This paper presents a novel design technique using beam-forming networks based on CORPS (coherently radiating periodic structures) technology to achieve the simplification of the feed network of Fermat spiral antenna arrays. The use of one-layer CORPS structures generates the values of co-phasal excitation required for the feeding network system based on subarrays. The setting of subarrays has been achieved through the study of the behavior of phases of each antenna element in scanning. In this way, elements that exhibit linear behavior in scanning can be grouped. Furthermore, the geometry of the antenna array system using a Fermat spiral configuration applies methods for side lobe level (SLL) reduction such as: a raised cosine amplitude excitation and optimization of the amplitude excitations through the method of genetic algorithms (GA), CORPS amplitude distribution and uniform distribution. The contribution of this paper is to provide a design of a phased antenna system for a Fermat spiral array geometry considering the analysis and study in the performance of SLL, scanning range, and the phase shifters reduction. Full-wave electromagnetic results are provided for the full phased antenna system by using circular patch antenna elements at a frequency of 6 GHz. If our system using CORPS is compared with the use of a conventional feeding network where every antenna in the spiral array is fed with a phase shifter, the benefits of using this phased spiral array system are: a phase shifters reduction capability of 33%, steering ranges of ±22° in the elevation plane, low SLL using the proposed distribution techniques. Furthermore, the choice of CORPS 2×3 networks would allow the integration of the antenna system where one layer is proposed for the feeding network and another layer for the antenna array with the aim of avoiding crossings and unwanted radiation. Full article

Phased antenna arrays have revolutionized modern wireless systems by enabling dynamic beamforming, multibeam synthesis, and user tracking to enhance data rates and reduce interferences, yet their reliance on expensive active components (e.g., phase shifters, amplifiers) embedded in antenna array elements limits adoption in cost-sensitive sub-GHz applications. Therefore, the active phased antenna arrays are still considered as high-end technology and primarily designed only for high-frequency bands and demanding applications such as radars and mobile base stations in microwave bands. In contrast, various important radio communication services still operate in sub-GHz bands with no adequate solution for modern antenna systems with beamforming capability. This paper introduces a 3D antenna array with switched-beam or multibeam capability, designed to eliminate mechanical rotators and active circuitry while maintaining all-sky coverage. By integrating collinear radiating elements with a Butler matrix feed network, the proposed 3D array achieves transmit/receive multibeam operation in the 435 MHz amateur satellite band and adjacent 433 MHz ISM band. Simulations demonstrate a design that provides selectable eight beams, enabling horizontal 360° coverage with only one radio connected to the Butler matrix. If eight noncoherent radios are used simultaneously, the proposed antenna array acts as a multibeam all-sky coverage antenna. Innovations in our design include a 3D circular collinear topology combining the broad and adjustable elevation coverage of collinear antennas with azimuthal beam steering, a passive Butler matrix enabling bidirectional transmit/receive multibeam operation, and scalability across sub-GHz bands where collinear antennas dominate (e.g., Lora WAN, trunked radio). Results show sufficient gain, confirming feasibility for low-earth-orbit satellite tracking or long-range IoT backhaul, and maintenance-free beamforming solutions in sub-GHz bands. Given the absence of practical beamforming or multibeam-capable solutions in this frequency band, our novel concept—featuring non-coherent cooperation across multiple ground stations and/or beams—has the potential to fundamentally transform how the growing number of CubeSats in low Earth orbit can be efficiently supported from the ground segment perspective. Full article

In this paper, two orthogonally placed Vivaldi antennas with a septum-like polarizer to generate circular polarized (CP) waves are presented. Septum polarizers have garnered attention due to their simple structure and high quality of CP waves. While a typical septum polarizer has been applied to various types of waveguides, its applicability to the substrate integrated Vivaldi antenna is demonstrated here for the first time. A pulse train-shaped polarizer is used, which is placed on one of the two Vivaldi antennas. The contours of the polarizer are optimized using a genetic algorithm to provide an equal amplitude and 90° phase difference between the two orthogonal electric fields. In contrast to typical feed networks with a 90° phase shifter, any unwanted loss caused by an electronic circuit can be greatly mitigated. The antenna prototype was fabricated, and its radiation pattern and impedance matching were measured and compared to the simulated results. Full article

A wideband multi-polarized square-horn antenna based on an orthogonal mode transducer (OMT) is developed for working in the whole W-band in this paper. The designed antenna is capable of radiating multiple polarization modes as horizontal polarization (HP) and vertical polarization (VP) when as single-port excitation and left-handed circular polarization (LHCP) and right-handed circular polarization (RHCP) when as dual-port excitation, owing to the characteristic of the OMT with the transmitting of orthogonally polarized waves. A CNC-layered fabrication approach is proposed, which means that the antenna prototype integrating with a Boifot-type OMT, turning waveguide, twisting waveguide and phase shifter is divided into three layers along the vertical direction to be fabricated based on computerized numerical control (CNC) technology. In the design, the turning waveguide and twisting waveguide are employed to achieve plane consistency of the antenna branch ports. Furthermore, a phase shifter is designed to compensate the orthogonally polarized waves, which can keep the phase of the orthogonally polarized waves consistent in a wideband frequency range from 75 GHz to 110 GHz. A prototype is fabricated and measured to verify the performance of the proposed multi-polarization antenna, and the measured results agree well with the simulation ones. In the whole W-band, the value of return loss is better than 10 dB of all polarization modes, and the value of AR of the LHCP and RHCP is below 3.5 dB. The maximum gain of the antenna reaches up to 18.8 dBi at 110 GHz. In addition, regarding the layered structure, the possible layered assembly error analysis is discussed, which verifies the feasibility of the layered machining for this antenna. Full article

A wideband superdirective array, composed of a two-element circular monopole configuration, is introduced. The monopoles are placed in close proximity, facing each other on a metal ground. To ensure good matching at high frequencies, two pairs of elliptical patches are added to the sides of the monopoles, enhancing the surface current of the circular patch for wideband performance. To achieve equal amplitude excitation and the desired phase difference, a wideband power divider with a phase shifter is designed to feed the antenna array. Simulation and measurement results demonstrate that the proposed wideband antenna array, operating within the frequency range of 2.94–7.93 GHz, exhibits a maximum directivity of 8.36–10 dBi, with an antenna efficiency ranging from 47.86 to 83.18% across the bandwidth. The proposed array has the advantages of miniaturization, high directivity and wideband operation and can be widely used in various portable wireless communication systems, including WLAN (5.05–5.9 GHz), ISM (5.725–5.875 GHz), 5G communication (3.3–3.8 GHz), etc. Full article

This paper presents a novel high-power rotary waveguide phase shifter based on circular polarizers specifically engineered for high-power microwave (HPM) applications. The phase shifter is capable of performing a precise 360° linear phase shift through rotation and consists of three parts: a linearly polarized to left-handed circularly polarized (LP-LHCP) mode converter, a left-handed to right-handed circularly polarized (LH-RHCP) mode converter, and a linearly polarized to right-handed circularly polarized (LP-RHCP) mode converter. This paper analyzes the phase-shifting principle, optimizes the three parts of the X-band rotary waveguide phase shifter, and conducts simulation studies on the entire phase shifter, which is made of aluminum. The results show that the reflection is less than −20 dB and the insertion loss is below 0.3 dB within 9.5 GHz to 10.2 GHz. The phase shift is equal to twice the rotation angle within this frequency range. Specifically, the phase shifter can achieve a linear phase shift of 360° when rotated from 0° to 180°, with a maximum deviation of less than 1.2°. Moreover, the power-handling capacity of the phase shifter in vacuum exceeds 242 MW. In the meantime, a prototype of a phase shifter was manufactured, and the experimental results are in good agreement with the simulation results. Full article

This paper presents a low-complexity multi-size circular-shift network (MCSN) structure for 5th-generation (5G) New Radio (NR) quasi-cyclic low-density parity-check (QC-LDPC) decoders. In particular, a fine-coarse approach-based multi-size cyclic shift network, which decomposes the cyclic shift size into fine part and coarse part, is introduced. The proposed MCSN structure is composed of a pre-rotator performing the fine part of the cyclic shift, and a main rotator executing the coarse part of the cyclic shift. In addition, a forward routing circular-shift (FRCS) network, which is based on the barrel shifter and the forward routing process is presented. The proposed switch network is able to support all 51 different submatrix sizes as defined in the 5G NR standard through an efficient forward routing switch network and help reduce the hardware complexity using a cyclic shift size decomposition method. The proposed MCSN is analyzed, and indicates a substantial reduction in the hardware complexity. The experimental results on TSMC 65-nm CMOS technology show that the proposed MCSN structure for 5G NR LDPC decoder offers an area saving up to 56.75% compared to related works in the literature. Full article

Quasi-cyclic low-density parity-check (QC–LDPC) codes are introduced as a physical channel coding solution for data channels in 5G new radio (5G NR). Depending on the use case scenario, this standard proposes the usage of a wide variety of codes, which imposes the need for high encoder flexibility. LDPC codes from 5G NR have a convenient structure and can be efficiently encoded using forward substitution and without computationally intensive multiplications with dense matrices. However, the state-of-the-art solutions for encoder hardware implementation can be inefficient since many hardware processing units stay idle during the encoding process. This paper proposes a novel partially parallel architecture that can provide high hardware usage efficiency (HUE) while achieving encoder flexibility and support for all 5G NR codes. The proposed architecture includes a flexible circular shifting network, which is capable of shifting a single large bit vector or multiple smaller bit vectors depending on the code. The encoder architecture was built around the shifter in a way that multiple parity check matrix elements can be processed in parallel for short codes, thus providing almost the same level of parallelism as for long codes. The processing schedule was optimized for minimal encoding time using the genetic algorithm. The optimized encoder provided high throughputs, low latency, and up-to-date the best HUE. Full article

The global synthesis for antenna arrays that produce a desired radiation pattern is a scientific symmetry problem. This paper deals with the design of concentric ring antenna arrays to simplify the feeding system using a cophasal subarray configuration. This simplification in the feeding network is achieved by the reduction of phase shifters via a proper clustering of radiators applying one amplitude and one phase excitation by subarray in the array system. The array design for this geometry considers an optimization process based in differential evolution to reduce the side-lobe level, resulting in simplification of the feeding network. Simulation results based on CST Microwave Studio and HFSS are provided to verify the accuracy of the array model and to take mutual coupling into account. These simulations are provided using a circular patch as antenna element to generate a scannable array pattern over the elevation plane. Furthermore, an analysis of the manufacturing tolerances was made to verify the reliability of our design. Full article
