Creases in origami reflectarray antennas (ORAs) impose layout exclusion zones that invalidate conventional shaped beam synthesis, assuming continuous periodic apertures. A crease-compatible shaped beam synthesis approach is presented, in which crease-intersecting elements are treated as constrained reflectors by removing only their patches while retaining a continuous ground plane, thereby translating geometric restrictions into explicit amplitude/phase constraints. These constraints are incorporated into a modified alternating projection method (MAPM) via an iteration-updated ternary state matrix and a revised inverse projector, where the amplitudes of internal elements are kept prescribed, and only their phases are iteratively optimized. A 15 GHz hexagonal twist ORA using triangular-ring unit cells is designed to generate a sector beam in the xoz plane and a pencil beam in the yoz plane. Full-wave simulations demonstrate a peak gain of 26.4 dBi with sidelobe levels below −16.1 dB, validating the proposed beam shaping synthesis with crease constraints for ORAs. Full article

Laser beam scanning (LBS) projection systems based on MEMS micromirrors offer advantages such as compact size, low power consumption, and vivid color performance, making them well suited for applications like AR glasses and portable projectors. Among various scanning methods, raster scanning is widely adopted; however, it suffers from artifacts such as dark bands between adjacent scanning lines and non-uniform distribution of the scanning trajectory relative to the original image. These issues degrade the overall viewing experience. In this study, we address these problems by introducing random variations to the slow-axis driving signal to alter the vertical offset of the scanning trajectories between different scan cycles. The variation is defined as an integer multiple of 1/8 of the fast-axis scanning period ($1/{\mathrm{f}}_{\mathrm{h}}$) Due to the temporal integration effect of human vision, trajectories from different cycles overlap, thereby enhancing the scanning fill factor relative to the target image area. The simulation and experimental results demonstrate that the maximum ratio of non-uniform line spacing is reduced from 7:1 to 1:1, and the modulation of the scanned display image is reduced to 0.0006—below the human eye’s contrast threshold of 0.0039 under the given experimental conditions. This method effectively addresses scanning display artifacts without requiring additional hardware modifications. Full article

High-resolution imaging using Transmission Electron Microscopy (TEM) is essential for applications such as grain boundary analysis, microchip defect characterization, and biological imaging. However, TEM images are often compromised by electron energy spread and other factors. In TEM mode, where the objective and projector lenses are positioned downstream of the sample, electron–sample interactions cause energy loss, which adversely impacts image quality and resolution. This study introduces a simulation tool to estimate the electron energy loss spectrum (EELS) as a function of sample thickness, covering electron beam energies from 300 keV to 3 MeV. Leveraging recent advances in MeV-TEM/STEM technology, which includes a state-of-the-art electron source with 2-picometer emittance, an energy spread of $3\times {10}^{-5}$, and optimized beam characteristics, we aim to minimize energy spread. By integrating EELS capabilities into the BNL Monte Carlo (MC) simulation code for thicker samples, we evaluate electron beam parameters to mitigate energy spread resulting from electron–sample interactions. Based on our simulations, we propose an experimental procedure for quantitively distinguishing between elastic and inelastic scattering. The findings will guide the selection of optimal beam settings, thereby enhancing resolution for nanoimaging of thick biological samples and microchips. Full article

Cardiovascular diseases (CVDs) are the most common health threats worldwide. 2D X-ray invasive coronary angiography (ICA) remains the most widely adopted imaging modality for CVD assessment during real-time cardiac interventions. However, it is often difficult for the cardiologists to interpret the 3D geometry of coronary vessels based on 2D planes. Moreover, due to the radiation limit, often only two angiographic projections are acquired, providing limited information of the vessel geometry and necessitating 3D coronary tree reconstruction based only on two ICA projections. In this paper, we propose a self-supervised deep learning method called NeCA, which is based on neural implicit representation using the multiresolution hash encoder and differentiable cone-beam forward projector layer, in order to achieve 3D coronary artery tree reconstruction from two 2D projections. We validate our method using six different metrics on a dataset generated from coronary computed tomography angiography of right coronary artery and left anterior descending artery. The evaluation results demonstrate that our NeCA method, without requiring 3D ground truth for supervision or large datasets for training, achieves promising performance in both vessel topology and branch-connectivity preservation compared to the supervised deep learning model. Full article

In this study, we proposed a system to reduce the speaker’s suffering from the strong light of a beam projector by applying regional brightness control over the screen. Since the original image and the projected one on the screen are quite different in area, brightness, and color, the proposed system first transforms them so that they have the same area and similar color tone. Then, to accurately determine the difference between those images, we have introduced a SSIM map, which is a perception-based method of measuring image similarity. Accordingly, an image segmentation model is used to determine the speaker’s silhouette from the SSIM map. We applied a couple of well-trained segmentation models, such as Selfie and DeepLab-v3, provided with MediaPipe. The experimental results showed the operability of the proposed system and that it determines most of a lecturer’s body area on the screen. To closely evaluate the system’s effectiveness, we have measured error rates consisting of false-positive and false-negative errors in the confusion matrix. With the measured results, the error rates appeared so insignificant and stable that the proposed system provides a practical effect for the speakers, especially in the case of applying DeepLab-v3. With the results, it is implied that an accurate segmentation model can considerably elevate the effectiveness of the system. Full article

Material-resolving computed tomography is a powerful and well-proven tool for various clinical applications. For industrial scan setups and materials, several problems, such as K-edge absence and beam hardening, prevent the direct transfer of these methods. This work applies dual-energy computed tomography methods for material decomposition to simulated phantoms composed of industry-relevant materials such as magnesium, aluminium and iron, as well as some commonly used alloys like Al–Si and Ti64. Challenges and limitations for multi-material decomposition are discussed in the context of X-ray absorption physics, which provides spectral information that can be ambiguous. A deep learning model, derived from a clinical use case and based on the popular U-Net, was utilised in this study. For various reasons outlined below, the training dataset was simulated, whereby phantom shapes and material properties were sampled arbitrarily. The detector signal is computed by a forward projector followed by Beer–Lambert law integration. Our trained model could predict two-material systems with different elements, achieving a relative error of approximately 1% through simulated data. For the discrimination of the element titanium and its alloy Ti64, which were also simulated, the relative error increased to 5% due to their similar X-ray absorption coefficients. To access authentic CT data, the model underwent testing using a 10c euro coin composed of an alloy known as Nordic gold. The model detected copper as the main constituent correctly, but the relative fraction, which should be 89%, was predicted to be ≈70%. Full article

The objective of this manuscript is to investigate the determinants influencing the selection of over-the-top (OTT) platforms as opposed to traditional television mediums—cable, Internet protocol television (IPTV), and satellite broadcasting—for the consumption of content such as television shows and films. Employing data extracted from the 2020 Media Panel comprising 423,851 observations garnered from personal media diaries, this study scrutinizes the impacts of individual attributes, environmental conditions, and temporal factors on platform choice. The findings reveal a temporal influence characterized by a “Friday effect” and a heightened preference for OTT platforms during early afternoon (12:00–16:00) and late-night hours (00:00–04:00). Notably, the likelihood of selecting OTT platforms is significantly augmented during the late-night period in comparison to other time frames. In relation to individual characteristics, variables such as male gender, younger age, higher educational attainment, and elevated income levels were positively correlated with a predilection for OTT platforms. Additionally, environmental variables such as possession of an unlimited data plan and ownership of a tablet personal computer also emerged as significant predictors for OTT preference. Furthermore, the presence of a beam projector during late-night hours and residing in a household with multiple occupants during afternoon hours also served as contributing factors for OTT utilization. In conclusion, the study offers critical insights for stakeholders in both traditional television and burgeoning OTT markets, providing data-driven recommendations for the strategic allocation of resources in consideration of day-of-week and time-of-day variables. Full article

We propose a novel hybrid FPP-DIC technique to measure an object’s shape and deformation in 3D simultaneously by using a single 3CCD color camera, which captures the blue fringe patterns and red fluorescent speckles within the same image. Firstly, red fluorescent speckles were painted on the surface of the specimen. Subsequently, 12 computer-generated blue fringe patterns with a black background were projected onto the surface of the specimen using a DLP projector. Finally, both the reference and deformed images with three different frequencies and four shifted phases were captured using a 3CCD camera. This technique employed a three-chip configuration in which red–green–blue chips were discretely integrated in the 3CCD color camera sensor, rendering independent capture of RGB information possible. Measurement of out-of-plane displacement was carried out through the implementation of Fringe Projection Profilometry (FPP), whereas the in-plane displacement was evaluated using a 2D Digital Image Correlation (DIC) method by leveraging a telecentric-lens-based optical system. In comparison to the traditional FPP-DIC hybrid methodology, the present approach showed a lower incidence of crosstalk between the fringe patterns and speckle patterns while also offering a corrective for the coupling of the in-plane displacement and out-of-plane displacement. Experimental results for the in-plane cantilever beam and out-of-plane disk comparisons with the traditional 3D-DIC method indicated that the maximum discrepancy obtained between FPP-DIC and 3D-DIC was 0.7 μm and 0.034 mm with different magnifications, respectively, validating the effectiveness and precision of the novel proposed FPP-DIC method. Full article

Large survey telescopes are vital for mapping dark energy and dark matter in the deep universe. This study presents a fiber-linked internal motion metrology system that aligns the mirrors and large lenses in the telescopes to enhance alignment accuracy by improving the image quality at a lower weight, volume, power, and cost. The internal motion system comprises a photonic laser beam projector capable of projecting multiple Gaussian beams onto the detector of the telescope. The specific spatial frequency aberration component is determined by combining Gaussian beam location and the geometry model of the telescope. Furthermore, integrating the proposed system with the curvature-sensing wavefront system enables more precise alignment and camera sensing. In the experimental tests, the location precision was within 10 μm, and the rotation precision improved to 5 arcsecs, fulfilling the alignment and motion monitoring requirements of large survey telescopes. The results of this study can be used as a reference to improve the performance of closed-loop bandwidth systems and active camera optics. Full article

The aim of this study was to investigate properties of ceramic phosphors fabricated using nano Lu₃Al₅O₁₂:Ce³⁺ phosphors produced with a sol-gel-combustion method. These nano Lu₃Al₅O₁₂:Ce³⁺ phosphors had a size of about 200 nm, leading to high density when fabricated as a ceramic phosphor. We manufactured ceramic phosphors through vacuum sintering. Alumina powder was added to improve properties. We mounted the manufactured ceramic phosphor in a high-power laser beam projector and drove it to determine its optical performance. Ceramic phosphor manufactured according to our route will have a significant impact on the laser-driven lighting industry. Full article

The single-beam bathymetric light detection and ranging (LiDAR) system 1 (SBLS-1), which is equipped with a 532-nm-band laser projector and two concentric-circle receivers for shallow- and deep-water echo signals, is a lightweight and convenient prototype instrument with low energy consumption. In this study, a novel LiDAR bathymetric method is utilized to achieve single-beam and dual-channel bathymetric characteristics, and an adaptive extraction method is proposed based on the cumulative standard deviation of the peak and trough, which is mainly used to extract the signal segment and eliminate system and random noise. To adapt the dual-channel bathymetric mechanism, an automatic channel-selection method was used at various water depths. A minimum half-wavelength Gaussian iterative decomposition is proposed to improve the detection accuracy of the surface- and bottom-water waveform components and ensure bathymetric accuracy and reliability. Based on a comparison between the experimental results and in situ data, it was found that the SBLS-1 obtained a bathymetric accuracy and RMSE of 0.27 m and 0.23 m at the Weifang and Qingdao test fields. This indicates that the SBLS-1 was bathymetrically capable of acquiring a reliable, high-efficiency waveform dataset. Hence, the novel LiDAR bathymetric method can effectively achieve high-accuracy near-shore bathymetry. Full article

In this study, we propose CoR-SketchAR, an augmented reality (AR) environment authoring tool that uses dry-erase markers for real-time collaboration among users. The most important requirement for multi-user collaboration in an AR environment is that the 3D virtual object must be placed at a specific location and can be easily changed by multiple users. Because marker-based registration techniques, which are widely used for matching virtual objects with real ones, require a marker for each object, and creating a crowd simulation environment with objects of various shapes and sizes requires the use of a large number of markers, which is time consuming and expensive. CoR-SketchAR, instead, creates an urban AR environment by drawing sketches with easily altered dry-erase marker. Then, system recognizes the shapes and colors of the sketches automatically. Those recognized shapes and colors provide the exact positions for overlaying the 3D virtual objects, which are the environment factors, on the real environment in augmented reality manner. We can even specify the path the crowd are moving along with a simple sketch stroke. We apply the computer vision technique to recognize the colors and shapes of sketches. By altering the size, shape and color sketches, the system is able to create a wide variety of dynamic urban environments. To validate the proposed techniques, we built two stand-alone software systems to check the usability of the proposed system (a 2D screen-based environmental authoring tool and a sketch-based environmental authoring tool) and conducted experiments in which two users collaborated with each other to create an environment with a specific authoring tool and then report surveys. In the experiments, users collaborated in pairs to create environmental elements, such as highways, buildings, trees, and the starting and goal positions of crowds. After recognizing them, the system then automatically creates a 3D environment, and crowds are animated accordingly. Based on a user survey, we observed that participants who used sketch-based environmental authoring tools were more active and accessible than those who used 2D screen-based authoring tools. The results of the study show that CoR-SketchAR can be further used to create a dynamical crowd simulation on a large scale using beam projectors or portable devices by simply adding sketches based on different scenarios. Full article

Single circular targets are widely used as calibration objects during line-structured light three-dimensional (3D) measurements because they are versatile and easy to manufacture. This paper proposes a new calibration method for line-structured light 3D measurements based on a single circular target. First, the target is placed in several positions and illuminated by a light beam emitted from a laser projector. A camera captures the resulting images and extracts an elliptic fitting profile of the target and the laser stripe. Second, an elliptical cone equation defined by the elliptic fitting profile and optical center of the camera is established based on the projective geometry. By combining the obtained elliptical cone and the known diameter of the circular target, two possible positions and orientations of the circular target are determined and two groups of 3D intersection points between the light plane and the circular target are identified. Finally, the correct group of 3D intersection points is filtered and the light plane is progressively fitted. The accuracy and effectiveness of the proposed method are verified both theoretically and experimentally. The obtained results indicate that a calibration accuracy of 0.05 mm can be achieved for an 80 mm × 80 mm planar target. Full article

We proposed an aerial projection 3D display based on integral imaging. It is composed of a projector, a lens-array holographic optical element (HOE), and two parabolic mirrors. The lens-array HOE is a diffraction grating and is made by the volume holography technique. The lens-array HOE can be produced on a thin glass plate, and it has the optical properties of a lens array when the Bragg condition is satisfied. When the display beams of the element image array (EIA) are projected on the lens-array HOE, 3D images can be reconstructed. The two parabolic mirrors can project 3D images into the air. The Bragg-unmatched light simply passes through the lens-array HOE. Therefore, the aerial projection 3D images appear to be imaged in the air without any medium. In the experiment, a BenQ projector was used for the projection of 3D images, with a resolution of 1600 × 1200. The diameter and the height of each parabolic mirror are 150 mm and 25 mm, respectively. The inner diameter of the parabolic mirror is 40 mm. The 3D images were projected in the air, and the experimental results prove the correctness of our display system. Full article

Dual three-dimensional (3-D) view displays have been attracting much attention in many practical application fields since they can provide two kinds of realistic 3-D images with different perspectives to the viewer. Thus, in this paper, a new type of the dual-view 3-D display system based on direct-projection integral imaging using a convex-mirror-array (CMA) is proposed. Two elemental image arrays (EIAs) captured from each of the two 3-D objects are synthesized into a single dual-view EIA (DV-EIA) with a selective sub-image mapping scheme. The divergent beam of the projector containing the information of the DV-EIA is projected onto the CMA. On each convex mirror of the CMA, left and right-view components of the DV-EIA are separated and reflected back into their viewing directions. Two different 3-D scene images are then integrated and displayed on their respective viewing zones. Ray-optical analysis with the parallel-ray-approximation method and experiments with the test 3-D objects on the implemented 22″ DV 3-D display prototype confirm the feasibility of the proposed system in the practical application Full article
