Optical coordinate measurement is a universal technique that aligns with the rapid development of industrial technologies and new materials. Nevertheless, can this technique be consistently effective when applied to the precise measurement of all types of materials? As shown in this article, an analysis of optical measurement systems reveals that some materials cause difficulties during the scanning process. This article details the matting process, resulting, as demonstrated, in lower measurement uncertainty values compared to the pre-matting state, and identifies materials for which applying a matting spray significantly improves the measurement quality. The authors propose a classification of materials into easy-to-scan and hard-to-scan groups, along with specific procedures to improve measurements, especially for the latter. Tests were conducted in an accredited Laboratory of Coordinate Metrology using an articulated arm with a laser probe. Measured objects included spheres made of ceramic, tungsten carbide (including a matte finish), aluminum oxide, titanium nitride-coated steel, and photopolymer resin, with reference diameters established by a high-precision Leitz PMM 12106 coordinate measuring machine. Diameters were determined from point clouds obtained via optical measurements using the best-fit method, both before and after matting. Color measurements using a spectrocolorimeter supplemented this study to assess the effect of matting on surface color. The results revealed correlations between the material type and measurement accuracy. Full article

Accurate measurement uncertainty quantification and its propagation are critical for dimensional compliance in precision manufacturing. This study presents a novel framework that examines the evolution of measurement error along the axial length of CNC-turned components, focusing on spatial and material-specific factors. A systematic experimental comparison was conducted between a manual Digital Vernier Caliper (DVC) and an automated Coordinate Measuring Machine (CMM) using five engineering materials: Aluminum Alloy 6061, Brass C26000, Bronze C51000, Carbon Steel 1020 Annealed, and Stainless Steel 304 Annealed. Dimensional measurements were taken from five consecutive machining zones to capture localized metrological behaviors. The results indicated that the CMM consistently achieved lower expanded uncertainty (as low as 0.00166 mm) and minimal propagated uncertainties (≤0.0038 mm), regardless of material hardness or cutting position. In contrast, the DVC demonstrated significantly higher uncertainty (up to 0.03333 mm) and propagated errors exceeding 0.035 mm, particularly in harder materials and unsupported zones affected by surface degradation and fixture variability. Root-sum-square (RSS) modeling confirmed that manual measurements are more prone to operator-induced error amplification. While the DVC sometimes recorded lower absolute errors, its substantial uncertainty margins hampered measurement reliability. To statistically validate these findings, a two-way ANOVA was performed, confirming that both the measurement system and machining zone significantly impacted uncertainty, as well as their interaction. These results emphasize the importance of material-informed and zone-sensitive metrology, highlighting the advantages of automated systems in sustaining measurement repeatability and dimensional stability in high-precision applications. Full article

This article presents research and a discussion on the proper use of filtration in optical measurements. Measurements were taken using a Werth multisensory machine using a Werth Zoom optical sensor. During optical measurements, the filtration option can be used. The manufacturer defines filters as “Dust”. They allow the machine operator to define the appropriate size depending on the type of inclusions or artifacts created in the production process. They can occur in processes such as punching on presses or production in the injection molding process of plastics. The presented research results and statistical analyses confirm the assumptions regarding the validity of using filters and their values. The use of filters with a higher value significantly affects the obtained results and forces the machine user to make a reasonable choice. Full article

Attaining dimensional accuracy in CNC-machined parts is essential for high-precision manufacturing, especially when working with materials that exhibit varying mechanical and thermal characteristics. This research provides a thorough experimental comparison of manual and automated metrological systems, specifically the Digital Vernier Caliper (DVC) and Coordinate Measuring Machine (CMM), as applied to five different engineering alloys through five progressively machined axial zones. The study assesses absolute error, relative error, standard deviation, and measurement repeatability, factoring in material hardness, thermal conductivity, and surface changes due to machining. The results indicate that DVC performance is significantly affected by operator input and surface irregularities, with standard deviations reaching 0.03333 mm for Bronze C51000 and relative errors surpassing 1.02% in the initial zones. Although DVC occasionally showed lower absolute errors (e.g., 0.206 mm for Aluminum 6061), these advantages were countered by greater uncertainty and poor repeatability. In comparison, CMM demonstrated enhanced precision and consistency across all materials, with standard deviations below 0.0035 mm and relative errors being neatly within the 0.005–0.015% range, even with challenging alloys like Stainless Steel 304. Furthermore, a Principal Component Analysis (PCA) was conducted to identify underlying measurement–property relationships. The PCA highlighted clear groupings based on sensitivity to error in manual versus automated methods, facilitating predictive classification of materials according to their metrological reliability. The introduction of multivariate modeling also establishes a new framework for intelligent metrology selection based on material characteristics and machining responses. These results advocate for using CMM in applications requiring precise tolerances in the aerospace, biomedical, and high-end tooling sectors, while suggesting that DVC can serve as an auxiliary tool for less critical evaluations. This study provides practical recommendations for aligning measurement techniques with Industry 4.0’s needs for accuracy, reliability, and data-driven quality assurance. Full article

As additive manufacturing technologies continue to gain ground in industrial applications, the need for the accurate metrological evaluation of parts produced with advanced materials becomes increasingly critical. In this context, non-contact metrology plays a key role. This research investigates the performance of conoscopic holography as an optical metrology technique for the inspection of ceramic parts manufactured by stereolithography. However, its reliability needs to be validated, especially as factors such as material properties, surface finish, and color can significantly affect measurement accuracy. Spherical artifacts in alumina were chosen as mathematically well-defined reference elements, and a representative series was produced with the best values for the printing, debinding, and sintering parameters. These spheres were first measured via contact with a coordinate measuring machine (CMM) to establish dimensional (diameter) and geometrical (form error) reference values. These parameters were then compared with measurements obtained via conoscopic holography and optimized by means of Gaussian filters. The results indicated significant dimensional (up to 60 µm) and geometrical (up to 280 µm) deviations from the CMM reference data. The investigation shows that conoscopic holography does not ensure an accurate measurement method for this additive process and ceramic material, making it impossible to achieve power and frequency settings that would allow signal-to-noise ratios above 50%. Full article

Optical window freeform surfaces have emerged as a critical research focus in advanced optical engineering owing to their extensive surface degrees of freedom. These surfaces enable the simultaneous correction of on-axis and off-axis aberrations while satisfying stringent requirements for high-performance, lightweight, and compact optical systems. In the initial metrological characterization of these surfaces, coordinate measuring machines (CMMs) are conventionally employed for target point cloud acquisition. However, the achievable measurement accuracy (>2 μm) inherently constrained by CMM precision imposes fundamental limitations for subsequent optical inspections requiring sub-micron to nanometer-level resolution. Meanwhile, although optical measurement methods can result in higher measurement accuracy, they also lead to an increase in costs and testing difficulties. To overcome these limitations, we propose an accelerated point cloud registration methodology based on point-to-triangulation distance estimation. In simulation, using optimal coordinate transformation enabled good capabilities for exceptional surface characterization: peak-to-valley (PV) surface error of 10⁻⁶ nm, residual error of 5 nm, and registration accuracy of log₁₀ (mm/°). Further, in the experiment, the PV surface error was reduced from 27.3 μm to 6.9 μm, equivalent to a reduction of 3.95 times. These results confirm that the point-to-triangulation distance approximation maintains sufficient fidelity to the nominal point-to-surface distance, thereby empirically validating the efficacy of our proposed methodology. Notably, compared with conventional 3D alignment methods, our novel 2D estimation registration approach with point-to-triangulation surface normal vectors demonstrates significant advantages in computational complexity, which achieved a 78% reduction from O(n³) to O(n) while maintaining sub-millisecond alignment times. We believe that the method has potential for use as a low-cost optical precision measurement in manufacturing technology. Full article

This study investigates the influence of isopropyl alcohol (IPA) washing time on the surface roughness of stereolithography (SLA)-printed parts fabricated using the Formlabs Form 3B+ printer. Three photopolymer resins provided by the manufacturer were evaluated: Gray, Tough 2000, and Rigid 10K. Samples were printed in standardized geometries and post-processed under controlled conditions, with IPA washing times ranging from 6 to 30 min, followed by UV post-curing. The surface roughness parameters (Ra, Rz, Rt, and RSm) were measured using a Taylor Hobson Form Talysurf i-Series profilometer under metrologically controlled conditions. The results revealed a clear correlation between increased IPA exposure time and improved surface finish, though the magnitude and monotonicity of this effect were material dependent. Rigid 10K exhibited the most consistent reduction in roughness with longer washing, while Tough 2000 showed substantial improvement with extended durations but also demonstrated temporary surface degradation at intermediate wash times. Gray resin achieved near-optimal roughness after moderate rinsing, with orientation-dependent differences observed. The findings indicate that the careful optimization of washing duration can significantly enhance the surface quality in SLA prints, potentially eliminating the need for secondary finishing processes. The implications are relevant to both industrial and medical applications where dimensional fidelity and surface smoothness are critical. Recommendations for optimal washing durations are proposed for each material, and directions for further research are outlined. Full article

This paper presents the results of investigations on the accuracy of contact point identification during coordinate measurement, which is crucial in the context of the Industry 4.0 concept. In particular, the effects of swivel length and probe declination angle during measurement were analyzed. In the experiments, deviations from the expected coordinates (0,0,0) of the contact point were analyzed for different rotational angles of the probing head. It was found that the recommended vertical positioning of the stylus at an angle of A = 0° might have introduced some insignificant errors. Increasing angle A up to 15° generated additional errors of negligible values in comparison with the measurement accuracy of the CMM. However, an increase in angle A up to 90° introduced additional errors as high as 10 μm. This contact point identification error will have a certain effect on the best fitting element and subsequent calculations and on the respective measurement results. Full article

Medical laboratories are perhaps the largest measurement industry in the world. The metrology terminology is relevant for effective and efficient communication, particularly where metrology activities are carried out by operators with different metrology skills. The World Association of Societies of Pathology and Laboratory Medicine (WASPaLM) and SIPMeL have had some opportunities to propose changes to the documents in preparation for the Clinical and Laboratory Standards Institute (CLSI) and the ISO/TC 212 in order to harmonize the terminology with the Metrology Vocabulary (VIM) of the Joint Committee for Guides in Metrology (JCGM). Many proposals have been accepted. Here, we summarize some particularly critical points for metrological terms. The main terms discussed are the following: measuring, measuring range, examination, pre-examination, post-examination, manufacturer, measuring instrument, quantitative, qualitative, semi-quantitative, processing, measurement error, maximum permissible error of measurement, total error of measurement, monitoring, variability, performance, reliability, influence, interference, selectivity, sensitivity, detection limit, reliability, comparability, compatibility, control material. Despite all the efforts to coordinate terminologies, it is inevitable that overlapping and inconsistent terminologies will continue to be used because documents and policies are produced in different contexts. In some ISO/TC 212 and CLSI documents, the phenomenon of magnetic attraction toward common words (such as “analysis” and derivatives), without any consideration of the true metrological meaning, is noted. The ISO/TC 212 and CLSI working groups show, alongside moments of openness, phenomena of true self-referential conservatism. Full article

This paper is concerned with coordinate measuring machine (CMM) uncertainty evaluation, in particular, the uncertainties associated with point clouds and distances derived from the point cloud. The uncertainty evaluation approach is model-based following the principles of the Guide to the Expression of Uncertainty in Measurement and the law of the propagation of uncertainty. The paper considers a range of CMM influence factors and derives an explicit dependence for the point cloud data coordinates on the influence factors, allowing uncertainties associated with the influence factors to be propagated through to point cloud uncertainties. The paper describes the use of Gaussian processes to model kinematic and probing errors using a small number of statistical hyper-parameters. These models permit an explicit statement of the uncertainty associated with point clouds and length measurement, enabling the latter to be compared directly with a statement of the maximum permissible error in length measurement. The uncertainty evaluation methodology is direct in that it requires no optimisation nor Monte Carlo simulations. Full article

The CT (computed tomography) scanner has been used for many years now not only for medical measurements but also in many industries, for example, in defectoscopy for measuring sheet thickness and checking the joining of materials, as well as for measuring the geometry of individual components. This type of scanner is a good complement to coordinate contact and non-contact measurements for intra-structural measurements and inaccessible places. The variety of materials, however, makes it very difficult to select individual CT parameters. In this paper, a curve for selecting the maximum and minimum voltage of the lamp depending on the density of a given material is determined and an interpolation polynomial (1d with a third-degree polynomial) is used, by defining third-degree glued functions (cubic spline) to determine intermediate voltage values to a given material density, so as to determine full data ranges. This approach can facilitate the work of selecting scanning parameters for non-destructive testing, as this is a difficult process and sometimes consumes half of the measurement time. The practical experiments were carried out at the Accredited Coordinate Metrology Laboratory to develop a multi-criteria matrix for selecting CT measurement parameters for measurement accuracy. This approach reduced the time by an average of half an hour and effectively optimized the selection of scanning parameters. Full article

In modern manufacturing, there is an increasing demand for reliable in-process measurement methods directly on large CNC machine tools, eliminating the need to transport workpieces to metrological laboratories. This study assesses the capability and applicability of an articulated arm coordinate measuring machine and a machine tool touch-trigger probe when measuring to a specified tolerance of 0.05 mm in a production environment. Experiments were conducted using the KOBA calibration standard and included measurements with and without applying the articulated arm coordinate measuring machine leapfrog method. The results were evaluated according to ISO 22514-7:2021 and ISO 14253-1:2017, which establish criteria for measurement system capability. The findings revealed that neither measurement system met the capability requirements of ISO 22514-7:2021, particularly due to unsatisfactory Q_MS and C_MS values. However, under ISO 14253-1:2017, both systems were deemed conditionally suitable for verifying conformity to the specifications, with the articulated arm coordinate measuring machine showing lower applicability when using the leapfrog method. This research supports the idea that unreasonable demands for compliance with current standards may lead to questioning of the systems that previously met older standards. The study contributes to the ongoing discussion on integrating advanced metrological tools into the manufacturing process and underscores the need for careful evaluation to ensure the capability and reliability of measurement systems in industrial practice. Full article

Coordinate measuring machines are widely used in the industrial field due to their ease of automation. However, estimating the measurement uncertainty is a delicate task, especially when controlling for deviation, given the large number of factors that influence the measurement. A precise estimate of the uncertainty is crucial to avoid incorrect conformity assessments. The purpose of this study is to control geometrical-form tolerance specifications, taking into consideration their associated uncertainty. A surface fitting model based on the least squares criterion is proposed, allowing one to obtain the variance–covariance matrix by iterative calculation according to the Levenberg–Marquard optimization method. The form deviation is then evaluated following the Geometrical Product Specifications (GPS) Standard, and its associated uncertainty is estimated using the guide to the expression of uncertainty in measurement (GUM) propagation of the uncertainty law. Finally, the conformity assessment is performed based on the measured deviation and its associated uncertainty. Different results for the measurement of straightness, flatness, circularity, roundness, and cylindricity are presented and detailed. This model is thereafter validated by a Monte Carlo simulation, and interlaboratory comparisons of the obtained results were performed, which showed satisfactory outcome. This contribution is of great use to manufacturing companies and metrology laboratories, allowing them to meet the normative guidelines, which stipulates that each measurement result must be accompanied by its associated uncertainty. Full article

Virtual experiments are a digital representation of a real measurement and play a crucial role in modern measurement sciences and metrology. Beyond their common usage as a modeling and validation tool, a virtual experiment may also be employed to perform a parameter sensitivity analysis or to carry out a measurement uncertainty evaluation. For the latter to be compliant with statistical principles and metrological guidelines, the procedure to obtain an estimate and a corresponding measurement uncertainty requires careful consideration. We employ a Monte Carlo sampling procedure using a virtual experiment that allows one to perform a measurement uncertainty evaluation according to the Monte Carlo approach of JCGM-101 and JCGM-102, two widely applied guidelines for uncertainty evaluation in metrology. We extend and formalize a previously published approach for simple additive models to account for a large class of non-linear virtual experiments and measurement models for multidimensionality of the data and output quantities, and for the case of unknown variance of repeated measurements. With the algorithm developed here, a simple procedure for the evaluation of measurement uncertainty is provided that may be applied in various applications that admit a certain structure for their virtual experiment. Moreover, the measurement model commonly employed for uncertainty evaluation according to JCGM-101 and JCGM-102 is not required for this algorithm, and only evaluations of the virtual experiment are performed to obtain an estimate and an associated uncertainty of the measurand. We demonstrate the efficacy of the developed approach and the effect of the underlying assumptions for a generic polynomial regression example and an example of a simplified coordinate measuring machine and its virtual representation. The results of this work highlight that considerable effort, diligence, and statistical considerations need to be invested to make use of a virtual experiment for uncertainty evaluation in a way that ensures equivalence with the accepted guidelines. Full article

Additive Manufacturing (AM) is advancing technologically towards the production of components for high-demand mechanical applications with stringent dimensional accuracy, leveraging metallic and ceramic raw materials. The AM process for ceramic components, known as Ultraviolet Laser Stereolithography (SLA), enables the fabrication of unique parts or small batches without substantial investments in molds and dies, and avoids the problems associated with traditional manufacturing, which involves multiple stages and final machining for precision. This study addresses the need to produce reference elements or targets for metrological applications, including verification, adjustment, or calibration of 3D scanners and mid- to high-range optical sensors. Precision spheres are a primary geometry in this context due to their straightforward mathematical definition, facilitating rapid and accurate error detection in equipment. Our objective is to exploit this novel SLA process along with the advantageous optical properties of technical ceramics (such as being white, matte, lightweight, and corrosion-resistant) to materialize these reference objects. Specifically, this work involves the fabrication of alumina hemispheres using SLA. The manufacturing process incorporates four design variables (wall thickness, support shape, fill type, and orientation) and one manufacturing variable (the arrangement of spheres on the printing tray). To evaluate the impact of the design variables, dimensional and geometric parameters (GD&T), including diameters, form errors, and their distribution on the surface of the sphere, have been characterized. These measurements are conducted with high accuracy using a Coordinate Measuring Machine (CMM). The study also examines the influence of these variables in the dimensional and geometric accuracy of the spheres. Correlations between various parameters were identified, specifically highlighting critical factors affecting process precision, such as the position of the piece on the print tray and the wall thickness value. The smallest diameter errors were recorded at the outermost positions of the tray (rear and front), while the smallest shape errors were found at the central position, in both cases with errors in the range of tens of micrometers. In any case, the smallest deformations were observed with the highest wall thickness (2 mm). Full article
