In modern wireless communication systems, achieving high isolation and consistent signal gain is essential for optimizing Multiple-Input Multiple-Output (MIMO) antenna performance. This study presents a metamaterial-integrated smart sensor platform featuring a hexagonal two-element MIMO antenna designed to improve isolation and directive gain. Constructed on an FR4 substrate (1.6 mm thick), the proposed antenna configurations include a base hexagonal patch, an orthogonally oriented two-element system (TEH_OC), and further enhanced variants employing metamaterial arrays as the superstrate and reflector (TEH_OC_MTS and TEH_OC_MTR). The metamaterial structures significantly suppress mutual coupling, yielding superior diversity parameters such as Envelope Correlation Coefficient (ECC), Mean Effective Gain (MEG), and Channel Capacity Loss (CCL). All configurations were fabricated and validated through comprehensive anechoic chamber measurements. The results demonstrate robust isolation and radiation performance across the 3 GHz and 5 GHz bands, making these antennas well-suited for deployment in compact, low-latency smart sensor networks operating in 5G and IoT environments. Full article

Driven by the urgent demand for low-frequency vibration and noise control in engineering scenarios such as automobiles, acoustic metamaterials (AMs), as a new class of functional materials, have demonstrated significant application potential. This paper proposes a low-frequency band gap optimization design method for local resonance acoustic metamaterials (LRAMs) based on a multi-objective genetic algorithm. Within a COMSOL Multiphysics 6.2 with MATLAB R2024b co-simulation framework, a parameterized unit cell model of the metamaterial is constructed. The optimization process targets two objectives: minimizing the band gap’s deviation from the target and reducing the structural mass. A multi-objective fitness function is formulated by incorporating the band gap deviation and structural mass constraints, and non-dominated sorting genetic algorithm II (NSGA-II) is employed to perform a global search over the geometric parameters of the resonant unit. The resulting Pareto-optimal solution set achieves a unit cell mass as low as 26.49 g under the constraint that the band gap deviation does not exceed 2 Hz. The results of experimental validation show that the optimized metamaterial configuration reduces the peak of the low-frequency frequency response function (FRF) at 63 Hz by up to 75% in a car door structure. Furthermore, the simulation predictions exhibit good agreement with the experimental measurements, confirming the effectiveness and reliability of the proposed method in engineering applications. The proposed multi-objective optimization framework is highly general and extensible and capable of effectively balancing between the acoustic performance and structural mass, thus providing an efficient engineering solution for low-frequency noise control problems. Full article

In this study we explored the chiral behavior of a honeycomb-like chiral metamaterial with a negative Poisson’s ratio. This type of structure is widely used in sectors such as construction and packaging, but is not as common in electromagnetics/electrical engineering. Moreover, in contrast with typical layer-by-layer chiral metamaterial structures, which are usually formed by metallic patterns with C4 symmetry, this hexachiral structure presents C6 symmetry. The aim of this paper is analyzing the electromagnetic behavior of this kind of auxetic metamaterial with special attention to its chiral behavior. This structure is analyzed by means of measurements and simulations of its reflection and transmission responses (scattering parameters) in different configurations, showing that a dual-layer configuration with conjugated faces provides high electromagnetic activity (gyrotropy) with low losses. Full article

Acoustic metamaterials have been widely applied in fields such as sound insulation and noise reduction due to their controllable band structures and unique abilities to manipulate low-frequency sound waves. However, there exists a highly nonlinear mapping relationship between their structural parameters and performance responses, which causes traditional design methods to face the problems of inefficiency and poor generalization. Therefore, this paper proposes a bidirectional modeling framework based on deep learning. We constructed a forward prediction network that integrates an attention mechanism, a multi-scale feature fusion, and a reverse design model that combines an improved autoencoder and cascaded neural network to efficiently model the dispersion performance of acoustic metamaterials. In the feedforward network, the improved forward prediction model shows superior performance compared to the traditional Convolutional Neural Network model and the model based only on the Convolutional Block Attention Module attention mechanism, with a prediction accuracy of 99.65%. It has better fitting ability and stability in the high-frequency part of the dispersion curve. In the inverse network part, compression of the high-dimensional dispersion curves by an improved autoencoder reduces the training time by about 13.5% without significant degradation of the inverse prediction accuracy. The proposed network model provides a more efficient method for the design of metamaterials. Full article

Due to the significant impedance mismatch between water and air, two types of pipeline silencers designed for the same target frequency with different filling materials often have significantly different thickness. This increases the difficulty in designing silencers for multiple pipelines with different filling materials in narrow spaces. The paper reports a metamaterial design paradigm based on a Helmholtz cavity for low-frequency sound absorption for both air pipelines and water-filled pipelines. An asymmetric absorption metamaterial with coupled Helmholtz resonators is proposed to reduce the impact of low-frequency noise in air pipelines. By coupling the absorption mode and reflection mode, the asymmetric absorption metamaterial with a thickness of 71 mm achieves 95.6% absorption at 403 Hz. The tunable absorbing performance in broadband is confirmed by a finite element simulation. Additionally, a composite metamaterial constructed with HRs associated with a rubber layer is proposed for low-frequency broadband sound absorption in water-filled pipelines. An average absorptance of above 0.8 is achieved over the range of 380–508 Hz by coupling four basic composite metamaterial units with a thickness of 31.5 mm. The proposed design paradigm can reduce the complexity of designing multiple pipelines silencers with different filling materials because the muffler should have similar thickness in the same paradigm. Full article

We propose a microfluidic device that incorporates two layers of planar split-ring resonator (SRR)-based terahertz (THz) metamaterials and study its optical performance through simulation. The device features a concise design and leverages mature and straightforward fabrication processes. Our simulations reveal its remarkable sensing capabilities, with a sensitivity of up to 507.7 GHz/RIU for refractive index (RI) sensing and 16.03 GHz/μm for pressure sensing. Moreover, the device enables real-time monitoring, as it allows for a continuous flow of liquid between the layers. It can also function as an optical switch with a straightforward controlling method involving injecting and evacuating liquid. The maximum modulation depth (MD) achieved is 64.5%. The influence of fabrication errors during assembly of the two layers was studied in detail through simulation. The device demonstrates great robustness against fabrication imperfections, such as layer misalignment and spacer thickness variations, for most of the applications. Strict alignment is only necessary when targeting high-sensitivity RI sensing using the second resonance. The device’s unique combination of sensitivity, tunability, and compact design paves the way for potential applications in diverse fields, including biosensing, environmental monitoring, and optical communications. Full article

Acoustic sensing technology has attracted significant attention across various fields, including mechanical fault early warning and wireless communication, due to its high information density and advantages in remote wireless applications. However, environmental noise reduces the signal-to-noise ratio (SNR) in traditional acoustic systems. In response, this article proposes a novel Z-shaped channel gradient metamaterial (ZCGM) that leverages strong wave compression effects coupled with effective medium theory to detect weak signals in complex environments. The properties of the designed metamaterials were verified by theoretical derivation and finite element simulation of the model. Compared to conventional linear gradient acoustic metamaterials (GAMs), ZCGM demonstrates significantly superior performance in acoustic enhancement, with a lower capture frequency. Furthermore, the structure exhibits flexible tunability in its profile. In addition, the center frequency of each actual air gap is determined in this paper based on the swept frequency signal test. Based on this center frequency, a preset specific harmonic acoustic signal is used as an emission source to simulate the actual application scenario, and experiments are constructed and conducted to verify the performance of the designed metamaterials. The results consistently show that ZCGM has distinct advantages and promising application prospects in the detection, enhancement, and localization of weak acoustic signals. Full article

The conjoined split-ring resonator (Co-SRR) is proposed as the unit cell to construct terahertz (THz) metamaterial. The size and position of the gaps on both sides of the structure were adjusted, and the impact on the electromagnetic response to the incident THz wave was investigated via simulation. Results show that by properly controlling the structural asymmetry, the resonances can be tuned simultaneously or independently. The devices exhibit frequency shifts of up to 510 GHz, a tuning range of free spectral range (FSR) as wide as 613 GHz, and a high modulation depth (MD) of 93.4%. Additionally, a wide range of amplitude modulation can occur across multiple frequencies. Incorporating spatial asymmetry further enhances the performance, resulting in a high quality factor (Q) of 44.8 and a figure of merit (FOM) of 40.1. The impressive characteristics prove that Co-SRR-based metamaterial is a great candidate for applications in optical sensing, switching, filtering and programming devices. Full article

Mechanical metamaterials, especially the cells with a negative Poisson’s ratio (NPR), have received much attention since they offer more deformability potential in morphing wings. This paper proposes a strategy for regulating the deformation of metamaterial cells based on the deformation form of the wing planform. The deformation of the wing shape was achieved through this strategy, with the main control factor of NPR. In light of the strategy, taking bi-directional re-entrant anti-tetrachiral (BRATC) metamaterial cells with NPR as an example, a scheme for BRATC metamaterial cells to regulate NPR is proposed. Driven by the same increase in wingspan (Δspan = 5%), the wing models, which are constructed based on the BRATC metamaterial cells with NPR characteristics at the different chord length increment at wing root (Δchord = 20%, 25%, and 30%), achieved an acceptable object-contour shape error (K = 1.29%, 1.40%, and 2.10%) with corresponding relative area increases (Ar = 15.5%, 18.13%, and 20.75%). Finally, the feasibility of the method is verified by experimentally measuring the deformation of the wing model. Full article

Inherent material loss is a pivotal challenge that impedes the development of metamaterial properties, particularly in the context of 3D metamaterials operating at visible wavelengths. Traditional approaches, such as the design of periodic model structures and the selection of noble metals, have encountered a plateau. Coupled with the complexities of constructing 3D structures and achieving precise alignment, these factors have made the creation of low-loss metamaterials in the visible spectrum a formidable task. In this work, we harness the concept of deep learning, combined with the principle of weak interactions in metamaterials, to re-examine and optimize previously validated disordered discrete metamaterials. The paper presents an innovative strategy for loss optimization in metamaterials with disordered structural unit distributions, proving their robustness and ability to perform intended functions within a critical distribution ratio. This refined design strategy offers a theoretical framework for the development of single-frequency and broadband metamaterials within disordered discrete systems. It paves the way for the loss optimization of optical metamaterials and the facile fabrication of high-performance photonic devices. Full article

Metamaterials enable the modulation of elastic waves or acoustic waves in unprecedented ways and have a wide range of potential applications. This paper achieves the simultaneous manipulation of surface elastic waves (SEWs) and surface acoustic waves (SAWs) using two-dimensional acousto-elastic metamaterials (AEMMs). The proposed AEMMs are composed of periodic hollow cylinders on the surface of a semi-infinite substrate. The band diagrams and the frequency responses of the AEMMs are numerically calculated through the finite element approach. The band diagrams exhibit simultaneous bandgaps for the SEWs and SAWs, which can also be effectively tuned by the modification of AEMM geometry. Furthermore, we construct the AEMM waveguide by the introduction of a line defect and hence demonstrate its ability to guide the SEWs and SAWs simultaneously. We expect that the proposed AEMMs will contribute to the development of multi-functional wave devices, such as filters for dual waves in microelectronics or liquid sensors that detect more than one physical property. Full article

In this study, we demonstrate the reflectance spectrum of one-dimensional photonic crystals comprising two different types of metamaterials. In this regard, the designed structure can act as a simple and efficient detector for fat concentrations in milk samples. Here, the hyperbolic and gyroidal metamaterials represent the two types of metamaterials that are stacked together to construct the candidate structure; meanwhile, the designed 1D PCs can be simply configured as [G(ED)^m]^S. Here, G refers to the gyroidal metamaterial layers in which Ag is designed in a gyroidal configuration form inside a hosting medium of TiO₂. In contrast, (ED) defines a single unit cell of the hyperbolic metamaterials in which two layers of porous SiC (E) and Ag (D) are combined together. It is worth noting that our theoretical and simulation methodology is essentially based on the effective medium theory, characteristic matrix method, Drude model, Bruggeman’s approximation, and Sellmeier formula. Accordingly, the numerical findings demonstrate the emergence of three resonant peaks at a specified wavelength between 0.8 μm and 3.5 μm. In this context, the first peak located at 1.025 μm represents the optimal one regarding the detection of fat concentrations in milk samples due to its low reflectivity and narrow full bandwidth. Accordingly, the candidate detector could provide a relatively high sensitivity of 3864 nm/RIU based on the optimal values of the different parameters. Finally, we believe that the proposed sensor may be more efficient compared to other counterparts in monitoring different concentrations of liquid, similar to fats in milk. Full article

Low-frequency noise absorbers often require large structural dimensions, constraining their development in practical applications. In order to improve space utilization, an acoustic metamaterial with a spatial double helix, called a spatial double helix resonator (SDHR), is proposed in this paper. An analytical model of the spatial double-helix resonator is established and verified by numerical simulations and impedance tube experiments. By comparing the acoustic absorption coefficients of the spatial double-helix resonator, it is shown that the results of the analytical model, the numerical model, and the experiments are in good agreement, proving the accuracy of the theoretical model. The effects of different structural parameters on the peak sound absorption coefficient and resonance frequency are quantitatively revealed. The impedance variation law of the model is obtained, and the resistance and reactance distributions at the resonance frequency are analyzed. In the optimization model, the Back Propagation (BP) network is used to construct the mapping between the structural parameters and the resonance frequency and sound absorption coefficient, and this is used as the constraints of the equation, which is combined with Wild Horse Optimization (WHO) to establish the BP-WHO optimization model to minimize the volume of the spatial double helix resonator. The results show that, for a given noise frequency, the optimized structural parameters enhance the space utilization without affecting the performance of the space double helix resonator. Full article

In this work, the attenuation of surface seismic waves from large-scale phononic metamaterials is numerically studied. The proposed metamaterials consist of rectangular trenches that form either I-shaped or T-shaped cavities embedded at the ground surface. The numerical investigation includes the study of the response of the proposed structures for different values of their geometric parameters. In addition, modifications of the proposed structures where heavy cores coated with a soft material were considered in the cavities were also numerically studied. For a more realistic numerical approach, the transmission spectrum of a selected large-scale phononic metamaterial was also investigated in a suitable half-space numerical scheme. The results of the present research showed that the studied large-scale metastructures could be a very promising potential candidate for seismic shielding applications for the protection of existing urban or countryside structures. The proposed metamaterials are low in cost and easy to construct for the protection of existing buildings, critical infrastructures, or even entire urban areas without need for any kind of intervention at them, therefore providing an effective solution in the field of seismic isolation. Full article

This paper presents a type of acoustic metamaterial that combines a labyrinth channel with a Helmholtz cavity and a thin film. The labyrinth-opening design and thin-film combination contribute to the metamaterial’s exceptional sound-insulation performance. After comprehensive research, it is observed that in the frequency range of 20–1200 Hz, this acoustic metamaterial exhibits multiple sound-insulation peaks, showing a high overall sound-insulation quality. Specifically, the first sound-insulation peak is 26.3 Hz, with a bandwidth of 13 Hz and giving a transmission loss of 56.5 dB, showing excellent low-frequency sound-insulation performance. To further understand the low-frequency sound-insulation mechanism, this paper uses the equivalent model method to conduct an acoustic–electrical analogy, construct an equivalent model of the acoustic metamaterial, and delve into the sound-insulation mechanism at the first sound-insulation peak. To confirm the validity of the theoretical calculations, physical experiments are carried out by 3D printing experimental samples. The analysis of the experimental data has yielded results that are consistent with the simulation data, providing empirical evidence for the accuracy of the theoretical model. The material has significant practical application value. Finally, various factors are studied in depth based on the established equivalent model, which can provide valuable insights for the design and practical engineering application of acoustic metamaterials. Full article
