In practical applications of droplet actuation using digital microfluidic (DMF) systems based on electrowetting-on-dielectric (EWOD), various electrode failures can still arise due to diverse operational conditions. To improve droplet transport efficiency, this study proposes a heuristic-elite genetic algorithm (HEGA) for droplet path planning. We introduce a heuristic method and a bidirectional elite fragment recombination method to address the challenge of poor initialization quality in genetic algorithms, particularly in complex environments. These approaches aim to enhance the global search capability and accelerate the algorithm’s convergence. Simulations were performed using MATLAB, and the results indicate that compared to the basic ant colony algorithm, the proposed method reduces the average number of turning points by approximately 17.23% and the average search time by about 92.60%. In multi-droplet transport applications, the algorithm generates optimal paths for test droplets while maintaining fast convergence. Additionally, it effectively prevents droplets from accidentally contacting or merging in non-synthesis areas, ensuring improved testing outcomes for the chip. Full article

Technologies based on digital microfluidics (DMF) have made significant advancements in the automated manipulation of microscale liquids and complex multistep processes. Due to their numerous benefits, such as automation, speed, cost-effectiveness, and minimal sample volume requirements, these systems are particularly well suited for immunoassays. In this review, an overview is provided of diverse DMF manipulation platforms and their applications in immunological analysis. Initially, droplet-driven DMF platforms based on electrowetting on dielectric (EWOD), magnetic manipulation, surface acoustic wave (SAW), and other related technologies are briefly introduced. The preparation of DMF is then described, including material selection, fabrication techniques and droplet generation. Subsequently, a comprehensive account of advancements in the integration of DMF with various immunoassay techniques is offered, encompassing colorimetric, direct chemiluminescence, enzymatic chemiluminescence, electrosensory, and other immunoassays. Ultimately, the potential challenges and future perspectives in this burgeoning field are delved into. Full article

With the continuous expansion of pixel arrays in digital microfluidics (DMF) chips, precise droplet control has emerged as a critical issue requiring detailed consideration. This paper proposes a novel capacitance-based droplet sensing system for thin-film transistor DMF. The proposed circuit features a distinctive inner and outer dual-pixel electrode structure, integrating droplet driving and sensing functionalities. Discharge occurs exclusively at the inner electrode during droplet sensing, effectively addressing droplet perturbation in existing sensing circuits. The circuit employs a novel fan-shaped structure of thin-film transistors. Simulation results show that it can provide a 48 V pixel voltage and demonstrate a sensing voltage difference of over 10 V between deionized water and silicone oil, illustrating its proficiency in droplet driving and accurate sensing. The stability of threshold voltage drift and temperature was also verified for the circuit. The design is tailored for integration into active matrix electrowetting-on-dielectric (AM-EWOD) chips, offering a novel approach to achieve precise closed-loop control of droplets. Full article

The rapid quantification of nitrate nitrogen concentration plays a pivotal role in monitoring soil nutrient content. Nevertheless, the low detection efficiency limits the application of traditional methods in rapid testing. For this investigation, we utilized a digital microfluidic platform and 3D-printed microfluidics to accomplish automated detection of soil nitrate nitrogen with high sensitivity across numerous samples. The system combines digital microfluidics (DMF), 3D-printed microfluidics, a peristaltic pump, and a spectrometer. The soil solution, obtained after extraction, was dispensed onto the digital microfluidic platform using a micropipette. The digital microfluidic platform regulated the movement of droplets until they reached the injection area, where they were then aspirated into the 3D-printed microfluidic device for absorbance detection. Implementing this approach allows for the convenient sequential testing of multi-samples, thereby enhancing the efficiency of nitrate nitrogen detection. The results demonstrate that the device exhibits rapid detection (200 s for three samples), low reagent consumption (40 µL per sample), and low detection limit (95 µg/L). In addition, the relative error between the detected concentration and the concentration measured by ultraviolet spectrophotometry is kept within 20%, and the relative standard deviation (RSD) of the measured soil samples is between 0.9% and 4.7%. In the foreseeable future, this device will play a significant role in improving the efficiency of soil nutrient detection and guiding fertilization practices. Full article

Real-time pH control on-chip is a crucial factor for cell-based experiments in microfluidics, yet difficult to realize. In this paper, we present a flexible pH regulator on a digital microfluidic (DMF) platform. The pico-dosing technology, which can generate and transfer satellite droplets, is presented to deliver alkali/acid into the sample solution to change the pH value of the sample. An image analysis method based on ImageJ is developed to calculate the delivered volume and an on-chip colorimetric method is proposed to determine the pH value of the sample solution containing the acid-base indicator. The calculated pH values show consistency with the measured ones. Our approach makes the real-time pH control of the on-chip biological experiment more easy to control and flexible. Full article

Microfluidic-based platforms have become a hallmark for chemical and biological assays, empowering micro- and nano-reaction vessels. The fusion of microfluidic technologies (digital microfluidics, continuous-flow microfluidics, and droplet microfluidics, just to name a few) presents great potential for overcoming the inherent limitations of each approach, while also elevating their respective strengths. This work exploits the combination of digital microfluidics (DMF) and droplet microfluidics (DrMF) on a single substrate, where DMF enables droplet mixing and further acts as a controlled liquid supplier for a high-throughput nano-liter droplet generator. Droplet generation is performed at a flow-focusing region, operating on dual pressure: negative pressure applied to the aqueous phase and positive pressure applied to the oil phase. We evaluate the droplets produced with our hybrid DMF–DrMF devices in terms of droplet volume, speed, and production frequency and further compare them with standalone DrMF devices. Both types of devices enable customizable droplet production (various volumes and circulation speeds), yet hybrid DMF–DrMF devices yield more controlled droplet production while achieving throughputs that are similar to standalone DrMF devices. These hybrid devices enable the production of up to four droplets per second, which reach a maximum circulation speed close to 1540 µm/s and volumes as low as 0.5 nL. Full article

Poly(p-xylylene) derivatives, widely known as Parylenes, have been considerably adopted by the scientific community for several applications, ranging from simple passive coatings to active device components. Here, we explore the thermal, structural, and electrical properties of Parylene C, and further present a variety of electronic devices featuring this polymer: transistors, capacitors, and digital microfluidic (DMF) devices. We evaluate transistors produced with Parylene C as a dielectric, substrate, and encapsulation layer, either semitransparent or fully transparent. Such transistors exhibit steep transfer curves and subthreshold slopes of 0.26 V/dec, negligible gate leak currents, and fair mobilities. Furthermore, we characterize MIM (metal–insulator–metal) structures with Parylene C as a dielectric and demonstrate the functionality of the polymer deposited in single and double layers under temperature and AC signal stimuli, mimicking the DMF stimuli. Applying temperature generally leads to a decrease in the capacitance of the dielectric layer, whereas applying an AC signal leads to an increase in said capacitance for double-layered Parylene C only. By applying the two stimuli, the capacitance seems to suffer from a balanced influence of both the separated stimuli. Lastly, we demonstrate that DMF devices with double-layered Parylene C allow for faster droplet motion and enable long nucleic acid amplification reactions. Full article

Indium tin oxide (ITO)-based digital microfluidics (DMF) with unique optical and electrical properties are promising in the development of integrated, automatic and portable analytical systems. The fabrication technique using laser direct etching (LDE) on ITO glass has the advantages of being rapid, low cost and convenient. However, the fabrication resolution of LDE limits the minimum line width for patterns on ITO glasses, leading to a related wider lead wire for the actuating electrodes of DMF compared with photolithography. Therefore, the lead wire of electrodes could affect the droplet motion on the digital microfluidic chip due to the increased contact line with the droplet. Herein, we developed a finite element model of a DMF with improved efficiency to investigate the effect of the lead wire. An optimized electrode pattern was then designed based on a theoretical analysis and validated by a simulation, which significantly decreased the deformation of the droplets down to 0.012 mm. The performance of the optimized electrode was also verified in an experiment. The proposed simulation method could be further extended to other DMF systems or applications to provide an efficient approach for the design and optimization of DMF chips. Full article

Digital microfluidics (DMF) is a versatile platform for conducting a variety of biological and chemical assays. The most commonly used set-up for the actuation of microliter droplets is electrowetting on dielectric (EWOD), where the liquid is moved by an electrostatic force on a dielectric layer. Superhydrophobic materials are promising materials for dielectric layers, especially since the minimum contact between droplet and surface is key for low adhesion of biomolecules, as it causes droplet pinning and cross contamination. However, superhydrophobic surfaces show limitations, such as full wetting transition between Cassie and Wenzel under applied voltage, expensive and complex fabrication and difficult integration into already existing devices. Here we present Fluoropor, a superhydrophobic fluorinated polymer foam with pores on the micro/nanoscale as a dielectric layer in DMF. Fluoropor shows stable wetting properties with no significant changes in the wetting behavior, or full wetting transition, until potentials of 400 V. Furthermore, Fluoropor shows low attachment of biomolecules to the surface upon droplet movement. Due to its simple fabrication process, its resistance to adhesion of biomolecules and the fact it is capable of being integrated and exchanged as thin films into commercial DMF devices, Fluoropor is a promising material for wide application in DMF. Full article

The dynamic immune response to various diseases and therapies has been considered a promising indicator of disease status and therapeutic effectiveness. For instance, the human peripheral blood mononuclear cell (PBMC), as a major player in the immune system, is an important index to indicate a patient’s immune function. Therefore, establishing a simple yet sensitive tool that can frequently assess the immune system during the course of disease and treatment is of great importance. This study introduced an integrated system that includes an electrochemical impedance spectroscope (EIS)-based biosensor in a digital microfluidic (DMF) device, to quantify the PBMC abundance with minimally trained hands. Moreover, we exploited the unique droplet manipulation feature of the DMF platform and conducted a dynamic cell capture assay, which enhanced the detection signal by 2.4-fold. This integrated system was able to detect as few as 10⁴ PBMCs per mL, presenting suitable sensitivity to quantify PBMCs. This integrated system is easy-to-operate and sensitive, and therefore holds great potential as a powerful tool to profile immune-mediated therapeutic responses in a timely manner, which can be further evolved as a point-of-care diagnostic device to conduct near-patient tests from blood samples. Full article

Contact charge electrophoresis (CCEP) is an electrically controllable manipulation technique of conductive droplets and particles by charging and discharging when in contact with the electrode. Given its straightforward operation mechanism, low cost, and ease of system construction, it has gained traction as a versatile and potential strategy for the realistic establishment of lab-on-a-chip (LOC) in various engineering applications. We present a CCEP-based digital microfluidics (DMF) platform with two parallel electrode modules comprising assembled conventional pin header sockets, allowing for efficient mixing through horizontal and vertical shaking via droplet reciprocating motions. The temporal chromic change caused by the chemical reaction between the pH indicator and base solutions within the shaking droplets is quantitatively analyzed under various CCEP actuation conditions to evaluate the mixing performance in shaking droplets by vertical and horizontal reciprocating motions on the DMF platform. Furthermore, mixing flow patterns within shaking droplets are successfully visualized by a high-speed camera system. The suggested techniques can mix samples and reagents rapidly and efficiently in droplet-based microreactors for DMF applications, such as biochemical analysis and medical diagnostics. Full article

We introduce a digital microfluidics (DMF) platform specifically designed to perform a loop-mediated isothermal amplification (LAMP) of DNA and applied it to a real-time amplification to monitor a cancer biomarker, c-Myc (associated to 40% of all human tumors), using fluorescence microscopy. We demonstrate the full manipulation of the sample and reagents on the DMF platform, resulting in the successful amplification of 90 pg of the target DNA (0.5 ng/µL) in less than one hour. Furthermore, we test the efficiency of an innovative mixing strategy in DMF by employing two mixing methodologies onto the DMF droplets—low frequency AC (alternating current) actuation as well as back-and-forth droplet motion—which allows for improved fluorescence readouts. Fluorophore bleaching effects are minimized through on-chip sample partitioning by DMF processes and sequential droplet irradiation. Finally, LAMP reactions require only 2 µL volume droplets, which represents a 10-fold volume reduction in comparison to benchtop LAMP. Full article

Point-of-care (POC) tests capable of individual health monitoring, transmission reduction, and contact tracing are especially important in a pandemic such as the coronavirus disease 2019 (COVID-19). We develop a disposable POC cartridge that can be mass produced to detect the SARS-CoV-2 N gene through real-time quantitative polymerase chain reaction (qPCR) based on digital microfluidics (DMF). Several critical parameters are studied and improved, including droplet volume consistency, temperature uniformity, and fluorescence intensity linearity on the designed DMF cartridge. The qPCR results showed high accuracy and efficiency for two primer-probe sets of N1 and N2 target regions of the SARS-CoV-2 N gene on the DMF cartridge. Having multiple droplet tracks for qPCR, the presented DMF cartridge can perform multiple tests and controls at once. Full article

Digital microfluidic (DMF) has been a unique tool for manipulating micro-droplets with high flexibility and accuracy. To extend the application of DMF for automatic and in-site detection, it is promising to introduce colorimetric sensing based on gold nanoparticles (AuNPs), which have advantages including high sensitivity, label-free, biocompatibility, and easy surface modification. However, there is still a lack of studies for investigating the movement and stability of AuNPs for in-site detection on the electrowetting-based digital microfluidics. Herein, to demonstrate the ability of DMF for colorimetric sensing with AuNPs, we investigated the electrowetting property of the AuNPs droplets on the hydrophobic interface of the DMF chip and examined the stability of the AuNPs on DMF as well as the influence of evaporation to the colorimetric sensing. As a result, we found that the electrowetting of AuNPs fits to a modified Young–Lippmann equation, which suggests that a higher voltage is required to actuate AuNPs droplets compared with actuating water droplets. Moreover, the stability of AuNPs was maintained during the processing of electrowetting. We also proved that the evaporation of droplets has a limited influence on the detections that last several minutes. Finally, a model experiment for the detection of Hg²⁺ was carried out with similar results to the detections in bulk solution. The proposed method can be further extended to a wide range of AuNPs-based detection for label-free, automatic, and low-cost detection of small molecules, biomarkers, and metal ions. Full article
