Ga₂O₃ is an ultra-wide bandgap semiconductor material that has attracted significant attention for deep ultraviolet photodetector applications due to its excellent UV absorption capability and reliable stability. In this study, a novel plasma-enhanced thermal oxidation (PETO) method has been proposed to fabricate Ga₂O₃ thin films on the GaN/sapphire substrate in the gas mixture of Ar and O₂. By adjusting the O₂-to-Ar ratio (2:1, 4:1, and 8:1), the structural, morphological, and photoelectric properties of the synthesized Ga₂O₃ films are systematically studied as a function of the oxidizing atmosphere. It is demonstrated that, at an optimal O₂-to-Ar ratio of 4:1, the synthesized Ga₂O₃ thin film has the largest grain size of 31.4 nm, the fastest growth rate of 427.5 nm/h, as well as the lowest oxygen vacancy concentration of 16.61%. Furthermore, the nucleation and growth of Ga₂O₃ thin films on the GaN/sapphire substrate by PETO is proposed. Finally, at the optimized O₂-to-Ar ratio of 4:1, the metal–semiconductor–metal-structured Ga₂O₃-based photodetector achieves a specific detectivity of $2.74\times {10}^{13}$ Jones and a solar-blind/visible rejection ratio as high as 116 under a 10 V bias. This work provides a promising approach for the cost-effective fabrication of Ga₂O₃ thin films for UV photodetector applications. Full article

In this study, in situ piezoelectricity was incorporated into the photoactive region to prepare a self-powered deep-ultraviolet photodetector based on a mixture of polyvinylidene fluoride (PVDF)@Ga₂O₃ and polyethyleneimine (PEI)/carbon quantum dots (CQDs). A ferroelectric composite layer was prepared using β-Ga₂O₃ as a filler, and the β-phase of PVDF was used as the polymer matrix. The strong piezoelectricity of β-PVDF can facilitate the separation and transport of photogenerated carriers in the depletion region and significantly reduce the dark current when the device is biased with an external bias, resulting in a high on/off ratio and high detection capability. The self-powered PD exhibited specific detectivity (D* = 3.5 × 10¹⁰ Jones), an on/off ratio of 2.7, and a response speed of 0.11/0.33 s. Furthermore, the prepared PD exhibits excellent photoresponse stability under continuous UV light, with the photocurrent retaining 83% of its initial value after about 500 s of irradiation. Our findings suggest a new approach for developing cost-effective UV PDs for optoelectronic applications in related fields. Full article

In this study, we fabricated deep ultraviolet (DUV) photodetectors based on perovskite thin films doped with halide materials using formamidinium bromide (FABr) and methylammonium iodide (MAI). The device was fabricated using a simple surface engineering technique by post-treating the MAPbI₃ perovskite film with an FABr solution. This film acts as a light absorption layer, like a depletion layer with a p-i-n (PIN) structure, with n-type of SnO₂-SDBS and p-type of spiro-OMeTAD. Adding 0.10 M MACl to the MAPbI3 precursor solution during the manufacturing process could effectively reduce the trap density compared with existing films. Films with MACl added in the two-step process can control a wide band gap and improve crystallinity. In addition, the Cl atom has a smaller atomic radius than iodine and a higher electronegativity of 3.16, which can improve phase stability, and the effect of the added Cl⁻ increases the electron mobility of the perovskite, showing a fast response. Full article

In this study, a perovskite-based mixed cation/anion ultraviolet photodetector with an added halide material is fabricated using perovskite combined with an ABX_3 structure. Mixed cation/anion perovskite thin films of MAPbI₃/FABr are manufactured through a relatively simple solution process and employed as light-absorption layers. In the produced thin film, SnO₂–sodium dodecylbenzenesulfonate acts as an electron transport layer and spiro-OMeTAD acts as a hole injection layer. Compared to a single cation/anion perovskite, the fabricated device exhibits phase stability and optoelectronic properties, and demonstrates a responsivity of 72.2 mA/W and a detectability of 4.67 × 10¹³ Jones. In addition, the films show an external quantum efficiency of 56%. This suggests that mixed cation/anion films can replace single cation/anion perovskite films. Thus, photodetectors based on lead halides that can be applied in various fields have recently been manufactured. Full article

Ozone (O₃) is a critical gas in various industrial applications, particularly in semiconductor manufacturing, where it is used for wafer cleaning and oxidation processes. Accurate and reliable detection of ozone concentration is essential for process control, ensuring product quality, and safeguarding workplace safety. By studying the UV absorption characteristics of O₃ and combining the specific operational needs of semiconductor process gas analysis, a pressure-insensitive ozone gas sensor has been developed. In its optical structure, a straight-through design without corners was adopted, achieving a coupling efficiency of 52% in the gas chamber. This device can operate reliably in a temperature range from 0 °C to 50 °C, with only ±0.3% full-scale error across the entire temperature range. The sensor consists of a deep ultraviolet light-emitting diode in a narrow spectrum centered at 254 nm, a photodetector, and a gas chamber, with dimensions of 85 mm × 25 mm × 35 mm. The performance of the sensor has been meticulously evaluated through simulation and experimental analysis. The sensor’s gas detection accuracy is 750 ppb, with a rapid response time (t₉₀) of 7 s, and a limit of detection of 2.26 ppm. It has the potential to be applied in various fields for ozone monitoring, including the semiconductor industry, water treatment facilities, and environmental research. Full article

Ultraviolet (UV) photodetectors are key devices required in the industrial, military, space, environmental, and biological fields. The Schottky barrier (SB)-MOSFET, with its high hole and electron barrier, and given its extremely low dark current, has broad development prospects in the optoelectronics field. We analyze the effects of trap states on the output characteristics of an inversion mode n-channel GaN SB-MOSFET using TCAD simulations. At the oxide/GaN interface below the gate, it was demonstrated that shallow donor-like traps were responsible for degrading the subthreshold swing (SS) and off-state current density (I_off), while deep donor-like traps below the Fermi energy level were insignificant. In addition, shallow acceptor-like traps shifted the threshold voltage (V_t) positively and deteriorated the SS and on-state current density (I_on), while deep acceptor-like traps acted on a fixed charge. The output characteristics of the GaN SB-MOSFET were related to the resistive GaN path and the tunneling rate due to the traps at the metal (source, drain)/GaN interface. For the UV responses, the main mechanism for the negative V_t shift and the increases in the I_on and spectral responsivity was related to the photo-gating effect caused by light-generated holes trapped in the shallow trap states. These results will provide insights for UV detection technology and for a high-performance monolithic integration of the GaN SB-MOSFET. Full article

In this study, a highly crystalline and transparent indium-tin-oxide (ITO) thin film was prepared on a quartz substrate via RF sputtering to fabricate an efficient bottom-to-top illuminated electrode for an ultraviolet C (UVC) photodetector. Accordingly, the 26.6 nm thick ITO thin film, which was deposited using the sputtering method followed by post-annealing treatment, exhibited good transparency to deep-UV spectra (67% at a wavelength of 254 nm), along with high electrical conductivity (11.3 S/cm). Under 254 nm UVC illumination, the lead-halide-perovskite-based photodetector developed on the prepared ITO electrode in a vertical structure exhibited an excellent on/off ratio of 1.05 × 10⁴, a superb responsivity of 250.98 mA/W, and a high specific detectivity of 4.71 × 10¹² Jones without external energy consumption. This study indicates that post-annealed ITO ultrathin films can be used as electrodes that satisfy both the electrical conductivity and deep-UV transparency requirements for high-performance bottom-illuminated optoelectronic devices, particularly for use in UVC photodetectors. Full article

Monoclinic β-Ga₂O₃ microbelts were successfully fabricated using a one-step optical vapor supersaturated precipitation method, which exhibited advantages including a free-standing substrate, prefect surface, and low cost. The as-grown microbelts possessed a well-defined geometry and perfect crystallinity. The dimensions of individual β-Ga₂O₃ microbelts were a width of ~50 μm, length of ~5 mm, and thickness of ~3 μm. The SEM, XRD, HRTEM, XPS, and Raman spectra demonstrated the high single-crystalline structure of β-Ga₂O₃ microbelts. Twelve frequency modes were activated in Raman spectra. The optical band gap of the β-Ga₂O₃ microbelt was calculated to be ~4.45 eV. Upon 266 nm excitation, 2 strong UV emissions occurred in photoluminescence spectra through the radiative recombination of self-trapped excitons, and the blue emission band was attributed to the presence of donor-acceptor-pair transition. The individual β-Ga₂O₃ microbelt was employed as metal-semiconductor-metal deep-ultraviolet photodetector, which exhibits the photoresponse under 254 nm. This work provides a simple and economical route to fabricate high-quality β-Ga₂O₃ single-crystal microbelts, which should be a potential synthetic strategy for ultra-wide bandgap semiconductor materials. Full article

Constitutive engineering by adding halide anions is one effective way to improve the performance of photodetectors by adjusting the bandgap. In this study, a mixed-anion perovskite thin film was facile fabricated by post-processing of a pure FAPbI₃ film with a formamidinium bromide (FABr) solution. In addition, the manufactured thin film was used as the light absorption layer, SnO₂-SDBS as the electron transport layer, and spiro-OMeTAD as the hole injection layer to fabricate a deep ultraviolet(UV) photodetector. The device exhibited a response of 43.8 mA/W⁻¹, a detectability of 3.56 × 10¹³ Jones, and an external quantum efficiency of 38%. Therefore, this study is promising for various applications in the deep-UV wavelength region. Full article

Deep-ultraviolet (UV) sensing has attracted significant interest because of its wide range of applications. A mixed-cation halide perovskite-based photodetector prepared by mixing CH₃NH₃PbX₃ (X = I, Br, and Cl) and HC(NH₂)PbX₃ (X = I, Br, and Cl) exhibits high stability and excellent light absorption. In this study, perovskite was prepared by mixing CH₃NH₃⁺ (FA⁺) and HC(NH₂)₂⁺ (MA⁺) cations using I⁻, Br⁻, and Cl⁻ halide anions. The bandgaps of the prepared perovskites increased to 1.48, 2.25, and 2.90 eV with I-, Br-, and Cl-, respectively, and the light absorption spectra shifted to shorter wavelengths. An increase in the redshift of the light absorption led to an increase in the photocurrent. The FAPbCl₃-MAPbCl₃-based photodetector showed a high responsivity of 5.64 mA/W, a detectivity of 4.03 × 10¹¹, and an external quantum efficiency of 27.3%. The results suggested that the FAPbCl₃-MAPbCl₃ perovskite is suitable for deep-UV light sensing and is an excellent candidate for the fabrication of a sensitive photodetector. Full article

All-inorganic perovskites, with their low-cost, simple processes and superior heat stability, have become potential candidate materials for photodetectors (PDs). However, they have no representative responsivity in the deep-ultraviolet (UV) wavelength region. As a new-generation semiconductor, gallium oxide (Ga₂O₃), which has an ultrawide bandgap, is appropriate for solar-blind (200 nm–280 nm) deep-UV detection. In this work, ultrawide-bandgap Ga₂O₃ was introduced into an inorganic perovskite device with a structure of sapphire/β-Ga₂O₃/Indium Zinc Oxide (IZO)/CsPbBr₃. The performance of this perovskite PD was obviously enhanced in the deep UV region. A low-cost, vacuum-free Mist-CVD was used to realize the epitaxial growth of β-Ga₂O₃ film on sapphire. By introducing the Ga₂O₃ layer, the light current of this heterojunction PD was obviously enhanced from 10⁻⁸ to 10⁻⁷, which leds its detectivity (D*) to reach 1.04 × 10¹² Jones under a 254 nm light illumination with an intensity of 500 μW/cm² at a 5 V bias. Full article

Considering practical application and commercialization, the research of non-toxic and stable halide perovskite and its application in the field of photoelectric detection have received great attention. However, there are relatively few studies on deep ultraviolet photodetectors, and the perovskite films prepared by traditional spin-coating method have disadvantages such as uneven grain size and irregular agglomeration, which limit their device performance. Herein, uniform and ordered Cs₃Cu₂I₅ nanonet arrays are fabricated based on monolayer colloidal crystal (MCC) templates prepared with 1 μm polystyrene (PS) spheres, which enhance light-harvesting ability. Furthermore, the performance of the lateral photodetector (PD) is significantly enhanced when using Cs₃Cu₂I₅ nanonet compared to the pure Cs₃Cu₂I₅ film. Under deep ultraviolet light, the Cs₃Cu₂I₅ nanonet PD exhibits a high light responsivity of 1.66 AW⁻¹ and a high detection up to 2.48 × 10¹² Jones. Meanwhile, the unencapsulated PD has almost no response to light above 330 nm and shows remarkable stability. The above results prove that Cs₃Cu₂I₅ nanonet can be a great potential light-absorbing layer for solar-blind deep ultraviolet PD, which can be used as light absorption layer of UV solar cell. Full article

High Mg content (60%) ZnMgO samples with and without Ga dope were grown by an RF magnetron sputtering system. The effect of Ga dope on the ZnMgO sample and the respective ultraviolet photodetectors (UVPD) device’s performance were carefully studied by various experimental methods. The investigations of the structure and optical properties of the ZnMgO sample established that the Ga doped sample has a better crystal quality and larger band gap (5.54 eV). The current-voltage characteristics indicate that both the photocurrent and dark current were enhanced after Ga dope. Under 12 V bias, the undoped UVPD show two spectral response peaks at 244 nm and 271 nm with a responsivity of 1.9 A/W and 0.38 A/W, respectively. While the Ga doped UVPD showed only one response peak at 241 nm and the deep UV responsibility up to 8.9 A/W;, as the bias increased from 12 V to 60 V, the responsiveness raised to 52 A/W, with a signal to noise ratio (241 nm/700 nm) as high as 10⁵. Combining the results of XRD, PL spectrum and XPS, the enhanced ultraviolet photoresponse of the Ga dope device contributed to improving the crystal quality and “dopant-defect pairing effect” caused by Ga doping, which led to a considerable reduction in the number of ionized impurities in the scatting centers, and enhanced the carrier’s mobility. Our work demonstrates that even a high Mg content ZnMgO can exhibit enhanced UV performance after a Ga dope due to the dopant-defect pairing effect, which confirmed the advantage of the use of ZnMgO in the deep-UV region. Full article

Interest in the synthesis and fabrication of gallium oxide (Ga₂O₃) nanostructures as wide bandgap semiconductor-based ultraviolet (UV) photodetectors has recently increased due to their importance in cases of deep-UV photodetectors operating in high power/temperature conditions. Due to their unique properties, i.e., higher surface-to-volume ratio and quantum effects, these nanostructures can significantly enhance the sensitivity of detection. In this work, two Ga₂O₃ nanostructured films with different nanowire densities and sizes obtained by thermal oxidation of Ga on quartz, in the presence and absence of Ag catalyst, were investigated. The electrical properties influenced by the density of Ga₂O₃ nanowires (NWs) were analyzed to define the configuration of UV detection. The electrical measurements were performed on two different electric contacts and were located at distances of 1 and 3 mm. Factors affecting the detection performance of Ga₂O₃ NWs film, such as the distance between metal contacts (1 and 3 mm apart), voltages (5–20 V) and transient photocurrents were discussed in relation to the composition and nanostructure of the Ga₂O₃ NWs film. Full article

Ultrafast, high-sensitivity deep-ultraviolet (UV) photodetectors are crucial for practical applications, including optical communication, ozone layer monitoring, flame detection, etc. However, fast-response UV photodetectors based on traditional materials suffer from issues of expensive production processes. Here, we focused on pyrite with simultaneously cheap production processes and ultrafast response speed. Nanoseconds photovoltaic response was observed under UV pulsed laser irradiation without an applied bias at room temperature. In addition, the response time of the laser-induced voltage (LIV) signals was ~20 ns, which was the same as the UV laser pulse width. The maximum value of the responsivity is 0.52 V/mJ and the minimum value of detectivity was about to ~1.4 × 10¹³ Jones. When there exists nonuniform illumination, a process of diffusion occurs by which the carriers migrate from the region of high concentration toward the region of low concentration. The response speed is limited by a factor of the diffusion of the carriers. With an increment in laser energy, the response speed of LIV is greatly improved. The high response speed combined with low-cost fabrication makes these UV photodetectors highly attractive for applications in ultrafast detection. Full article
