Integration of renewable energy sources into existing residential and communal district heating systems requires technical adjustments and corrections. Measures aimed at reducing heat consumption at the points of delivery have a similar impact. This study aims, through simplified partial models (in heating mode), to present the relationships between these modifications and their potential effects on operational problems and deficiencies. The main parameters assessed in the design and correction of systems are temperature differentials, derived flow rates, pumping work, and control methods. Within the chain of heat source–primary distribution–secondary distribution–consumers, the analysis focuses on secondary circuits with consumers. A simplified multi-building network model was used to compare static and dynamic control strategies under temperature regimes of 70/50 °C, 60/40 °C, and 40/30 °C. The results show that dynamic control based on variable-frequency pumps, weather-compensated supply regulation, and optimized temperature differences between supply and return lines (ΔT) reduces pumping energy by 30–40% and increases heat delivery efficiency by up to 10%. A significant reduction in CO₂ emissions is also observed due to decreased pumping work, reduced heat losses in the distribution network, and the integration of renewable energy sources. The savings depend on the type and extent of RES utilization. The implementation of dynamic control in these systems significantly improves exergy efficiency, operational stability, and the potential for low-temperature operation, thus providing a practical framework for the modernization of district heating networks. Full article

Water distribution and pumping systems consume a large share of energy in metro HVAC operations and remain a major challenge to energy-efficient performance. This study, grounded in a practical metro project, investigates four control strategies for chilled water systems, focusing on chiller sequencing, pump frequency modulation, and variable flow regulation. A dynamic system model was developed using Dymola to simulate and evaluate the performance of each strategy. The results indicate that Strategy 2, which integrates real-time outdoor weather parameters into the frequency control logic, enhances operational stability and maintainability while achieving a 4.42% reduction in total energy consumption compared to the baseline. Strategy 4 employs a genetic algorithm to optimize chiller load distribution, resulting in improved system efficiency and energy savings of up to 8.62%. Further analysis reveals that chillers account for approximately 80% of the system’s total energy consumption, underscoring their central importance in system-wide energy optimization. Additionally, cooling towers show significant energy-saving potential under low wet-bulb temperatures. A 1 °C decrease in wet-bulb temperature results in an estimated 7% reduction in energy use. These findings offer quantitative insights and practical guidance for the low-carbon optimization of metro chilled water systems. Full article

The non-uniform thermal distribution in the active neutral-point clamped (ANPC) topology causes significant thermal gradients during high-power operation, restricting its use in large-capacity power conversion systems like variable-speed pumped storage. This study introduces a novel hybrid fundamental frequency modulation strategy. Through a dynamic allocation mechanism based on a reference signal, this strategy alternates inner and outer power switches at the fundamental frequency, ensuring balanced switching frequency across devices. Consequently, it effectively mitigates the inherent loss imbalance in conventional ANPC topologies. Quantitative analysis using a power device loss model shows that, compared to conventional carrier phase-shift modulation, the proposed method reduces total system losses by 39.98% and improves the loss-balancing index by 18.27% over inner-switch fundamental frequency modulation. A multidimensional validation framework, including an MW-level hardware platform, numerical simulations, and test data, was established. The results confirm the proposed strategy’s effectiveness in improving power device thermal balance. Full article

The accurate prediction of moisture content is crucial for controlling the drying process of agricultural products. While existing studies on drying models often rely on laboratory-scale experiments with limited data, real-time and high-frequency data collection under industrial conditions remains underexplored. This study collected and constructed a multi-dimensional dataset using an industrial-grade data acquisition system specifically designed for heat pump low-temperature circulating dryers. An artificial neural network (ANN) prediction model for moisture content during the rice drying process was developed. To prevent model overfitting, K-fold cross-validation was utilized. The model’s performance was evaluated using the mean squared error (MSE) and the coefficient of determination (R²), which also helped determine the preliminary structure of the ANN model. Bayesian regularization (trainbr) was then employed to train the network. Furthermore, optimization was conducted using neural network weights (RI) analysis and Sobol variance contribution analysis of the input variables to simplify the model structure and improve predictive performance. The experimental results showed that optimizing the model through RI sensitivity analysis simplified its topology to a 5-14-1 structure. The optimized model exhibited not only simplicity but also high prediction accuracy, achieving R² values of 0.969 and 0.966 for the training and testing sets, respectively, with MSEs of 5.6 × 10⁻³ and 6.3 × 10⁻³. Additionally, the residual errors followed a normal distribution, indicating that the predictions were reliable and realistic. Statistical tests such as t-tests, F-tests, and Kolmogorov–Smirnov tests revealed no significant differences between the predicted and actual values of rice moisture content, confirming the high consistency between them. Full article

This study investigates the transient behavior of a single-blade centrifugal pump under variable frequency speed regulation, with the objective of enhancing both pump efficiency and operational stability under variable frequency conditions. By integrating numerical simulations, external characteristic tests, and Particle Image Velocimetry (PIV) flow field experiments, the research provides a comprehensive analysis of the dynamic performance of the pump. The accuracy of the numerical simulations is first validated through a comparison between CFD results and experimental data, both at rated and variable speeds. This study then explores the transient external performance, internal flow patterns, and radial force characteristics of the pump under various speed-change schemes. In the process of acceleration, the variation trend of the centrifugal pump head and speed is basically the same, and Scheme 3 shows better stability; Scheme 2 minimizes the fluctuation of shaft power; with the increase in speed, the pressure and flow field in the pump will appear to be unstable. In the deceleration process, the Scheme 3 head fluctuates less, the change in shaft power is the most stable, and the more uniform pressure distribution and stable flow field can be maintained. The radial force increases with the increase in speed, but the degree of radial force fluctuation is different among different schemes. These findings offer valuable insights into the dynamic performance of centrifugal pumps under variable speed conditions and provide a foundation for optimizing both pump design and operational strategies. Full article

A variable-speed pump-turbine is the core component of a hydraulic storage and energy generation station. When the pump-turbine operates at a constant speed, its response to the power grid frequency is poor. In order to improve the hydraulic efficiency of the pumped storage unit, variable-speed units are used. However, there has been no numerical study on the effect of the rotational flow characteristics within the gap of a variable-speed pump-turbine. This paper calculates the flow characteristics within the gap of a variable-speed pump-turbine under three typical pump modes (maximum head minimum flow condition, minimum head maximum flow condition, and maximum speed condition). The research results indicate that the rotational speed significantly affects the pressure distribution, velocity distribution, and turbulent kinetic energy distribution within the crown and band gaps. The higher the speed, the larger the area of the high-pressure region before the runner inlet compared to other operating conditions, and similarly, the low-pressure area after the runner outlet is also larger than in other operating conditions. The change in speed mainly affects the internal flow field of the crown gap, with the most noticeable changes occurring in the pressure and flow velocity at the inlet and outlet of the crown gap. There is a clear trend of pressure drop and velocity increase within the gap as the speed increases. However, with the increase in speed, the pressure distribution and flow velocity within the band gap remain almost the same. In addition to speed changes, it is observed that the pressure within the gap and the flow velocity within the passages are also related to the head, especially in the condition of maximum head, where this relationship becomes more noticeable. Full article

In order to study the internal flow characteristics of the electric submersible pump (ESP) when the gas–liquid two-phase flow is conveyed by the variable frequency variable speed operation and the change of the imported gas content, the impeller of the Q10# ESP is taken as the research object, based on the Eulerian-Eulerian non-homogeneous phase. The flow model, the unsteady Reynolds time-averaged N-S equation, and the standard k-ε turbulence model are used for transient simulation calculations of the gas–liquid two-phase flow in the impeller of the ESP. Calculations show that with the rotation of the impeller, the gas phase is unevenly distributed in the flow channel. The gas phase is mainly concentrated on the inlet side of the flow channel near the front cover, and the gas phase exhibits periodic aggregation and diffusion in the flow channel. When the impeller speed increases, the period of periodic accumulation and diffusion of gas in the flow channel is shortened and the gas concentration in the impeller decreases, the overall flow velocity in the flow channel increases, and the pressure difference between the inlet and outlet increases. The pressure difference between the two sides of the blade is proportional to the speed of the impeller, and the fluctuation frequency of the blade surface also increases. As the gas content increases, the maximum concentration of gas phase in the flow channel increases. The area occupied by the high concentration of gas phase in the flow channel expands toward the blade’s working surface, and periodically accumulates, diffuses, and grows. The gas-liquid splitting area shrinks toward the front cover side and the pump. The internal pressure increases slightly, the main flow velocity increases, and the vortex action range increases. Full article

Pumped storage power stations can ensure the safe operation of the grid, as well as utilize clean energy sources to establish a low-carbon, safe, and efficient energy system. As pump turbines, the core components of pumped storage power plants, become more and more popular, the technical requirements for hydraulic design begin to improve year by year. However, when the unit operates far beyond the optimal range, the variable-speed pump turbine can overcome the shortcomings of the fixed-speed unit and solve the problem of unstable operation under partial load. The pressure pulsation of the unit in the pump condition is investigated by numerical simulation, analyzing the hydraulic thrust, and studying the dynamic response characteristics of the runner at a maximum speed of 456.5 rpm. Comparing the pressure pulsation amplitude of various components in the entire flow passage, the highest values of pressure pulsation were found in the runner and vaneless space. The axial hydraulic thrust has a fluctuation range between 174t and 198t and 0t to 40t for radial force. As per the structural analysis, it has been observed that the runner demonstrates uneven patterns in both its axial and radial deformations, with deformation mainly concentrated in radial displacement and stress distribution mainly concentrated on the blades near the crown. The dynamic stress amplitude of the runner at monitoring point S1 (located on the runner blade near the crown) is 37 MPa. This stress has a dominant frequency of 4.8f_n, while the monitoring point S2 (located on the runner blade near the band) is 4 MPa, and the dominant frequency is 1.8f_n. Using these findings, the design of the variable-speed pump turbine’s runner can be optimized, and the unit’s stable and secure operation can be guided accordingly. Full article

In order to investigate the influence of variable voltage and variable frequency (VVVF) regulation on the cavitation performance of the axial-flow pump, numerical simulation and experiments were used to analyze the cavitation performance of an axial-flow pump under different VVVF modes. The VVVF modes were uniform acceleration with constant acceleration, variable acceleration with increasing acceleration, variable acceleration with decreasing acceleration, and its corresponding deceleration scheme. Furthermore, a comprehensive performance test rig was built for the pump to carry out cavitation visualization tests which verified the accuracy of numerical simulation. For the uniform acceleration scheme with constant acceleration, the change of flow field inside the impeller was stable, the expansion rate of cavitation was slow, and the growth rate of the cavitation volume was the slowest. For the variable acceleration scheme with decreasing acceleration, the cavitation extended rapidly due to the large initial velocity. For the variable acceleration scheme with increasing acceleration, cavitation extension was the slowest. The growth rate of the cavity volume of the two variable acceleration schemes was faster than that of the uniform acceleration scheme, and the changing trend was consistent. This feature indicates that the impeller rotation speed has a significant impact on cavitation, and excessive rotation speed will rapidly extend the cavitation. By monitoring the influence of cavitation on pressure distribution under VVVF, it was shown that the three acceleration schemes all produce large pressure fluctuation. For the uniform acceleration scheme with constant acceleration, the fluctuation range of pressure was more balanced, and the pressure dropped slowly. For the acceleration scheme with higher acceleration, the pressure fluctuation amplitude increased in the late stage of acceleration and the pressure decline speed accelerated. For the acceleration scheme with decreasing acceleration, the pressure showed a downward trend with violent fluctuations in the early stage and gradually tended to be flat in the late stage. Full article

In electrical machinery, the rotor windings’ internal short-circuit faults are addressed by the instantaneous over-current protection of the power electronic excitation device, which has low sensitivity and has difficulty meeting the safety requirements. In this paper, a rotor windings’ internal short-circuit fault protection method is proposed based on the harmonic characteristics of the circulating current between stator branches. The magnetomotive force distribution of the short-circuit coils in the rotor windings is theoretically deduced, and the characteristic frequencies of the circulating current between stator branches are analyzed. On this basis, the protection criterion of the rotor windings’ internal short-circuit fault is constructed by using the harmonic component of the circulating current. Then, an analytic model of the variable-speed pumped storage unit is established based on the multi-loop method, and the finite element method is used to verify the correctness of the proposed modeling method. An actual large variable-speed pumped storage unit is taken as an example, and the possible faults under different slip ratios are simulated. In the simulation results, the stator branch circulation has the obvious characteristic frequency harmonic components, which is consistent with the theoretical analysis. It verifies the effectiveness of the proposed protection method. Finally, it is analyzed and verified that the proposed protection has a strong maloperation prevention ability under other kinds of faults. Full article

In order to explore the change in internal and external characteristics and the pressure fluctuation of the large bulb tubular pump unit during deceleration, a transient and steady three-dimensional (3D) numerical simulation is executed, based on the standard k-ε turbulence model and the change in boundary conditions such as flow rate. Finally, the pressure fluctuation data are analyzed by the wavelet method. There is a good agreement between the experimental data and numerical simulation results. During the deceleration process of the unit, the head decreases linearly while the efficiency remains stable. Meanwhile, the shock phenomenon and hysteresis effect appear before and after the unit head deceleration. Although there are vortex and backflow in the outlet conduit during deceleration, the pressure distribution on the suction surface of the impeller blades changes uniformly and significantly. The pressure fluctuation changes on the inlet surface of the impeller are more obvious during the deceleration: the closer to the hub, the greater the pressure, and this change decreases with decreasing radius. The fluctuation energy is mainly concentrated in the high-frequency region of 100–120 Hz and decreases uniformly with the deceleration of the rotational speed. This paper provides a reference for the energy utilization and safe operation of the water pump unit in adjusting speeds with variable frequency. Full article

Under the condition of variable rotating speed, it is difficult to extract the degradation characteristics of the axial piston pump, which also reduces the accuracy of degradation recognition. To address these problems, this paper proposes a degradation state recognition method for axial piston pumps by combining spline-kernelled chirplet transform (SCT), adaptive chirp mode pursuit (ACMP), and extreme gradient boosting (XGBoost). Firstly, SCT and ACMP are proposed to deal with the vibration signal instability and high noise of the axial piston pump under variable rotating speed. The instantaneous frequency (IF) of the axial piston pump can be extracted effectively by obtaining the accurate time-frequency distribution of signal components. Then, stable angular domain vibration signals are obtained by re-sampling, and multi-dimensional degradation characteristics are extracted from the angular domain and order spectrum. Finally, XGBoost is used to classify the selected characteristics to recognize the degradation state. In this paper, the vibration signals in four different degradation states are collected and analyzed through the wear test of the valve plate of the axial piston pump. Compared with different pattern recognition algorithms, it is verified that this method can ensure high recognition accuracy. Full article

Rotor-stator interaction (RSI) in the centrifugal pump-as-turbine (PAT) is a significant source of high amplitude of the pressure pulsation and the flow-induced vibration, which is detrimental to the stable operation of PAT. It is therefore imperative to analyze the rotor-stator interaction, which can subsequently be used as a guideline for reducing the output of PAT noise, vibration and cavitation. In addition, it is important for a PAT to have a wide operating range preferably at maximum efficiency. In order to broaden the operating range, this work proposes a multi-condition optimization scheme based on numerical simulations to improve the performance of a centrifugal PAT. In this paper, the optimization of PAT impeller design variables (b₂, β₁, β₂ and z) was investigated to shed light upon its influence on the output efficiency and its internal flow characteristics. Thus, the aim of the study is to examine the unsteady pressure pulsation distributions within the PAT flow zones as a result of the impeller geometric optimization. The numerical results of the baseline model are validated by the experimental test for numerical accuracy of the PAT. The optimized efficiencies based on three operating conditions (1.0Q_d, 1.2Q_d, and 1.4Q_d) were maximally increased by 13.1%, 8.67% and 10.62%, respectively. The numerical results show that for the distribution of PAT pressure pulsations, the RSI is the main controlling factor where the dominant frequencies were the blade passing frequency (BPF) and its harmonics. In addition, among the three selected optimum cases, the optimized case C model exhibited the highest level of pressure pulsation amplitudes, while optimized case B reported the lowest level of pressure pulsation. Full article

The growth in the integration of converter interfaced renewable energy has reduced the system inertia, which threatens system stability due to high rate of change of frequency (RoCoF) and frequency nadir issues unless steps are taken to mitigate it. There is a need to provide sufficient fast frequency response to maintain adequate inertia in the system. This paper investigates the capabilities of a variable speed heat pump to provide an emulated inertial response. This paper presents a virtual synchronous machine control for a variable speed heat pump that provides support for grid frequency regulation over the inertial response time frame. A small-signal model with the transfer function of the variable speed heat pump is developed to analyse the effectiveness and feasibility of providing virtual inertia at the device and grid level, respectively. Furthermore, the small-signal model is validated using hardware in the loop simulation. Finally, the aggregated frequency response and virtual inertia contribution by a population of the heat pumps are evaluated and quantified in an urban distribution system. Full article

Environmental goals set by world leaders to normalize climate changes are quite difficult to achieve without renewable power generation and suitable transmission technologies like low-frequency AC transmission (LFAC). The LFAC is nowadays becoming a popular choice for long-distance power transmission due to its high efficiency and low losses. This research work investigates the feasibility of employing the LFAC system for subsea transmission and distribution of 58 MW power. In this paper, the simulation model of the LFAC-based subsea transmission and distribution system is presented. This model is composed of several parts such as hexverter as a frequency converter, where a novel control strategy to optimize its zero-sequence circulating current is employed. Detailed mathematical modeling based on active, reactive power constraints and DQ transformation is performed to achieve the control strategy for zero-sequence current optimization. An offshore wind farm is proposed to be integrated with the LFAC subsea system to fulfill the compatibility requirements of the system. The control system of both the grid side and the machine-side inverter of the wind farm is designed to eliminate the real-time disturbances such as wind speed fluctuations and harmonics due to heavy inductive load operating at 16 Hz. To drive the subsea pump, a vector control-based variable-speed drive is employed for the heavy induction motor. A 5 MW, 16 Hz RL load is also added in the model to analyze the effect of general-purpose load. Each component of this system is carefully designed to make it as close to real-time as possible. The whole system is designed for 16 Hz and is compared with the standard 50 Hz system to validate this design. Full article
