Search Results (75)

The experimental and computational characterization of a cold model prototype designed to test the electromagnetic properties of a new RFQ (Radio-Frequency Quadrupole) cavity is reported. This cavity is intended to be an essential part of a compact, high-gradient proton accelerator for medical purposes. The RFQ’s design employs a novel RF power-coupler injection solution. One common way to couple the RF power in proton RFQs has been the use of loop-couplers inserted into the mid-section of the RFQ’s lobe sections. This technique has been demonstrated to be reliable and effective but introduces a significant perturbation into the lobe that can be more noticeable when dealing with compact structures. We propose a RF injection scheme that uses direct transition from a coaxial cable to the RFQ by connecting the inner coaxial conductor to the RFQ vane body. As a consequence, the lobe geometry is not perturbed, and the transversal electrical fields are directly excited through the vanes. Moreover, by using a pair of such couplers connected to opposite vanes at a given transversal plane of the RFQ, it is also possible to excite the desired quadrupolar TE210 modes while avoiding the excitation of dipolar TE110 modes. The resonances corresponding to different RFQ modes have been characterized, and the dependence of the amplitude of the modes on the relative phase of the field injected through the RF power ports has been demonstrated both by measurements and simulations. Full article

This study investigates a novel pulsed electromagnetic field (PEMF) device for dynamic testing and structural health monitoring. The research utilises a PEMF generator CD-1501 with a maximum energy capacity of 0.5 kJ and a flat multifilament coil (IC-1) with a 100 mm diameter. Experiments were conducted on a model steel stand with two joint configurations, using steel plates of 4 mm and 8 mm thickness. The device’s efficacy was evaluated through oscillation pattern analysis and spectral characteristics. Results demonstrate the device’s ability to differentiate between joint states, with the 4 mm plate configuration showing a 15% reduction in high-frequency components compared to the 8 mm plate. Fundamental resonant frequencies of 3D-printed specimens were observed near 5100 Hz, with Q-factors ranging between 200 and 300. The study also found that a 10% increase in volumetric porosity led to a 7% downward shift in resonant frequencies. The developed PEMF device, operating at 50–230 V and delivering 1–5 pulses per minute, shows promise for rapid, non-destructive monitoring of structural joints. When combined with the coaxial correlation method, the system demonstrates enhanced sensitivity in detecting structural changes, utilising an electrodynamic actuator (10 Hz to 2000 Hz range). This integrated approach offers a 30% improvement in early-stage degradation detection compared to traditional methods. Full article

This paper presents the design of a dual-band filter and a diplexer using an extremely miniaturized substrate-integrated coaxial cavity (SICC) structure. The presented dual-band filter can function as a front-end circuit block connected to 5G antennae, enabling dual-passband operation for 5G applications. The diplexer is designed for use in 5G communication systems, positioned after the 5G antennae to facilitate the switching of transmitting (Tx) and receiving (Rx) signals between the Tx and Rx terminals. The main contribution of this work is the development of a highly miniaturized substrate-integrated coaxial cavity (SICC) to design a dual-band filter (DBF) and a diplexer. The circuit area of the proposed dual-frequency SICC is a mere 2.1% of its conventional substrate-integrated waveguide (SIW) cavity counterpart when operating at the same frequency. A dual-band filter and a diplexer are realized using two and three highly miniaturized SICC resonators, respectively. The dual-band filter is designed to have a transmission zero on each passband side to enhance signal selectively. At most in-band frequencies, the isolation between the diplexer’s channel bands exceeds 20 dB. A sample dual-band filter and diplexer have been fabricated for experimental validation, demonstrating excellent agreement between the measured and simulated data. To the best of the authors’ knowledge, the designed dual-band filter and diplexer achieve the highest circuit area efficiency within the categories of dual-band SIW cavity filters and diplexers. Full article

Terahertz (THz) molecular fingerprint spectroscopy provides a powerful label-free tool for detecting trace-amount analytes. Introducing extra microstructures such as metasurfaces to confine the field energy is essential to improve the sensitivity. However, the area of analyte film on conventional enhancing metasurfaces must be larger than the beam spot in a free-space measuring setup. Here, we propose a tunable defect cavity of one-dimensional photonic crystal in the combined coaxial waveguide (CCW) and enhance the broadband THz fingerprint of trace analytes on a much smaller area. The peaks of high Q resonances can form a wide absorption spectrum by changing the length of the rubber part of the coaxial waveguide. For the 0.2 µm α-lactose film sample in the frequency range of 0.48–0.58 THz, the absorption enhancement factor of 89.2 times based on the thickness can be achieved and the sample area is about 1/1700 of that in the free-space measurement with the 5 mm beam waist. We first introduce the coaxial waveguide in the terahertz absorption spectra enhancement. With our proposed structure the analyte volume is effectively reduced which is significant in the real application scenario. Full article

The microphonic noise induced by the vibration from cryocoolers has been found to cause energy resolution degradation in vibration-sensitive instruments. In this paper, theoretical and experimental research on the vibration generation mechanism of an aerospace-grade coaxial pulse-tube cryocooler (CPTC) is presented. Accordingly, suggestions for suppressing the vibration of the pulse-tube cryocooler are provided. A vibration model for the Oxford-type dual-opposed linear compressor is established, and the mechanism of vibration induced by the compressor is theoretically analyzed. A numerical simulation indicates that deviations in the compressor’s inductance coefficient, electromagnetic force coefficient, and flexure spring stiffness coefficient significantly affect the axial vibration of the compressor. The theoretical and experimental studies show that the high-order harmonic vibrations of the compressor are determined by both the resonance of the flexure springs and the high-order harmonics of the driving power supply. Through experiments and simulations, it is revealed that the dynamic gas pressure only induces vibration axially at the cold tip, while the radial vibration at the cold tip is determined by the heat head ‘s vibration and the structural response characteristics of the cold finger. Full article

Multiple input multiple output (MIMO) antennas have recently received attention for improving wireless communication data rates in rich scattering environments. Despite this, the challenge of isolation persists prominently in compact MIMO-based electronics. Various techniques have recently emerged to address the isolation issues, among which the defected ground structure (DGS) stands out as a cost-effective solution. Additionally, selecting the appropriate feed mechanism is crucial for enhancing the key performance indicators of MIMO antennas. However, there has been minimal focus on how different feed methods impact the operation of MIMO antennas integrated with DGS. This paper begins with a comprehensive review of diverse antenna design, feeding strategies, and DGS architectures. Subsequently, the causal relationships between various feed networks and DGSs has been established through modeling, simulation, fabrication, and measurement of MIMO antennas operating within the sub-6 GHz spectrum. Particularly, dual elements of MIMO antennas grounded by a slotted complementary split ring resonator (SCSRR)-based DGS were excited using four standard feed methods: coaxial probe, microstrip line, proximity coupled, and aperture coupled feed. The influence of each feed network on the performance of MIMO antennas integrated with SCSRR-based DGSs has been thoroughly investigated and compared, leading to guidelines for feed network selection. The coaxial probe feed network provided improved isolation performance, ranging from 16.5 dB to 46 dB in experiments.The aperture and proximity-coupled feed network provided improvements in bandwidth of 38.7% and 15.6%, respectively. Furthermore, reasonable values for envelope correlation coefficient (ECC), diversity gain (DG), channel capacity loss (CCL), and mean effective gain (MEG) have been ascertained. Full article

In this paper, a complementary split-ring resonator (CSRR)-based patch antenna is proposed as a microwave sensor to measure the salt concentration of NaCl solution. The microwave sensor consists of an RF-4 substrate, where a small copper disc is attached on the top as the radiator, a larger copper disc integrated with two CSRRs is attached on the bottom side as the finite ground plane, and a coaxial feeding port is introduced at the ground plane center. During salt concentration sensing, only the top disc is immersed into NaCl solution. The results indicate that the proposed microwave sensor can measure salt concentrations ranging from 5‰ to 35‰ with a maximum sensitivity of 0.367 (kHz/(mg/L)). The proposed microwave sensor is low-cost, low-profile, electrically small, lightweight, and easy to fabricate, and it also can be applied to other solutions’ concentration sensing. Full article

In the context of 5G networks, this paper investigates microstrip array antennas and mobile terminal MIMO array antennas. It introduces two innovative designs and, based on these, develops and fabricates a mobile terminal antenna. The first of these designs, a 4 × 4 microstrip array antenna operating in the LTE band 42 (3.4–3.6 GHz), is researched and fabricated and an innovative approach, combining embedded and coaxial feeding methods, is proposed and employed. Measurement results indicate a bandwidth of 373 MHz (3.321–3.694 GHz), achieving a relative bandwidth of 10.7%. The antenna exhibits a high gain of 12.7 dBi, with an undistorted radiation pattern, demonstrating excellent directional characteristics. The second of these designs, a “loop-slot” MIMO antenna designed for 5G mobile devices with metal frames, is investigated. By opening slots in the metal frame and integrating them into the antenna’s feeding structure, the decoupling principle is analyzed from the perspective of characteristic mode theory. This design shares resonant modes between the loop and slot antennas, allowing for the overlapping placement of the two antenna units. Experimental results confirm an isolation level exceeding 21 dB, with significantly reduced dimensions. Finally, an eight-unit MIMO antenna is designed and fabricated for 5G mobile devices with metal frames. Continuous optimization of the “loop-slot” module layout and unit spacing leads to a compact and miniaturized antenna structure. Measurement results show an isolation level exceeding 17 dB, radiation efficiency ranging from 65.8% to 73.7%, and an envelope correlation coefficient (ECC) below 0.03. Finally, an analysis of specific absorption rate (SAR) demonstrates excellent MIMO performance in terms of human body radiation exposure. Full article

This report is on magneto-electric (ME) interactions in bulk composites with coaxial fibers of nickel–zinc ferrite and PZT. The core–shell fibers of PZT and Ni_1−xZn_xFe₂O₄ (NZFO) with x = 0–0.5 were made by electrospinning. Both kinds of fibers, either with ferrite or PZT core and with diameters in the range of 1–3 μm were made. Electron and scanning probe microscopy images indicated well-formed fibers with uniform core and shell structures and defect-free interface. X-ray diffraction data for the fibers annealed at 700–900 °C did not show any impurity phases. Magnetization, magnetostriction, ferromagnetic resonance, and polarization P versus electric field E measurements confirmed the ferroic nature of the fibers. For ME measurements, the fibers were pressed into disks and rectangular platelets and then annealed at 900–1000 °C for densification. The strengths of strain-mediated ME coupling were measured by the H-induced changes in remnant polarization P_r and by low-frequency ME voltage coefficient (MEVC). The fractional change in P_r under H increased in magnitude, from +3% for disks of NFO–PZT to −82% for NZFO (x = 0.3)-PZT, and a further increase in x resulted in a decrease to a value of −3% for x = 0.5. The low-frequency MEVC measured in disks of the core–shell fibers ranged from 6 mV/cm Oe to 37 mV/cm Oe. The fractional changes in P_r and the MEVC values were an order of magnitude higher than for bulk samples containing mixed fibers with a random distribution of NZFO and PZT. The bulk composites with coaxial fibers have the potential for use as magnetic field sensors and in energy-harvesting applications. Full article

A compact photoacoustic spectroscopy system integrated with a non-coaxial multi-pass cell was developed for improving the instrument performance in the measurement of methane. The multi-pass cell with compact light spot mode was proposed for concentrating the light radiation within a limited space, which effectively reduces the instrument dimension. A distributed feedback (DFB) laser with a central wavelength of 1653 nm was employed to excite the photoacoustic signal of methane. A total of 21 round trips of reflection were achieved in an acoustic resonant cavity with a radius of 4 mm and a length of 36 mm. Four microphones were installed around the cavity to collect the signal. An 11-fold enhancement of the photoacoustic signal was achieved through the multi-pass cell, compared to a single-pass cell with dimension of 10 cm. The system was used to measure different concentrations of methane, which showed good linearity. The continuous detection of 10 ppm methane gas was carried out for 6000 s. The Allan standard deviation analysis indicates that the limit of detection of the system was 5.7 ppb with an optimum integration time of 300 s. Full article

Magnetic resonance electrical properties tomography (MR EPT) can retrieve permittivity from the ${\mathit{B}}_1^{+}$ magnitude. However, the accuracy of the permittivity measurement using MR EPT is still not ideal due to the low signal-to-noise ratio (SNR) of ${\mathit{B}}_1^{+}$ magnitude. In this study, the probability density function (PDF)-based channel-combination Bloch–Siegert (BSS) method was firstly introduced to MR EPT for improving the accuracy of the permittivity measurement. MRI experiments were performed using a 3T scanner with an eight-channel receiver coil. The homogeneous water phantom was scanned for assessing the spatial distribution of ${\mathit{B}}_1^{+}$ magnitude obtained from the PDF-based channel-combination BSS method. Gadolinium (Gd) phantom and rats were scanned for assessing the feasibility of the PDF-based channel-combination BSS method in MR EPT. The Helmholtz-based EPT reconstruction algorithm was selected. For quantitative comparison, the permittivity measured by the open-ended coaxial probe method was considered as the ground-truth value. The accuracy of the permittivity measurement was estimated by the relative error between the reconstructed value and the ground-truth value. The reconstructed relative permittivity of Gd phantom was 52.413, while that of rat leg muscle was 54.053. The ground-truth values of relative permittivity of Gd phantom and rat leg muscle were 78.86 and 49.04, respectively. The relative error of average permittivity was 33.53% for Gd and 10.22% for rat leg muscle. The results indicated the high accuracy of the permittivity measurement using the PDF-based channel-combination BSS method in MR EPT. This improvement may promote the clinical application of MR EPT technology, such as in the early diagnosis of cancers. Full article

Partial discharge (PD) is the dominant insulating defect in Gas-Insulated Switchgear (GIS). The existing detection methods are mainly divided into built-in wire-connected disk antennas with destructive drilling and external ultra-high frequency antennas with poor anti-interference ability. This research introduces a passive wireless PD sensor implanted inside GIS on the observation window. The sensor is implemented by a sheeting branch-inductor with multiple resonances which is able to enhance detection sensitivity. A coaxially aligned readout circuit, positioned outside the GIS, interrogates the PD sensor to wirelessly obtain the PD signal. The proposed sensing scheme improves signal-to-noise ratio and ensures minimal disruption to the electric field distribution inside GIS. An experimental setup was established in a controlled laboratory environment to benchmark the multi-resonant sensor against the commercial UHF sensor. A 2.5-times enhancement of signal strength was observed. Since our sensor was implanted inside the GIS, a high signal-to-noise ratio (68.82 dB) was obtained. Moreover, we constructed a wireless calibration test to investigate the accuracy of the proposed sensor. The precision of the signal test was as high as 0.72 pC. The pulse phase distribution information was collected to demonstrate a phase-resolved partial discharge (PRPD) pattern. The experiment results validate the effectiveness of the proposed method and demonstrate excellent performance in PD detection. Full article

The generation of high-quality wideband frequency sweeps presents a significant challenge, particularly in modern telecommunication, radar, and measurement systems where miniaturization is paramount. While phase-locked loops (PLLs) have become the dominant technique for signal generation, their application in broadband sweeps necessitates fractional-N operation. This, in turn, degrades phase noise and introduces unwanted spurs. This paper proposes a novel approach for broadband signal generation. By cascading two PLLs and utilizing a coaxial resonator, we achieve a high-performance oscillator that operates without the excessive fractional spurs, maintaining their level below −80 dBc across the entire frequency band. The prototype demonstrates non-degraded phase noise performance, reaching −102 dBc/Hz at 100 kHz offset and −121 dBc/Hz at 1 MHz offset for signals at 10 GHz. Despite significant frequency jumps, our design achieves lock times below 41 µs. These results, supported by theoretical analysis, validate the proposed method’s effectiveness in generating low-noise broadband frequency sweeps, ideal for local oscillator applications. Full article

In contrast to the room temperature cyclotron, the superconducting cyclotron’s high operational magnetic field and small extraction radius lead to a magnet design with a reduced radius. This limits the space available for the RF cavity in the 11 MeV superconducting cyclotron, necessitating a more compact RF cavity design. By using the transmission line theory, the complex structure of the quarter-wavelength coaxial cavity can be represented as a microwave circuit. Through relevant theoretical analytical formulas, equivalent circuit parameters can be derived. The resonant frequency of the RF cavity is then determined using the equivalent circuit method. The optimization of the RF cavity structure was achieved by creating a numerical model and conducting finite element numerical calculations on the high-frequency resonant system. The comparative results between the equivalent circuit and numerical calculations indicate that the frequency error remains within 0.1%, validating the compact RF cavity design. A multiple linear regression analysis facilitates the prediction of resonance frequency across various parameter variables. By analyzing the fitting formula, RF cavity machining error requirements are established, ensuring a prediction error within 1%, thus meeting engineering design criteria. Full article

Media exposed to atmospheric pressure plasma (APP) produce reactive oxygen and nitrogen species (RONS), with hydrogen peroxide (H₂O₂), nitrite (NO₂⁻), and nitrate (NO₃⁻) being among the most detected species due to their relatively long lifetime. In this study, a standardized microwave-excited (ME) APP jet (APPJ) source was employed to produce gaseous RONS to treat liquid samples. The source was a commercially available plasma jet, which generated argon plasma utilizing a coaxial transmission line resonator at the operating frequency of 2.45 GHz. An ultraviolet-visible spectrophotometer was used to measure the concentrations of H₂O₂ and NO₃⁻ in plasma-activated media (PAM). Three different types of media (deionized water, Hank’s balanced salt solution, and cell culture solution Dulbecco’s modified eagles medium [DMEM]) were utilized as liquid samples. Among these media, the plasma-treated DMEM was observed to have the highest levels of H₂O₂ and NO₃⁻. Subsequently, the feasibility of using argon ME-APPJ-activated DMEM (PAM) as an adjuvant to enhance the therapeutic effects of cisplatin on human bladder cancer cells (T-24) was investigated. Various cancer cell lines, including T-24 cells, treated with PAM were observed in vitro for changes in cell viability using the 3-(4,5-dimethylthiazol-2-yl)-2,5-diphenyl-2H-tetrazolium bromide (MTT) assay. A viability reduction was detected in the various cancer cells after incubation in PAM. Furthermore, the study’s results revealed that PAM was effective against cisplatin-resistant T-24 cells in vitro. In addition, a possible connection between HER expression and cell viability was sketched. Full article
