Recent advancements in cryogenic etching, characterized by high aspect ratios and etching rates, address the growing demand for enhanced performance and reduced power consumption in electronics. To precisely maintain the temperature under high loads, the cascade mixed-refrigerant cycle (CMRC) is predominantly used. However, most refrigerants currently used in semiconductor cryogenic etching have high global warming potential (GWP). This study introduces a −100 °C chiller using a mixed refrigerant (MR) with a GWP of 150 or less, aiming to comply with stricter environmental standards and contribute to environmental preservation. The optimal configuration for the CMRC was determined based on a previously established methodology for selecting the best MR configuration. Comprehensive analyses—energy, exergy, environmental, and exergoeconomic—were conducted on the data obtained using Matlab simulations to evaluate the feasibility of replacing conventional refrigerants. The results reveal that using eco-friendly MRs increases the coefficient of performance by 52%, enabling a reduction in compressor size due to significantly decreased discharge volumes. The exergy analysis indicated a 16.41% improvement in efficiency and a substantial decrease in exergy destruction. The environmental analysis demonstrated that eco-friendly MRs could reduce carbon emissions by 60%. Economically, the evaporator and condenser accounted for over 70% of the total exergy costs in all cases, with a 52.44% reduction in exergy costs when using eco-friendly MRs. This study highlights the potential for eco-friendly refrigerants to be integrated into semiconductor cryogenic etching processes, responding effectively to environmental regulations in the cryogenic sector. Full article

Micro-optical gyroscopes (MOGs) place a range of components of the fiber-optic gyroscope (FOG) onto a silicon substrate, enabling miniaturization, low cost, and batch processing. MOGs require high-precision waveguide trenches fabricated on silicon instead of the ultra-long interference ring of conventional F OGs. In our study, the Bosch process, pseudo-Bosch process, and cryogenic etching process were investigated to fabricate silicon deep trenches with vertical and smooth sidewalls. Different process parameters and mask layer materials were explored for their effect on etching. The effect of charges in the Al mask layer was found to cause undercut below the mask, which can be suppressed by selecting proper mask materials such as SiO₂. Finally, ultra-long spiral trenches with a depth of 18.1 μm, a verticality of 89.23°, and an average roughness of trench sidewalls less than 3 nm were obtained using a cryogenic process at −100 °C. Full article

As metasurfaces begin to find industrial applications there is a need to develop scalable and cost-effective fabrication techniques which offer sub-100 nm resolution while providing high throughput and large area patterning. Here we demonstrate the use of UV-Nanoimprint Lithography and Deep Reactive Ion Etching (Bosch and Cryogenic) towards this goal. Robust processes are described for the fabrication of silicon rectangular pillars of high pattern fidelity. To demonstrate the quality of the structures, metasurface lenses, which demonstrate diffraction limited focusing and close to theoretical efficiency for NIR wavelengths λ ∈ (1.3 μm, 1.6 μm), are fabricated. We demonstrate a process which removes the characteristic sidewall surface roughness of the Bosch process, allowing for smooth 90-degree vertical sidewalls. We also demonstrate that the optical performance of the metasurface lenses is not affected adversely in the case of Bosch sidewall surface roughness with 45 nm indentations (or scallops). Next steps of development are defined for achieving full wafer coverage. Full article

Deformation-induced martensitic transformation as the basis of a hardening process is dependent, among others, on the stress state. In applications such as cryogenic cutting, where a hardened martensitic subsurface can be produced in metastable austenitic steels, different stress states exist. Furthermore, cutting typically occurs at high strain rates greater than ${10}^3$${\mathrm{s}}^{-1}$. In order to gain a deeper insight into the behavior of a metastable austenitic steel (AISI 304) upon cryogenic cutting, the influence of high strain rates under different loading conditions was analyzed. It was observed that higher strain rates lead to a decrease in the ${\alpha }^{\prime }$-martensite content if exposed to tensile loads due to generated adiabatic heat. Furthermore, a lath-like ${\alpha }^{\prime }$-martensite was induced. Under shear stress, no suppression of ${\alpha }^{\prime }$-martensite formation by higher strain rates was found. A lath ${\alpha }^{\prime }$-martensite was formed, too. In the specimens that were subjected exclusively to compressive loading, almost no ${\alpha }^{\prime }$-martensite was present. The martensitic surface generated by cutting experiments showed deformation lines in which ${\alpha }^{\prime }$-martensite was formed in a wave-like shape. As for the shear specimens, more ${\alpha }^{\prime }$-martensite was formed with increasing strain rate, i.e., force. Additionally, magnetic etching proved to be an effective method to verify the transformation of ferromagnetic ${\alpha }^{\prime }$-martensite. Full article

The cryogenic process is well known to etch high aspect ratio features in silicon with smooth sidewalls. A time-multiplexed cryogenic process, called STiGer, was developed in 2006 and patented. Like the Bosch process, it consists in repeating cycles composed of an isotropic etching step followed by a passivation step. If the etching step is similar for both processes, the passivation step is a SiF₄/O₂ plasma that efficiently deposits a SiO_xF_y layer on the sidewalls only if the substrate is cooled at cryogenic temperature. In this paper, it is shown that the STiGer process can achieve profiles and performances equivalent to the Bosch process. However, since sidewall passivation is achieved with polymer free plasma chemistry, less frequent chamber cleaning is necessary, which contributes to increase the throughput. Full article

This study presents the design and manufacture of metasurface lenses optimized for focusing light with 1.55 µm wavelength. The lenses are fabricated on silicon substrates using electron beam lithography, ultraviolet-nanoimprint lithography and cryogenic deep reactive-ion etching techniques. The designed metasurface makes use of the geometrical phase principle and consists of rectangular pillars with target dimensions of height h = 1200 nm, width w = 230 nm, length l = 354 nm and periodicity p = 835 nm. The simulated efficiency of the lens is 60%, while the master lenses obtained by using electron beam lithography are found to have an efficiency of 45%. The lenses subsequently fabricated via nanoimprint are characterized by an efficiency of 6%; the low efficiency is mainly attributed to the rounding of the rectangular nanostructures during the pattern transfer processes from the resist to silicon due to the presence of a thicker residual layer. Full article

The research field of metasurfaces has attracted considerable attention in recent years due to its high potential to achieve flat, ultrathin optical devices of high performance. Metasurfaces, consisting of artificial patterns of subwavelength dimensions, often require fabrication techniques with high aspect ratios (HARs). Bosch and Cryogenic methods are the best etching candidates of industrial relevance towards the fabrication of these nanostructures. In this paper, we present the fabrication of Silicon (Si) metalenses by the UV-Nanoimprint Lithography method and cryogenic Deep Reactive Ion Etching (DRIE) process and compare the results with the same structures manufactured by Bosch DRIE both in terms of technological achievements and lens efficiencies. The Cryo- and Bosch-etched lenses attain efficiencies of around 39% at wavelength λ = 1.50 µm and λ = 1.45 µm against a theoretical level of around 61% (for Si pillars on a Si substrate), respectively, and process modifications are suggested towards raising the efficiencies further. Our results indicate that some sidewall surface roughness of the Bosch DRIE is acceptable in metalense fabrication, as even significant sidewall surface roughness in a non-optimized Bosch process yields reasonable efficiency levels. Full article

A silicon photonic microresonator comprising two curved vertical grating couplers and a single suspended Si nanowaveguide (NWG) is developed to investigate the giant enhanced Brillouin scattering in subwavelength NWGs caused by photon-phonon interaction. Finite element modelling based on COMSOL Multiphysics is conducted to optimize the critical device parameters (e.g., waveguide width, height, and length). As the smallest structures that need to be resolved are down to ~15 nm in size, electron-beam nanolithography is employed. In this case, dosage tests are carried out to minimize proximity charging effects during the nanopatterning of the silicon-on-insulator (SOI) surface, resulting in appropriate adaptive current area dosage distributions for the periodic gratings, couplers peripheral areas, and NWG, respectively. Furthermore, an enhanced inductively coupled plasma dry reactive ion etching (ICP-DRIE) process at a cryogenic temperature is used to realize smooth vertical sidewalls. Finally, buffered hydrofluoric acid (BHF)-based wet chemical etching is carried out to remove the buried oxide resulting in a suspended Si waveguide. Full article

Silicon and germanium pillar structures (i.e., micro- and nanowires) were fabricated by a top-down approach including nanoimprint lithography and cryogenic dry etching. Various etching parameters were tested to ensure a reliable fabrication process. The impression of nanomechanical properties of such 3-D structures were extracted experimentally by nanoindentation showing promising and comparative results to utilize such nanostructures as small force artefacts. Full article
