Direct-drive permanent magnet synchronous generators (DD-PMSGs) have been widely adopted in wind power generation systems owing to their distinctive advantages, including direct-drive operation, high power density, and superior energy conversion efficiency. However, the high power density of the generator inevitably leads to heat generation issues, which affect the reliability of the generator. To address the thermal issues in the 4.5 MW direct-drive permanent magnet synchronous generator (DD-PMSG), this paper proposes a novel forced air-cooling ventilation system. Through comprehensive computational fluid dynamics (CFD) simulations and fundamental thermodynamic analysis, the cooling performance is systematically evaluated to determine the optimal width of the stator ventilation ducts. Furthermore, based on the temperature distribution of the stator and rotor, three optimization schemes for non-uniform core segments are proposed. By comparing the ventilation cooling performance under three structural schemes, the optimal structural scheme is provided for the generator. Finally, the feasibility of the heat dissipation scheme and the accuracy of the simulation calculations are verified by fabricating a prototype and setting up an experimental platform. The above conclusions and research results can provide some reference for the design of the core ventilation ducts structure of subsequent wind turbines. Full article

This research introduces the first design concept for a ducted coaxial-rotor amphibious spherical robot (BYQ-A1), utilizing the principle of variable mass control. It investigates whether the BYQ-A1’s variable-mass slider has a certain regularity in its impact on the aerodynamic properties of the BYQ-A1. Utilizing the Blade Element Momentum Theory (BEM) and Wall Jet Theory, an aerodynamic calculation model for the BYQ-A1 is established. An orthogonal experimental method is used to conduct tests on the impact of the variable-mass slider on the aerodynamic properties of the ducted coaxial-rotor system and validate the effectiveness of the aerodynamic calculation model. The results show that the slider generates an internal ground effect and ceiling effect within the BYQ-A1 that enhance the lift of the upper and lower rotors when the robot is equipped with it. The increased total lift compensates for the additional aerodynamic drag caused by the presence of the slider. This novel finding provides guidance for the subsequent optimization design and control method research of the BYQ-A1 and also offers valuable references for configuration schemes that incorporate necessary devices between coaxial dual rotors. Full article

This study analyzed and validated a 1 MW hydropower turbine system using computational fluid dynamics (CFD) in conjunction with field test data. The fluid domain of the hydropower system includes the runner blade, vane, duct, and both inflow and outflow free surface flows. An implicit unsteady flow solver and the SST k-ω turbulence model were employed. The rotational motion of the rotor blade was simulated using the moving reference frame (MRF) method. To handle a non-conformal mesh among the intake, runner, and outlet domains, an internal interface boundary condition was applied. System performance was evaluated by adjusting the guide vane opening ratio and the runner blade pitch angle. A free surface model was also developed to accurately represent the water level. The results show that the CFD analysis predicted the turbine’s power output with a maximum deviation of 1.7% from field test measurements under different tide conditions. The numerical analysis also confirmed the influence of the runner blade pitch angle, with a 1° change in pitch angle leading to a 68 kW variation in power output. The accuracy of the CFD analysis was verified by comparing it to performance data from actual field tests. Full article

The integrated ducted structure significantly enhances the aerodynamic performance of the duct–rotor system, reducing noise and enhancing rotor safety. However, in the duct–rotor system, the coupled parameters of the rotor and the duct are crucial to its aerodynamic characteristics. This study employs a Computational Fluid Dynamics numerical analysis to investigate the aerodynamic performance of the duct–rotor, focusing on coupled parameters related to the rotor blade’s relative position and tip gap. Additionally, our research delves into the fundamental mechanisms of key coupled parameters, such as the blade tip gap, elucidating their role in optimizing the duct–rotor’s aerodynamics. The results emphasize the critical role of the tip gap in influencing the aerodynamic performance of the duct–rotor. Notably, when the tip gap exceeds 3.0% of the duct’s radius, the aerodynamic advantage provided by the duct is insufficient to offset the loss in the rotor’s performance. As the tip gap exceeds 7.0% of the duct’s radius, the aerodynamic deterioration caused by the duct gradually stabilizes. Furthermore, the influence of rotor blade position on aerodynamic performance is relatively minor. However, placing the rotor at the duct exit position proves advantageous for improving the aerodynamic distribution characteristics of the system. Full article

Electric propulsion systems have emerged as a disruptive technological approach towards achieving sustainable and climate-neutral aviation. To expand the operational envelope of such propulsion units in terms of altitude and velocity, an enclosing duct and counter-rotating rotors to enhance efficiency can be utilized. In this study, an iterative CFD-based design tool developed for these novel propulsion systems is utilized to design a reference engine, having a classic rotor–stator configuration. Being the key component of this propulsor, a manufacturing process for composite blades is presented. This effort aims to make state-of-the-art technology accessible to smaller research projects, promoting the widespread adoption of electric propulsion technology in the aviation sector. By experimental investigations of the blade elongation both in tensile tests and engine operation, measuring the tip clearance with a high-speed camera, this process could be validated to facilitate the transferability of research. Finally, the performance of the manufactured engine is measured by a five-hole miniature probe, not only in design point but also in off-design operation. The results indicate that a substantial reduction in discrepancies between initial specifications, subsequent CFD simulations, and experimental investigations compared to conventional design tools relying on empirical formulations can be achieved due to the CFD-based approach. This allows the CFD-based tool to be validated for designing scalable contra-rotating fan engines. Full article

Oscillating Water Column (OWC) systems harness wave energy using a partially submerged chamber with an underwater opening. The Savonius turbine, a vertical-axis wind turbine, is well-suited for this purpose due to its efficiency at low speeds and self-starting capability, making it an ideal power take-off (PTO) mechanism in OWC systems. This study tested an OWC device with a Savonius turbine in an air duct to evaluate its performance under varying flow directions and loads. An innovative aspect was assessing the influence of power augmenters (PAs) positioned upstream and downstream of the turbine. The experimental setup included load cells, Pitot tubes, differential pressure sensors and rotational speed sensors. Data obtained were used to calculate pressure differentials across the turbine and torque. The primary goal of using PA is to increase the C_P–λ curve area without modifying the turbine geometry, potentially enabling interventions on existing turbines without rotor dismantling. Additionally, another novelty is the implementation of a regression Machine-Learning algorithm based on decision trees to analyze the influence of various features on predicting pressure differences, thereby broadening the scope for further testing beyond physical experimentation. Full article

The present paper is aimed at providing an updated review of prediction methods for the aerodynamic noise of ducted rotor–stator stages. Indeed, ducted rotating-blade technologies are in continuous evolution and are increasingly used for aeronautical propulsion units, power generation and air conditioning systems. Different needs are faced from the early design stage to the final definition of a machine. Fast-running, approximate analytical approaches and high-fidelity numerical simulations are considered the best-suited tools for each, respectively. Recent advances are discussed, with emphasis on their pros and cons. Full article

Thermal deformation of the rotor is a critical factor leading to radial air leakage in rotary air preheaters. However, previous studies have not comprehensively established the correlation between rotor thermal deformation during thermal operation and radial air leakage. This study addresses this gap by introducing a novel model for calculating radial air leakage, incorporating the thermal deformation of the rotor. To achieve this, we selected a three-section rotary air preheater from a 330 MW coal-fired unit boiler for investigation. This research begins by constructing a heat transfer–structure coupled numerical simulation model using Fluent and ANSYS Workbench. This model is employed to analyze the thermal deformation of the rotor under varying unit power generation loads. This paper meticulously examines the thermal deformation patterns of the rotor in diverse circumstances, explores their impact on air leakages, and provides a comprehensive analysis of air leakage fluctuations in different ducts. The influence of rotor thermal deformation on the local radial leak characteristics is ultimately established. The results indicate that incorporating the impact of preheater thermal deformation into the examination of preheater air leakage enhances the model’s capacity to accurately simulate values of leakage distribution at various cell clearances. This research concludes by offering recommendations for effectively managing hot end radial air leakage in preheater systems, providing valuable insights for the design and adjustment of sealing systems. Full article

This study provides an overview of new trends in the development of cooling systems for electric motors. It includes a summary of academic research and patents for cooling systems implemented by leading motor manufacturers at TRL9. New trends in the cooling management of air and liquid cooling systems are discussed and analyzed with a focus on temperature distribution and its influence on the power-to-dimension ratio of electric motors. The prevailing cooling method for synchronous and asynchronous motors is air cooling using external fins, air circulation ducts, air gaps, and fan impellers to enhance efficiency and reliability. Internal cooling with rotor and stator ducts, along with optimized air duct geometry, shows potential to increase the power-to-dimension ratio and reduce motor size. Liquid cooling systems offer a power-to-dimension ratio of up to 25 kW/kg, achieved through redesigned cooling ducts, stator heat exchangers, and cooling tubes. However, liquid cooling systems are complex, requiring maintenance and high ingress protection ratings. They are advantageous for providing high power-to-dimension ratios in vehicles and aircraft. Discussions on using different refrigerants to improve efficient motor cooling are underway, with ozone-friendly natural refrigerants like CO₂ considered to be promising alternatives to low-pressure refrigerants with high global warming potential. Full article

This paper deals with the problem of increasing the energy efficiency of a hybrid vertical take-off and landing aircraft. To this end, an innovative aerial vehicle was developed, featuring a distributed electrical propulsion system with ducted-fan rotors. To compare and analyze the effectiveness of the proposed propulsion system, two configurations with a different number of ducted-fan rotors were examined: a four-rotor configuration and a six-rotor configuration. The mathematical model of the four-rotor configuration was derived using the Newton–Euler formalism, allowing the design and implementation of a control strategy for conducting model-in-the-loop simulations. These simulations enabled the evaluation and analysis of the performance of the proposed propulsion system, where the numerical results demonstrated the functionality of both designs and showed that, during the multirotor flight, the configuration with six rotors increased its energy efficiency by up to 11%, providing higher vertical lift with the same power consumption. This was achieved by distributing its weight among a higher number of engines. The incorporation of two additional ducted fans increased the weight and the drag of the six-rotor configuration, resulting in a low augmentation in power consumption of 1%. Finally, this caused a decrease in airspeed by up to 4% during the cruise speed phase. Full article

This paper presents experimental investigations on aerodynamic performance of a ducted coaxial-rotor system to evaluate its potential application as a small unmanned aerial vehicle (SUAV). Aimed at determining the influence of design parameters (rotor spacing, tip clearance and rotor position within the duct) on hover performance, a variety of systematic measurements for several correlative configurations (single/coaxial rotor with or without a duct) in terms of thrust and torque, as well as power, were conducted in an attempt to identify a better aerodynamic configuration. The experimental results for the coaxial-rotor system indicated that varying rotor spacing affected the thrust-sharing proportion between the two rotors, but this had no significant effect on the propulsive efficiency. The optimal H/R ratio was identified as being 0.40, due to a larger thrust and stronger stability in the case of identical rotation speeds. As for the ducted single-rotor configuration, the tip clearance played a dominant role in improving its thrust performance, especially for smaller gaps ($\delta \le 0.015\mathrm{R}$), while the rotor position made subordinate contributions. The maximum performance was obtained with the rotor located at the P₅ position (0.31C_d from the duct lip), which resulted in an enhancement of approximately 20% in power loading over the isolated single rotor. When the coaxial rotors were surrounded within the duct, the system thrust for a given power degraded with the increasing rotor spacing, which was mainly attributed to the upper rotor suffering from heavier leakage losses. And hence, the ducted coaxial-rotor system with S₁ spacing had the best propulsion efficiency and hover performance with a figure of merit of 0.61. Full article

The purpose of the paper is to characterize the aerodynamic behavior of a rotor-downstream hub cavity rim seal in a high-pressure turbine (HPT) stage. The experimental data are acquired in the Transonic Test Turbine Facility at the Graz University of Technology: the test setup includes two engine-representative turbine stages (the last HPT stage and first LPT stage), with the intermediate turbine duct in between. All stator-rotor cavities are supplied with purge flows by a secondary air system, which simulates the bleeding air from the compressor stages of the real engine. The HPT downstream hub cavity is provided with wall taps and pitot tubes at different radial and circumferential locations, which allows the performance of steady pressure and seed gas concentration measurements for different purge mass flows and HPT vanes clocking positions. Moreover, miniaturized pressure transducers are adopted to evaluate the unsteady pressure distribution, and an oil flow visualization is performed to retrieve additional information on the wheel space structures. The annulus pressure asymmetry depends on the HPT vane clocking, but this is shown to have negligible impact on the minimum purge mass flow required to seal the cavity. However, the hub pressure profile drives the distribution of the cavity egress in the turbine channel. The unsteady pressure field is dominated by blade-synchronous oscillations. No non-synchronous components with comparable intensity are detected. Full article

With the expanding electrification in all sectors of transport, it is necessary to look for new efficient solutions for propulsion systems for use in air transport. One of the approaches can be the use of electric ducted fans (EDFs), especially in, but not limited to, the case of unmanned aerial vehicles with vertical takeoff and landing. This concept has been known for several decades but has been used very little and therefore has been almost unexplored. This opens up opportunities for investigating the performance characteristics, electrical consumption or efficient thrust vectoring of EDFs with respect to their design and operational use. The presented study therefore deals with the influence of the EDF design change on its performance characteristics. These design changes mainly concerned the geometry of the cowling, i.e., reduction and increase of outlet cross section, and arrangement of fans, i.e., one- and two-rotor specification. The comparison was based on measuring of vertical thrust and power consumption during static testing. The results showed that the increasing outlet is the most suitable construction for the generation of vertical thrust during static testing, considering the specifically used EDF construction arrangement. Based on the findings, it can also be concluded that EDFs are a suitable option for use in unmanned aircraft as a competition to other propulsion systems. Full article

Designing blades for efficient energy transfer by turning the flow and angular momentum change is both an art and iterative multidisciplinary engineering process. A robust parametric design tool with few inputs to create 3D blades for turbomachinery and rotating or non-rotating energy converters is described in this paper. The parameters include axial–radial coordinates of the leading/trailing edges, construction lines (streamlines), metal angles, thickness-to-chord ratio, standard, and user-defined airfoil type among others. Using these, 2D airfoils are created, conformally mapped to 3D stream surfaces, stacked radially with multiple options, and they are transformed to a 3D Cartesian coordinate system. Smooth changes in blade curvature are essential to ensure a smooth pressure distribution and attached flow. B-splines are used to control meanline curvature, thickness, leading edge shape, sweep-lean, and other parameters chordwise and spanwise, making the design iteration quick and easy. C2 curve continuity is achieved through parametric segments of cubic and quartic B-splines and is better than G2. New geometries using an efficient parametric scheme and minimal CAD interaction create watertight solid bodies and optional fluid domains. Several examples of ducted axial and radial turbomachinery with special airfoil shapes or otherwise, unducted rotors including propellers and wind and hydrokinetic turbines are presented to demonstrate versatility and robustness of the tool and can be easily tied to any automation chain and optimizer. Full article

A pump-jet propulsion system is composed of rotor, stator, and duct. The stator has the front stator type and the rear stator type; the conduit also has the acceleration conduit and the deceleration conduit two forms. It is difficult to design and evaluate the performance of a pump-jet propulsion system because of its complex structure and many changes in component parameters. Due to the limitation of time and cost in the design process of the pump-jet propulsion system, it is difficult to find the optimal scheme in the design space. However, under the guidance of an optimization algorithm, the automatic optimization method can fill the design space with a large number of design schemes. In this paper, the geometry reconstruction technique, hydraulic performance evaluation technique and optimization technique of the pump-jet propulsion system are combined to realize the automation of the whole design process. Firstly, the geometric modeling of the pump-jet propulsion system is completed by a full parametric modeling method, and then the hydrodynamic performance of the pump-jet propulsion system is calculated based on the numerical simulation technique. The radial parameters in the fully parametric configuration of the pump-jet propulsion system were selected as the optimization design variables, and the hydro-dynamic performance was optimized as the objective function. Finally, the pump-jet propulsion system optimization design system was constructed by using the global intelligent optimization algorithm. This study provides a theoretical basis and technical guidance for numerical calculation and configuration optimization design of pump-jet propulsion system. Full article
