Search Results (176)

Distributed fiber-optic sensing (DFOS) with intentionally spaced mechanical fixity points was experimentally evaluated for the structural health monitoring (SHM) of reinforced concrete (RC) members. A full-scale four-point bending test was conducted on a 12 m RC beam (400 × 400 mm) instrumented with a single-mode DFOS cable incorporating internal anchors at 2 m intervals and bonded externally with structural epoxy. Brillouin time-domain analysis (BOTDA) provided distributed strain measurements at approximately 0.5 m spatial resolution, with all cables calibrated to ±15,000 µε. Under stepwise monotonic loading, the system captured smooth, repeatable strain baselines and clearly resolved localized tensile peaks associated with crack initiation and propagation. Long-gauge averages exhibited a near-linear load–strain response (R² ≈ 0.99) consistent with discrete foil and vibrating-wire strain gauges. Even after cracking, the DFOS signal remained continuous, while some discrete sensors showed saturation or scatter. Temperature compensation via a parallel fiber ensured thermally stable interpretation during load holds. The fixed-point configuration mitigated local debonding effects and yielded unbiased long-gauge strain data suitable for assessing serviceability and differential settlement. Overall, the results confirm the suitability of fixed-point DFOS as a durable, SHM-ready sensing approach for RC foundation elements and as a dense data source for emerging digital-twin frameworks. Full article

Distributed acoustic sensing (DAS) technology is gaining popularity for real-time monitoring during the hydraulic fracturing of unconventional reservoirs. By transforming a standard optical fiber into a dense array of acoustic sensors, DAS provides continuous spatiotemporal measurements along the entire wellbore. Although accurate DAS-based real-time diagnosis of multistage hydraulic fracturing is critical for optimizing the efficiency of stimulation operations and mitigating operational risks in horizontal tight oil wells, existing methods often fail to provide integrated qualitative and quantitative insights. To address this gap, we present an original diagnostic workflow that synergistically combines frequency band energy (FBE), low-frequency DAS (LF-DAS), and surface injection data for simultaneous fluid/proppant allocation and key downhole anomaly identification. Field application of the proposed framework in a 47-stage well demonstrates that FBE (50–200 Hz) enables robust cluster-level volume estimation, while LF-DAS (<0.5 Hz) reveals fiber strain signatures indicative of mechanical integrity threats. The workflow can successfully diagnose sand screenout, diversion, out-of-zone flow, and early fiber failure—events often missed by conventional monitoring. By linking distinct acoustic fingerprints to specific physical processes, our approach transforms raw DAS data into actionable operational intelligence. This study provides a reproducible, field-validated framework that enhances understanding in the context of fracture treatment, supports real-time decision making, and paves the way for automated DAS interpretation in complex completions. Full article

The primary objective of layered settlement monitoring of deep soil is to obtain settlement data for both the soil and superstructure, enabling appropriate measures to be taken to ensure the structure’s safety and stability. Traditional deep soil monitoring technologies are either limited in the number of measurement points (e.g., fiber Bragg grating sensing technology) or exhibit low measurement accuracy (e.g., distributed fiber optic sensing technology). This study proposes a layered settlement monitoring technique for deep soil based on the ultra-weak fiber Bragg grating sensors. First, ultra-weak fiber Bragg grating strain sensors packaged by fiber-reinforced polymer (FRP) were developed, and experimental research on the sensors’ sensing and directional recognition characteristics was conducted. Subsequently, the sensors were deployed for ground subsidence monitoring in Gaoyang County, China, with investigations conducted on sensor installation techniques and long-term measurement data. Experimental and engineering test results demonstrate that the strain and temperature sensing coefficients of the sensors are 1.22 pm/με and 17.06 pm/°C, respectively. Sensors incorporating dual ultra-weak fiber Bragg grating arrays can simultaneously detect both vertical and lateral soil displacement. Long-term monitoring data effectively reflects subsidence changes in the Gaoyang region. Full article

This review summarizes recent progress and emerging trends in multiparameter optical fiber sensing, emphasizing techniques that enable the simultaneous measurement of temperature, strain, acoustic waves, pressure, and other environmental quantities within a single sensing network. Such capabilities are increasingly important for structural health monitoring, environmental surveillance, industrial diagnostics, and geophysical observation, where multiple stimuli act on the fiber simultaneously. The paper outlines the physical principles and architectures underlying these systems and focuses on strategies for compensating and decoupling cross-sensitivity among measured parameters. Special attention is devoted to advanced distributed sensing schemes based on coherent optical frequency-domain reflectometry (C-OFDR), coherent phase-sensitive time-domain reflectometry (Φ-OTDR), and Brillouin optical time-domain reflectometry (BOTDR). Their theoretical foundations, their signal-processing algorithms, and the design modifications that improve parameter discrimination and accuracy are analyzed and compared. The review also highlights the roles of polarization and mode diversity and the growing application of machine-learning techniques in the interpretation and calibration of data. Finally, current challenges and promising directions for the next generation of fiber-optic multiparameter sensors are outlined, with a view toward high-resolution, low-cost, and field-deployable solutions for real-world monitoring applications. Full article

Deformation monitoring of heavy-haul railway tunnels is essential for ensuring operational safety. However, the spatial resolution of traditional point-based sensors is often insufficient for capturing the continuous deformation fields of tunnel structures. To overcome this limitation, in this study, densely distributed strain data that are acquired through distributed fiber-optic sensing technology are used, and a deep learning-based inversion framework that integrates high-resolution strain measurements with sparsely sampled convergence data is introduced. By employing a hybrid particle swarm optimization–random forest (PSO-RF) algorithm, a deep correlation model is constructed to establish the relationship between distributed strain profiles and discrete convergence measurements. This approach enables the prediction of cross-sectional convergence across multiple tunnel sections by using only a limited set of calibrated convergence sensors in combination with continuous strain field data, thereby effectively achieving global deformation inversion with minimal hardware deployment. The proposed method was validated through numerical simulations and field tests by using monitoring data from a heavy-haul railway tunnel. The algorithm exhibited a mean absolute error of less than 2 mm, thus demonstrating its ability to supply high-resolution deformation field data that are essential for structural health monitoring and diagnostics of tunnel infrastructures. Full article

Geohazards pose significant dangers to human safety, infrastructures, and the environment, highlighting the need for advanced monitoring techniques for early damage detection and structure management. The distributed optical fiber sensors (DFOS) are strain, temperature, and vibration monitoring tools characterized by minimal intrusiveness, accuracy, ease of deployment, and the ability to perform measurements with high spatial resolution. Although these sensors rely on well-established measurement techniques, available for over 40 years, their diffusion within monitoring and early warning systems is still limited, and there is a certain mistrust towards them. In this regard, based on several case studies, the implementation of DFOS for early warning of various geotechnical hazards, such as landslides, earthquakes and subsidence, is discussed, providing a comparative analysis of the typical advantages and limitations of the different systems. The results show that real-time monitoring systems based on well-established distributed fiber-optic sensing techniques are now mature enough to enable reliable and long-term geotechnical applications, identifying a market segment that is only minimally saturated by using other monitoring techniques. More challenging remains the application of the technique for vibration detection that still requires improved interrogation technologies and standardized practices before it can be used in large-scale, real-time early warning systems. Full article

The overlying rock layers in a mining area may collapse or settle, subjecting pipelines to uneven forces that can lead to deformation or even fracture. This paper proposes a pipeline safety monitoring method that combines fiberoptic vibration and strain sensing to detect vibrations and deformations caused by rock layer collapse in mining zones. First, pipeline deformation monitoring under unknown force directions was investigated using fiber Bragg grating (FBG) sensing technology. Second, we constructed a mining area pipeline model and conducted vibration/deformation monitoring tests employing FBG sensors, distributed Brillouin strain sensing, and distributed fiberoptic vibration sensing technologies. The experimental results demonstrate that FBG sensor arrays deployed at 90-degree intervals can effectively identify the pipeline’s primary force direction and maximum strain, with direction angle errors of less than 5.2%. The integrated analysis of vibration and strain data enables accurate identification and measurement of extended vibration responses and pipeline deformations in open-air zones. This study establishes a comprehensive monitoring framework for ensuring pipeline safety in mining areas. Full article

Fiber optic technologies have strong potential to augment and improve existing areas of sensor performance across many applications. Magnetic sensing, in particular, has attracted significant interest in structural health monitoring and ferromagnetic object detection. However, current technologies such as fluxgate magnetometers and inspection gauges rely on measuring magnetic fields as single-point sensors. By using fiber optic distributed strain sensors in tandem with magnetically biased magnetostrictive material, static and dynamic magnetic fields can be detected across long lengths of sensing fiber. This paper investigates the relationship between Fiber Bragg Grating (FBG)-based strain sensors and the magnetostrictive alloy Metglas^® 2605SC for the distributed detection of static fields for use in a compact cable design. Sentek Instrument’s picoDAS system is used to interrogate the FBG based sensors coupled with Metglas^® that is biased with an alternating sinusoidal magnetic field. The sensing system is then exposed to varied external static magnetic field strengths, and the resultant strain responses are analyzed. A minimum magnetic field strength on the order of 300 nT was able to be resolved and a variety of sensing configurations and conditions were also tested. The sensing system is compact and can be easily cabled as both FBGs and Metglas^® are commercialized and readily acquired. In combination with the robust and distributed nature of fiber sensors, this demonstrates strong promise for new means of magnetic characterization. Full article

Conducting structural monitoring of highway subgrades is crucial for investigating damage evolution mechanisms under dynamic load-temperature coupling effects. However, existing sensing technologies struggle to achieve distributed, long-term, and high-precision measurements of subgrade structures. Therefore, this study employs next-generation fiber-optic array sensing technology to construct a distributed monitoring system based on weak reflection grating arrays. A dual-parameter sensing network for strain and temperature was designed and installed during the expansion and renovation of a highway in Fujian Province, enabling high-precision monitoring of the entire continuous strain field and temperature field of the subgrade structure. Through a comprehensive analysis of dynamic loading test data and long-term monitoring records, the system revealed the dynamic response patterns of subgrade structures under the interaction of modulus differences, burial depth effects, temperature gradients, and load parameters. It elucidated the mechanical sensitivity of flexible base layers and the interlayer stress redistribution mechanism. The study validated that grating array sensors not only offer advantages such as easy installation, a high survival rate, and excellent durability but also enable high-capacity, long-distance, and high-precision measurements of subgrade structures. This provides a new technical approach for full lifecycle monitoring of expressways. Full article

As an important traffic and transportation roadway, tunnel engineering is widely used in important fields such as highways, railways, water conservancy, subways and mining. It is limited by complex geological conditions, harsh construction environments and poor robustness of the monitoring system. If the construction process and monitoring method are not properly designed, it will often directly induce disasters such as tunnel deformation, collapse, leakage and rockburst. This seriously threatens the safety of tunnel construction and operation and the protection of the regional ecological environment. Therefore, based on distributed fiber optic sensing technology, the full–cycle spatiotemporally continuous sensing information of the tunnel structure is obtained in real time. Accordingly, the health status of the tunnel is dynamically grasped, which is of great significance to ensure the intrinsic safety of the whole life cycle for the tunnel project. Firstly, this manuscript systematically sorts out the development and evolution process of the theory and technology of structural health monitoring in tunnel engineering. The scope of application, advantages and disadvantages of mainstream tunnel engineering monitoring equipment and main optical fiber technology are compared and analyzed from the two dimensions of equipment and technology. This provides a new path for clarifying the key points and difficulties of tunnel engineering monitoring. Secondly, the mechanism of action of four typical optical fiber sensing technologies and their application in tunnel engineering are introduced in detail. On this basis, a spatiotemporal continuous perception method for tunnel engineering based on DFOS is proposed. It provides new ideas for safety monitoring and early warning of tunnel engineering structures throughout the life cycle. Finally, a high–speed rail tunnel in northern China is used as the research object to carry out tunnel structure health monitoring. The dynamic changes in the average strain of the tunnel section measurement points during the pouring and curing period and the backfilling period are compared. The force deformation characteristics of different positions of tunnels in different periods have been mastered. Accordingly, scientific guidance is provided for the dynamic adjustment of tunnel engineering construction plans and disaster emergency prevention and control. At the same time, in view of the development and upgrading of new sensors, large models and support processes, an innovative tunnel engineering monitoring method integrating “acoustic, optical and electromagnetic” model is proposed, combining with various machine learning algorithms to train the long–term monitoring data of tunnel engineering. Based on this, a risk assessment model for potential hazards in tunnel engineering is developed. Thus, the potential and disaster effects of future disasters in tunnel engineering are predicted, and the level of disaster prevention, mitigation and relief of tunnel engineering is continuously improved. Full article

This study focuses on a comprehensive analysis of the common methods for road infrastructure monitoring, as well as the perspective of various fiber-optic sensor (FOS) realization solutions in road monitoring applications. Fiber-optic sensors are a topical technology that ensures multiple advantages such as passive nature, immunity to electromagnetic interference, multiplexing capabilities, high sensitivity, and spatial resolution, as well as remote operation and multiple physical parameter monitoring, hence offering embedment potential within the road pavement structure for needed smart road solutions. The main key factors that affect FOS-based road monitoring scenarios and configurations are analyzed within this review. One such factor is technology used for optical sensing—fiber Bragg grating (FBG), Brillouin, Rayleigh, or Raman-based sensing. A descriptive comparison is made comparing typical sensitivity, spatial resolution, measurement distance, and applications. Technological approaches for monitoring physical parameters, such as strain, temperature, vibration, humidity, and pressure, as a means of assessing road infrastructure integrity and smart application integration, are also evaluated. Another critical aspect concerns spatial positioning, focusing on the point, quasi-distributed, and distributed methodologies. Lastly, the main topical FOS-based application areas are discussed, analyzed, and evaluated. Full article

This article focuses on activities addressed in the European project hydrogen lightweight & innovative tank for zero-emission aircraft, H2ELIOS. The authors propose a preliminary approach oriented to the design of a structural health monitoring SHM system conceived for a cryo-tank liquid hydrogen storage for medium range vehicles. The system was ideated to be installed on board and operating during service, to provide early detection and localization of potential damage, critical both in terms of safety and maintenance. The use of optical fibers for strain measurement is justified, on one hand, by the capability of pure silica fiber to prevent hydrogen darkening effects and, on the other hand, by the absence of metal components, which eliminates the risk of embrittlement. In detail, distributed and fiber Bragg grating FBG sensors designed for this specific application have demonstrated reliable monitoring capabilities, even after exposure to hydrogen and at cryogenic temperatures. Furthermore, another key contribution of this preliminary activity is the analysis of thermoplastic material faults by correlating damage characteristics with static and dynamic response. This is due to the fact that the investigated physics strongly depend on the nature of occurring damage. Achievements lie in the demonstrated ability to assess the health status of the reference composite structure, establishing the first steps for a future qualification of the proprietary system, made of commercial and original hardware and software. Full article

For the first time, comprehensive investigations into the tensile load-bearing behavior and crack formation of reinforced concrete based on ultrasound are presented. Uniaxial tensile tests are performed on reinforced concrete tension members equipped with embedded ultrasonic transducers. Key mechanical parameters across all ranges of tensile behavior are continuously quantified by recording ultrasonic signals and evaluated with coda wave interferometry. The investigations include member configurations of different lengths to cover different numbers of cracks. For reference, crack patterns and crack widths are analyzed using digital image correlation, while the strain in the reinforcement is monitored with distributed fiber optic sensors. For the first time, a direct proportional relationship between the relative velocity change in ultrasonic signals and crack widths is established in the ranges of crack formation and stabilized cracking. In the non-cracked state, linear correlations are found between the velocity change and the average strain, as well as the length of the specimens. The experimental results significantly enhance the general understanding of the phenomena related to ultrasonic signals in flexural reinforced concrete members, particularly concerning cracking in the tensile zone. Consequently, this study contributes to the broader objective of employing coda wave interferometry to evaluate the condition of infrastructure. Full article

The wide-spread application of carbon fiber-reinforced polymer (CFRP) composites in industrial fields has led to high demand for developing a rapid detection method for assessing the structural performance of CFRP composites in operation based on optical fiber sensing technology. Therefore, the effectiveness and reliability of evaluating the fatigue resistance of CFRP plates based on fiber Bragg grating (FBG) monitoring information were explored. The strain response of CFRP plates at key positions under constant amplitude fatigue load was monitored by bare FBGs in series and packaged quasi-distributed FBGs in series. The structural performance and fatigue resistance characteristics of CFRP plates were evaluated by statistical analysis and fatigue life prediction theory. The validity and accuracy of the test and analysis results were demonstrated by finite element modeling analysis. Compared with the traditional methods that evaluate the structural fatigue performance based on mass destructive experiments, this method significantly improves the detection efficiency and realizes the non-destructive and rapid online evaluation of structural service performance. Research shows that the designed FBG sensors can effectively monitor the strain response of CFRP plate under fatigue load, and the correlated fatigue algorithm can provide feasible and reliable technical approaches for online detection and evaluation on the structural performance of CFRP components. Full article

Steel pipes, while essential for modern infrastructure due to their high strength and load-bearing capacity, are prone to corrosion in the marine environment, leading to material degradation, compromised structural integrity, and elevated safety risks and economic losses. In this study, distributed fiber-optic sensors were deployed on steel pipe surfaces to monitor corrosion in the splash zone (a region particularly vulnerable to cyclic wet–dry conditions). The sensors were engineered to withstand aggressive marine exposure. Strain variations induced by expansive corrosion products were detected via the fiber-optic array and used to calculate localized mass loss. Color-coded corrosion severity maps were generated to visualize the non-uniform corrosion distribution. Experimental results demonstrate that sensor-derived mass loss values align with 3D laser scanning measurements, validating the operational efficacy of distributed fiber-optic sensing for marine corrosion monitoring. This approach provides quantitative insights into the field applicability of optical sensing in structural health monitoring. Full article
