The growing need for efficient and safe high-energy lithium-ion batteries (LIBs) in electric vehicles and grid storage necessitates advanced internal monitoring solutions. This work presents a comprehensive simulation model of a novel integrated optical sensor based on ethylene carbonate-filled photonic crystal fiber (EC-PCF). The proposed design synergistically combines a chirped fiber Bragg grating (FBG) and an extrinsic Fabry–Pérot interferometer (EFPI) on a multiplexed platform for the multifunctional sensing of refractive index (RI), temperature, strain, and pressure (via strain coupling) within LIBs. By matching the RI of the PCF cladding to the battery electrolyte using ethylene carbonate, the design maximizes light–matter interaction for exceptional RI sensitivity, while the cascaded EFPI enhances mechanical deformation detection beyond conventional FBG arrays. The simulation framework employs the Transfer Matrix Method with Gaussian apodization to model FBG reflectivity and the Airy formula for high-fidelity EFPI spectra, incorporating critical effects like stress-induced birefringence, Transverse Electric (TE)/Transverse Magnetic (TM) polarization modes, and wavelength dispersion across the 1540–1560 nm range. Robustness against fabrication variations and environmental noise is rigorously quantified through Monte Carlo simulations with Sobol sequences, predicting temperature sensitivities of ∼12 pm/°C, strain sensitivities of ∼1.10 pm/$\mathsf{\mu }$$\mathsf{\epsilon }$, and a remarkable RI sensitivity of ∼1200 nm/RIU. Validated against independent experimental data from instrumented battery cells, this model establishes a robust computational foundation for real-time battery monitoring and provides a critical design blueprint for future experimental realization and integration into advanced battery management systems. Full article

In this paper, we present the development of a new semi-distributed interferometer (SDI) biosensor with a Zn, Cu, and Co metal oxide nanopowder coating for the detection of a kidney disease biomarker as a model system. The combination of nanopowder coating with the SDI platform opens up unique opportunities for improving measurement reproducibility while maintaining high sensitivity. The fabrication of sensors is simple, which involves one splice and subsequent cutting at the end of an optical fiber. To ensure specific detection of the biomarker, a monoclonal antibody was immobilized on the surface of the probe. The biosensor has demonstrated an impressive ability to detect biomarkers in a wide range of concentrations, from 1 aM to 100 nM. The theoretical limit of detection was 126 fM, and the attomolar detection level was experimentally achieved. The sensors have achieved a maximum sensitivity of 190 dB/RIU and operate with improved stability and reduced dispersion. Quantitative analysis revealed that the sensor’s response gradually increases with increasing concentration. The signal varies from 0.05 dB at 1 aM to 0.81 dB at 100 nM, and the linear correlation coefficient was R² = 0.96. The sensor showed excellent specificity and reproducibility, maintaining detection accuracy at about 10⁻⁴ RIU. This opens up new horizons for reliable and highly sensitive biomarker detection, which can be useful for early disease diagnosis and monitoring using a cost-effective and reproducible sensor system. Full article

The effective monitoring of methane (CH₄) point sources is important for climate change research. Satellite-based observations have demonstrated significant potential for emission estimation. In this study, the methane plumes with different emission rates are modelled and pseudo-observations with diverse spatial resolution, spectral resolution, and signal-to-noise ratios (SNR) are simulated by the radiative transfer model. The iterative maximum a posteriori–differential optical absorption spectroscopy (IMAP-DOAS) algorithm is applied to retrieve the column-averaged methane dry air mole fraction (XCH₄), a three-dimensional matrix of estimated plume emission rates is then constructed. The results indicate that an optimal plume estimation requires high spatial and spectral resolution alongside an adequate SNR. While a spatial resolution degradation within 120 m has little impact on quantification, a high spatial resolution is important for detecting low-emission plumes. Additionally, a fine spectral resolution (<5 nm) is more beneficial than a higher SNR for precise plume retrieval. Scientific SNR settings can also help to accurately quantify methane plumes, but there is no need to pursue an overly extreme SNR. Finally, miniaturized spectroscopic systems, such as dispersive spectrometers or Fabry–Pérot interferometers, meet current detection needs, offering a faster and resource-efficient deployment pathway. The results can provide a reference for the development of current detection instruments for methane plumes. Full article

A wavelength-swept laser (WSL) demodulation system offers a unique time-domain analysis solution for high-sensitivity optical fiber sensors, providing a high-resolution and high-speed method compared to optical spectrum analysis. However, most traditional WSL-demodulated sensing systems require a synchronous trigger signal or an additional optical dispersion link for sensing analysis and typically use a fiber Bragg grating (FBG) as the sensing unit, which limits displacement sensitivity and increases fabrication costs. We present a novel displacement sensing system that combines a trigger-free WSL demodulation method with a cascaded balloon-like interferometer, featuring a simple structure, high sensitivity, and low temperature cross-sensitivity. The sensor is implemented by bending a short length of single-mode fiber with an optimal radius of around 4 mm to excite cladding modes, which form an interference spectral response with the core mode. Experimental findings reveal that the system achieves a high sensitivity of 397.6 pm/μm for displacement variation, corresponding to 19.88 ms/μm when demodulated using a WSL with a sweeping speed of 20 nm/s. At the same time, the temperature cross-sensitivity is as low as 5 pm/°C or 0.25 ms/°C, making it a strong candidate for displacement sensing in harsh environments with significant temperature interference. Full article

In this paper we demonstrate a new approach to the measurement of dispersion of light reflected in integrated optical devices. The approach utilizes the fact that light reflected from the end facet of an integrated waveguide will interfere with light reflected from points inside the device under test (DUT), effectively creating a Michelson interferometer. The distance between the measured fringes of this interferometric signal will depend directly on the group delay experienced in the device under test, allowing for fast and easy measurement of waveguide dispersion. This approach has been used to determine the dispersion of a fabricated linearly chirped Bragg gratings waveguide and the result agrees well with the designed value. Full article

This article introduces the design of a novel high-speed silicon-photonics hitless switch that adheres to wavelength-division multiplexing (WDM) standards for channel 3 dB bandwidth, channel free spectral range, crosstalk, shape factor, and dispersion. The design combines the advantages of two structures, a compound ring resonator structure, and a Mach–Zehnder interferometer (MZI) modulator. The mathematical treatment for the proposed device is detailed, and two designs are presented. For a switch of five ring resonators, the through (drop) channel 3 dB bandwidth is 60 GHz (38 GHz), channel crosstalk is −24 dB (−24 dB), dispersion is 22 ps/nm (21 ps/nm), shape factor is 0.66 (0.5), and insertion loss is 0.3 dB (1.7 dB). For a switch of nine ring resonators, the through (drop) channel 3 dB bandwidth is 59 GHz (38 GHz), channel crosstalk is −37 dB (−24 dB), dispersion is 28.5 ps/nm (29 ps/nm), shape factor is 0.8 (0.73), and insertion loss is 0.3 dB (2.3 dB). For the five-ring design, the switch-on/off ratio is 30 dB, and for the nine-ring design, it is 31 dB. For both designs, the switching speed is 100 GHz. Full article

This study examines the wettability behaviour of 304 stainless steel (304SS) and Ti-6Al-4V (Ti64) surfaces after sequential nanosecond (ns) and picosecond (ps) laser texturing; in particular, how the multi-scale surface structures created influence the lifecycle of surface hydrophobicity. The effect of different post-process treatments is also examined. Surfaces were analysed using Scanning Electron Microscopy (SEM), a white light interferometer optical profiler, and Energy Dispersive X-ray (EDX) spectroscopy. Wettability was assessed through sessile drop contact angle (CA) measurements, conducted at regular intervals over periods of up to 12 months, while EDX scans monitored elemental chemical changes. The results show that sequential (ns + ps) laser processing produced multi-scale surface texture with laser-induced periodic surface structures (LIPSS). Compared to the ns laser case, the (ns + ps) laser processed surfaces transitioned more rapidly to a hydrophobic state and maintained this property for much longer, especially when the single post-process treatment was ultrasonic cleaning. Some interesting features in CA development over these extended timescales are revealed. For 304SS, hydrophobicity was reached in 1–2 days, with the CA then remaining in the range of 120 to 140° for up to 180 days; whereas the ns laser-processed surfaces took longer to reach hydrophobicity and only maintained the condition for up to 30 days. Similar results were found for the case of Ti64. The findings show that such multi-scale structured metal surfaces can offer relatively stable hydrophobic properties, the lifetime of which can be extended significantly through the appropriate selection of laser process parameters and post-process treatment. The addition of LIPSS appears to help extend the longevity of the hydrophobic property. In seeking to identify other factors influencing wettability, from our EDX results, we observed a significant and steady rate of increase in the carbon content at the surface over the study period. Full article

A novel demodulation scheme for a point-type fiber sensor is designed for salinity concentration monitoring based on a Sagnac interferometer (SI) composed of a tapered polarization-maintaining fiber (TPMF) and optical time stretching technology. The SI, constructed using a PMF with a taper region of 5.92 μm and an overall length of 30 cm, demonstrated a notable enhancement in the evanescent field, which intensifies the interaction between the light field and external salinity. This enhancement allows for a direct assessment of salinity concentration changes by analyzing the variations in the SI reflection spectra and the experimental results indicate that the sensitivity of the sensor is 0.151 nm/‰. In contrast to traditional fiber optic sensors that depend on spectral demodulation with slower response rates, this work introduces a new approach where the spectral shift is translated to the time domain, utilizing a dispersion compensation fiber (DCF) with the demodulation rate reaching up to 50 MHz. The experimental outcomes reveal that the sensor exhibits a sensitivity of −0.15 ns/‰ in the time domain. The designed sensor is anticipated to play a pivotal role in remote, real-time monitoring of ocean salinity. Full article

In this paper, a brake cylinder coating comprising a composite material of an Fe₃Al and Cr₃C₂ mixed powder was prepared by adding laser cladding onto carbon structural steel. We studied the influence of process parameters on the microstructure and tribological properties of the cladding materials using scanning electron microscopy (SEM), energy-dispersive spectroscopy (EDS), and 3D white light interferometer and wear tests. The influence of different processes on the morphology of the carbide strengthening phase was found to be relatively small with a Cr₃C₂ content of 15 wt.%. The carbides mainly exhibited a network structure in each group of cladding layers. The area of the network strengthening phase varied under different processes. Of the cladding layers formed with different processes, the scanning speed of the 0.003 m/s cladding layer had the lowest wear rate. When the laser power was too low or the powder feed rate was too high, unmelted Cr₃C₂ particles could be found in the cladding layer. During the wear process, the particles peeled off, causing severe abrasive wear. When the powder feeding rate was too low, more materials in the base material entered the cladding layer. This made the composition of the cladding layer similar to that of the grinding material, resulting in severe adhesive wear. Full article

A fiber curvature sensor based on a Mach–Zehnder Interferometer (MZI) constructed using the waist-enlarged technique to splice a segment of non-zero dispersion-shifted fiber (NZ-DSF) between two segments of single mode fiber (SMF) is proposed and experimentally demonstrated. All fabricated sensors presented an improvement in their curvature sensitivity when they were coated with polydimethylsiloxane (PDMS) polymer. The sensor that exhibited the best performance was 6.5 cm long, with a curvature sensitivity of 8.27 nm/m⁻¹ in a range of 0.69 m⁻¹ (from 1.08 to 1.77 m⁻¹). This sensitivity is 3.22 times higher than that of the sensor without polymer. Additionally, the sensor coated with polymer exhibited cross-sensitivity that is 2.23 times smaller than the sensor without polymer. The easy fabrication and notable performance of this device makes it alluring for structural health monitoring. Full article

Dispersive interferometry based on a femtosecond laser is extensively utilized for achieving absolute distance measurements with high accuracy. However, this method cannot measure arbitrary distances without encountering a dead zone, and deviations in its output results are inevitable due to inherent theory limitations. Therefore, two enhanced data-processing algorithms are proposed to improve the accuracy and reduce the dead zone of dispersive interferometry. The principles of the two proposed algorithms, namely the truncated-spectrum algorithm and the high-order-angle algorithm, are proposed after explaining the limitations of conventional methods. A series of simulations were conducted on these algorithms to show the improved accuracy of measurement results and the elimination of the dead zone. Furthermore, an experimental setup based on a dispersive interferometer was established for the application of these proposed algorithms to the experimental interference spectral signals. The results demonstrated that compared with the conventional algorithm, the proposed truncated-spectrum algorithm could reduce the output distance deviations derived from direct inverse Fourier transforming by eight times to reach as low as 1.3 μm. Moreover, the unmeasurable dead zone close to the zero position of the conventional algorithm, i.e., the minimum working distance of a dispersive interferometer, could be shortened to 22 μm with the implementation of the proposed high-order-angle algorithm. Full article

In this study, we simultaneously measured the group refractive index dispersion and thickness of fused silica using a scanning white light interferometer on a spectral range from 800 to 1050 nm. A delay error correction was performed using a He-Ne laser. The accuracy of the measured group refractive index dispersion of fused silica, when compared to the temperature-dependent Sellmeier equation, is within 4 × 10⁻⁵. Full article

We experimentally studied the supercontinuum induced by femtosecond filamentation in different liquid media. Using a Mach–Zehnder interferometer, we determined the relative filamentation thresholds (P_th) of these media. Research has shown that the value of the filamentation threshold is greater than that of P_cr (critical power for self-focusing), which can mainly be attributed to the strong dispersion effect. Changing the focal length of the focusing lens affects filamentation dynamics, thereby affecting the measured results regarding the filamentation threshold. With shorter focal lengths, the linear focusing (i.e., geometrical focusing) regime dominates, and the measured values of P_th for different liquid media are almost the same; as the focal length becomes larger, self-focusing starts to play a role, making the values of P_th for different media different from each other. This study presents an efficient method for investigating the femtosecond filamentation phenomenon in liquid media, helpful to provide further insights into the physical mechanism of supercontinuum generation via femtosecond filamentation in liquid media. Full article

We demonstrated a new optical fiber modal interferometer (MI) for airflow sensing; the novelty of the proposed structure is that an MI is fabricated based on a piece of HAF, which makes the sensitive MI itself also a hotwire. The interferometer is made by applying arc-discharge tapering and then flame tapering on a 10 mm length high attenuation fiber (HAF, 2 dB/cm) with both ends spliced to a normal single mode fiber. When the diameter of the fiber in the processing region is reduced to about 2 μm, the near-infrared dispersion turning point (DTP) can be observed in the interferometer’s transmission spectrum. Due to the absorption of the HAF, the interferometer will have a large temperature increase under the action of a pump laser. At the same time, the spectrum of the interferometer with a DTP is very sensitive to the change in ambient temperature. Since airflow will significantly affect the temperature around the fiber, this thermosensitive interferometer with an integrated heat source is suitable for airflow sensing. Such an airflow sensor sample with a 31.2 mm length was made and pumped by a 980 nm laser with power up to 200 mW. In the comparative experiment with an electrical anemometer, this sensor exhibits a very high air-flow sensitivity of −2.69 nm/(m/s) at a flowrate of about 1.0 m/s. The sensitivity can be further improved by enlarging the waist length, increasing the pump power, etc. The optical anemometer with an extremely high sensitivity and a compact size has the potential to measure a low flowrate in constrained microfluidic channels. Full article
