Search Results (14)

This study investigated the squeal noise characteristics of the in-plane mode of the disc in a disc brake system as influenced by the temperature of the brake pad. The temperature range of the brake pad was set between 50 °C and 300 °C, and the squeal noise was analyzed by calculating the complex eigenvalues using the finite element method (FEM). The FEM analysis indicated that instability was most sensitive near 80 °C, and it was observed that instability exhibited mode exchange from the disc’s in-plane mode to the out-of-plane mode in a nearby frequency band due to thermal deformation of the pad. A reproduction test was conducted using a brake dynamometer, where the main squeal noise was found to be approximately 10,000 Hz, consistent with the FEM analysis. Additionally, the squeal noise occurred most near 100 °C, and the noise disappeared after 250 °C. These results largely align with the FEM analysis model, validating the suitability of the analysis approach. Full article

In this paper, the stability of the split doublet mode pair in a disc brake squeal is analytically investigated. A reduced-order doublet mode model is derived based on the formulation of annular plate vibration, sliding contact kinematics, and the assumed mode method. The solution is approximated using a two-mode expansion for the doublet mode pair. The time-varying motion of the slightly asymmetric rotating disc is described through the moving mode shape function method. A stability analysis of the frequency split between the doublet mode pair is performed by calculating the characteristic multipliers using the Floquet theory. The stability boundary is determined within the domain of frequency split variations and other parameters. Finally, the influence of mode splitting on the squeal behaviour of the asymmetric disc is analysed and discussed. Full article

In various applications, dry friction could induce vibrations. A well-known example is frictional braking systems in ground transportation vehicles involving a sliding contact between a rotating and a stationary part. In such scenarios, the emission of high-intensity noise, commonly known as squeal, can present human health risks based on the noise’s intensity, frequency, and occurrences. Despite the importance of squeal in the context of advancing urbanization, the parameters determining its occurrence remain uncertain due to the complexity of the involved phenomena. This study aims to identify a relevant operando indicator for predicting squeal occurrences. To this end, a pin-on-disc test rig was developed to replicate various contact conditions found in road profiles and investigate resulting squealing. Each test involves a multimodal instrumentation, complemented by surface observations. It is illustrated that the enhanced thermal indicator identified is relevant because it is sensitive to the thermomechanical and tribological phenomena involved in squealing. Full article

Brake squeal—an audible high-frequency noise phenomenon in the range between 1 kHz and 15 kHz resulting from self-excited vibrations—is one of the main cost drivers while developing brake systems. Increasing damping is often a crucial factor in the context of self-excited vibrations. Countermeasures applied for preventing brake squeal have been investigated particularly for disk brakes in the past. However, in recent years, drum brakes have once again become more important, partly because of the issue of particle emissions. Concerning noise problems, drum brakes have a decisive advantage compared to disk brake systems in that the outer drum surface is freely accessible for applying damping devices. This paper focuses on the fundamental proving and evaluation of passive damping measures on a simplex drum brake system. To obtain a detailed understanding of the influence of additional damping on the squealing behavior of drum brakes, extensive experimental investigations are performed on a brake with an intentionally introduced high squealing tendency in the initial configuration. This made it possible to investigate the influence of different types of damping measures on their effectiveness. Techniques from the field of big data analysis and machine learning are tested to detect squeal in measured time series data. These techniques were remarkably reliable and made it possible to detect squeal efficiently even in data that was not generated on a traditional costly NVH brake dynamometer. To investigate whether the simulation method usually used for the simulation of brake squeal is applicable to depicting the influence of additional damping in drum brakes, a complex eigenvalue analysis was performed with Abaqus, and the results were compared with those from the experiments. Full article

This study examined the dynamic instability of a drum brake induced by the rigid modes of the brake shoe. The brake shoe was modeled as a rigid curved plate subject to frictional contact with a rotating drum. In the presence of a negatively sloped friction curve, dynamic instability was numerically analyzed with respect to variation in the system parameters. The results showed that mode-coupling instability did not occur, but dynamic instability was induced by negative damping in a specific rigid mode, and its propensity varied with the operating conditions and geometric changes. Full article

Radiated noise is a major topic of interest regarding the brake squeal phenomenon as it is directly linked to the noise generated which can be potentially detrimental to user comfort and perception. However, very few studies offer in-depth and comprehensive insight into the analysis and understanding of acoustic noise during squeal events. This study is intended to provide an original contribution to this issue by investigating acoustic phenomena occurring during the squeal phenomenon via a digital antenna composed of 117 microphones. Experiments are performed on the Friction-Induced Vibration and noisE test bench at Ecole Centrale de Lyon (FIVE@ECL). The first main aim is to investigate the characteristics of the acoustic radiated field during brake squeal and more particularly to describe the evolution of the radiated field patterns per revolution of the disc system. The second major aim is to illustrate the possibility of reconstructing the radiated acoustic field everywhere in the space surrounding the brake system, leading to the construction of a robust representation of 3D acoustic patterns, providing acoustic squeal events in the physical space around the brake system. Results show that the vibratory signature remains identical during squeal event braking test. The acoustic signature of squeal noise consists mainly of a fundamental frequency and its harmonic components, with secondary lower contributions from other fundamental frequencies. The associated radiated acoustic field during squeal events are characterized by different directivities and intensities of the acoustic radiated field for each squeal frequency, with potential changes in these directivities and intensities over short times corresponding to the rotation period of the disc. Full article

Brake noise is a problem that is still being studied owing to continuous issues in the vehicle industry, and many countermeasures have been suggested using experimental and simulation approaches. The assembled brake system comprises several subparts, and a contribution analysis is an efficient solution for selecting the subpart with the most influence on squealing. In this study, a finite-element model of the assembled brake system was verified with modal test results for each part. Then, a forced response analysis of the assembled brake system model was conducted to obtain the spectral response vector of the subparts under white-noise excitation. A contribution analysis was formulated by calculating the similarity between the total and partial response vectors of each part and deriving the contribution index of all subparts of interest. The brake pad was selected as the target of design modification, and the feasibility was validated using an experimental chassis dynamometer test. Full article

Friction induced vibrations such as brake squealing, or juddering are still challenging topics in product engineering processes. So far, this topic was particularly relevant for the automobile industry because they were the main market for disc brake systems. However, since mobility habits change, disc brake system are more often to be found on bikes or e-scooters. In all of these systems, vibrations are excited in contacts on the micro scale but affect the user comfort and safety on the macro scale. Therefore, the aim of this cross-scale method is to analyze a system on a micro scale and to transfer the excitation mechanisms on a macro scale system. To address both scales, the current work presents a finite element model on the micro scale for the determination of the coefficient of friction, which is transferred to the macro scale and used in a multi-body simulation. Finally, a finite element modal analysis is conducted, which allowed us to evaluate the brake system behavior on base of an excitation. Full article

The connection of two phenomena, nonconservative friction forces and dissipation-induced instability, can lead to many interesting engineering problems. We study the general material-dependent damping influence on the dynamic instability of disc brake systems leading to brake squeal. The effect of general damping is demonstrated on minimal and complex models of a disc brake. Experimental analyses through the frequency response function (FRF) show different damping of the brake system coalescent modes, indicating possible dissipation-induced instability. A complex system including material-dependent damping is defined in commercial finite element (FE) software. A FE model validated by experimental data on the brake-disc test bench is used to compute the influence of a pad and disc damping variations on the system stability using complexe igenvalue analysis (CEVA). Numerical analyses show a significant sensitivity of the experimentally verified unstable mode of the system to the ratio of the damping between the disc and the friction material components. Full article

This paper is devoted to discussion of the efficiency of reduced models based on a Double Modal Synthesis method that combines a classical modal reduction and a condensation at the frictional interfaces by computing a reduced complex mode basis, for the prediction of squeal noise of mechanical systems subjected to friction-induced vibration. More specifically, the use of the multiresolution signal decomposition of acoustic radiation and wavelet representation will be proposed to analyze details of a pattern on different observation scales ranging from the pixel to the size of the complete acoustic pattern. Based on this approach and the definition of specific resulting criteria, it is possible to quantify the differences in the representation of the acoustic fields for different reduced models and thus to perform convergence studies for different scales of representation in order to evaluate the potential of reduced models. The effectiveness of the proposed approach is tested on the finite element model of a simplified brake system that is composed of a disc and two pads. The contact is modeled by introducing contact elements at the two friction interfaces with the classical Coulomb law and a constant friction coefficient. It is demonstrated that the new proposed criteria, based on multiresolution signal decomposition, allow us to provide satisfactory results for the choice of an efficient reduced model for predicting acoustic radiation due to squeal noise. Full article

Friction-induced vibrations (brake squeal) produced during braking applications have been one of the major problems in the transportation for many years. It can be the most troublesome for passengers because of its high frequency and acoustic pressure. The role of frictional contact surface geometry on the occurrence of squeal was investigated recently by some researchers. However, it has never been systematically studied at different scales simultaneously. Contact localizations are induced on the one hand by macro effects such as thermal dilatation (macroscopic scale) and on the other hand, by the heterogeneity of third body (tribolayer) generated by friction (mesoscopic scale). The aim of this paper is to investigate the effect of contact localization at both scales through stability analysis on a simplified pad on disc system. The model has been developed numerically by the finite element method (FEM) to introduce a non-uniform contact at macroscopic and mesoscopic scales. The results showed a strong dependency between squeal frequencies and effective contact zone at macroscopic and mesoscopic scales for the investigated configuration. Especially, it is found that squeal frequencies depend on the contact area at a macroscopic scale whereas the probability of occurrence of squeal frequency strongly relies on mesoscopic contact distribution. Full article

The modeling of contact is one of the main features of contact dynamics in the context of friction-induced vibrations. It can have a strong impact on the numerical results and consequently on the design choices during the optimization or specification of industrial mechanical systems. This is particularly the case for scientific studies interested in brake squeal. The objective of the paper is to recall and to promote developments concerning the use of non smooth contact dynamics approach for numerical simulations based on finite element method. The specific problem of the prediction of self-excited vibration in the context of brake squeal is discussed. In order to illustrate the potential benefit for the mechanical community of using formulations and theoretical developments from the mathematical community, the stability analysis and the estimation of nonlinear vibrations of a brake system with multiple frictional interface is investigated. Full article

In brake systems, some dynamic phenomena can worsen the performance (e.g., fading, hot banding), but a major part of the research concerns phenomena which reduce driving comfort (e.g., squeal, judder, or creep groan). These dynamic phenomena are caused by specific instabilities that lead to self-excited oscillations. In practice, these instabilities can be investigated using the Complex Eigenvalues Analysis (CEA), in which positive real parts of the eigenvalues are identified to characterize instable regions. Measurements on real brake test benches or tribometers show that the coefficient of friction (COF), $\mu$ , is not a constant, but dynamic, system variable. In order to consider this aspect, the Method of Augmented Dimensioning (MAD) has been introduced and implemented, which couples the mechanical degrees of freedom of the brake system with the degrees of freedom of the friction dynamics. In addition to this, instability prediction techniques can often determine whether a system is stable or instable, but cannot eliminate the instability phenomena on a real brake system. To address this, the current work deals with the quantification of the relevant polymorphic uncertainty of the friction dynamics, wherein the aleatory and epistemic uncertainties are described simultaneously. Aleatory uncertainty is concerned with the stochastic variability of the friction dynamics and incorporated with probabilistic methods (e.g., a Monte Carlo simulation), while the epistemic uncertainty resulting from model uncertainties is modeled via fuzzy methods. The existing measurement data are collected and processed through Data Driven Methods (DDM) for the identification of the dynamic friction models and corresponding parameters. Total Variation Regularization is used for the evaluation of derivatives within noisy data. Using an established minimal model for brake squealing, this paper addresses the question of probabilities for instabilities and the degree of certainty with which this conclusion can be made. The focus is on a comparison between the conventional Coulomb friction model and a dynamic friction model in combination with the MAD. This shows that the quality of the predictive accuracy improves dramatically with the more precise friction model. Full article

In the research into the mechanism of brake squeal, minimal models with two degrees of freedom (DoFs) are widely used. Compared with the finite element method, the minimal model is more concise and efficient, making it easier to analyze the effect of parameters. However, how to accurately determine its kinetic parameters is rarely reported in the literature. In this paper, firstly, the finite element model of a disc brake is established and the complex eigenvalue analysis (CEA) is carried out to obtain unstable modes of the brake. Then, an unstable mode with seven nodal diameters predicted by CEA is taken as an example to establish the 2-DoF model. In order that the natural frequency, Hopf bifurcation point and real parts of eigenvalues of the minimal model coincide with that of the unstable mode with seven nodal diameters, the response surface method (RSM) is applied to determine the kinetic parameters of the minimal model. Finally, the parameter-optimized minimal model is achieved. Furthermore, the negative slope of friction-velocity characteristic is introduced into the model, and transient analysis (TA) is used to study the effect of braking velocity on stability of the brake system. The results show that the brake system becomes unstable when braking velocity is lower than a critical value. The lower the velocity is, the worse the stability appears, and the higher the brake squeal propensity is. Full article
