Bridges play a key and controlling role in transportation systems. Steel bridges are favored for their high strength, good seismic performance, and convenient construction. As important node connectors of steel bridges, high-strength bolts are extremely susceptible to damage such as corrosion and loosening. Therefore, accurate identification of bolt loosening is crucial. First, a new type of adhesive piezoelectric sensor is designed and prepared using PMN-PT piezoelectric single-crystal materials. The PMN-PT sensor and polyvinylidene fluoride (PVDF) sensor are subjected to steel plate fixed frequency load and swept frequency load tests to test the performance of the two sensors. Then, a steel plate component connected by high-strength bolts is designed. By applying exciter square wave load to the structure, the vibration response characteristics of the structure are analyzed to identify the loosening of the bolts. In addition, a piezoelectric smart washer sensor is designed to make up for the shortcomings of the adhesive piezoelectric sensor, and the effectiveness of the piezoelectric smart washer sensor is verified. Finally, a bolt loosening index is proposed to quantitatively evaluate the looseness of the bolt. The results show that the sensitivity of the PMN-PT sensor is 21 times that of the PVDF sensor. Compared with the peak stress change, the natural frequency change is used to identify the bolt loosening more effectively. Piezoelectric smart washer sensor and bolt loosening indicator can be used for bolt loosening identification. Full article

Bolted joints, prevalent in industrial applications for component fastening, are susceptible to self-loosening—a critical issue resulting in a gradual reduction in clamping force. Gaining insight into the underlying mechanisms of self-loosening is crucial. While prior research has largely focused on evaluating component stiffness, limited attention has been given to its impact on the self-loosening behavior of bolted joints under transverse cyclic loading. This study investigates how component stiffness influences self-loosening in bolted joints by varying the material and thickness of clamped members. An experimental setup replicating real-world conditions is devised to simulate loosening caused by cyclic lateral displacement. Tests are conducted using steel and high-density polyethylene (HDPE) clamped members of different grip lengths to explore the relationship between stiffness and self-loosening. Key parameters measured include bolt axial load, transverse force on clamped members, relative displacement, and rotation between the bolt and nut. The findings provide valuable insights into the effects of stiffness across various clamped member materials and grip length combinations, which can enhance the understanding of conditions that promote loosening resistance. Moreover, by highlighting stage-II or rotational loosening, with each test resulting in complete preload loss, the study provides a comparative analysis of the influencing factors. This enables the identification of distinct loosening patterns and supports the development of improved bolted joint designs to reduce loosening. Full article

Steel bridges often experience bolt loosening and even fatigue fracture due to fatigue load, forced vibration, and other factors during operation, affecting structural safety. This study proposes a high-precision bolt key point positioning and recognition method based on deep learning to address the high cost, low efficiency, and poor safety of current bolt loosening identification methods. Additionally, a bolt loosening angle recognition method is proposed based on digital image processing technology. Using image recognition data, the angle-preload curve is revised. The established correlation between loosening angle and pretension for commonly utilized high-strength bolts provides a benchmark for identifying loosening angles. This finding lays a theoretical foundation for defining effective detection intervals in future bolt loosening recognition systems. Consequently, it enhances the system’s ability to deliver timely warnings, facilitating swift manual inspections and repairs. Full article

Strong impacts and vibrations exist in various structures of rice combine harvesters in harvesting, so the bolt connection structure on the harvesters is prone to loosening and failure, which would further affect the service life and working efficiency of the working device and structure. In this paper, based on the vibration signal acquisition experiment on the bolt and connection structure of the vibrating screen on the harvester, failure feature identification is studied. According to the sensitivity analysis results and the primary extraction of the time-frequency feature, most features have limitations on the identification of failure features of vibrating screen bolts. Therefore, based on the establishment of a high-dimensional feature matrix and multivariate fusion feature matrix, the validity of the feature set was verified based on the whale optimization algorithm. And then, based on the SVM method and high-dimensional mapping of the kernel functions, the high-dimensional feature matrix is trained by the LIBSVM classification decision model. The identify success rates of time domain feature matrix A, frequency domain feature matrix B, WOA-VMD energy entropy matrix C, and normalized multivariate fusion feature matrix G are 64.44%, 74.44%, 81.11%, and more than 90%, respectively, which can reflect the applicability of the failure state identification of the normalized multivariate fusion feature matrix. This paper provided a theoretical basis for the identification of a harvester bolt failure feature. Full article

In the field of bolt loosening detection, although some progress has been made, there are still challenges such as high operational complexity, single feature extraction methods, and insufficient analysis model performance, especially in large steel truss structures, where there is a lack of efficient and accurate bolt loosening identification solutions. In response to these shortcomings, this article proposes an innovative bolt loosening damage recognition method based on sound signals. This method integrates feature extraction techniques of Mel frequency cepstral coefficients (MFCCs) and wavelet packet energy spectra (WPES), and comprehensively characterizes sound signals by constructing MFCC-WPES combined features. Subsequently, the random forest (RF) algorithm optimized by genetic algorithm was used for feature selection and model training, aiming to improve recognition accuracy and robustness. The experimental results show that this method can not only accurately identify bolt loosening signals in steel truss structure bolt loosening detection, but also has strong identification ability for environmental noise. Compared with traditional methods, the proposed solution in this article shows significant improvements in both performance and practicality, providing a new perspective and solution for the technological advancement of bolt loosening detection in steel truss structures. Full article

In this paper, a new image-correction method for flange joint bolts is proposed. A checkerboard is arranged on the side of a flange node bolt, and the homography matrix can be estimated using more than four feature points, which include the checkerboard corner points. Then, the perspective distortion of the captured image and the deviation of the camera position angle are corrected using the estimated homography matrix. Due to the use of more feature points, the stability of homography matrix identification is effectively improved. Simultaneously, the influence of the number of feature points, camera lens distance, and light intensities are analyzed. Finally, based on a bolt image taken using an iPhone 12, the prototype structure of the flange joint in the laboratory is verified. The results show that the proposed method can effectively correct image distortion and camera position angle deviation. The use of more than four correction points not only effectively improves the stability of bolt image correction but also improves the stability and accuracy of bolt-loosening detection. The analysis of influencing factors shows that the proposed method is still effective when the number of checkerboard correction points is reduced to nine, and the average error of the bolt-loosening detection result is less than 1.5 degrees. Moreover, the recommended camera shooting distance range is 20 cm to 60 cm, and the method exhibits low sensitivity to light intensity. Full article

Under external load excitation, damage such as breathing cracks and bolt loosening will cause structural time domain acceleration to have nonlinear features. To solve the problem of time domain nonlinear damage identification, a damage identification method based on the Kullback–Leibler (KL) distance of time domain model residuals is proposed in this paper. First, an autoregressive (AR) model order was selected using the autocorrelation function (ACF) and Akaike information criterion (AIC). Then, an AR model was obtained based on the structural acceleration response time series, and the AR model residual was extracted. Finally, the KL distance was used as a damage indicator to judge the structural damage source location. The effectiveness of the proposed method was verified by using a multi-story, multi-span stand model experiment and a simulated eight-story shear structure. The results show that the proposed structural nonlinear damage identification method can effectively distinguish the structural damage location of multi-degree-of-freedom shear structures and complex stand structures, and it is robust enough to detect environmental noise and small damage. Full article

The condition of an offshore wind turbine (OWT) should be monitored to assure its reliability against various environmental loads and affections. The modal parameters of the OWT can be used as an indicator of its condition. This paper combines the Kalman filter, the random decrement technique (RDT), and the stochastic subspace identification (SSI) methods and proposes an RDT-SSI method to estimate the operational frequency of an OWT subjected to ambient excitation. This method imposes no requirement on the input/loads; therefore, it is relatively easy for field application. An experimental study with a small-scale OWT was conducted to verify the accuracy of the proposed RDT-SSI method. The test results implied that the frequency estimated by the RDT-SSI method is close to that estimated by an impact hammer test. Moreover, the small-scale OWT was buried at different embedment depths to simulate the influence of the scouring phenomenon, and the frequency of the OWT decreased with decreasing embedment depth. Additionally, the bolts at the root of the turbine blades were also loosened to investigate their influence on the frequency. As more blades were loosened, the identified frequency of the OWT also decreased, indicating that the proposed RDT-SSI method can be employed for the health monitoring of an OWT. Full article

A high-strength bolt connection is the key component of large-scale steel structures. Bolt loosening and preload loss during operation can reduce the load-carrying capacity, safety, and durability of the structures. In order to detect loosening damage in multi-bolt connections of large-scale civil engineering structures, we proposed a multi-bolt loosening identification method based on time-frequency diagrams and a convolutional neural network (CNN) using vi-bro-acoustic modulation (VAM) signals. Continuous wavelet transform was employed to obtain the time-frequency diagrams of VAM signals as the features. Afterward, the CNN model was trained to identify the multi-bolt loosening conditions from the raw time-frequency diagrams intelligently. It helps to get rid of the dependence on traditional manual selection of simplex and ineffective damage index and to eliminate the influence of operational noise of structures on the identification accuracy. A laboratory test was carried out on bolted connection specimens with four high-strength bolts of different degrees of loosening. The effects of different excitations, CNN models, and dataset sizes were investigated. We found that the ResNet-50 CNN model taking time-frequency diagrams of the hammer excited VAM signals, as the input had better performance in identifying the loosened bolts with various degrees of loosening at different positions. The results indicate that the proposed multi-bolt loosening identification method based on VAM and ResNet-50 CNN can identify bolt loosening with a reasonable accuracy, computational efficiency, and robustness. Full article

This paper designed a bolt-loosening Support Vector Machines’ conduct detection method with feature vectors comprising eigenvalue decomposition based on Variational Modal Decomposition (VMD) and Singular Value Decomposition (SVD), combined with permutation entropy. Particle Swarm Optimization-Support Vector Machines (PSO-SVMs) are used for small-sample machine learning and can effectively identify and judge the state of bolt preload. The effectiveness of the proposed method is verified in a typical example of a connection structure under random-amplitude impulse loads and Gaussian white noise with different signal-to-noise ratios. The effect of other bolt numbers being arranged is also discussed in the results. This method’s bolt-loosening identification rate is close to 90% under both equal-amplitude and variable-amplitude loads. Following the interference, with a signal-to-noise ratio of 20 dB, the method also has a recognition rate higher than 70% under various working conditions and bolt equipment schemes. The effectiveness of the method was verified by experiments. Full article

Vibration signals from centrifugal pumps are nonlinear, non-smooth, and possess implied trend terms, which makes it difficult for traditional signal processing methods to accurately extract their fault characteristics and details. With a view to rectifying this, we introduced empirical mode decomposition (EMD) to extract the trend term signals. These were then refit using the least squares (LS) method. The result (EMD-LS) was then combined with multi-fractal theory to form a new signal identification method (EMD-LS-MFDFA), whose accuracy was verified with a binomial multi-fractal sequence (BMS). Then, based on the centrifugal pump test platform, the vibration signals of shell failures under different degrees of cavitation and separate states of loosened foot bolts were collected. The signals’ multi-fractal spectra parameters were analyzed using the EMD-LS-MFDFA method, from which five spectral parameters ($\Delta \alpha$, $\Delta f$, ${\alpha }_0$, ${\alpha }_{\max }$, and ${\alpha }_{\min }$) were extracted for comparison and analysis. The results showed EMD-LS-MFDFA’s performance was closer to the BMS theoretical value than that of MFDFA, displayed high accuracy, and was fully capable of revealing the multiple fractal characteristics of the centrifugal pump fault vibration signal. Additionally, the mean values of the five types of multi-fractal spectral characteristic parameters it extracted were much greater than the normal state values. This indicates that the parameters could effectively distinguish the normal state and fault state of the centrifugal pump. Moreover, ${\alpha }_0$ and ${\alpha }_{\max }$ had a smaller mean square than $\Delta \alpha$, $\Delta f$ and ${\alpha }_{\min }$, and their stability was higher. Thus, compared to the feature parameters extracted by MFDFA, our method could better realize the separation between the normal state, cavitation (whether slight, moderate, or severe), and when the anchor bolt was loose. This can be used to characterize centrifugal pump failure, quantify and characterize a pump’s different working states, and provide a meaningful reference for the diagnosis and study of pump faults. Full article

Since artificial intelligence (AI) was introduced into engineering fields, it has made many breakthroughs. Machine learning (ML) algorithms have been very commonly used in structural health monitoring (SHM) systems in the last decade. In this study, a vibration-based early stage of bolt loosening detection and identification technique is proposed using ML algorithms, for a motor fastened with four bolts (M8 × 1.5) to a stationary support. First, several cases with fastened and loosened bolts were established, and the motor was operated in three different types of working condition (800 rpm, 1000 rpm, and 1200 rpm), in order to obtain enough vibration data. Second, for feature extraction of the dataset, the short-time Fourier transform (STFT) method was performed. Third, different types of classifier of ML were trained, and a new test dataset was applied to evaluate the performance of the classifiers. Finally, the classifier with the greatest accuracy was identified. The test results showed that the capability of the classifier was satisfactory for detecting bolt loosening and identifying which bolt or bolts started to lose their preload in each working condition. The identified classifier will be implemented for online monitoring of the early stage of bolt loosening of a multi-bolt structure in future works. Full article

Bolted connections are widely used in timber structures. Bolt looseness is one of the most important factors leading to structural failure. At present, most of the detection methods for bolt looseness do not achieve a good balance between cost and accuracy. In this paper, the detection method of small angle of bolt loosening in a timber structure is studied using deep learning and machine vision technology. Firstly, three schemes are designed, and the recognition targets are the nut’s own specification number, rectangular mark, and circular mark, respectively. The Single Shot MultiBox Detector (SSD) algorithm is adopted to train the image datasets. The scheme with the smallest identification angle error is the one identifying round objects, of which the identification angle error is 0.38°. Then, the identification accuracy was further improved, and the minimum recognition angle reached 1°. Finally, the looseness in a four-bolted connection and an eight-bolted connection are tested, confirming the feasibility of this method when applied on multi-bolted connection, and realizing a low operating costing and high accuracy. Full article

Pre-stressed bolted joints are widely used in civil structures and industries. The tightening force of a bolt is crucial to the reliability of the joint connection. Loosening or over-tightening of a bolt may lead to connectors slipping or bolt strength failure, which are both harmful to the main structure. In most practical cases it is extremely difficult, even impossible, to install the bolts to ensure there is a precise tension force during the construction phase. Furthermore, it is inevitable that the bolts will loosen due to long-term usage under high stress. The identification of bolt tension is therefore of great significance for monitoring the health of existing structures. This paper reviews state-of-the-art research on bolt tightening force measurement and loosening detection, including fundamental theories, algorithms, experimental set-ups, and practical applications. In general, methods based on the acoustoelastic principle are capable of calculating the value of bolt axial stress if both the time of incident wave and reflected wave can be clearly recognized. The relevant commercial instrument has been developed and its algorithm will be briefly introduced. Methods based on contact dynamic phenomena such as wave energy attenuation, high-order harmonics, sidebands, and impedance, are able to correlate interface stiffness and the clamping force of bolted joints with respective dynamic indicators. Therefore, they are able to detect or quantify bolt tightness. The related technologies will be reviewed in detail. Potential challenges and research trends will also be discussed. Full article
