Search Results (28)

This study investigates the response of laterally loaded pile foundations embedded in sloping beds under scour conditions, which is vital for the design and stability of coastal and offshore infrastructure like sea-crossing bridges, offshore wind turbines, and wharves. While previous studies have focused on scour-affected pile performance in horizontal beds, this research expands the scope by incorporating sloped beds and corresponding scour effect, which are common in coastal and offshore environments. A three-dimensional finite element model was established to evaluate the pile foundation’s lateral load-bearing capacity under different slope and scour conditions, according to preceding flume tests on the mechanism of local scour around a pile in sloping bed. The results indicate that the lateral response of the pile is significantly influenced by the seabed slope and scour depth. A negatively inclined seabed weakens the interaction between the pile and the surrounding sediment, thereby reducing the lateral bearing capacity and bending moment. As the scour depth increases, the support provided by the soil further weakens, intensifying the reduction in lateral resistance. This effect is particularly pronounced for steep negative slopes, where the combined impact of slope and scour has a more significant detrimental effect. Full article

The monopile foundation is a popular foundation type for offshore wind turbines; due to the harsh marine environment, there are lateral loads applied on the monopile foundation from winds and currents, and scouring also often occurs around the pile, reducing the bearing capacity and impacting the normal operation of offshore wind turbines. A series of 1 g model tests is conducted to investigate the lateral load response and scouring response of the monopile in sand. Based on the experimental results, the characteristics of the pile’s load-displacement curves, bending moments, and p-y curves under the effects of scour were analyzed. Particle Image Velocimetry technology was adopted to analyze the deformation development rules of soil particles around the pile. It is found that under the same lateral load, the maximum bending moment of the pile increases and the bearing capacity is reduced as the scour depth increases, the scour width increases, or the scour slope decreases. The effects of scour depth, slope, and width on pile bearing stability decrease successively. Soil displacements and strains in the passive zone in front of the pile develop gradually in both radial and vertical directions. Full article

In recent years, the frequent collapse of bridges has underscored the severe threats posed by ship collisions and seismic forces to bridge pile foundations, particularly under scour conditions. Scour significantly increases bending moments, weakens foundation stability, and exacerbates damage under ship impacts and seismic loading. This review systematically examines the dynamic responses of bridge pile foundations subjected to multi-hazard scenarios, focusing on how scour-induced degradation exacerbates the impacts of ship collisions and seismic events. The synthesis covers experimental studies, numerical simulations, and theoretical approaches, providing a comprehensive evaluation of methodologies and findings. Advanced bibliometric tools, such as CiteSpace and VOSviewer, are employed to identify research trends, hotspots, and collaborations in this domain. Additionally, the review highlights the integration of intelligent technologies for mitigating ship collision risks and improving bridge safety management in scour-prone environments. By consolidating existing knowledge, this paper can serve as a critical reference for understanding the compounded effects of scour and other hazards on bridge pile foundations, offering guidance for future research and engineering practices. Full article

To address the problem of concave bank scour in a 120° bend river, this study designed and explored the bank protection effect of different arrangements of semi-cylinder sandbags. Based on the actual riverbed structure, a simplified geometric model of the bend riverbed was constructed, and the bank protection effect of sandbags arranged at different angles and spacings under different flow conditions was evaluated by using a multi-objective genetic algorithm (MOGA). The optimization results showed that the net sediment mass flow rate of the riverbed in the curved riverbed model using one semi-cylinder sandbag was maximum when the angle between the semi-cylinder sandbag and the concave bank of the riverbed was 158°. Further, the results of the analyses of velocity and spacing indicated that the effect of inlet flow velocity on the effectiveness of bank protection is 1.5 times greater than the spacing of the throw pillows in a bend channel with two semi-cylindrical sandbags. In the conventional flow velocity range of 1~2 m/s, the net sediment mass flow rate in the riverbed is the largest when the throw pillow distance is set at 49 m, which is about 9.4 kg/s, which can provide a better bank protection effect and can provide a certain reference for the design of engineering bank protection. Full article

This study puts forward a reliability analysis for the bearing performance of piles subjected to the coupled action of chloride corrosion and scouring. A chloride diffusion model was constructed based on the stiffness degradation factor and Fick’s law. The Monte Carlo simulation method, along with the consideration of the scouring effect of water flow on the pile foundation, was employed to assess the impact of key factors on the failure probability, considering both the bending moment and lateral displacement damage criteria. The results show that for the same exposure period, the failure probability increases as the bending moment, lateral and vertical loads, and seawater velocity increase; furthermore for the same conditions, the failure probability increases with longer exposure times. According to a particular case study, the mean bending moment, mean lateral and vertical loads, and seawater velocity all have an impact on the lateral displacement failure criterion, making it more sensitive than the bending moment failure criterion. Full article

Anchor damage is one of the main risk factors for the safe operation of submarine cables. Additionally, due to a scour effect induced by seabed currents, submarine cables are prone to exposure or even suspension, increasing the risk of being dragged by anchors. Therefore, it is necessary to study the global response of exposed and suspended submarine cables subjected to anchor dragging. In this study, the tensile and bending stiffnesses of submarine cables are calculated by theoretical methods, and the accuracy of these calculations is verified by establishing a detailed finite element model. Then, the mechanical properties of the submarine cables are equivalently modeled using beam elements, and a large-scale finite element model for exposed and suspended cables under anchor dragging is established. Considering different dragging forces, exposed lengths, spanning lengths, and spanning heights, the overall deformation and mechanical responses of exposed and suspended cables are analyzed separately. The results show that under dragging forces, axial forces are uniformly distributed along exposed and suspended segments, while bending moments concentrate at the central hooking area and the ends of exposed and suspended segments. The influence of dragging force, exposed length, spanning length, and spanning height on the stress and deformation of submarine cables is significant. The results can be used for submarine cable damage assessments caused by anchor dragging. Full article

The long-term effects of the centrifugal force of water flow in a curved river channel result in the scouring of the concave bank and the silting of the convex bank. This phenomenon significantly impacts the stability of bank slopes and the surrounding ecological environment. A common hydraulic structure, the spur dike, is extensively employed in river training and bank protection. Focusing on a 180° bend flume as the research subject, this study examines the effects of spur dike placement on the concave bank side of the bend. To this end, a second-order accurate computational format in computational fluid dynamics (CFD) and the RNG k-ε turbulence model were employed. Specifically, the influence mechanism of the pick angle and the river-width-narrowing rate on the flow dynamics and eddy structures within the bend were investigated. The results indicated that both the river-width-narrowing rate and pick angle significantly influence the flow structure of the bend, with the pick angle being the more dominant factor. The vortex scale generated by a positive pick angle of the spur dike is the largest, while upward and downward pick angles produce smaller vortex scales. Both upward and positive pick angles have larger areas of influence, and the maximum value of turbulent kinetic energy occurs at the back of the secondary spur dike. In contrast, the downward pick angle has a smaller area of influence for turbulent kinetic energy, resulting in a smaller vortex at the back of the spur dike and leading to smoother water flow overall. In river-training and bank-protection projects, the selection of the spur dike angle is crucial for controlling scour risk. The findings provide valuable insights for engineering design and construction activities. Full article

High-pile foundation is a common form of deep foundation commonly used in ocean environments, such as docks and bridge sites. Aiming at the problem of bearing capacity of high pile foundations, this paper proposes the calculation of bearing capacity and the analysis of scour depth of high pile foundations under the action of scour based on the modified p-y curve. In this paper, three kinds of scour mechanisms—natural evolution scour, general scour, and local scour—are described; and the calculation methods of scour widely used at present are compared and analyzed. The solution of the vertical stress of soil around the pile under local scour is solved and applied to the β method to solve the lateral resistance of the pile under local scour. The local erosion is equivalent to the whole erosion, and the expression of the ultimate soil resistance before and after the equivalent is calculated, respectively, according to the principle that the ultimate soil resistance at a certain point above the equivalent pile end remains unchanged. The distance from the equivalent soil surface to the pile end can be obtained simultaneously, and then the equivalent erosion depth, p-y curve of sand at different depths, and high pile bearing capacity can be obtained. Finally, it is found that the bending moment of a single pile body varies along the pile body in the form of a parabola, and the maximum bending moment of the pile body is below the mud surface and increases with the increase in horizontal load. When the scouring depth is 30 m, the horizontal load is 25 KN, and the maximum bending moment of the pile body is about 150 N·m. The data with a relative error greater than 10% accounted for only 16.6% of the total data, and the error between the calculated value and the measured value was small. The formula can predict the erosion depth more accurately. Full article

Japan’s rivers are shaped by distinctive topography and abundant rainfall, and they face flooding and sediment supply escalation concerns under climate change. Small- and medium-sized rivers tend to catch unprecedented forces that exceed planned levels, leading to substantial widening and excavation. Thus, there is a demand for a method that is capable of managing significant flood flows over an extended period. The spur dike can maintain channel clearance by promoting erosion as well as providing bank protection. However, the effectiveness of this spur dike function has not been well studied in small- and medium-sized rivers and curved reaches. In this study, we evaluate the function of spur dikes in improving channel sustainability based on examples of small- and medium-sized rivers that have maintained their channel for more than ten years after spur dike installation. First, the applicability of the empirical rule was evaluated by comparing it with actual cases of erosion depths in curved sections in Japan. Next, one-dimensional simulations were performed to evaluate the sustainability of the section over a long period. Finally, a depth-averaged morphodynamic simulation, including the secondary flow effect, was applied to evaluate the location of the flow core and elevation changes due to the spur dike. The results showed that a slight difference in the ratio of river curvature radius to river width (r/B) caused the river channel to be erosive and sedimentary. The reasons for the difference were the cross-sectional expansion caused by the excavation of the bend and the difference in the plane flow regime caused by the shift of the flow core to the inside of the bend. Although it is structurally challenging to reproduce localized scour around a spur dike in a depth-averaged simulation, it is essential for designing to apply the simulation model and combine empirical knowledge. Full article

Flow structure and channel bed deformation caused by double piers in a tandem arrangement under ice-covered flow conditions in a bent channel is more complicated than those around a single pier in a straight channel. Based on experiments in an S-shaped flume, the scouring phenomenon at double piers in a tandem arrangement under an ice cover has been conducted by varying pier spacing distance, bend apex cross section (BACS), and hydraulic parameters. Results show that, under identical hydraulic conditions, the variation trend of the scour depth in the vicinity of double piers in a tandem arrangement in a bent channel is similar to that in a straight channel. The deepest depth of scour holes at the upstream BACS is more than that at piers at the downstream BACS. At each BACS, the effect resulting from the interaction of double piers gradually decreases with the pier spacing distance. Different from the characteristics of local scour at double piers in a tandem arrangement in the straight flume, when the ratio of pier spacing distance to pier diameter (L/D) is more than 15, the horseshoe vortex generated by the front pier has negligible impact on the rear pier, and the maximum depth of scour hole at the rear pier scour hole is about 90% that of the front pier. Also, when L/D is higher than 15, the influence of the rear pier on the front one is negligible, and the scour hole depth at the front pier remains the same. However, this phenomenon occurs when the straight flume’s L/D is greater than 17. Full article

The pier scour process is normally intensified in the presence of an ice cover, which poses risks to the longevity and safety of bridges. In the present study, the impact of the densimetric Froude number, locations, and pier spacing of side-by-side piers on the local scour depth under ice-covered flow conditions were investigated based on clear water scour experiments in an S-shaped laboratory flume. The results demonstrated that the local scour at piers along the convex bank was more substantial than that along the concave bank when other factors stayed identical. The densimetric Froude number clearly has more impact on local scour at piers along the convex bank than that along the concave bank. Different from the mechanism of the pier scour in a straight channel, the scour depth around a pier along the convex bank in the S-shaped flume increases as the distance between two piers (or pier spacing) increases, while it decreases around the piers along the concave bank. Similar scour patterns were observed when the side-by-side piers were installed at different bend apex cross-sections. The maximum local scour depths at piers along the convex bank measured at different bend apex cross-sections were relatively unchanged when other influencing factors were held constant. However, the maximum scour depth around piers along the concave bank decreased as the bends increased toward downstream. Full article

In single-bend channels or meandering channels, groynes are widely used as a river-training structure. Geometric factor is an important principle of groyne design. In this paper, the numerical method based on the Renormalization Group (RNG) k-ε turbulence model is used to study the effects of groynes with different lengths and orientations on the mean flow pattern and turbulence characteristics in a mildly meandering channel. The analysis shows that compared with equal-length groynes, the groynes arranged in descending order perform well in improving the flow velocity of the main channel, and the maximum longitudinal velocity at the channel center can be increased by 1.57 times the average velocity. However, at the same time, they bring higher Normalized Turbulent Kinetic Energy (NTKE) and Normalized Bed Shear Stress (NBSS) values. The attracting groynes arranged in descending order help to reduce scouring. The groynes arranged in ascending order reduce the velocity of the riverbank in some downstream areas and are suitable for bank protection. It effectively decreases the NTKE and NBSS around the groyne fields and can reduce the inner bank scouring of the mildly meandering channel. The findings are helpful for the management of meandering rivers. Full article

Different flow-altering methods, such as W−Weirs, have been developed to reduce erosion. For this study, we performed two experiments: (1) installing a W−Weir in various positions to determine the best angle for placement, and (2) investigating the variation of flow patterns and bed shear stress distribution in a 90-degree sharp bend by measuring the 3D components of flow velocities, with and without W−Weirs, where the greatest scour depth occurs. The results from the three installation angles indicate that less scour depth and volume of sediment removal occur when the weir is located close to the end of a bend. In addition, the value of the secondary circular power without a weir was higher than the position with a weir; however, this value significantly increased at 70 degrees due to turbulence flow near the W−Weir. This secondary flow power reduction at 45 degrees with a W−Weir increased by 65.8 percent for a Froude number value of 0.17, and by 29.8 percent for a Froude number value of 0.28, compared to values without the W−Weir, respectively. Full article

At the multigate sluice structure on a fluvial river, undesired sediment deposition affects the normal operation of the reservoir in question. Physical and numerical models are hybridized to help explore flow and sedimentation patterns. Field and laboratory investigations show that the deposition is attributable to the formation of large recirculation zones at low and medium discharges. As a potential countermeasure, an array of guide vanes is recommended to cope with the concern. Their attack angle with the flow is a dominant parameter that needs to be evaluated. Tests in the fixed-bed model demonstrate that the vanes bend the reservoir flow towards the sluice and suppress the circulation zones along both banks. The favorable range of attack angle is 15–20°. With the examination of sedimentation of both bed and suspended loads, the numerical modeling indicates that the sediment-removal efficiency increases with an increase in attack angle. By weighing the flushing efficiency and the risk of local scouring at the vanes, the 15° vane layout is recommended. This study is expected to provide a reference for guide-vane design in similar situations. Full article

Scour, caused by swiftly moving water, can remove alluvial sediment and soil, creating holes surrounding a bridge component and compromising the integrity of the bridge structure. Such problems can be equally critical for bridges with piers-on-bank bridges subjected to severe storm and flooding issues. In this paper, the Phillips Road Bridge over Toby Creek (35°18′28.2″ N 80°44′16.6″ W, Charlotte, NC, USA), a pier-on-bank bridge with critical/significant local scour holes and deep riverbank erosion cuts was selected as case study bridge. To investigate the scour effect on the bridge with pier-on-bank performance, the scoured area around a single pier is first quantified using a terrestrial laser and then modeled using nonlinear finite element (FE) analysis, where the local scour is modeled as progressive mass losses using the Element Removal (ER) technique. The FE results are compared to the design loading scenario and the results substantiated that the local scouring could cause large deflection and increased bending moment on the bridge pier. Full article
