Search Results (67)

This paper presents a real-time remote-control platform for small wind turbines (SWTs) equipped with a permanent magnet synchronous generator (PMSG). The proposed system integrates a DC–DC boost converter controlled by an Arduino^® microcontroller, a Raspberry Pi^® hosting a WebSocket server, and a desktop application developed using MATLAB^® App Designer (version R2024b). The platform enables seamless remote monitoring and control by allowing upper layers to select the turbine’s operating mode—either Maximum Power Point Tracking (MPPT) or Power Curtailment—based on real-time wind speed data transmitted via the WebSocket protocol. The communication architecture follows the IEC 61400-25 standard for wind power system communication, ensuring reliable and standardized data exchange. Experimental results demonstrate high accuracy in controlling the turbine’s operating points. The platform offers a user-friendly interface for real-time decision-making while ensuring robust and efficient system performance. This study highlights the potential of combining open-source hardware and software technologies to optimize SWT operations and improve their integration into distributed renewable energy systems. The proposed solution addresses the growing demand for cost-effective, flexible, and remote-control technologies in small-scale renewable energy applications. Full article

A diode-based rectifier (DR) is an attractive transmission technology for offshore wind farms, which reduces the volume of large bulk platforms. A novel parallel–series DC wind farm based on a distributed DR is proposed, which meets the requirements of high voltage and high power with an isolation capability from other units. The coupling mechanism between a modular multilevel converter (MMC) and a DR has been built, and the coordinate control strategy for the whole system has been proposed based on the MMC triple control targets with intermediate variables. Under the proposed control strategy, the system automatically operates at maximum power point tracking (MPPT). The feasibility of topology and the effectiveness of the control strategy are verified under start-up, power fluctuation, onshore alternating current (AC) fault, and direct current (DC) fault based on the power systems computer-aided design (PSCAD)/electromagnetic transients including direct current (EMTDC) simulation. Full article

This paper discusses the operation and control of a low-voltage DC (LVDC) isolated distribution network powered by distributed generation (DG) from a variable-speed wind turbine induction generator (WTIG) to supply unbalanced AC loads. The system incorporates a DC-DC storage converter to regulate network voltages and interconnect battery energy storage with the DC network. The wind turbines are equipped with a squirrel cage induction generator (IG) to connect a DC network via individual power inverters (WTIG inverters). Loads are unbalanced ACs and are interfaced using transformerless power inverters, referred to as load inverters. The DC-DC converter is equipped with a novel control strategy, utilizing a droop regulator for the DC voltage to stabilize network operation. The control system is modeled based on Clark and Park transformations and is developed for the load inverters to provide balanced AC voltage despite unbalanced load conditions. The system employs the perturbation and observation (P&O) method for maximum power point tracking (MPPT) to optimize wind energy utilization, while blade angle controllers maintain generator performance within rated power and speed limits under high wind conditions. System operation is analyzed under two scenarios: normal operation with varying wind speeds and the effects of load variations. Simulation results using PSCAD/EMTDC demonstrate that the proposed LVDC isolated distribution network (DC) achieves a stable DC bus voltage within ±5% of the nominal value, efficiently delivers balanced AC voltages with unbalanced levels below 2%, and operates with over 90% wind energy utilization during varying wind speeds, confirming LVDC network reliability and robustness. Full article

This paper presents a variable step-size efficient learning modified P&O (LMPO) MPPT algorithm and adaptive proportional–integral (API)-based control techniques for a two-stage three-phase grid-integrated photovoltaic (TS-GIPV) system using an LCL filter. The proposed novel controlled technique introduces two-stage systems under different meteorological conditions and load deviations. The two-stage system with the presented control technique includes maximum power point tracking (MPPT) techniques, intermediate DC-link voltage, and grid current synchronization with a voltage source converter (VSC), respectively. This technique is implemented to improve the extract MPP of the solar PV generator system. An innovative grid-side VSC control technique addresses DC link regulation. Furthermore, this method regulates DC link voltage with an outer voltage loop and an inner current loop controller. Distinctively, the proposed technique regulates the inner loop while avoiding the outer loop. A control mechanism uses an API controller to regulate DC link voltage, distribute power, and synchronize grid current in the face of different scenarios. The fluctuating voltage of the DC link will be kept stable through power balancing. Hence, this technique improves the system stability, dynamic response, and component longevity by effectively reducing oscillations in the fluctuating DC link voltage at twice the grid frequency. The total harmonic distortion (THD%) of the grid currents of the PV power generated in the grid is maintained within the recommended limits. The proposed technique is simulated and verified through MATLAB/Simulink 2019b under different scenarios. Full article

Data generated during the shutdown or start-up processes of wind turbines, particularly in complex wind conditions such as offshore environments, often accumulate in the low-wind-speed region, leading to reduced multivariate power estimation accuracy. Therefore, developing efficient filtering methods is crucial to improving data quality and model performance. This paper proposes a novel filtering method that integrates the control strategies of variable-speed, variable-pitch wind turbines, such as maximum-power point tracking (MPPT) and pitch angle control, with statistical distribution characteristics derived from supervisory control and data acquisition (SCADA). First, thresholds for pitch angle and rotor speed are determined based on SCADA data distribution, and the filtering effect is visualized. Subsequently, a sliding window technique is employed for the secondary confirmation of potential outliers, enabling further anomaly detection (AD). Finally, the performance of the power estimation model is validated using two wind turbine datasets and two machine learning algorithms, with results compared with and without filtering. The results demonstrate that the proposed filtering method significantly enhances the accuracy of multivariate power estimation, proving its effectiveness in improving data quality for wind turbines operating in diverse and complex environments. Full article

Currently, numerous intelligent maximum power point tracking (MPPT) algorithms are capable of tackling the global optimization challenge of multi-peak photovoltaic output power under partial shading conditions, yet they often face issues such as slow convergence, low tracking precision, and substantial power fluctuations. To address these challenges, this paper introduces a hybrid algorithm that integrates an improved salp swarm algorithm (SSA) with the perturb and observe (P&O) method. Initially, the SSA is augmented with a dynamic spiral evolution mechanism and a Lévy flight strategy, expanding the search space and bolstering global search capabilities, which in turn enhances the tracking precision. Subsequently, the application of a Gaussian operator for distribution calculations allows for the adaptive adjustment of step sizes in each iteration, quickening convergence and diminishing power oscillations. Finally, the integration with P&O facilitates a meticulous search with a small step size, ensuring swift convergence and further mitigating post-convergence power oscillations. Both the simulations and the experimental results indicate that the proposed algorithm outperforms particle swarm optimization (PSO) and grey wolf optimization (GWO) in terms of convergence velocity, tracking precision, and the reduction in iteration power oscillation magnitude. Full article

Renewable energy sources are particularly significant in global energy production, with wind and solar being the most prevalent sources. Managing the simultaneous connection of wind and solar energy generators to the smart grid as distributed generators involves complex control and stabilization due to their inherent uncertainties, making their management more intricate than traditional power plants. This study focuses on enhancing the speed and efficiency of the maximum power point tracking (MPPT) system in a solar power plant. A hybrid network is modeled, comprising a wind turbine with a doubly-fed induction generator (DFIG), a solar power plant with photovoltaic (PV) cells, an MPPT system, a Z-source converter, and a storage system. The proposed approach employs a motion detection-based method, utilizing image-processing techniques to optimize the MPPT of PV cells based on shadow movement patterns within the solar power plant area. This method significantly reduces the time required to reach the maximum power point (MPP), lowers the computational load of the control system by predicting shadow movements, and enhances the MPPT speed while maintaining system stability. The approach, which is suitable for relatively large solar farms, is implemented without the need for any additional sensors and relies on the system’s history. The simulation results show that the proposed approach improves the MPPT system’s efficiency and reduces the pressure on the control circuits by more than 70% in a 150,000 m² solar farm under shaded conditions. Full article

This paper presents an inductor current-based maximum power point tracking (IC-MPPT) strategy and a single-inductor multi-input single-output (SI-MISO) structure with energy storage battery for distributed photovoltaic (PV) systems. In this study framework, the duty cycle of each PV channel can be controlled independently based on the presented IC-MPPT strategy, and the components/sensors costs are reduced through the presented SI-MISO PV system structure. In addition, a model predictive control (MPC) method is presented to regulate DC bus voltage, by controlling the bidirectional converter in the battery circuit. The presented control strategies have been rigorously derived and experimentally validated, and the experimental results demonstrate that each PV module can rapidly and efficiently track to the maximum power point in less than 0.016 s, while the bus voltage is stabilized near the set value, with an overshoot of less than 2.6%. Full article

This study compares bio-inspired optimization algorithms for enhancing an ANN-based Maximum Power Point Tracking (MPPT) forecast system under partial shading conditions in photovoltaic systems. Four algorithms—grey wolf optimizer (GWO), particle swarm optimization (PSO), squirrel search algorithm (SSA), and cuckoo search (CS)—were evaluated, with the dataset augmented by perturbations to simulate shading. The standard ANN performed poorly, with 64 neurons in Layer 1 and 32 in Layer 2 (MSE of 159.9437, MAE of 8.0781). Among the optimized approaches, GWO, with 66 neurons in Layer 1 and 100 in Layer 2, achieved the best prediction accuracy (MSE of 11.9487, MAE of 2.4552) and was computationally efficient (execution time of 1198.99 s). PSO, using 98 neurons in Layer 1 and 100 in Layer 2, minimized MAE (2.1679) but had a slightly longer execution time (1417.80 s). SSA, with the same neuron count as GWO, also performed well (MSE 12.1500, MAE 2.7003) and was the fastest (987.45 s). CS, with 84 neurons in Layer 1 and 74 in Layer 2, was less reliable (MSE 33.7767, MAE 3.8547) and slower (1904.01 s). GWO proved to be the best overall, balancing accuracy and speed. Future real-world applications of this methodology include improving energy efficiency in solar farms under variable weather conditions and optimizing the performance of residential solar panels to reduce energy costs. Further optimization developments could address more complex and larger-scale datasets in real-time, such as integrating renewable energy sources into smart grid systems for better energy distribution. Full article

Transitioning from petrol or gas vehicles to electric vehicles (EVs) poses significant challenges in reducing emissions, lowering operational costs, and improving energy storage. Wireless charging EVs offer promising solutions to wired charging limitations such as restricted travel range and lengthy charging times. This paper presents a comprehensive approach to address the challenges of wireless power transfer (WPT) for EVs by optimizing coupling frequency and coil design to enhance efficiency while minimizing electromagnetic interference (EMI) and heat generation. A novel coil design and adaptive hardware are proposed to improve power transfer efficiency (PTE) by defining the optimal magnetic resonant coupling WPT and mitigating coil misalignment, which is considered a significant barrier to the widespread adoption of WPT for EVs. A new methodology for designing and arranging roadside lanes and facilities for dynamic wireless charging (DWC) of EVs is introduced. This includes the optimization of transmitter coils (TCs), receiving coils (RCs), compensation circuits, and high-frequency inverters/converters using the partial differential equation toolbox (pdetool). The integration of wireless charging systems with smart grid technology is explored to enhance energy distribution and reduce peak load issues. The paper proposes a DWC system with multiple segmented transmitters integrated with adaptive renewable photovoltaic (PV) units and a battery system using the utility main grid as a backup. The design process includes the determination of the required PV array capacity, station battery sizing, and inverters/converters to ensure maximum power point tracking (MPPT). To validate the proposed system, it was tested in two scenarios: charging a single EV at different speeds and simultaneously charging two EVs over a 1 km stretch with a 50 kW system, achieving a total range of 500 km. Experimental validation was performed through real-time simulation and hardware tests using an OPAL-RT platform, demonstrating a power transfer efficiency of 90.7%, thus confirming the scalability and feasibility of the system for future EV infrastructure. Full article

This paper focuses on the distributed generation (DG) controller of a PV-based microgrid. An independent DG controller (IDGC) is designed for PV applications to improve Maximum-Power Point Tracking (MPPT). The Extreme-Learning Machine (ELM)-based MPPT method exactly estimates the controller’s reference input, such as the voltage and current at the MPP. Feedback controls employ linear PI schemes or nonlinear, intricate techniques. Here, the converter controller is an IDGC that is improved by directly measuring the converter duty cycle and PWM index in a single DG PV-based MG. It introduces a fast-learning Extreme-Learning Machine (ELM) using the Moore–Penrose pseudo-inverse technique and online sequential ridge methods for robust control reference (CR) estimation. This approach ensures the stability of the microgrid during PV uncertainties and various operational conditions. The internal DG control approach improves the stability of the microgrid during a three-phase fault at the load bus, partial shading, irradiance changes, islanding operations, and load changes. The model is designed and simulated on the MATLAB/SIMULINK platform, and some of the results are validated on a hardware-in-the-loop (HIL) platform. Full article

The primary disadvantage of solar photovoltaic systems, particularly in partial shadowing conditions (PSC), is their low efficiency. A power–voltage curve with a homogenous distribution of solar irradiation often has a single maximum power point (MPP). Without a doubt, it can be extracted using any conventional tracker—for instance, perturb and observe. On the other hand, under PSC, the situation is entirely different since, depending on the number of distinct solar irradiation levels, the power–voltage curve has numerous MPPs (i.e., multiple local points and one global point). Conventional MPPTs can only extract the first point since they are unable to distinguish between local and global MPP. Thus, to track the global MPP, an optimized MPPT based on optimization algorithms is needed. The majority of global MPPT techniques seen in the literature call for sensors for voltage and current in addition to, occasionally, temperature and/or solar irradiance, which raises the cost of the system. Therefore, a single-sensor global MPPT based on the recent red-tailed hawk (RTH) algorithm for a PV system interconnected with a DC link operating under PSC is presented. Reducing the number of sensors leads to a decrease in the cost of a controller. To prove the superiority of the RTH, the results are compared with several metaheuristic algorithms. Three shading scenarios are considered, with the idea of changing the shading scenario to change the location of the global MPP to measure the consistency of the algorithms. The results verified the effectiveness of the suggested global MPPT based on the RTH in precisely capturing the global MPP compared with other methods. As an example, for the first shading situation, the mean PV power values varied between 6835.63 W and 5925.58 W. The RTH reaches the highest PV power of 6835.63 W flowing through particle swarm optimization (6808.64 W), whereas greylag goose optimizer achieved the smallest PV power production of 5925.58 W. Full article

With its technical advantages of high speed, low latency, and broad connectivity, fifth-generation mobile communication technology has brought about unprecedented development in numerous vertical application scenarios. However, the high energy consumption and expansion difficulties of 5G infrastructure have become the main obstacles restricting its widespread application. Therefore, aiming to optimize the energy utilization efficiency of 5G base stations, a novel distributed photovoltaic 5G base station DC microgrid structure and an energy management strategy based on the Curve Fitting–Perturb and Observe–Incremental Conductance (CF-P&O-INC) Maximum Power Point Tracking (MPPT) algorithm from the perspectives of energy and information flows are proposed. Simulation results show that the proposed MPPT algorithm can increase the efficiency to 99.95% and 99.82% under uniform irradiation and partial shading, respectively. Under the proposed strategy, when the base station load changes drastically, the voltage fluctuation of the DC bus is less than 1.875%, and returns to a steady state within 0.07s, alleviating the high energy consumption of 5G base stations effectively and achieving coordinated optimization management of various types of energy in multi-source power supply systems. Full article

Static waste heat recovery, by means of thermoelectric generator (TEG) modules, constitutes a fast-growing energy harvesting technology on the way towards greener transportation. Many commercial solutions are already available for small internal combustion engine (ICE) vehicles, whereas further development and cost reductions of TEG devices expand their applicability at higher-power transportation means (i.e., ships and aircrafts). In this light, the integration of waste heat recovery based on TEG modules in a shipboard distribution network is studied in this work. Several voltage step-up techniques are considered, whereas the most suitable ones are assessed via the LTspice simulation platform. The design procedure of the selected LLC resonant converter is presented and analyzed in detail. Furthermore, a flexible control strategy is proposed, capable of either output voltage regulation (constant voltage) or maximum power point tracking (MPPT), according to the application demands. Finally, both simulations and experiments (on a suitable laboratory testbench) are performed. The obtained measurements indicate the high efficiency that can be achieved with the LLC converter for a wide operating area as well as the functionality and adequate performance of the control scheme in both operating conditions. Full article

The need for public fast electric vehicle charging station (FEVCS) infrastructure is growing to meet the zero-emission goals of the transportation sector. However, the large charging demand of the EV fleet may adversely impact the grid’s stability and reliability. To improve grid stability and reliability, the development of a DC microgrid (MG) leveraging renewable energy sources to supply the energy demands of FEVCSs is the sustainable solution. Balancing the intermittent EV charging demand and fluctuating renewable energy generation with the stable DC bus voltage of a DC MG is a challenging objective. To address this objective, a piece-wise droop control strategy is proposed in this work. The proposed scheme regulates DC bus voltage and power sharing with droop value updating in a region-based load current distribution. Voltage compensation in individual regions is carried out to further improve the degree of freedom. In this paper, the performance of the proposed strategy is evaluated with the consideration of real-time solar PV dynamics and EV load dynamics. Further, to showcase the effectiveness of the proposed strategy, a comparative analysis with a maximum power point tracking (MPPT) controller against various dynamic EV load scenarios is carried out, and the results are validated through a hardware-in-loop experimental setup. Despite the intermittent source and EV load dynamics, the proposed piece-wise droop control can maintain voltage regulation with less than 1% deviation. Full article
