Electro-optical modulators are effectively used for ultrafast pulse lasers operation control. The scheme of picosecond pulse-periodic high-peak-power Nd:YAG lasers is composed of an active-passive mode-locked and negative feedback-controlled master oscillator and regenerative amplifier based on common end-diode-pumped Nd:YAG crystal. A double-crystal thermally compensated Pockels cell based on KTP crystals of the Y-cut direction is employed as a key control element. The cell was assembled using a pair of equal-length crystals grown according to high-resistivity technology. The scheme provides output pulses with energy up to 1.6 mJ, a duration of 25 ps at repetition rates tunable from 0 to 200 Hz. The laser operation stages are analyzed in detail. The scheme looks attractive and promising for developing advanced ultrafast laser systems with higher repetition rates, peak and, accordingly, average power levels. The Pockels cell based on KTP crystals expands the line of available fast electro-optical control elements, along with the previously used RTP ones. The factors limiting laser pulse energy and repetition rate are discussed. Parasitic nonlinear conversion in the crystals of the Pockels cell along the axis may play an essential role. The results of comparative measurements of the second and third harmonics made with the Pockels cells based on KTP and RTP crystals of both X-cut and Y-cut directions are presented. The minimum second and third harmonics efficiency levels observed in the Y-cut Pockels cells of the KTP crystal seem to be their important advantage. Full article

As an important optoelectronic integration platform, silicon photonics has achieved significant progress in recent years, demonstrating the advantages on low power consumption, low cost, and complementary metal–oxide–semiconductor (CMOS) compatibility. Among the different silicon photonics devices, the silicon electro-optic modulator is a key active component to implement the conversion of electric signal to optical signal. However, conventional silicon Mach–Zehnder modulators and silicon micro-ring modulators both have their own limitations, which will limit their use in future systems. For example, the conventional silicon Mach–Zehnder modulators are hindered by large footprint, while the silicon micro-ring modulators have narrow optical bandwidth and high temperature sensitivity. Therefore, developing a new structure for silicon modulators to improve the performance is a crucial research direction in silicon photonics. Meanwhile, slow-light effect is an important physical phenomenon that can reduce the group velocity of light. Applying slow-light effect on silicon modulators through photonics crystal and waveguide grating structures is an attractive research point, especially in the aspect of reducing the device footprint. In this paper, we review the recent progress of silicon-based slow-light electro-optic modulators towards future communication requirements. Beginning from the principle of slow-light effect, we summarize the research of silicon photonic crystal modulators and silicon waveguide grating modulators in detail. Simultaneously, the experimental results of representative silicon slow-light modulators are compared and analyzed. Finally, we discuss the existing challenges and development directions of silicon-based slow-light electro-optic modulators for the practical applications. Full article

Active semiconductor layers of TiO₂ were synthesized via pulsed laser deposition in He, N₂, O₂, or Ar to manufacture DSSC structures. As-prepared nanostructured TiO₂ coatings grown on FTO were photosensitized by the natural absorption of the N719 (Ruthenium 535-bis TBA) dye to fabricate photovoltaic structures. TiO₂ photoanode nanostructures with increased adsorption areas of the photosensitizer (a combination with voluminous media) were grown under different deposition conditions. Systematic SEM, AFM, and XRD investigations were carried out to study the morphological and structural characteristics of the TiO₂ nanostructures. It was shown that the gas nature acts as a key parameter of the architecture and the overall performance of the deposited films. The best electro-optical performance was reached for photovoltaic structures based on TiO₂ coatings grown in He, as was demonstrated by the short-circuit current (Isc) of 5.40 mA, which corresponds to the higher recorded roughness (of 44 ± 2.9 nm RMS). The higher roughness is thus reflected in a more efficient and deeper penetration of the dye inside the nanostructured TiO₂ coatings. The photovoltaic conversion efficiency (η) was 1.18 and 2.32% for the DSSCs when the TiO₂ coatings were deposited in O₂ and He, respectively. The results point to a direct correlation between the electro-optical performance of the prepared PV cells, the morphology of the TiO₂ deposited layers, and the crystallinity features, respectively. Full article

The detection of an electromagnetic pulse (EMP) field is of great significance in determining the field environment of tested equipment in small spaces. Finger-shaped miniature optical fiber sensors for electromagnetic pulse field measurement were designed. The antenna of a weak field sensor was integrated with a shielding shell, and the wire welded at the direct electro-optic converting circuit connected to an optical fiber through special structure and circuit design was taken as the antenna of a strong field sensor. Measurements in the time domain and frequency domain had been carried out for the two sensors. Experiment results demonstrate that the weak field sensor and the strong field sensor have flat responses from 100 kHz to 1 GHz with a variation of 2.3 dB and 2.9 dB, respectively, and the EMP waveform detected by the sensors agrees well with the applied standard square wave. Moreover, the strong field sensor exhibits linear responses from 645 V/m to 83 kV/m. The resolution of the weak field sensor is as low as 13 V/m. The result indicated that the designed sensors had good performance. Full article

Terahertz (THz) technology has unique applications in, for example, wireless communication, biochemical characterization, and security inspection. However, high-efficiency, low-cost, and actively tunable THz modulators are still scarce. We propose a broadband tunable THz beam deflector based on liquid crystals (LCs). By a periodic gradual distribution of the orientation of the LC in one direction, a frequency-independent geometric phase modulation is obtained. The LC device with this specific orientation distribution was obtained through ultraviolet polarization exposure. We have verified the broadband beam deflection in both the simulation and experiment. The device can achieve a good spin-coupled beam deflection effect in the 0.8–1.2 Thz band, and the average polarization conversion efficiency exceeds 70%. Moreover, because the electro-optical responsivity of LCs is excellent, graphene transparent electrode layers introduced on the upper and lower substrates enable the deflection modulation to be switched and dynamic tuning to be achieved. Full article

We present an on-chip tunable infrared (IR) metamaterial emitter for gas sensing applications. The proposed emitter exhibits high electrical-thermal-optical efficiency, which can be realized by the integration of microelectromechanical system (MEMS) microheaters and IR metamaterials. According to the blackbody radiation law, high-efficiency IR radiation can be generated by driving a Direct Current (DC) bias voltage on a microheater. The MEMS microheater has a Peano-shaped microstructure, which exhibits great heating uniformity and high energy conversion efficiency. The implantation of a top metamaterial layer can narrow the bandwidth of the radiation spectrum from the microheater to perform wavelength-selective and narrow-band IR emission. A linear relationship between emission wavelengths and deformation ratios provides an effective approach to meet the requirement at different IR wavelengths by tailoring the suitable metamaterial pattern. The maximum radiated power of the proposed IR emitter is 85.0 µW. Furthermore, a tunable emission is achieved at a wavelength around 2.44 µm with a full-width at half-maximum of 0.38 µm, which is suitable for high-sensitivity gas sensing applications. This work provides a strategy for electro-thermal-optical devices to be used as sensors, emitters, and switches in the IR wavelength range. Full article

This paper presents a 10 to 20 GHz bandwidth microwave polarimeter demonstrator, based on the implementation of a near-infra-red frequency up-conversion stage that allows both the optical correlation, when operating as a synthesized-image interferometer, and signal detection, when operating as a direct-image instrument. The proposed idea is oriented towards the implementation of ultra-sensitive instruments presenting several dozens or even thousands of microwave receivers operating in the lowest bands of the cosmic microwave background. In this work, an electro-optical back-end module replaces the usual microwave detection stage with Mach–Zehnder modulators for the frequency up-conversion, and an optical stage for the signals correlation and detection at near-infra-red wavelengths (1550 nm). As interferometer, the instrument is able to correlate the signals of large-format instruments, while operating as a direct imaging instrument also presents advantages in terms of the possibility of implementing the optical back end by means of photonic integrated circuits to achieve reductions in cost, weight, size, and power consumption. A linearly polarized input wave, with a variable polar angle, is used as a signal source for laboratory tests. The receiver demonstrator has proved its capabilities of being used as a new microwave-photonic polarimeter for the study of the lowest bands of cosmic microwave background. Full article

Performance modeling of the characteristics of mid-infrared quantum cascade lasers (MIR QCL) is an essential element in formulating consistent component requirements and specifications, in preparing guidelines for the design and manufacture of the QCL structures, and in assessing different modes of operation of the laser device. We use principles of system physics to analyze the electro-optical characteristics of high power MIR QCL, including thermal backfilling of the lower laser level, hot electron effects, and Stark detuning during lasing. The analysis is based on analytical modeling to give simple mathematical expressions which are easily incorporated in system-level simulations of defense applications such as directed infrared countermeasures (DIRCM). The paper delineates the system physics of the electro-optical energy conversion in QCL and the related modeling. The application of the performance model to a DIRCM QCL is explained by an example. Full article
