the specimens without the spherical-cap gap. Based on the sectional constraint partition model, we propose the calculation formula of axial compression bearing capacity for GSECFST composite short columns. Consequently, this study is a reference for the elastic-plastic analysis of frame systems with similar composite columns. Full article

In order to study the mechanical bearing behavior of arched sandwich roof structures, a full combination and independent action mode of concrete sandwich composite panels was constructed using the finite element method, and an arched steel–concrete composite sandwich roof with a span of 18 m was subjected to a numerical simulation test under a full-span vertical uniformly distributed load, with the bearing characteristics of the arched sandwich roof discussed in depth. The results show that the cross-sections of l/16 and l/2 of the elliptical arch sandwich roof are weak sections, and the tensile cracking of concrete appears for the first time in the upper and lower wythes of the elliptical arch sandwich roof, the von Mises stress level of the lower wythe of the l/16 section is higher under the ultimate load, and the roof shows four-part form failure characteristics. With the expansion of the cracking range of the upper and lower concrete wythes of the steel–concrete composite sandwich arch roof, the load–displacement curve of the roof structure does not decrease significantly, and the bearing capacity of the structure is high and the vertical deformation is small. The steel–concrete composite segment at the end of the roof effectively strengthens the edge constraint of the roof and improves the integrity of the sandwich roof. The upper and lower concrete wythes of the sandwich roof show a fully combined action mode in the elastic working stage and, when the concrete cracks, it shows a partial combined action mode. Full article

In recent years, excessive lateral deformation of subway shield tunnels has been observed due to adjacent engineering activities. This study examines the monitoring of excessive lateral deformation of the shield tunnel and the special steel plate reinforcement process to enhance the safety and stability of the operating subway tunnel structure. It uses a three-dimensional refined finite-element model of the shield tunnel for parametric structural loading simulation analysis to propose a structural deformation limit value suitable for the subway shield tunnel. This study’s findings indicated the following: (1) as observed from the engineering examples, a tunnel with significant elliptical deformation increases the likelihood of cracking and other structural issues in the adjacent subway shield tunnel segment; (2) as observed from the post-reinforcement monitoring data, the steel plate reinforcement method effectively enhances the load-bearing stability of the damaged tunnel structure; (3) based on the finite-element simulation results and the comprehensive review of practical conditions, the standard warning value for lateral deformation, using ellipticity evaluation of the subway shield tunnel, is established at 20‰, with a control value of 25‰. The outcomes of this research offer valuable insights into the operation, maintenance, and health monitoring of subway shield tunnels. Full article
