Search Results (9)

Air purification is a key process aimed at removing harmful impurities and providing a safe and comfortable environment for human life and work. This study presents the results of an investigation into the composition, textural, and sorption properties of a multichannel carbon filtering material developed for air purification from biological (infectious) contaminants. The filtering block has a cylindrical shape and is manufactured by extrusion of a plastic composition based on carbonized rice husk with the addition of binding agents, followed by staged thermal treatment (calcination, activation, and demineralization). The filter’s effectiveness is based on the inactivation of pathogenic microorganisms as the air passes through the porous surface of the sorbent, which is modified with broad-spectrum antiseptic agents (active against bacteria, bacilli, fungi, and protozoa). X-ray diffraction analysis revealed the presence of amorphous carbon in a tubostratic structure, with a predominance of sp- and sp²-hybridized carbon atoms not incorporated into regular graphene lattices. IR spectroscopy demonstrated the presence of reactive functional groups characteristic of the developed porous structure of the material, which is capable of selective sorption of antiseptic molecules. SEM surface analysis revealed an amorphous texture with a loose structure and elements in the form of spherical semi-ring formations formed by overlapping carbon plates. An experimental setup was also developed using cylindrical multichannel carbon blocks with a diameter of 48 mm, a length of 120 mm, and 100–120 longitudinal channels with a cross-section of 1 mm². The obtained results confirm the potential of the proposed material for use in air purification and disinfection systems under conditions of elevated biological risk. Full article

This paper presents the results of experimental studies on the propagation of longitudinal and transverse ultrasonic waves through a metamaterial—a composite material based on polymer matrix with periodically arranged cylindrical elements. Such structures are known as phononic crystals. Amplitude–frequency characteristics were measured for phononic crystals with air and metal cylindrical elements, for both longitudinal waves (in the frequency range from 1.5 to 3 MHz) and transverse waves (in the range from 0.2 to 1.2 MHz). A twofold decrease in the amplitude of the transmitted longitudinal ultrasonic wave was experimentally demonstrated in the passband centered at 1.87 MHz during rotation of the phononic crystal. It was also found that the polarization angle of the transverse ultrasonic wave influences the localization of band gaps and passbands. Band gaps, characterized by amplitude minima near 240 kHz, 290 kHz, and 830 kHz and observed for waves polarized parallel to the crystal axis, are replaced by passbands when the wave is polarized perpendicularly. These results suggest the potential for developing analog ultrasonic frequency filters tunable by the angle of rotation. Full article

This paper presents an experimental study of the effect of the mass of dust retained on a fibrous filter bed operating singly and in a “cyclone-filter-bed” system on changes in filtration efficiency and accuracy, as well as the increase in flow resistance. The research was carried out using a novel and unprecedented method, determining the dust absorption coefficient km of the filter baffle under laboratory conditions. A filtration system built of a single cyclone and a cylindrical filter cartridge with an appropriately sized surface set behind it was studied. Conditions corresponding to the actual operating conditions of the air filter were maintained: dust concentration, filtration speed and dust extraction from the cyclone settling tank. The purpose of the research was to evaluate filter materials with different structures in terms of filtration efficiency and accuracy, as well as flow resistance. The study showed that the parameters of the structure of filter materials—permeability, grammage and thickness—affect the process of retaining dust particles. It was shown that the increase in the flow resistance of the filter bed has a higher intensity when dust grains of small sizes are directed at it, which is the case when the bed is operated behind a cyclone, which separates larger dust grains from the air. There is a reduction in the operating time of the filtration system due to the limitation of the permissible resistance ∆p_fdop, and the corresponding dust absorption k_m has a lower value. For a fixed value of the flow resistance, the dust absorption coefficient k_m2 of three different filtration baffles AC, B2, and B, working with a cyclone, take values 50–100% smaller than when working in a single-stage system. It has been shown that the “cyclone-filter baffle” unit, due to its greater dust separation capability, allows the filter cartridge to operate for a longer time until a certain flow resistance is reached. This allows the unit to operate longer at lower flow resistance without changing the filter cartridge, thus saving energy. The k_m values obtained during the tests, using the proposed original method, allow the selection of the filter bed for specific vehicle operating conditions by modelling its course. Full article

Fungal spores that cause infectious fungal diseases in rice are mainly transmitted through air. The existing fixed, portable or vehicle-mounted fungal spore collection devices used for rice infectious diseases have several disadvantages, such as low efficiency, large volume, low precision and incomplete information. In this study, a mobile fungal spore collection device is designed, consisting of six filters called “Capture-A”, which can collect spores and other airborne particles onto a filter located on a rotating disc of six filters that can be rotated to a position allowing for the capture of six individual samples. They are captured one at a time and designed and validated by capturing spores above the rice field, and the parameters of the key components of the collector are optimized through fluid simulation and verification experiments. The parameter combination of the “Capturer-A” in the best working state is as follows: sampling vessel filter screen with aperture size of 0.150 mm, bent air duct with inner diameter of 20 mm, negative pressure fan with 1500 Pa and spore sampling of cylindrical shape. In the field test, the self-developed “Capturer-A” was compared with the existing “YFBZ3” (mobile spore collection device made by Yunfei Co., Ltd., Zhengzhou, China). The two devices were experimented on at 15 sampling points in three diseased rice fields, and the samples were examined and counted under a microscope in the laboratory. It was found that the spores of rice blast disease and rice flax spot disease of rice were contained in the samples; the number of samples collected by a single sampling vessel of “Capturer-A” was about twice that of the device “YFBZ3”in the test. Full article

The material most commonly used to filter and clean the intake air of vehicle internal combustion engines is pleated filter paper, which in most cases is shaped in the form of a cylinder or panel. The production technology has a low cost and is not complicated. In addition to high separation efficiency and filtration performance, pleated filter media are required to have low initial pressure drop, which depends on the geometry of the bed. Much research has been conducted in this area. Dust accumulated in the filter bed causes an increase in pressure drop, which is the cause of deformation and sticking of pleats. The lack of stability of the pleats, the need to strengthen them, and the need to obtain small sizes while achieving high efficiency and accuracy of filtration of engine intake air was the reason for the development of a different design and a new technology for making filter cartridges called PowerCore. The distinctive feature of these filters is axial flow in one direction of the air stream, which avoids turbulence and thus minimizes pressure drop. This paper presents a comparative analysis of a standard PowerCore and PowerCore G2 filter bed and two cylindrical filters with a pleated filter bed made of cellulose and polyester. The conditions and methodology of experimental testing of filters with test dust are presented. During the tests, the characteristics of separation efficiency and filtration performance, as well as pressure drop as a function of the mass of dust retained on the filter of two PowerCore filters and two cylindrical filters were performed. Three specimens of test filters with the same filtration area were made from each sample of filter bed. The results showed that in each test of the filter bed, there is an initial filtration period characterized by low (96–98%) initial separation efficiency and the presence of large (d_pmax) dust grains. As the dust loading of the bed increases, the separation efficiency and filtration performance obtain higher and higher values. The initial period of filtration ends when the conventional value (99.9%) of separation efficiency is reached. The duration of this period depends on the type of filter bed and for the PowerCore G2 filter ends for a dust loading of k_m = 33.1 g/m², and for the cellulose filter for k_m = 117.3 g/m². During the initial period, the air behind the PowerCore G2 filter contains grains with sizes in the range of d_pmax = 9–16 µm. Behind the cellulose filter, dust grains are much larger, d_pmax = 17–35 µm. The total operating time of the PowerCore G2 filter, limited by the achievement of the permittivity resistance Δp_wdop = 3 kPa, is twice that of the other filter compositions tested. Full article

It has been shown that tangential inlet return cyclones are commonly used for inlet air filtration of off-road vehicle engines. The wear of the engine elements, and thus their durability, is determined by the efficiency and accuracy of the inlet air filtration. It has been shown that the possibilities of increasing the separation efficiency or decreasing the pressure drop of a cyclone by changing the main dimensions of the cyclone are limited, because any arbitrary change in one of the dimensions of an already operating cyclone may cause the opposite effect. A literature analysis of the possibility of increasing the filtration efficiency of cyclones by modifying the design of selected cyclone components was conducted. In this paper, three modifications of the cyclone design with a tangential inlet of the inlet air filter of a military tracked vehicle were proposed and performed. The symmetrical inlet of the cyclone was replaced with an asymmetrical inlet. The cylindrical outlet tube was replaced with a conical tube, and the edges of the inlet opening were given an additional streamlined shape. The modification process was carried out on three specimens of the reversible cyclone with a tangential inlet. After each modification, an experimental evaluation of the modifications was carried out. The influence of the modifications on the cyclone’s efficiency characteristics and pressure drop was examined. Subsequent modifications of the cyclone were performed on the same specimen without removing the previous modifications. Tests were performed in the air flow range Q_G = 5–30 m³/h. Polydisperse “fine” test dust with grain size d_pmax = 80 µm was used for testing. The dust concentration at the cyclone inlet was set at 1 g/m². The performed modifications caused a slight (about 1%) increase in separation efficiency in the range of small (up to Q_G = 22 m³/h) flux values and about 30% decrease in pressure drop in the whole range of the Q_G flux, which positively influences the increase in engine filling and its power. There was a noticeable increase in filtration accuracy in the range of low and high values of Q_G flux, which results in a decrease in the wear of engine components, especially the piston-piston ring-cylinder (P-PR-C) association, and an increase in their durability. Full article

The purification of indoor pathogenic microorganisms has become a topic of concern. The use of nonwoven media air filters causes high resistance, and the problem of noise limited their application under high air volume. Thus, we propose a micro-electrostatic filter, which has improved performance compared to an electrostatic filter, with a new type of cylindrical structure to tackle indoor pathogenic microbial aerosol pollution. Through simulation, it is found that the filtration performance of a cylindrical structure is better than that of a plate structure under all simulation conditions. For particles larger than 1 μm, the shortest theoretical length of the dust collecting plate required for the cylindrical structure is 34% shorter than that for the plate structure. For 0.1 μm particles, the filtration efficiency of the cylindrical structure is nearly 20~30% (the maximum value is 29.76%) higher than that of the plate structure, while the air velocity is 1.5 m/s~2.5 m/s. The resistance of the cylindrical micro-electrostatic filter is only half of that of the combined plate type micro-electrostatic filter, indicating that the cartridge structure has enormous energy-saving potential. The introduction of the quality factor further proves that the integrated filtration performance of the cartridge micro-electrostatic filter is better. The application of cylindrical micro-electrostatic filters in HVAC systems can help improve indoor air quality and reduce health risks. Full article

The negative air ions (NAI) are used for the removal of particles or droplets from the air. In this study, three types of piezoelectric cold plasma generators (PCPG), in combination with cylindrical electrostatic ion filters, are applied for NAI production. The high voltage on the filter cylinder is induced by the electric field from the piezoelectric transformer of the PCPG. To achieve the dc bias, the cylinder of the electrostatic filter is connected to the ground over ultrafast switching diodes. The ion concentrations are measured for different airflows, PCPG powers, and electrostatic filter geometries. The NAI concentration in the order of magnitude of 10${}^7$ cm${}^{-3}$, and a negative-to-positive ion concentration ratio of over 200 is reached. The production of ozone is evaluated and the PCPG configuration with a minimum ozone production rate is proposed. The ozone concentration below 60 ppb is reached in the airflow of 90 m${}^3$/h. Full article

An aerostatic spindle is a core component in ultra-precision machine tools. The rotor of the spindle has extremely high manufacturing accuracy, which cannot be directly achieved via traditional machining, but always via manual grinding. The deterministic figuring theory is introduced into the machining of shaft parts, which overcomes many shortcomings of manual grinding. The manufacturing error of the shaft’s surface contains different frequency components, which have different effects on its working performance and the figuring process. Because the deterministic figuring method can only correct the error within a limited frequency range, in order to ensure high efficiency and high precision of the figuring process, we need to use reasonable filtering parameters to filter out the error with unnecessary frequencies. In this paper, the influence of contour error with different frequencies and amplitudes on the air film are analyzed using computational fluid dynamics (CFD) software, and the amplitude–frequency analysis as a function of the power spectral density (PSD) characteristic curve is used to study the filtering parameters of the measured data. After the figuring experiment using the filtering parameters obtained from the analysis, the average roundness of the shaft converged from 0.419 μm to 0.101 μm, and the cylindricity converged from 0.76 μm to 0.35 μm. The precision reached the level of manual grinding, which proves the rationality of the analysis using filtering parameters in a shaft’s deterministic figuring. Full article
