The increasing penetration of renewable energy into power systems has intensified transient power quality (PQ) disturbances, demanding efficient detection and classification methods to enable timely operational decisions. This paper introduces a hybrid framework combining an Improved Adaptive S-Transform (IAST) with a Random Forest (RF) classifier to address these challenges. The IAST employs a globally adaptive Gaussian window as its kernel function, which automatically adjusts window length and spectral resolution based on real-time frequency characteristics, thereby enhancing time–frequency localization accuracy while reducing algorithmic complexity. To optimize computational efficiency, window parameters are determined through an energy concentration maximization criterion, enabling rapid extraction of discriminative features from diverse PQ disturbances (e.g., voltage sags and transient interruptions). These features are then fed into an RF classifier, which simultaneously mitigates model variance and bias, achieving robust classification. Experimental results show that the proposed IAST–RF method achieves a classification accuracy of 99.73%, demonstrating its potential for real-time PQ monitoring in modern grids with high renewable energy penetration. Full article

This article proposes a multiscale classification framework for detecting voltage disturbances in electrical distribution systems using artificial neural networks (ANNs) combined with the Hilbert–Huang transform (HHT). The framework targets four core power quality (PQ) events defined in the IEEE 1159-2019 standard: normal operation and voltage sag, swell, and interruption. Unlike traditional methods that operate on a fixed disturbance duration, our approach incorporates multiple time scales (0.2 s, 0.4 s, and 0.8 s) to improve detection robustness across varied event lengths, a critical factor in real-world scenarios where disturbance durations are unpredictable. Features are extracted using empirical mode decomposition (EMD) and Hilbert spectral analysis, enabling accurate representation of the signals’ non-stationary and nonlinear characteristics. The ANN is trained using statistical descriptors derived from the first two intrinsic mode functions (IMFs), capturing both amplitude and frequency content. The method was validated in MATLAB on the IEEE 33-bus radial distribution test system using simulated disturbances. The proposed model achieved a classification accuracy of 94.09% and demonstrated consistent performance across all time windows, supporting its suitability for real-time monitoring in smart distribution networks. This study contributes a scalable and adaptable solution for automated PQ event classification under variable conditions. Full article

Power quality disturbances (PQDs) are major obstacles to maintaining the reliability and stability of electrical systems. This study introduces a new multi-scale deep learning method to classify PQDs, aiming to enhance the accuracy and efficiency of power quality (PQ) analysis and monitoring systems. By combining 1-D convolutional neural networks (CNNs) with an attention mechanism, this approach overcomes the limitations of traditional techniques. Moreover, varying-size convolutional layers allow for the direct learning of complex patterns and features from PQ signals. To address the challenge of limited labeled PQ datasets, this research utilizes an open-source dataset generator to create large-scale datasets with annotated PQDs. Through a comparison with existing models in the field, the superiority of the proposed CNN-based approach is evident, achieving an accuracy level of up to $99.49\%$. The results demonstrate promising classification performance in terms of simplicity and accuracy, highlighting the potential of this approach to improve PQ analysis and disturbance identification. Full article

Power quality (PQ) monitoring and detection has emerged as an essential requirement due to the proliferation of sensitive power electronic interfacing devices, electric vehicle charging stations, energy storage devices, and distributed generation energy sources in the recent smart grid and microgrid scenarios. Even though, to date, the traditional approaches play a vital role in providing a solution to the above issue, the limitations, such as the requirement of significant human effort and not being scalable for large-scale power systems, force us to think of alternative approaches. Looking at a better perspective, deep-learning (DL) has gained the main attraction for various researchers due to its inherent capability to classify the data by extracting dominating and prominent features. This manuscript attempts to provide a comprehensive review of PQ detection and classification based on DL approaches to explore its potential, efficiency, and consistency to produce results accurately. In addition, this state-of-the-art review offers an overview of the novel concepts and the step-by-step method for detecting and classifying PQ events. This review has been presented categorically with DL approaches, such as convolutional neural networks (CNNs), autoencoders, and recurrent neural networks (RNNs), to analyze PQ data. This paper also highlights the challenges and limitations of using DL for PQ analysis, and identifies potential areas for future research. This review concludes that DL algorithms have shown promising PQ detection and classification results, and could replace traditional methods. Full article

Power Quality (PQ) has become a significant issue in power networks. Power quality disturbances must be precisely and appropriately identified. This activity involves identifying, classifying, and mitigating power quality problems. A case study of the Awada industrial zone in Ethiopia is taken into consideration to show the practical applicability of the proposed work. It is found that the current harmonic distortion levels exceed the restrictions with a maximum percentage Total Harmonic Distortion of Current (THDI) value of up to 23.09%. The signal processing technique, i.e., Stockwell Transform (ST) is utilized for the identification of power quality issues, and it covers the most important and common power quality issues. The Support Vector Machine (SVM) method is used to categorize power quality issues, which enhances the classification procedure. The ST scored better in terms of accuracy than the Wavelet Transform (WT), Fourier Transform (FT), and Hilbert Transform (HT), obtaining 97.1%, as compared to 91.08%, 88.91%, and 86.8%, respectively. The maximum classification accuracy of SVM was 98.3%. To lower the current level of harmonic distortion in the industrial sector, a Distribution Static Compensator (D-STATCOM) is developed in the current control mode. To evaluate the performance of the D-STATCOM, the performance of the distribution network with and without D-STATCOM is simulated. The simulation results show that THDI is reduced to 4.36% when the suggested D-STATCOM is applied in the system. Full article

This paper introduces a power quality (PQ) detection and categorization algorithm actuated by multiple signal processing techniques and rule-based decision tree (RBDT). This is aimed to recognize PQ events of simple nature and higher order multiplicity with less computational time using hybridization of the signal processing techniques. A voltage waveform with a PQ event (PQE) is processed using the Stockwell transform (ST) to compute the Stockwell PQ detection index (SPDI). The voltage waveform is also processed using the Hilbert transform (HT) to compute the Hilbert PQ detection index (HPDI). A voltage waveform is also decomposed using the Discrete Wavelet transform (DWT) to compute the classification feature index (CFI) [CFI1 to CFI4]. A combined PQ detection index (CPDI) is computed by multiplication of the SPDI, the HPDI and CFI1 to CFI4. Incidence of a PQE on a voltage signal is located with the help of a location PQ disturbance index (LPDI) which is computed by differentiating the CPDI with respect to time. CFI5, CFI6 and CFI7 are computed from the SPDI, the HPDI and the CPDI, respectively. Categorization of PQ events is performed using CFI1 to CFI7 by the rule-based decision tree (RBDT) with the help of simple decision rules. We conclude that the proposed algorithm is effective to identify the PQE with an accuracy of 98.58% in a noise-free environment and 97.62% in the presence of 20 dB SNR (signal-to-noise ratio) noise. Ten simple nature PQEs and eight combined PQ events (CPQEs) with multiplicity of two, three and four are effectively detected and categorized using the algorithm. The algorithm is also tested to detect a sag PQ event due to a line-to-ground (LG) fault incident on a practical distribution utility network. The performance of the investigated method is compared with a DWT-based technique in terms of accuracy of classification with and without noise, maximum computational time of PQ detection and multiplicity of PQE which can be effectively detected. A simulation is performed using the MATLAB software. MATLAB codes are used for modelling the PQE disturbances and the proposed algorithm using mathematical formulations. Full article

Identifying power quality (PQ) disturbances is an important prerequisite for developing mitigation measures to improve PQ. However, the coupling of multiple PQ disturbances in the noise condition makes it difficult to achieve effective feature extraction and classification. This article proposes a novel method to identify multiple PQ disturbances by integrating improved TQWT with XGBoost algorithm. The improved TQWT is proposed to automatically select the proper tuning parameters by screening the spectral information of PQ signals. Then, the improved TQWT is used to decompose PQ disturbances into sub-bands for further feature extraction. Optimum feature selection and classification are implemented in XGBoost. Classification accuracies of 26 categories of synthetic PQ disturbances under different noisy levels are tested and compared with existing methods. Results indicate that the proposed method is efficient and noise-resistant, and the classification accuracy can reach 97.63% under 20 dB noise, and keep above 99% under lower level noise. Full article

The detection, mitigation, and classification of power quality (PQ) disturbances have been issues of interest in the power system field. This paper proposes an approach to detect and classify various types of PQ disturbances based on the Stockwell transform (ST) and decision tree (DT) methods. At first, the ST is developed based on the moving, localizing, and scalable Gaussian window to detect five statistical features of PQ disturbances such as the high frequency of oscillatory transient, distinction between stationary and non-stationary, the voltage amplitude oscillation around an average value, the existence of harmonics in a disturbance signal, and the root mean square voltage at the internal period of sag, swell or interruption. Then, these features are classified into nine types, such as normal, sag, swell, interruption, harmonic, flicker, oscillatory transient, harmonic voltage sag, and harmonic voltage swell by using the DT algorithm that is based on a set of rules with the structure “if…then’’. This proposed study is simulated using MATLAB simulation. The IEEE 13-bus system, the recorded real data based on PQube, and the experiment based on the laboratory environment are applied to verify the effectiveness. Full article

The economic impact associated with power quality (PQ) problems in electrical systems is increasing, so PQ improvement research becomes a key task. In this paper, a Stockwell transform (ST)-based hybrid machine learning approach was used for the recognition and classification of power quality disturbances (PQDs). The ST of the PQDs was used to extract significant waveform features which constitute the input vectors for different machine learning approaches, including the K-nearest neighbors’ algorithm (K-NN), decision tree (DT), and support vector machine (SVM) used for classifying the PQDs. The procedure was optimized by using the genetic algorithm (GA) and the competitive swarm optimization algorithm (CSO). To test the proposed methodology, synthetic PQD waveforms were generated. Typical single disturbances for the voltage signal, as well as complex disturbances resulting from possible combinations of them, were considered. Furthermore, different levels of white Gaussian noise were added to the PQD waveforms while maintaining the desired accuracy level of the proposed classification methods. Finally, all the hybrid classification proposals were evaluated and the best one was compared with some others present in the literature. The proposed ST-based CSO-SVM method provides good results in terms of classification accuracy and noise immunity. Full article

This paper presents a hybrid approach combining phase space reconstruction (PSR) with a convolutional neural network (CNN) for power quality disturbance (PQD) classification. Firstly, a PSR technique is developed to transform a 1D voltage disturbance signal into a 2D image file. Then, a CNN model is developed for the image classification. The feature maps are extracted automatically from the image file and different patterns are derived from variables in CNN. A set of synthetic signals, as well as operational measurements, are used to validate the proposed method. Moreover, the test results are also compared with existing methods, including empirical mode decomposition (EMD) with balanced neural tree (BNT), S-transform (ST) with neural network (NN) and decision tree (DT), hybrid ST with DT, adaptive linear neuron (ADALINE) with feedforward neural network (FFNN), and variational mode decomposition (VMD) with deep stochastic configuration network (DSCN). Based on deep learning algorithms, the proposed method is capable of providing more accurate results without any human intervention for PQDs. It also enables the planning of PQ remedy actions. Full article

Over the past few years, power quality (PQ) monitoring has become of paramount importance for utilities and users since poor PQ generates negative consequences. In monitoring, fast detection and accurate classification of PQ disturbances (PQDs) are desirable features. In this work, a new method to detect and classify PQDs is proposed. The proposal takes advantage of the low computational resources of both a phasor measurement unit (PMU)-based signal processing scheme and the homogeneity approach. To classify the PQDs, if–then–else rules are used. To validate and test the proposal, synthetic and real signals of sags, swells, interruptions, notching, spikes, harmonics, and oscillatory transients are considered. For the generation of real signals, a PQD generator based on a power inverter is used. In the proposed method, the PMU information is directly used to classify sags, swells, and interruptions, whereas the homogeneity index is used to distinguish among the remaining PQDs. Results show that the proposal is an effective and suitable tool for PQ monitoring. Full article

This paper proposes a novel, two-stage and hybrid approach based on variational mode decomposition (VMD) and the deep stochastic configuration network (DSCN) for power quality (PQ) disturbances detection and classification in power systems. Firstly, a VMD technique is applied to discriminate between stationary and non-stationary PQ events. Secondly, the key parameters of VMD are determined as per different types of disturbance. Three statistical features (mean, variance, and kurtosis) are extracted from the instantaneous amplitude (IA) of the decomposed modes. The DSCN model is then developed to classify PQ disturbances based on these features. The proposed approach is validated by analytical results and actual measurements. Moreover, it is also compared with existing methods including wavelet network, fuzzy and S-transform (ST), adaptive linear neuron (ADALINE) and feedforward neural network (FFNN). Test results have proved that the proposed method is capable of providing necessary and accurate information for PQ disturbances in order to plan PQ remedy actions accordingly. Full article

In a context with an increased level of competitiveness, companies are more and more interested in aspects concerning sustainable development. The implications of inadequate power quality (PQ) can determine important financial losses and influence companies’ sustainable development through the generated effects. This article aims to facilitate the management of PQ by proposing a method for estimating the economic consequences of a poor PQ, with priority for the disturbances with significant economic effects. To determine the total cost for each type of PQ perturbation that may occur a classification of cost categories was made such as interruptions, process slowdowns, equipment failure, equipment downtime, reduced energy efficiency, lower product quality, lower labor productivity, and other indirect costs. Each PQ disturbance affects the final end-user differently. For calculating the total value for each type of PQ issues, different calculation formulas have been proposed so that each perturbation includes only those components associated with that perturbation. A case study was used to validate the proposed method. Also, the paper includes a technical and economic analysis of the possible compensation solutions for PQ disturbances that may affect the studied company. In conclusion, an understanding of PQ issues’ consequences and an appropriate approach to PQ compensation solutions can be beneficial to any electrical power end-user. Full article

This paper presents a transient power quality (PQ) disturbance classification approach based on a generalized S-transform and probabilistic neural network (PNN). Specifically, the width factor used in the generalized S-transform is feature oriented. Depending on the specific feature to be extracted from the S-transform amplitude matrix, a favorable value is determined for the width factor, with which the S-transform is performed and the corresponding feature is extracted. Four features obtained this way are used as the inputs of a PNN trained for performing the classification of 8 disturbance signals and one normal sinusoidal signal. The key work of this research includes studying the influence of the width factor on the S-transform results, investigating the impacts of the width factor on the distribution behavior of features selected for disturbance classification, determining the favorable value for the width factor by evaluating the classification accuracy of PNN. Simulation results tell that the proposed approach significantly enhances the separation of the disturbance signals, improves the accuracy and generalization ability of the PNN, and exhibits the robustness of the PNN against noises. The proposed algorithm also shows good performance in comparison with other reported studies. Full article

Power quality signal feature selection is an effective method to improve the accuracy and efficiency of power quality (PQ) disturbance classification. In this paper, an entropy-importance (EnI)-based random forest (RF) model for PQ feature selection and disturbance classification is proposed. Firstly, 35 kinds of signal features extracted from S-transform (ST) with random noise are used as the original input feature vector of RF classifier to recognize 15 kinds of PQ signals with six kinds of complex disturbance. During the RF training process, the classification ability of different features is quantified by EnI. Secondly, without considering the features with zero EnI, the optimal perturbation feature subset is obtained by applying the sequential forward search (SFS) method which considers the classification accuracy and feature dimension. Then, the reconstructed RF classifier is applied to identify disturbances. According to the simulation results, the classification accuracy is higher than that of other classifiers, and the feature selection effect of the new approach is better than SFS and sequential backward search (SBS) without EnI. With the same feature subset, the new method can maintain a classification accuracy above 99.7% under the condition of 30 dB or above, and the accuracy under 20 dB is 96.8%. Full article
