Search Results (181)

Permeability anisotropy, which is widely present in natural soil deposits, plays an important role in controlling groundwater flow patterns and ground deformation during deep excavation dewatering. However, isotropic assumptions are still commonly adopted in engineering practice, making it difficult to accurately capture realistic subsurface hydraulic conditions. In this study, a deep foundation pit of a metro station in Jinan, China, is taken as a case study. A three-dimensional excavation–dewatering model incorporating permeability anisotropy is established using PLAXIS 3D to systematically investigate the influence of the permeability ratio (Kx/Kz) ranging from 0.1 to 10 on the seepage field evolution, dewatering influence radius, ground surface settlement, and consolidation time history. The results indicate that increasing permeability anisotropy promotes a fundamental transition of the seepage regime from vertically concentrated recharge to laterally dominated radial flow. Correspondingly, the dewatering influence radius exhibits a pronounced non-monotonic response to Kx/Kz, decreasing significantly with increasing permeability ratio and reaching a minimum at approximately Kx/Kz ≈ 5, followed by a slight rebound. Meanwhile, surface settlement profiles evolve from a localized concentration pattern to a widely distributed form as permeability anisotropy increases, accompanied by a remarkable outward expansion of the settlement influence zone. Both the magnitude and spatial distribution of settlement show high sensitivity to variations in permeability anisotropy. Based on these findings, a three-stage conceptual seepage structure model accounting for permeability anisotropy is proposed, characterized by vertically dominated flow, a transitional competition regime, and horizontally dominated flow. The staged evolution of seepage structures is shown to govern the non-monotonic variation in the dewatering influence radius and the spatial–temporal response of ground settlement. The results indicate a dual-scale influence mechanism of permeability anisotropy on dewatering-induced hydro-mechanical behavior, providing a theoretical basis for refined dewatering design and environmental impact assessment in deep excavation projects. Full article

Assembled H-shaped steel strut (AHSS) has been widely applied in deep excavation projects. In this study, the collapse failure of AHSS C1 in a deep excavation project in China was investigated. The collapse of C1 was directly attributed to the settlement of its supporting columns in the mid-span, which was triggered by a nearby pit bottom leakage through an exploration borehole. Then the implementation of the emergency measures and reconstruction works were introduced. Theoretical and numerical pre-assessments confirmed that the reconstructed C1 exhibited adequate safety for strength, in-plane stability and out-of-plane stability, with all steel components and bolts within their safe limits. The good working performance of reconstructed C1 was finally verified through the monitoring results (i.e., strut axial force, soil horizontal displacement, column vertical displacement, road settlement and building settlement) of the foundation pit during the subsequent soil excavation and basement construction. This study is believed to provide references for future excavation projects using AHSS with similar risks. Full article

With the acceleration of urbanization, deep and large foundation pit projects have become increasingly common, posing challenges for retaining structural performance. This study investigates the mechanism of the recently proposed vertical–inclined pile wall (VIPW) through physical model tests. Six sets of large-scale model tests of foundation pit excavation under 1 g gravity conditions were carried out. Among these tests, one employed the soldier pile wall (SPW) as the support system, while the remaining five adopted the VIPW. By monitoring and analyzing the distribution and variation in the vertical pile deformation, surface settlement, pile bending moment, and inclined pile top axial force during the excavation process, the action mechanism of the VIPW was revealed, and it was verified that VIPWs exhibit better support performance than SPWs. Furthermore, four key parameters, including the embedded depth, the inclination angle, the support position of the inclined piles, and the embedded depth of the vertical piles, were varied to study their influence on the deformation and force characteristics of the VIPW, providing a theoretical basis for structural optimization design. Moreover, by comparing the instability and failure characteristics of the foundation pit, it was proved that the VIPW can effectively ensure the stability of the foundation pit. Full article

This study addresses the high-risk scenario of dual-sided deep foundation pit construction adjacent to operational metro lines, a complex urban underground engineering context with significant safety implications. A multi-level dynamic safety risk assessment model is proposed by integrating the Analytic Hierarchy Process (AHP) with a risk matrix. Existing approaches generally lack the capability to dynamically incorporate spatiotemporal variations and real-time construction management information, limiting their applicability under complex working conditions. To overcome these limitations, the Tianjin Shouchuang Beiyunhe Metro Complex project is adopted as a case study to develop a concise and efficient risk assessment framework. The framework introduces spatiotemporal effect and safety management coefficients to dynamically adjust risk values and conducts risk identification and integrated evaluation across four dimensions—geology, environment, design, and construction—using 25 indicators. The model enables quantitative, real-time identification and dynamic control of safety risks during metro foundation pit construction. The assessment results indicate that the overall project risk is classified as Level I (highest), with the western pit exhibiting slightly higher risk. Targeted mitigation measures include the use of diaphragm walls with internal buttresses and grouting reinforcement. Compared with conventional methods, the proposed model demonstrates significant advantages in adapting to dynamic construction conditions, enhancing engineering applicability, and strengthening early-warning capability. These improvements provide a scientific, practical, and scalable technical solution for the accurate identification of critical risks and proactive safety management in complex metro foundation pit projects. Full article

To evaluate the coupled deformation of existing shield tunnels induced by multi-segment excavations with isolation piles, this study develops an integrated analytical framework combining a Kerr three-parameter foundation-plate model with a three-dimensional image-source solution. A closed-form expression for the soil displacement field is first derived by incorporating layered soil conditions, staged excavation, and associated spatial effects. The soil–pile interaction of isolation piles is then modeled using the Kerr foundation, and the flexural response is obtained through variational formulation and finite-difference discretization. These responses are sequentially propagated through the excavation stages, enabling the superposition of multi-pit effects on the final retaining-wall deformation. The image-source method and a volume-equivalent transformation are further used to convert wall deformation into an additional stress field acting on the tunnel, which is ultimately coupled with a tunnel–soil deformation–coordination model to compute horizontal tunnel displacements. This unified workflow establishes a continuous mechanical transfer chain—from excavation-induced soil loss to isolation-pile bending and finally tunnel deformation. Parametric analyses show that lateral displacement of the retaining structure is jointly governed by wall bending and pit-bottom uplift, producing a right-skewed “S-shaped’’ profile. The bending-moment peak shifts toward earlier-excavated zones, indicating a memory effect of excavation sequencing. Two engineering cases verify that the proposed method accurately reproduces the magnitude and depth of measured wall deflections, while predicted tunnel displacements show a near-Gaussian pattern with high accuracy near the peak. The analytical framework provides a robust theoretical basis for optimizing pit segmentation and excavation sequencing adjacent to shield tunnels. Full article

The deep foundation pit excavation of subway will cause horizontal displacement, uneven settlement and other adverse effects on the adjacent shield. The use of servo steel strut has a certain effect on deflection correction, but the current understanding of the influencing factors of deflection correction is not comprehensive. Based on structural and spatial symmetry, the influence of tunnel depth, tunnel and foundation pit clear distance and deformation control quantity of enclosure structure on deflection correction quantity was studied by symmetrically designed model test and numerical simulation, and the prediction formula of deflection correction quantity considering tunnel and foundation pit clear distance and deformation control quantity of enclosure structure was proposed. The results show that with an increase in the tunnel’s burial depth, deflection correction decreases significantly. When the tunnel is near the foundation pit bottom, there is no significant correction effect, and the control law of the tunnel ground pressure under the servo steel strut loading is consistent with the correction law. Deflection correction is negatively correlated with the tunnel and foundation pit clear distance, and positively correlated with the deformation control of the diaphragm wall. The curve of the deformation control of the enclosure structure and the deflection correction is parabolic. The deflection correction is an exponential function of the ratio of the deformation control of the enclosure structure to the clear distance between the tunnel and the foundation pit, and the servo deflection correction follows a normal distribution along the longitudinal axis of the tunnel, showing obvious symmetry characteristics in the foundation pit influence zone. Full article

Three-dimensional spatial effects in deep excavations critically govern the mechanical response of retaining structures and adjacent soils, yet their quantitative characterization remains a challenge. This study systematically investigates the spatial behavior of row-pile-supported foundation pits through an integrated approach combining model tests, theoretical analysis, and numerical simulations. A novel formulation for the spatial effect influence coefficient K is derived from limit equilibrium principles and subsequently validated via ABAQUS-based finite element simulations. Model test results reveal pronounced spatial heterogeneity in earth pressure and bending moment distributions along the pit perimeter: lateral earth pressure at corner regions exceeds that at mid-side locations at equivalent depths, whereas bending moments in mid-side piles are substantially larger than those at corners. Displacement field measurements further demonstrate that corner zones, constrained bidirectionally, undergo minimal deformation, while maximum displacement occurs at the midpoints of the long sides. These observations collectively confirm the existence of a marked corner effect and a subdued side-midpoint effect under three-dimensional confinement. Complementary numerical analyses indicate that the coefficient K decreases monotonically with increasing half-angle corners and distance from the corner, thereby quantitatively capturing the decay of spatial constraint intensity. Together, these findings establish a theoretical framework for assessing excavation-induced spatial effects and provide actionable guidance for the rational design of deep foundation pit support systems. Full article

Addressing the challenges in 3D reconstruction of large-scale open-pit mines, such as dramatic terrain undulations, complex texture features, and the difficulty of balancing geometric accuracy with real-time rendering efficiency using traditional methods, this paper proposes a high-fidelity reconstruction framework integrating UAV multi-modal data with the state-of-the-art 3D Gaussian Splatting (3DGS) architecture. First, an integrated air-ground multi-modal data acquisition system is established. Using a UAV equipped with LiDAR and a high-resolution camera, high-quality geometric and textural data of the mining area are acquired through terrain-adaptive flight planning. Second, to tackle the VRAM bottlenecks and loose geometric structures inherent in original 3DGS for large scenes, we adopt the advanced CityGaussianV2 architecture as our core reconstruction engine. By leveraging its divide-and-conquer parallel training strategy, 2DGS planar geometric constraints, and Decomposed Gradient Densification (DGD) mechanism, this framework effectively overcomes memory limitations and significantly enhances the geometric sharpness of slope crests and toes. Finally, engineering validation was conducted at Kambove Mining. Experimental results demonstrate that the proposed method achieves centimeter-level geometric accuracy, a real-time web rendering frame rate exceeding 60 FPS, and a model storage compression rate of over 90%. The digital twin control platform built upon this model successfully achieves deep fusion and visual scheduling of multi-source heterogeneous data, providing a novel technical path for constructing high-precision reality-based foundations for smart mines. Full article

Current methods for predicting deep excavation deformation suffer from insufficient accuracy and limited generalization capability. Moreover, the applicability of these methods to different types of monitoring data also requires in-depth analysis. To address this, a machine learning-based prediction model, i.e., the VMD-GWO-CNN model, integrating Variational Mode Decomposition (VMD), the Grey Wolf Optimizer (GWO), and the Convolutional Neural Network (CNN), is proposed to predict various types of monitoring data. The GWO algorithm optimizes both the key parameters of VMD and the hyperparameters of the CNN. The optimized CNN model predicts each subsequence decomposed by VMD, and the final prediction is obtained by superimposing these results. Furthermore, the prediction performance of the proposed model is evaluated against the LSTM, CNN, and GWO-CNN models using four metrics (RMSE, MAE, MAPE, R²). The results indicate that all four algorithms possess effective predictive capability for the monitoring data, in which the VMD-GWO-CNN model demonstrates the best performance across all metrics. Specifically, its RMSE for surface settlement prediction is reduced by 59.2%, 34.1%, and 33.0% compared to the LSTM, CNN, and GWO-CNN models, respectively. Moreover, the VMD-GWO-CNN model exhibits strong predictive performance for deformation in slope engineering and subgrade engineering, demonstrating its good applicability across different geotechnical engineering. The findings provide a scientific basis for safe excavation construction and contribute to efficient and rapid execution of foundation pit projects. Full article

With the intensive development of urban underground space, excavations adjacent to existing tunnels have become increasingly common. This study investigates the response of adjacent tunnels and surrounding soil to multi-step foundation pit excavation and the effect and mechanism of a new capsule technology. Centrifuge model tests and finite element analysis were conducted for models both with and without a capsule. The results show that the soil deformation caused by each excavation step is confined to an influence zone. As the excavation deepens, this influence zone progressively expands. Excavation causes the tunnel to move outward and the retaining wall to rotate clockwise. The results demonstrate that capsule pressurization can effectively reduce the maximum horizontal displacement of the adjacent tunnel by approximately 30–40% compared to the case without reinforcement. Capsule pressurization alters the earth pressure distribution on the retaining wall and reduces tunnel displacement. The effect of the capsule decays with increasing distance from the capsule to the tunnel. The excavation impact propagates to the tunnel via wall–soil and soil–tunnel interactions. Capsule pressurization mitigates the tunnel response by ensuring that the surrounding soil experiences a smaller reduction in horizontal stress and exhibits a higher modulus during subsequent excavation. This enhanced state of the soil produces smaller deformation, which ultimately transfers less of the excavation effect to the tunnel and controls its displacement. The study concludes that the active pressure control offered by the capsule technology is a promising method for protecting existing tunnels during adjacent deep excavations. Full article

Diaphragm walls are widely used for deep foundation pit support and permanent underground structures. The joints between adjacent panels are critical weak points, significantly influencing the overall deformation and stress distribution of the structure. To address the insufficient shear and tensile capacity of existing diaphragm wall joints, this study proposes a novel rigid joint incorporating retractable shear studs. The joint features a straightforward and constructible design, primarily comprising retractable shear studs, H-section steel, and shear stud pop-out limit plates. By withdrawing the limit plates inserted into the H-section steel, the retractable shear studs mounted on the web automatically extend along their axis, penetrating into the adjacent reinforcement cage to form an intrusive lap joint. This mechanism effectively enhances the integrity and load-bearing capacity at the joint. To validate its mechanical performance, large-scale specimens featuring this new joint were fabricated and subjected to shear and tensile tests. The experimental results demonstrate that, compared to traditional H-section steel joints, the peak shear and tensile strengths of the proposed joint are increased by approximately 10 times and 16 times, respectively. These findings fully verify the excellent mechanical performance of the novel diaphragm wall joint structure. Full article

With its advantages such as large capacity, punctuality and low environmental impact, the metro has become one of the primary means of alleviating urban traffic congestion. However, safety accidents still occur frequently during the construction of metro deep foundation pits. A review of domestic and international studies reveals that safety risk management for metro deep foundation pit construction remains insufficient, particularly in terms of comprehensive risk identification, analysis of risk interrelationships and systematic risk assessment. To improve the level of safety risk management in metro deep foundation pit construction, this study analyzes safety risk factors using Chinese word segmentation, AHP, ISM, and MICMAC methods. Based on text mining and literature review, a case database comprising 156 metro deep foundation pit construction safety accidents reports was established and integrated into a unified text corpus. Chinese word segmentation was then performed on the corpus, and through risk interpretation combined with relevant standards and codes, 29 safety risk factors were identified and classified into five categories: technology, management, material, personal and environment. On this basis, 22 main safety risk factors were extracted using the AHP method. The results indicate that management-related factors constitute the most critical type of safety risk. Subsequently, the ISM method was employed to identify the interactions among the main safety risk factors and to construct a five-level hierarchical model, in which the top level contains nine safety risk factors, while the bottom level consists of two factors. Through MICMAC analysis, the safety risk factors were classified into three categories, based on which a safety risk management framework for metro deep foundation pit construction was established, and specific control measures were proposed for six representative safety risk factors. Full article

As China’s urban underground area grows, deep foundation pit projects in complex geological circumstances, particularly near critical infrastructure, must adhere to tight deformation control guidelines. However, limited research has been conducted on the deformation behavior of internal bracing systems in Sichuan’s sandy cobble strata. This research centers on a deep excavation near civil defense facilities in Pujiang County, Chengdu. We investigated the deformation characteristics of retaining piles and internal bracing systems using field monitoring, finite element simulations, and parameter sensitivity analysis, and proposed optimization solutions for the support scheme. Road settlement, pile-head vertical displacement, building settlement, and deep lateral displacement of retaining piles were all monitored in the field at different phases of excavation. MIDAS/GTS was used to generate a 3D finite element model that included bored piles as a contiguous pile wall. The model was verified against monitored data and showed a maximum variation of 3.7%. Parametric studies were conducted to optimize the equivalent stiffness of the contiguous pile wall and the standardized internal bracing system. The findings indicate that the maximum lateral displacement of retaining piles is the primary optimization restriction. Reducing the equivalent stiffness to 0.6t (relative to the baseline thickness t) causes displacement to surpass the warning threshold (35 mm), whereas increasing it to 1.2t or 1.4t limits deformation without incurring significant costs. Case G of the standardized internal bracing system ensures that the maximum pile displacement (21.95 mm) remains below the warning criterion (24.5 mm) while improving constructability. This work elucidates the deformation characteristics of internal bracing systems in sandy cobble strata near sensitive buildings, offering theoretical and practical assistance for comparable projects. Full article

The elastic support stiffness coefficient $k_R$ of opposing horizontal struts constitutes a critical parameter in the design of strutted retaining structures for deep excavations. The determination of the fixed-point adjustment coefficient $\lambda$ serves as a fundamental prerequisite for the quantitative assessment of this stiffness coefficient. To identify the fixed-point location and establish a computational approach for $\lambda$, the endpoint displacements of opposing horizontal struts are classified into four distinct scenarios. For each scenario, the relationship between the lateral earth pressures on both sides of the excavation is derived, the support mechanism of the internal strut is elucidated, and the corresponding fixed-point locations of the struts are determined. Utilizing the response curve between the support-point displacement of the retaining structure and the lateral earth pressure, and adhering to the principle of linearization, analytical formulas for $\lambda$ under the four scenarios are formulated. The proposed method is employed to compute and evaluate the fixed-point adjustment coefficient of the opposing horizontal struts in a case study drawn from the literature, with the results rigorously compared against the existing published data. Furthermore, the $\lambda$ values for opposing horizontal struts in a metro station excavation project are computed and contrasted with values back-calculated from monitored horizontal displacements of the retaining structure. The findings demonstrate that the proposed method for determining $\lambda$ is both computationally efficient and practically applicable. The derived $\lambda$ values can be effectively used to predict internal forces and deformations in retaining structures for asymmetrically loaded deep excavations. This research offers substantial theoretical insights and practical implications for the scientifically informed design and construction of deep excavation support systems. Full article

Deep foundation excavation in water-rich sand strata presents complex deformation characteristics driven by fluid–solid interaction, which distinguishes it from excavations in cohesive soft clay. This study investigates the spatiotemporal evolution and deformation mechanisms of retaining structures through a comparative analysis of field monitoring data and 3D numerical simulation, based on a subway station project in Xi’an. While the numerical simulation predicted a continuous “bulging” deformation mode, field monitoring revealed a distinct transition from a “bulging” profile to a “step-like” deformation pattern as the excavation deepened. Quantitatively, while the simulation captured the spatial trend, the measured maximum surface settlement (7.8 mm) exceeded the simulated value (1.2 mm), highlighting the dominant role of seepage consolidation. Detailed analysis indicates that this discrepancy—and the unique step-like evolution—is primarily driven by two mechanisms: the rapid stress relaxation of cohesionless sand during the time lag of support installation, and the superimposed seepage forces induced by continuous dewatering, which are often simplified in standard elastoplastic models. The study further identifies that the vertical displacement of the pile top is governed by the combined effects of basal heave and the “kick-out” deformation at the pile toe. These findings demonstrate that in high-permeability water-rich sand, deformation control depends critically on minimizing the unsupported exposure time of the excavation face. This research provides a theoretical basis for optimizing the spatiotemporal sequencing of excavation in similar geological conditions. Full article
