This research study aims to study and investigate the corrosion rate, hot tensile properties, and microstructures of SSDS 2507 and AISI 316 gas tungsten arc dissimilar weldments. Three separate samples were developed with frequencies of 2, 4, and 6 Hz using the pulse arc mode technique. The tensile characteristics were assessed at two distinct temperatures (27 °C and 350 °C) in order to examine the behavior of the welded structure. Mechanical characterization such as hardness measurement and corrosion behavior were studied. The metallurgical characteristics of pulsed and continuous current weldments were examined using microscopes (optical and scanning), revealing variations across different zones. At the 4 Hz pulse frequency, the material exhibited improved tensile qualities compared to constant arc welding. The microstructures indicated that the fusion zone in the pulsed arc weldment consisted of a balanced mixture of inter-granular austenite and ferrite phases. A better corrosion resistance rate of 0.0487 mm/year was observed in the pulsed arc weldment compared to both the SSDS2507 base metal and the constant arc weldment. Specifically, at a temperature of 27 °C, the ultimate tensile strength was 695 MPa, whereas at a temperature of 350 °C, the tensile strength was 475 MPa. The weld strength of the pulsed arc weldment exhibited a 15.8% improvement in comparison to the constant arc weldment. The surface hardness value increased to 240 HV compared to the constant arc weldment, which had an HV of 225. Full article

As high-strength and ultra-high-strength steels are widely used in all kinds of modern welded constructions, a lot of research is carried out to investigate the mechanical properties of the weldments of these steels, but there is little information on such important characteristics as their corrosion behaviour. This research focuses on the corrosion behaviour of the weld metal of the weldments of S906QL and S700MC steels. The weld metal was tested electrochemically in a 3.5% NaCl aqueous solution via a potentiodynamic scan to determine the corrosion rate and its dependence on the welding gap. No influence of the welding gap on the corrosion rate was found, but the experimental results suggested that the corrosion rate depended on the chemical composition of the filler material and the microstructure of the weld metal. Full article

High-strength steel is a candidate material for offshore structures, which are currently being constructed with regular-strength steel. These structures are constantly exposed to harsh environmental conditions and experience cyclic loadings, which can lead to premature failure due to the synergistic effects of corrosion and fatigue. In this regard, the current study aims to investigate the effects of corrosion and High-Frequency Mechanical Impact (HFMI) treatment on the fatigue behavior of welded joints made of S700MC steel. Multipass butt-welded joints were fabricated via the Robot GMAW method at an optimally selected heat input of 0.7405 kJ/mm. The microstructure of the weldments was studied using light optical microscopy. Tensile and Vickers microhardness tests were performed to evaluate the mechanical properties of the welded joints. To simulate marine environment corrosion in the laboratory, the as-welded samples were exposed to salt fog spray for 720 h. Subsequently, specimens were subjected to cyclic loading to evaluate their fatigue strength, while SEM and stereomicroscopy were used to analyze the fractured surfaces, providing a comprehensive understanding of the fracture mode. The findings suggest that although corrosion led to increased surface roughness and the formation of corrosion pits, its influence on the fatigue behavior of the weldments might be less significant compared to other geometrical factors, at least for the exposure time employed in the study. Full article

In this study, the welding performance of three filler wires, ER4043, ER5356, and the newly developed FMg0.6, were systematically investigated in the gas metal arc welding of high-strength AA6011-T6 plates. An extensive analysis of the microstructural evolution, mechanical properties, fatigue resistance, and corrosion behavior of different weldments was conducted. The ER4043 and FMg0.6 joints exhibited finer grain sizes in the fusion zone (FZ) than the ER5356 joint. The as-welded ER5356 and FMg0.6 joints exhibited higher hardness and tensile strength values than the ER4043 joint. The FMg0.6 joint demonstrated the highest mechanical strength among all of the joints with superior fatigue resistance under both the as-welded and post-weld heat treatment (PWHT) conditions. In the as-welded state, the ER5356 joint exhibited the lowest corrosion resistance, attributed to the precipitation of β-Al₂Mg₃ at the grain boundaries. The FMg0.6 joint, characterized by a high-volume fraction of eutectic Mg₂Si in the as-welded state, exhibited a higher corrosion rate than that of the ER4043 joint. However, the PWHT effectively improved the corrosion resistance of the FMg0.6 joint. Given its excellent tensile properties, superior fatigue properties, and satisfactory corrosion resistance, particularly with PWHT, the newly developed FMg0.6 filler has emerged as a promising candidate for welding high-strength 6xxx alloys. Full article

Austenitic stainless steels used in structural applications suffer from stress corrosion cracking due to residual stresses during welding. Much research is being conducted to prevent the stress corrosion cracking of austenitic steels by inducing compressive residual stresses. One method is ultrasonic shot peening (USP), which is used to apply compressive stress by modifying the mechanical properties of the material’s surface. In this study, 304L stainless steel was butt-welded by gas tungsten arc welding (GTAW) and subsequently subjected to compressive residual stress to a depth of 1 mm from the surface by a USP treatment. The influence of USP on microstructural changes in the base metal, the HAZ and weldment, and the corrosion properties was analyzed. A microstructural analysis was conducted using SEM-EDS, XRD, and EBSD methods alongside residual stress measurements. The surface and cross-sectional corrosion behavior was evaluated and analyzed using a potentiodynamic polarization test, electrochemical impedance spectroscopy (EIS) measurements, a double-loop electrochemical potentiokinetic reactivation (DL-EPR) test, and an ASTM A262 Pr. C test. The surface was deformed and roughened by the USP. The deformed areas formed crevices, and the inside of the crevices contained some cracks. The crevices and internal cracks caused pitting, which reduced the resistance of the passivation film. The cross-section was subjected to compressive residual stress to a depth of 1 mm from the surface, and the outermost area of the cross-section had fine grain refinement, forming a solid passivation film that improved the corrosion resistance. Full article

A surface modification through multiple microshot peening (MSP) was performed on Mg–steel weldment. Application of MSP was found beneficial to the elimination of surface microdefects owing to severe plastic deformation induced by MSP. Moreover, MSP treatment transformed the residual tensile stress of the weld surface into residual compressive stress, which was beneficial to inhibit the initiation and propagation of surface microdefects. Strain strengthening and grain refining were introduced into the shot peened joint, resulting in the notable increase in surface hardness and tensile strength. Compared with an untreated joint, the tensile strength of optimized Mg/steel weldment was markedly enhanced and raised 28% to 244 MPa, and fracture ultimately occurred in the Mg alloy base material. Moreover, the refinement of weld grain induced by MSP treatment was beneficial to strengthen the stress corrosion sensitivity of Mg/steel joints, while also promoting the formation of a denser Mg(OH)₂ passivation film on the weld surface and enhancing the corrosion resistance of the joints. Full article

Prompted by the unexpected observation of the pitting of the weldments of a highly corrosion- and pitting-resistant duplex stainless steel, SAF2507, in chloride solutions with nitride addition, the pitting and corrosion resistance of SAF2507 and its weldments were investigated in chloride solutions with and without different levels of nitrite. The Incoloy 825 and 316L austenitic stainless steels were included for the purpose of developing a comparative appreciation. The microstructures of the weldments were characterised, and 316L showed a profound influence of nitrite addition in inhibiting pitting, while ‘meta-stable’ pitting transients that were clearly visible in the chloride solution without nitrite were absent when nitrite was added. Both the parent metal and the weldment of SAF2507 had similar pitting potential (E_p) in 0.1 M NaCl without nitrite, which was the highest E_p among the three alloys tested. Additions of nitrite at low concentrations had an inhibitive effect on pitting, whereas higher nitrite contents had a deleterious effect on pitting resistance. On the other hand, Incoloy 825 showed a trend of E_p ennoblement with an increasing nitrite content of 0.1 M NaCl, and the weldment underwent greater ennoblement. Moreover, 316L showed a trend similar to Incoloy 825; however, the E_p ennoblements were significantly more pronounced for both the weldment and the base metal of 316L. Full article

Friction stir processing (FSP) is a solid-state processing technique used to refine the microstructures of metallic alloys. It involves inserting a rotating tool into the material, which generates heat and plastic deformation, leading to the recrystallization and refinement of the microstructure. The aluminium alloy 7050 is a high-strength alloy possessing good corrosion resistance, and is commonly used in aerospace applications. By incorporating SiC particles into the alloy with different percentiles of 0 to 1%, the resulting composite can have improved mechanical properties, such as higher strength and stiffness, as well as increased wear resistance. Mechanical testing and optical metallographic characterization were conducted. The test results showed that weldments have improved mechanical properties compared to the base material, making them suitable for high-strength and low-weight applications. Full article

This study analyzes the corrosion inhibition efficiency of sodium molybdate (SM) solution on weldment specimens in 1 M HCl, based on H₂ bubbles detection. The detection of the bubbles produced by the corrosion process is achieved by a YOLOv4 deep learning algorithm. The results indicate that the corrosion rate is higher on the weld metal zone than on the base metal zone in the same solution, which might be attributed to the coarser grain of the weld metal zone and the stability of the produced oxide layer. The addition of sodium molybdate was discovered to boost the stability of the oxide layer, hence enhancing the specimens’ corrosion resistance. The overall inhibitory efficiency of the sodium molybdate solution was 59% for the weld metal (WM) (0.4 g/L), 52% for the heat-affected zone (HAZ) (0.2 g/L), and 37% for the base metal (BM) (0.2 g/L). The object detection algorithm models showed 97% for the mAP and 0.98 for recall. The minimum average bubble detected for the WM was 0.353 /mm² at an SM concentration of 0.4 g/L, while the HAZ was 0.612 /mm² at 0.2 g/L, and the BM was 1.055 /mm² at 0.2 g/L. The results of the bubbles detection appeared to be consistent with the corrosion experiment outcomes obtained by the potentiodynamic polarization and hydrogen volume measurement tests. This experiment validates the distinctiveness of the different weld zones in terms of the inhibitor concentration required for successful corrosion prevention, as well as the potential of analyzing corrosion using machine learning algorithms for object detection. Full article

In this research, the gas tungsten arc welding method was used to join 201 and 316L austenitic stainless steels using various filler electrodes (316L, 309L and 309LMo), resulting in dissimilar welds, and its various properties, namely, microstructural evolution, mechanical behavior and corrosion behavior were investigated. The ferrite–austenite solidification mode was attained, and therefore, different types of ferrite (lathy ferrite and skeletal ferrite) were formed in the austenite matrix in all of the filler electrode weldments’ weld zones, however, the variation in content of ferrite was observed. A ferritoscope was used to estimate the ferrite content in the weld zone, and for E316L, E309L and E309LMo filler electrodes, the ferrite number observed were 8.78, 9.05 and 12.69 units, respectively. Hence, the 316L filler electrode exhibited the lowest ferrite content, while the 309LMo filler electrode weldment displayed a higher ferrite content ascribed to the variation in the chemical composition of filler electrodes (different chemical composition of ferrite stabilizer elements, namely, chromium, molybdenum, etc.). Further, the mechanical characteristics, including microhardness and tensile characteristics, were determined to be higher in the 309LMo filler electrode weldment, followed by the 309L and 316L filler electrode weldments, primarily due to the increased ferrite content. All the welds exhibited failure in the ductile mode. Moreover, higher sensitization was observed in the 309LMo filler electrode weldment, with the 309L and 316L filler electrode weldments following suit, which is ascribed to the higher ferrite content. This higher ferrite content resulted in higher interphase regions of ferrite/austenite, thus resulting in higher sensitization. Full article

Welded joints in metallic pipelines and other structures are used to connect metallic structures. Welding defects, such as cracks and lack of fusion, are vulnerable to initiating early-age cracking and corrosion. The present damage identification techniques use ultrasonic-guided wave procedures, which depend on the change in the physical characteristics of waveforms as they propagate to determine damage states. However, the complexity of geometry and material discontinuity (e.g., the roughness of a weldment with or without defects) could lead to complicated wave reflection and scatters, thus increasing the difficulty in the signal processing. Artificial intelligence and machine learning exhibit their capability for data fusion, including processing signals originally from ultrasonic-guided waves. This study aims to utilize deep learning approaches, including a convolutional neural network (CNN), Long-short term memory network (LSTM), or hybrid CNN-LSTM model, to demonstrate the capability in automation for damage detection for pipes with welded joints embedded in soil. The damage features in terms of welding defect types and severity as well as multiple defects are used to understand the effectiveness of the hybrid CNN-LSTM model, which is further compared to the two commonly used deep learning approaches, CNN and LSTM. The results showed the hybrid CNN-LSTM model has much higher classification accuracy for damage states under all scenarios in comparison with the CNN and LSTM models. Furthermore, the impacts of the pipelines embedded in different types of materials, ranging from loose sand to stiff soil, on signal processing and data classification were further calibrated. The results demonstrated these deep learning approaches can still perform well to detect various pipeline damage under varying embedment conditions. However, the results demonstrate when concrete is used as an embedding material, high attention to absorbing the signal energy of concrete could pose a challenge for the signal processing, particularly under high noise levels. Full article

The growing demand for Magnesium in the automotive and aviation industries has enticed the need to improve its corrosive properties. In this study, the WE43 magnesium alloys were friction stir welded (FSW) by varying the traverse speed. FSW eliminates defects such as liquefication cracking, expulsion, and voids in joints encountered frequently in fusion welding of magnesium alloys. The microstructural properties were scrutinized using light microscopy (LM) and scanning electron microscopy (SEM). Additionally, the elemental makeup of precipitates was studied using electron dispersive X-ray spectroscopy (EDS). The electrochemical behavior of specimens was evaluated by employing potentiodynamic polarization tests and was correlated with the microstructural properties. A defect-free weldment was obtained at a traverse and rotational speed of 100 mm/min and 710 rpm, respectively. All weldments significantly improved corrosion resistance compared to the base alloy. Moreover, a highly refined microstructure with redistribution/dissolution of precipitates was obtained. The grain size was reduced from 256 µm to around 13 µm. The corrosion resistance of the welded sample was enhanced by 22 times as compared to the base alloy. Hence, the reduction in grain size and the dissolution/distribution of secondary-phase particles within the Mg matrix are the primary factors for the enhancement of anti-corrosion properties. Full article

In order to predict the corrosion depth of a district heating pipeline, it is necessary to analyze various corrosion factors. In this study, the relationship between corrosion factors such as pH, dissolved oxygen, and operating time and corrosion depth was investigated using the Box–Behnken method within the response surface methodology. To accelerate the corrosion process, galvanostatic tests were conducted in synthetic district heating water. Subsequently, a multiple regression analysis was performed using the measured corrosion depth to derive a formula for predicting the corrosion depth as a function of the corrosion factors. As a result, the following regression formula was derived for predicting the corrosion depth: “corrosion depth (μm) = −133 + 17.1 pH + 0.00072 DO + 125.2 Time − 7.95 pH × Time + 0.002921 DO × Time”. Full article

Dissimilarities in metal laser welding lead to brittleness in welded joints due to differences in the thermophysical and chemical properties between dissimilar base materials. To overcome such brittleness, the addition of a preset coating onto the base materials as an interlayer is a method for attaining reliable welded joints. Nd:YAG laser butt welding of DP590 dual-phase steel and 304 stainless, both with a thickness of 1 mm, was performed with a preset nickel coating as an interlayer using an electroplating process. The relationship between the microstructure and the mechanical properties of the welded joints was researched, the microstructure and composition of the weldment were analyzed, and the microhardness, tensile strength and corrosion resistance were tested. The results showed that the preset nickel coating increased the content of Ni element in the welded joints, which is beneficial to the formation of lath martensite. The average hardness of the welded joints increased by 12%, and the tensile strength was higher than 370 MPa. The corrosion rate of the welded joints can be slowed down, and the corrosion resistance can be improved by increasing the nickel coating. Full article

Transgranular chloride-induced stress corrosion cracking (TGCISCC) is a mounting concern for the safety and longevity of arc welds on austenitic stainless steel (AuSS) nuclear waste storage canisters. Recent studies have shown the key role of crystallography in the susceptibility and propagation of TGCISCC in SS weldments. Given that crystallography underlies mechanical heterogeneities, the mechanical-crystallographic relationship during TGCISCC growth must be understood. In this study, welded SS 304L coupons are loaded in four-point bend fixtures and then boiled in magnesium chloride to initiate TGCISCC. Nanoindentation mapping is paired with scanning electron microscopy (SEM) electron backscatter diffraction (EBSD) to understand the correlation between grain orientation, grain boundaries, and hardening from TGCISCC propagation. The nanoindentation hardness of individual grains is found to not be a controlling factor for TGCISCC propagation. However, intragranular hardness is generally highest immediately around the crack due to localized strain hardening at the crack tip. This work shows that nanoindentation techniques can be useful in understanding CISCC behaviors when paired with electron microscopy. Full article
