Search Results (176)

Multistable energy harvesters have attracted considerable attention due to their shallow potential wells, which facilitate low-energy inter-well oscillations. Although bistable or tristable configurations can be realized using combined magnets or springs, two critical challenges remain: (i) the difficulty in obtaining a higher number of stable equilibrium points and (ii) the inability to arbitrarily prescribe the coordinates of these equilibrium points. To address these issues, this paper proposes a piezoelectric cantilever beam-based multistable energy harvester that allows programmable specification of both the number and the positions of equilibrium points. As demonstrations, a tristable and a pentastable energy harvester with user-defined equilibrium coordinates are designed, and their energy harvesting performances are systematically investigated. Simulation and experimental results show that under an excitation acceleration of 0.1 g, both harvesters can only perform intra-well motion, exhibiting softening nonlinearity. When the excitation acceleration increases to 0.2 g, the pentastable harvester successfully overcomes the maximum potential barrier to achieve inter-well oscillation, displaying hardening nonlinearity and significantly broadening the operational bandwidth, while the tristable harvester remains confined to intra-well motion. At an excitation acceleration of 0.4 g, both harvesters can achieve inter-well oscillation, but the pentastable harvester possesses a wider operational bandwidth and a lower starting frequency for energy harvesting. The proposed method enables the design of multistable vibration energy harvesters without increasing structural complexity with the number of equilibrium points, which is of great significance for optimizing multistable vibration energy harvesters. Full article

To accurately reveal the mechanism of interlayer separation, crack propagation, and progressive instability of vault strata in underground cavities in gentle-dipping bedded rock masses, this paper systematically elucidates the entire mechanical behavior of separation evolution, crack penetration, structural transformation, and step-by-step caving of vault bedded rock masses under excavation disturbance through a comprehensive integration of excavation unloading mechanical analysis, the Griffith strength criterion, and the dynamic transformation theory of beam structures. The results show that excavation induces radial unloading and circumferential stress concentration in the surrounding rock, and the vault rock mass preferentially undergoes interlayer separation along near-horizontal gentle-dipping bedding planes, forming a spatial zoning feature of gradient attenuation from bottom to top: a strong separation zone at the lower part, a transition zone in the middle, and a closed zone at the upper part. The vault strata undergo a cyclic dynamic structural transformation of cantilever beam–fixed-end beam–simply supported beam, exhibiting stepped fracturing and layer-by-layer caving failure characteristics. The fracture and caving range follow a three-stage evolution law of initial increase–peak–subsequent convergence and stabilization. Based on the elastic mechanics stress transformation relationship, a Griffith initiation criterion for surrounding rock of circular cavities under non-axisymmetric loads is derived and established, and mechanical calculation models of single beam and composite beam suitable for stratified rock masses are constructed, which quantitatively reveal the controlling effects of tensile strength of strata, lateral pressure coefficient, tunnel diameter, stratification thickness, and burial depth on crack initiation and failure degree. Verified by a city-gate-shaped tunnel numerical test and an practical engineering case of a large-scale underground tunnel in western China, the theoretical calculation results are in good agreement with the on-site failure morphology and numerical analysis results. The established separation criterion and mechanical model can effectively predict the initiation risk and stability critical conditions of vault strata. The research results can provide a theoretical basis and technical support for the stability evaluation, early warning, and optimal design of support structures of surrounding rock in underground engineering in gentle-dipping bedded rock masses. Full article

This paper investigates vibration suppression of finite-length cylindrical shells using linear locally resonant absorbers and nonlinear energy sinks (NESs). A theoretical model is first established for a finite-length locally resonant cylindrical shell equipped with periodically distributed linear cantilever-beam absorbers based on Flügge’s thin shell theory. By combining the modal superposition method and the harmonic balance method, analytical expressions for the vibration responses and average velocity levels of the cylindrical shell are derived. The theoretical model is validated by finite element simulations, and the locally resonant bandgap characteristics are further analyzed. Parametric studies are conducted to clarify the effects of absorber length, thickness, width, and distribution density on the bandgap position, bandgap width, and vibration attenuation performance. On this basis, nonlinear energy sinks are introduced as an additional broadband vibration suppression strategy and investigated through experiments and COMSOL transient simulations. The experimental results show that the NESs effectively suppress resonance peaks near the bandgap edges and improve broadband vibration attenuation. Furthermore, transient simulations under different excitation amplitudes demonstrate the excitation-amplitude-dependent response characteristics of the NESs, indicating enhanced nonlinear energy transfer under higher excitation levels. The results provide theoretical guidance for the design of finite-length locally resonant cylindrical shells and further verify the broadband vibration suppression capability of nonlinear energy sinks through experimental and numerical investigations. Full article

This paper presents and validates a unified spreadsheet-based framework for engineering mechanics education and preliminary design. Three modules are integrated within a single openly available workbook: multi-point resultant force and moment computation; axial normal stress with stress concentration effects for three geometric configurations (plate with hole, shoulder plate, stepped shaft); and beam deflection for simply supported and cantilever configurations under point loads. All governing equations are implemented as explicit closed-form expressions validated against analytical reference solutions for six independent cases; relative errors fall below ${10}^{-10}$ in all cases. Three worked exercises demonstrate the practical scope of the framework. A biomechanical multi-point force system yields joint moments of $-6880$, −33,421, and −58,241 N·mm at the wrist, elbow, and shoulder, respectively. A tensile shoulder plate with $K_t\approx 1.85$ produces ${\sigma }_{max}=232$ MPa against ${\sigma }_y=200$ MPa, identifying a design failure; a parametric redesign with fillet radius $r=10$ mm reduces $K_t$ to approximately 1.59 and ${\sigma }_{max}$ to approximately 198.7 MPa, restoring structural safety. A cantilever beam subjected to a 20,000 N tip load yields a maximum deflection of 13,133 μm. The framework constitutes a validated intermediate layer between manual analytical derivations and high-fidelity numerical simulations, applicable to preliminary design, parametric sensitivity studies, and engineering education at the linear elastic level. Full article

As the core sensor of inertial measurement units, the reliability of Micro-Electro-Mechanical Systems (MEMS) gyroscopes is critical for long-term navigation and motion control applications. To bridge the mechanism-data gap in MEMS multi-mechanism degradation modeling, this paper proposes a physics-informed dual-indicator reliability assessment framework based on Wiener processes. Two degradation indicators under consideration are frequency-related degradation caused by stiffness degradation and Q-factor degradation caused by damping degradation, for which corresponding physics-embedded stochastic degradation models are formulated. The two indicators are normalized and fused through a generalized weighted limit state function, where failure is defined as gyroscope-level performance failure. Closed-form reliability expressions are derived for linear limit states, while Monte Carlo simulation is used for nonlinear cases. Reduced-order multiphysics simulation cases, including a double-ended fixed beam and a cantilevered MEMS mass block, are used to demonstrate the mechanism-to-indicator-to-reliability modeling procedure. The results show that the proposed dual-indicator framework provides more balanced reliability assessment than single-indicator analysis under the simulation setting. The proposed method offers an alternative mechanism-informed approach for reliability analysis and lifetime prediction of other MEMS devices. Full article

Complex engineering optimization problems often exhibit high-dimensional, multi-constraint, and nonlinear characteristics. Traditional deterministic optimization methods rely on gradient information and have limited optimization ranges, making it difficult to meet the requirements of efficient and accurate solutions. Intelligent optimization algorithms have become the core means of solving such problems. Aiming at the limitations of the standard artificial lemming algorithm (ALA), such as insufficient population diversity, premature convergence, weak local exploitation ability, and slow convergence speed, which make it difficult to meet the requirements of solving complex engineering optimization problems, this paper proposes a reverse mutation for optimization learning artificial lemming algorithm (RMALA). Based on the ALA algorithm, the algorithm integrates three strategies: Cauchy mutation, the improved salp swarm algorithm (ISSA), and reverse mutation for optimization learning. The Cauchy mutation is used to maintain population diversity and avoid premature convergence of the algorithm. The improved salp swarm algorithm enhances the local exploitation ability of the algorithm and improves the optimization accuracy. Reverse mutation for optimization learning guides the population toward the global optimal solution region and accelerates the convergence speed. The significant experimental results show that in the CEC2017 and CEC2022 standard test sets, as well as the three classic engineering constrained optimization problems of welded beams, cantilever beams, and pressure vessels, RMALA’s optimization accuracy is improved by more than 30% compared to the original ALA, and its convergence speed is improved by more than 25%. Its stability and robustness are better than those of five new swarm intelligence algorithms proposed in recent years. It can efficiently solve complex high-dimensional, nonlinear constrained optimization problems and has high significant engineering application value and academic innovation. Full article

Brush seals, as a fundamental dynamic sealing technology in the aerospace and energy propulsion industries, require performance enhancement through instantaneous adjustment of the friction coefficient and force analysis of brush filaments. This paper establishes an instantaneous friction coefficient correction method based on the open volume between bristles and the backing plate. The downstream section of the double-row brush wire (2.6 mm) was quantitatively identified as the maximum leakage point, and it was found that the vortex characteristic length in the downstream area is approximately 1–3 times the bristle gap, with an increasing pressure ratio enhancing downstream turbulence and reducing gas leakage. A cantilever beam structural model was developed to assess the motion, force, and hysteresis properties of a single filament. Additionally, a porous medium model was utilized to elucidate the flow field and temperature distribution within the seal. The results suggest that the lag angle increases linearly over the first one-third of the brush wire’s length from the free end to the fixed end and is directly proportional to the pressure difference ΔP, reaching a maximum of 10.18°. The viscous drag causes the radial force y-component F_xy to increase and then decrease near the free end. The rear baffle contact force, F_b, shows variable peaks at two-thirds of the filament length. The displacement at the brush filament’s free end, the deflection angle, and the bending moment are directly proportional to the pressure differential. As pressure increases, the deformed region propagates toward the fixed end, and the maximum displacement at the free end of the brush wire reaches 13.04 mm. The leakage rate increases nearly linearly with ΔP and its deformation, reaching a maximum of 0.00849 m²/s. The pressure gradient growth rates of 164%, 73%, and 29% at the front baffle corner demonstrate that adding pressure chambers on front and rear baffles is optimal for high-pressure scenarios (ΔP > 0.3 MPa), while the formation of vortices between bristles and rotor reduces tip friction force and front-row turbulent disturbance, providing design guidance for extending seal service life. Full article

Polymer insulation layers such as polyimide (PI) have gradually replaced inorganic dielectric layers (SiO₂, SiCN) in the integrated packaging process of hybrid bonding (HB). PI can fill the gaps in the thermal compression bonding process and help to obtain a good Cu/Polymer bonding interface. At present, the existing post-crack double cantilever beam tensile test (PBC-DCB) has been successfully applied to the quantitative measurement of bonding strength of hybrid bonding with inorganic materials, but this method only considers elastic behavior. Since PI exhibits viscidity, elasticity and plasticity, knowing how to correlate these properties to the bonding process is challenging. Whether PBC-DCB is suitable for the characterization of PI bonding is unclear. This paper presents a comprehensive experimental and finite element analysis (FEA) study on the PI–PI bonding interface. Firstly, nanoindentation experiments and simulations are performed on the prepared PI interface to obtain key elasticity and plasticity parameters. Then, the bonding strength is characterized by the PBC-DCB test. Theoretical and experimental results show that the plasticity of PI causes energy dissipation during stretching, resulting in a deviation of approximately 2.51% compared with pure elasticity. Based on experimental data, the Cohesive Zone Model (CZM) FEA method is used to simulate the crack propagation. The results indicate that the Embedded Process Zone (EPZ) model can accurately describe crack initiation and delamination behavior, with a margin of error of about 3.61%. Finally, based on the EPZ CZM, defects such as bonding void and wafer warpage are further discussed in relation to bonding strength measurement. Full article

This paper presents a yarn tension sensor based on Surface Acoustic Waves (SAW). To enhance the detection accuracy of the sensor, an improved beam structure is designed for tension measurement, along with intelligent algorithms for temperature compensation. Firstly, regarding the sensor structure, a simply supported beam with a hyperbolic surface is designed to achieve stress concentration by reducing the section modulus at the beam’s midpoint. Secondly, by incorporating an unbalanced split-electrode Interdigital Transducer (IDT) design, the sensor effectively suppresses signal sidelobe interference and significantly improves the structure’s tension sensitivity. Finally, in terms of signal processing, to eliminate the influence of environmental temperature fluctuations on measurements, a temperature-compensation algorithm based on Bayesian Optimization Least Squares Support Vector Machine (BO-LSSVM) with Gaussian Process regression is proposed. Experimental results show that the tension sensitivity of the improved structure was 8.2% higher than that of the doubly clamped beam and 12.7% higher than that of the cantilever beam. For temperature compensation, the BO-LSSVM model reduced the Mean Relative Error (MRE) by 5.67 percentage points relative to raw data and by 2.04 percentage points relative to the fixed-parameter LSSVM model, lowering the temperature sensitivity coefficient from 4.09 $(\times {10}^{-3}/°\mathrm{C})$ to 0.41 $({10}^{-3}/°\mathrm{C})$. Full article

This paper presents a systematic application of the Homotopy Perturbation Method (HPM) to the nonlinear static analysis of cantilever beams subjected simultaneously to three coplanar follower loads: an axial force H, a transverse force V, and a bending moment M₁. The studied configuration introduces complex mathematical self-coupling, as the bending moment depends on the solution of the differential equation even in its boundary conditions (γ₁), transforming the problem into a nonlinear one that is resistant to standard analytical methods. The primary methodological contribution of this work is the successful extension of the HPM framework to treat, within a unified mathematical formalism, this complete loading case, which has practical applications in compliant mechanisms, micro-electromechanical systems (MEMSs), and auxetic structures. The paper provides a complete mathematical formulation and explicit derivation of the HPM solution terms up to the third order and a rigorous demonstration of the method’s convergence, with quantitative error estimates and the establishment of a practical domain of validity, γ₁ < 30°, for an accuracy below 0.5%. As a direct consequence of this analytical advancement, we derive a series of practical engineering tools: nomograms, simplified empirical formulas, interaction diagrams, and a systematic six-step design procedure, which includes an adaptive algorithm for selecting the auxiliary parameter η to optimize convergence. The solution’s structure also lends itself to AI-based optimization frameworks, demonstrating how HPM solutions can serve as a foundation for machine learning surrogates and automated multi-objective optimizations. HPM proves to be a robust and efficient alternative, providing semi-analytical solutions in the form of convergent series without requiring an explicitly small physical parameter. This enables a direct parametric understanding of the structural response and offers rapid tools for the conceptual and preliminary sizing phases, thereby complementing the intensive numerical methods used in the final design stages. Full article

China’s roof-cutting and pressure relief gob-side entry retaining (RCPR-GER) technology provides an efficient non-pillar mining solution that significantly enhances coal recovery. This paper presents a systematic review of the technological progress in Chinese coal mines from 2011 to 2023, based on an analysis of 1038 publications from CNKI, EI, and Web of Science using VOS viewer and Origin software. Four main technical approaches are examined: gob-side entry retaining without roadside filling, with roadside filling, with roof-cutting and pressure relief, and hybrid methods. Five key roof-cutting techniques are evaluated: dense drilling, high-pressure water-jet slotting, hydraulic fracturing, blasting, presplitting, and roof water injection softening. Successful applications have been documented in coal seams with thicknesses of 1.6–6.15 m and burial depths of 92–1037 m, demonstrating wide adaptability. The roof-cutting short-beam theory underpins the mechanism, which reduces roadway deformation, shortens the cantilever beam length, and alters stress transfer paths. Compared to previous reviews on general gob-side entry retaining, this study offers a dedicated synthesis and comparative analysis of RCPR-GER technologies, establishing a selection framework grounded in geological compatibility and engineering practice. Future research should focus on adaptive parameter design for deep hard composite roofs, quantitative modeling of passive roof-cutting effects, optimization of cutting timing and orientation, and floor-heave control technologies to extend applications under complex geological conditions. Full article

The paper deals with the design of a Digital Twin model of an energy harvesting cantilever beam for low frequency energy harvesting applications and specifically with a digital model matching simulations corresponding with Finite Element Method solutions in order to validate the model. The physical behavior is based on the main parameters to be investigated. The finite elements analysis is geometrically and parametrically carried out for a small PZT5A device of the orders of millimeters and is optimized to take into consideration the relationships between tip displacement, generated voltages and vibration gravitational forces for standard industrial applications in the acceleration range between 0.5 and 2 g. Then a procedure to integrate the Digital Twin into a design framework has been developed, including an artificial intelligence algorithm that supports the modelling of the real behavior of the device. The paper is devoted to help researchers involved in a Digital Twin adoption in the field of electronic design and of the physical characterization of low frequency energy harvesting devices exclusively using open-source tools. Full article

Fretting wear due to flow-induced vibration (FIV) remains a primary cause of fuel failure in light water nuclear reactors. In the study of axial FIV, i.e., FIV caused by axial flows, three vibration characteristics, namely natural frequency, damping ratio, and root-mean-square (RMS) amplitude, are critical for mitigating fretting wear by avoiding resonance, maximising overdamping, and preventing large-amplitude instability motion, respectively. This paper presents a set of best practices for simulating axial FIV with a focus on predicting these parameters based on a URANS-FSI numerical framework, utilising high-Reynolds-number Unsteady Reynolds-Averaged Navier–Stokes (URANS) turbulence modelling and two-way fluid–structure interaction (FSI) coupling. This strategy enables accurate and efficient prediction of vibration parameters and offers promising scalability for full-scale nuclear fuel assembly applications. Validation is performed against a semi-empirical model to predict RMS amplitude and experimental benchmarking. The validation experiments involve two setups: vibration of a square beam with fixed and roller-supported ends in annular flow tested at Vattenfall AB, and self-excited vibration of a cantilever beam in annular flow tested at the University of Manchester. The study recommends best practices for numerical schemes, mesh strategies, and convergence criteria, tailored to improve the accuracy and efficiency for each validated parameter. Full article

To address the issue of low efficiency in recovering low-frequency vibration energy during vehicle operation, this paper proposes a piezoelectric energy capture harvester based on wheel vibration. The device employs a parallel configuration of dual cantilever beam piezoelectric transducers in its mechanical structure, with additional mass blocks to optimize its resonant characteristics in the low-frequency range. A synchronous switch energy harvesting circuit was designed. By actively synchronizing the switch with the peak output voltage of the piezoelectric element, it effectively circumvents the turn-on voltage threshold limitations of diodes in bridge rectifier circuits, thereby enhancing energy conversion efficiency. A dynamic model of this device was established, and multiphysics simulation analysis was conducted using COMSOL-Multiphysics to investigate the modal characteristics, stress distribution, and output performance of the energy harvester. This revealed the influence of the piezoelectric vibrator’s thickness ratio and the mass block’s weight on its power generation capabilities. Experimental results indicate that under 20 Hz, 12 V sinusoidal excitation, the system achieves an average output power of 3.019 mW with an average open-circuit voltage reaching 16.70 V. Under simulated road test conditions at 70 km/h, the output voltage remained stable at 6.86 V, validating its feasibility in real-world applications. This study presents an efficient and reliable solution for self-powering in-vehicle wireless sensors and low-power electronic devices through mechatronic co-design. Full article

Piezoelectric actuators are devices that convert electrical energy into mechanical energy. One of the applied structures of such actuators is a cantilever beam, which is composed of a nonpiezoelectric carrier layer and one or more piezoelectric active layers. The twisting motion of such a beam can be generated by using a double-bimorph structure, in which the beam twisting can be generated by the appropriate control of each of the two bimorphs. However, obtaining the desired twist angle requires the displacements of both bimorphs to be measured. The need to measure these displacements significantly limits the applicability of this type of actuator for generating twisting motions, because the size of the displacement sensors and their mounting components, which can significantly exceed the size of the beam actuator itself, means that a large space is needed to implement the twist angle measurement system. It is, therefore, necessary to develop techniques for controlling such an actuator based on a mathematical model. In this paper, a vision method was proposed to verify the mathematical model of a double-bimorph actuator. The results of these experiments can be used to synthesize a control system of the twist angle of the double-bimorph actuator without the need for displacement measurements of both bimorphs. Full article
