Search Results (25)

This study investigates the shell hydroforming of 1.2 mm-thick AA5052 aluminum alloy sheets to produce hemispherical domes which possess inherent spatial symmetry about their central axis. Shell hydroforming is widely used in fabricating lightweight, high-strength components for aerospace, automotive, and energy applications. The forming process was driven by a spatially symmetrical internal pressure distribution applied uniformly across the blank to maintain balanced deformation and minimize geometrical distortion. Experimental trials aimed at achieving a dome depth of 50 mm revealed wrinkle formation at the blank periphery caused by circumferential compressive stresses symmetrical in nature with respect to the dome’s central axis. To better understand the forming behavior, a validated 3D finite element (FE) model was developed, capturing key phenomena such as material flow, strain rate evolution, hydrostatic stress distribution, and wrinkle development under symmetric boundary conditions. The effects of the internal pressure (IP), blank holding force (BHF), coefficient of friction (CoF), and flange radius (FR) were systematically studied. A strain rate of 0.1 s⁻¹ in the final stage improved material flow, while a symmetric tensile hydrostatic stress of 160 MPa facilitated dome expansion. Although tensile stresses can induce void growth, the elevated strain rate helped suppress it. An optimized parameter set of IP = 5.43 MPa, BHF = 140 kN, CoF = 0.04, and FR = 5.42 mm led to successful formation of the 50 mm dome with 19.38% thinning at the apex. Internal pressure was identified as the most critical factor influencing symmetric formability. A process window was established to predict symmetric failure modes such as wrinkling and bursting. Full article

To accurately investigate the stress and deformation behavior of support structures during mechanical shaft construction, this study proposes an analytical method for active earth pressure calculation based on limit equilibrium theory, incorporating both the radial variation of the circumferential stress coefficient and the spatial arching effect. Considering the entire sliding soil mass behind the shaft wall as the analytical object, the inclination angle of the sliding surface under active limit conditions is derived. Subsequently, by incorporating interlayer shear forces, a horizontal layer analysis is employed to establish the vertical and radial force equilibrium equations, leading to the formulation of an active earth pressure model for circular shafts. Furthermore, based on elastic mechanics theory, a corresponding method is developed to calculate the internal forces of the shaft structure. The theoretical predictions show good agreement with existing model test results and field monitoring data, demonstrating the accuracy and reliability of the proposed approach. The findings provide a theoretical basis for optimizing the design of circular shafts and assessing the structural stability of shaft walls. Full article

This paper presents an analysis of the wear of the surface layer of drawing dies after the steel wire drawing process. It was shown that the working surface of the drawing die is characterized by high roughness combined with the occurrence of numerous scratches and blurs. As a result of high pressures in the deformation zone, premature wear of drawing dies combined with mechanical damage and the sticking of steel on the drawing surfaces can occur during the industrial drawing process. The finite element method analysis showed a significant relationship between the friction coefficient and the rate of drawing die wear. The varying distribution of stresses in the drawing die during the drawing process can contribute to mechanical damage. Longitudinal tensile stresses at the wire’s entrance to the drawing die increase the risk of circumferential cracking of drawing dies. Full article

FRP-confined gangue aggregate concrete partially filled steel tubes (CGCPFTs) can not only effectively enhance the performance of coal gangue concrete, but also fully exploit the elastic-plastic mechanical behavior of the steel tubes. However, research on theoretical models that can describe their mechanical properties is yet to be conducted. To fill this gap, theoretical models for structural design and analysis were proposed for CGCPFTs. For the analytical model, based on the available experimental data, a prediction method for the stress–strain behavior of the gangue aggregate concrete in CGCPFTs, which is confined only by FRP and partly confined by both FRP and the steel tubes, was first proposed. Additionally, the condition for the synergetic deformation of the two confined states of gangue aggregate concrete within the CGCPFT was proposed. Based on the condition, an iterative incremental process was developed which subsequently allows for the theoretical calculation of the load–displacement curve for the CGCPFT under monotonic axial compression. For the design model, by introducing the constraint contribution coefficient of the steel tube, the existing closed-loop calculation formula for the stress–strain relationship of FRP-confined concrete was revised. Furthermore, by expressing the axial and lateral stresses of the steel tube as a unified circumferential effect on the concrete, the calculation methods for the ultimate strength and strain in the closed-loop formula were redefined, thus achieving the prediction of the stress–strain behavior of CGCPFTs. The comparison with the test data obtained by the author and their team revealed that both the analysis and design models could provide accurate predictions. Full article

316L stainless steel pipes are widely used in the storage and transportation of low-temperature media due to their excellent low-temperature mechanical properties and corrosion resistance. However, due to their low thermal conductivity and large coefficient of linear expansion, they often lead to significant welding residual tensile stress and thermal cracks in the weld seam. This also poses many challenges for their secure and reliable applications. In order to effectively control the crack defects caused by stress concentration near the heat-affected zone of the weld, this paper establishes a thermal elastoplastic three-dimensional finite element (FE) model, constructs a welding heat source, and simulates and studies the influence of process parameters on the residual stress around the pipeline circumference and axial direction in the heat-affected zone. Comparison and verification were conducted using simulation and experimental methods, respectively, proving the rationality of the finite element model establishment. The axial and circumferential residual stress distribution obtained by the simulation method did not have an average deviation of more than 30 MPa from the numerical values obtained by the experimental method. This study also considers the effects of welding energy, welding speed, and welding start position on the pipe’s circumferential and axial residual stress laws. The results indicate that changes in welding energy and welding speed have almost no effect on the longitudinal residual stress but have a more significant effect on the transverse residual stress. The maximum transverse residual stress is reached at a welding energy of 1007.4~859.3 J/mm and a welding speed of 6.6 mm/s. Various interlayer arc-striking deflection angles can impact the cyclic phase angle of the transverse residual stress distribution in the seam center, but they do not alter its cyclic pattern. They do influence the amplitude and distribution of the longitudinal residual stress along the circumference. The residual stress distribution on the surface of the pipe fitting is homogenized and improved at 120°. Full article

Reinforcement corrosion significantly impacts the service life of reinforced concrete structures. The present study investigates the circumferential and longitudinal non-uniformity of steel corrosion in concrete subjected to mechanical load. Results indicate that, in the case of steel corrosion in concrete subjected to mechanical load, the distribution of rust layer thickness around the perimeter of the steel bar is fitted well with a Gaussian distribution. As the corrosion rate gradually increases, the uniform coefficient is linearly proportional to the minimum thickness of the rust layer. With respect to the longitudinal non-uniformity of steel corrosion, load-induced transverse cracks have a significant impact on the non-uniformity of corrosion, leading to the formation of rust peaks near the locations of transverse cracks. In the vicinity of each rust peak, the corrosion rate of the steel bar follows a Gaussian distribution. With respect to the non-uniformity of corrosion along the longitudinal rebar, a Gumbel distribution is identified to fit well, both in the cases of the non-stressed section and the pure bending section, although with dissimilar non-uniform parameters. Crack coefficients (α and β) are introduced to describe the influence of transverse cracks on the longitudinal non-uniformity of steel corrosion. Full article

The grout pressure in the shield tunnel tail void during synchronous grouting is the key to controlling ground settlement and restraining the segment. However, the circumferential, longitudinal, and radial distribution of grout pressure considering the temporal variation in grout viscosity has not been well explored yet. In this study, a theoretical model of grout pressure distribution and dissipation considering the temporal variation in Bingham grout viscosity was established. The simulation results of the pressure model were verified by field-measured data. The results showed that the radial and longitudinal distributions of grout pressure considering the temporal variation in grout viscosity were closer to the field-measured data. The impacts of the main parameters on the pressure distribution and dissipation were analyzed. Compared with the effect of the shield tail void thickness, tunnel radius and yield shear stress have greater effects on grout pressure during the circumferential filling phase. During the longitudinal and radial diffusion phases, the increase in soil porosity and permeability coefficient was conducive to grout diffusion. The increase in the grout viscosity reduces the pressure loss during the grout flow process. The results of this research can provide a theoretical basis for the grout design process in shield tunnels. Full article

To investigate and analyze the influence of different stress environments on the deformation and destabilization of the rocks surrounding laminated roadways under high stress, this study conducted numerical simulations of coal–rock combination under different circumferential pressures and of the surrounding rocks of highly stressed laminated roadways under different lateral pressure coefficients. In addition, a new custom constitutive structure model was constructed based on the Mohr–Coulomb criterion and realized in FLAC3D software by combining field working conditions. The model was then developed in FLAC3D software for a second time. The results show that the calculated results of the model in this study are in good agreement with the experimental results and the errors are small, while the calculated results of the Mohr–Coulomb model differ from the experimental values under two types of surrounding rock pressure. The deformation of the Mohr–Coulomb model is significantly smaller than that of the customized model, which verifies the reasonableness and superiority of the self-built model in combination with the field conditions. This provides theoretical and practical bases for the design and optimization of stratigraphic roadway support in underground coal mines. Full article

In order to study the bearing safety and influencing factors of the support structures of hydraulic tunnels in cold regions under the action of low-temperature frost heave, a mechanical model of the support structure and surrounding rock was established. Taking a hydraulic tunnel of a hydropower station in Xinjiang as the research object, a combination of field measurement and a numerical simulation method was adopted to study the bearing safety of the support structure during a period of freezing weather. Based on this model, the effects of different thermal expansion coefficients, temperature differences, and surrounding rock porosity on the bearing safety of the support structure in the low-temperature region were studied. From the calculation results, it was concluded that the simulation results of the numerical model established by using the mechanical model in this paper were in good agreement with the actual measurement results of the project. The circumferential freezing and compressive stresses at the arch waist of the supporting structure of the project were the largest, and significant plastic strain was generated near the arch waist. The displacement at the arch of the supporting structure was the largest, while the weak points were at the arch waist and arch top of the supporting structure. The coefficient of thermal expansion, greater temperature difference, and increased porosity of the surrounding rock all led to an increase in the rock freezing and swelling force to varying degrees, thus reducing the load-bearing safety of the supporting structure. The research results could provide a theoretical basis and a reliable mechanical and numerical simulation model for establishing the bearing safety of tunnels in the cold region. Full article

New finite element analysis procedures are developed in this study to obtain the precise stress distribution patterns of prestressed composites. Within the FEM procedures, an equivalent thermal method is modified to realize the prestress application, and a multi-step methodology is developed to consider coupling effects of polymer curing and prestress application. Thereafter, the effects of interphases’ properties, including the elastic modulus and coefficient of thermal expansion (CTE), on the stress distribution patterns are revealed. Analytical methods for residual stress prediction are modified in this study to demonstrate the finite element analysis procedures. From the residual stress results, it is found that the increase in the prestress level tends to contribute to the initiation of interphase debonding. The increase in the elastic modulus or CTE of the interphase results in very large circumferential and axial stress values appearing in the interphase. When the elastic modulus in the interphase is heterogeneous, the predicted stress values in the fiber and matrix are similar to the results predicted with the equivalent elastic modulus of the interphases. However, the heterogeneous elastic modulus results in serious circumferential and axial stress gradients in the interphase. Full article

The aim of this study was to analyze the force and deformation law of an artificial frozen wall. Thus, the frost heave coefficient was introduced to describe the frost heave characteristics, and the frozen wall was regarded as a heterogeneous material whose material properties changed in a parabolic pattern with the radius. The elastoplastic stress and displacement formulas of a non-uniform frozen wall considering frost heave characteristics were derived according to different strength criteria. Consequently, the derived formulas were used to calculate and analyze the mechanical characteristics of the artificial frozen wall. The results showed that the radial stress of the frozen wall changed linearly, whereas the circumferential stress change followed a parabolic pattern after considering the non-uniform characteristics. Moreover, the displacement of the outer edge of the frozen wall was always greater than that of the inner edge, and the displacement of the inner edge changed with the increasing temperature, significantly greater than that of the outer edge. When the frozen wall was in the elastic state, its displacement caused by frost heave was constant. When the frozen wall entered the elastic–plastic state, the displacement of its inner edge caused by frost heave increased with the increase in the radius of the plastic zone, whereas the displacement of the outer edge caused by frost heave decreased with the increase in the radius of the plastic zone. Full article

This article is devoted to the study of means and methods for non-destructive testing mechanical properties of polyethylene gas pipelines that have been in operation for 25–55 years. In order to assess mechanical properties, stress at yield was chosen as a key parameter. Stress at yield is determined from the results of tensile tests and is associated with the limiting circumferential (hoop) stress, determined from the results of tests for short-term pressure. Tensile tests require sample cutting and the shutdown of pipelines’ service. To solve this problem of nondestructive testing of pipelines, tests were carried out using the methods of Shore, Leeb and dynamic instrumental indentation. According to the test results, it was revealed that the correlation coefficient between the values of stress at yield and hardness, obtained by the method of dynamic instrumental indentation, is 0.98 which confirms the possibility of the evaluation of the mechanical properties of pipelines by the method of dynamic instrumental indentation. Full article

The analytic solution for surrounding rock of roadway is of significance for stability analysis and roadway support. However, analytical solution for surrounding rock of roadway which took influences of water seepage, strain softening, dilatancy and intermediate principal stress all into account did not receive much reporting. To promote research in this aspect, a mechanical model simultaneously considering water seepage, strain softening, rock dilatancy, and intermediate principal stress was established based on porous elastoplastic mechanics, and then unified analytical solution for surrounding rock of roadway was obtained. Based on an example, influences of water seepage, strain softening, rock dilatancy, residual cohesion and intermediate principal stress on surrounding rock of roadway were thoroughly investigated using single factor analysis. The obtained results are as follows: radii of plastic zones and surface displacement of roadway would increase exponentially with water pressure increasing and their magnitudes are greater than corresponding values without water seepage considered; with softening modulus increasing, peak circumferential stress location would slightly shift to deeper surrounding rock, while broken zone radius and surface displacement of roadway would increase in a decay velocity; rock dilatancy has little effect on peak circumferential stress and plastic softening zone radius, while broken zone radius and surface displacement of roadway increase linearly with dilatancy coefficient α1 increasing indicating their magnitudes are overestimated if associated flow rule is adopted; with weighted coefficient increasing, stress components in plastic zones at the same distance from roadway center would increase, while radii of two plastic zones and surface displacement of roadway are reduced, i.e., self-bearing capacity of rock is enhanced considering intermediate principal stress effect compared to Mohr–Coulomb criterion; with residual cohesion increasing, peak circumferential stress remains unchanged, while stress components in plastic zones at the same distance from roadway center would increase and radii of two plastic zones decrease significantly. The above results implicated that water seepage effect should be carefully considered for roadway stability under groundwater environment; strain-softening and flow rule of rock should be reasonably analyzed and chosen to accurately predict surface displacement and broken zone radius of roadway; rock bolt length should be increased with softening modulus increasing, while it can be decreased with intermediate principal stress effect considered; grouting measure is an effective measure to improve roadway stability. In short, the research provides a theoretical basis and some practical engineering implication for roadway support. Full article

Shale gas is a promising new energy source stored in shale. This research aims to study the laws of rock crack initiation and propagation under the low-temperature fracturing of liquid nitrogen, explore the influencing factors of the shale reservoir fracturing effect, and identify the method that achieves the best fracturing effect and obtains the highest economic benefits. Herein, a visualized physical experiment of the liquid nitrogen effect is carried out, and the fracture process of a numerical model under cold shock is simulated to analyze the effect of homogeneity on shale crack propagation. The results show that two different crack development modes could be observed in the field test. The first one was the horizontal plane radial crack caused by longitudinal thermal shrinkage, and the other one was the vertical tensile crack caused by circumferential shrinkage. A certain interval length was frequently found between the horizontal cracks. The crack propagation of the specimens with different homogenization degrees was basically distributed in the direction perpendicular to the liquid nitrogen contact surface. When the homogenization degrees were m = 2 and 5, the crack surface was rough and the microfracture was disordered and dotted around the crack tip. When m ≥ 10, the dotted damage around the crack tip did not appear, and the crack propagation was close to the results obtained from using the homogeneous materials. Finally, this work simulates the fracture process of a circular hole plane model under cold shock, analyzes the influences of heat transfer coefficient, in situ stress and other parameters on shale temperature, minimum principal stress distribution, and crack propagation, and discusses the optimal method to improve the heat transfer coefficient. The results show that increasing the heat transfer coefficient can increase the tensile stress value and influence the range of the contact boundary, making the rock more prone to cracking and resulting in greater crack development and a better crack initiation effect. The lateral stress coefficient affects the propagation direction of the cracks, and the propagation depths of low-temperature cracks were found to be deeper in the direction of larger principal stress. Full article

To explore the effect of dents on the tribological behavior of the “washers-cage-rollers” system of rolling element bearings (REBs), the friction and wear properties of dents textured thrust cylindrical roller bearings (81107TN) with different diameters of dents (DAOD, 200, 250, 300 μm), depth of dents (DPOD, 4, 8, 12 μm) as well as circumferential interval angle (CFIA, 1.5°, 2.0°, 2.5°) were researched under dry wear. The surface stresses of REBs and the influence mechanism of dents were also compared and discussed. The results show that: due to the nylon film formed and left on the raceways, the coefficients of friction (COFs) of dents textured bearings are all higher than the average COF of smooth ones, while their wear losses may become higher or lower, depending on the combination of pattern parameters. The influence of the DPOD on the tribological performance of textured bearings is more significant than that of the DAOD. The results show that, when the DAOD and DPOD are 250 and 8 μm, respectively, compared with the smooth ones, the mass losses of bearings can be reduced by up to 49.22% under dry wear, which would be an important reference for the optimal design of the “washers-cage-rollers” system of REBs. Full article
