To investigate the size effect on fragmentation phenomena during hypervelocity impact, scaled experiments were conducted using a 30 mm smooth-bore ballistic range (DBR30) driven by a detonation-driven two-stage launching system. Unique stripping of sandstone target was observed, revealing that free-surface unloading waves govern peak pressure attenuation and fragmentation patterns. By establishing a shock wave attenuation model, the typical failure characteristics of different regions were distinguished, including jetting, crushing, and cracking. Parameter λ was defined to distinguish two forms of destruction, Class I (stripping-dominated) and Class II (cratering-dominated). Given the significant difference between the compressive and tensile strength of sandstone, the influence of the size effect on its failure characteristics was notable. This research also provides a valuable reference for understanding the evolution and formation mechanisms of binary asteroids. Full article

Thanks to Pompeii’s burial under Vesuvio’s 79 AD eruption deposits, the ballistic imprints on its northern defensive perimeter are uniquely attributable to Sulla’s siege of 89 BC. These impact marks were digitally documented using integrated survey techniques and custom pipelines. The virtual casts generated—dimensionally accurate, high-resolution surface replicas—serve as key inputs for the reverse-modeling of damage craters, supporting terminal ballistics analyses. Two case studies—a stone projectile cavity and fan-shaped dart impressions—were 3D-printed at 1:1 scale. Prototype casting thus emerges as a cultural asset and rapidly updatable component of a dynamic data ecosystem, inclusive of users with disabilities. Full article

A well-equipped legionary army prepared to lay siege to Pompeii. Among the weapons deployed along the northern stretch of the city walls were battering rams and mobile siege towers equipped with ballistae and scorpions. The impact marks from Republican-era stone balls and dart tips remain visible today between the Vesuvio and Ercolano Gates. In 2002 and 2016, the authors surveyed significant cavities using both direct and indirect methods. The collected data were then used to calculate the volume of fractured stone material. Given the hardness of the wall ashlars, ballistic parameters were quantified based on Hellenistic treatises. The results make it possible to derive dimensions for reconstructing artillery calibrated to the observed effects. Full article

Between 2020 and 2022, more than sixty lava fountains occurred at Mt. Etna (Italy), which formed high eruption columns rising up to 15 km above sea level (a.s.l.). During those events, several ballistics fell around the summit craters, sometimes reaching touristic areas. The rather frequent activity poses questions on how the impact associated with the fallout of those particles, can be estimated. In this work, we present field data collected soon after the lava fountain on 21 February 2022. This event produced a volcanic plume of about 10 km a.s.l. which was directed toward the southeast. Several ballistics fell in the area of the Barbagallo Craters (just southeast of the summit area at around 2900 m a.s.l.), which is one of the most popular touristic areas on Etna. Hence, we collected several samples and performed laboratory analyses in order to retrieve their size, shape and density. Those values together with a quantitative analysis of the lava fountain were compared with results obtained by a free-available calculator of ballistic trajectories named the ‘Eject!’. A similar approach was hence applied to other lava fountains of the 2020–2022 sequence for which the fallout of large clasts was reported. This work is a first step to identifying in near real-time the area affected by the fallout of ballistics during Etna lava fountains and quantifying their hazard. Full article

Steel plate reinforced concrete (SC) walls can effectively resist projectile impact by preventing the rear concrete fragments flying away, thus attracting much attention in defence technology. This work numerically and analytically investigated the hard projectile perforation of steel plate reinforced concrete walls. Impact resistance theories, including cavity expansion analysis as well as the petaling theory of thin steel plates were used to describe the cratering, tunneling and plugging phases of SC walls perforation. Numerical modeling of SC walls perforation was performed to estimate projectile residual velocity and target destructive form, which were validated against the test results. An analytical model for SC wall perforation was established to describe the penetration resistance featuring five stages, i.e., cratering, tunneling and plugging, petaling with plugging and solely petaling. Analytical model predictions matched numerical results well with respect to projectile deceleration evolution as well as residual velocity. From a structural absorbed energy perspective, the effect of front concrete panel and rear steel plate thickness combinations was also studied and analyzed. Finally, equivalent concrete slab thickness was derived with respect to the ballistic limit of SC walls, which may be helpful in the design of a protective strategy. Full article

Self-secondaries are a population of background secondaries, and they have been observed on top of impact melt and ballistically emplaced ejecta deposits on various planetary bodies. Self-secondaries are formed by impacts of sub-vertically launched ejecta, but the launch mechanism is not confirmed. The potential threat of self-secondaries to the theoretical and applicable reliability of crater chronology has been noted, but not constrained. Hitherto discovered self-secondaries were located around complex impact craters, but their potential existence around simple craters has not been discovered. Here we report the first discovery of self-secondaries around lunar cold spot craters, which are an extremely young population of simple craters formed within the past ~1 million years on the Moon. Self-secondaries are widespread on layers of cascading flow-like ejecta deposits around cold spot craters. The spatial density of self-secondaries dwarfs that of potential primary craters. The spatial distribution of self-secondaries is highly heterogeneous across the ejecta deposits. With respect to the impactor trajectory that formed cold spot craters, self-secondaries formed at the downrange of the ejecta deposits have the largest spatial density, while those at the uprange have the smallest density. This density pattern holds for all cold spot craters that were formed by non-vertical impacts, but self-secondaries do not exhibit other systematic density variations at different radial distances or at other azimuths with respect to the impactor trajectory. Among known mechanics of ejecting materials to the exterior of impact craters, impact spallation is the most likely scenario to account for the required large ejection velocities and angles to form self-secondaries. The production population of self-secondaries is estimated based on the highly diverse crater size-frequency distributions across the ejecta deposits of cold spot craters. For a better understanding of the impact history on the Moon, a systematic investigation for the effect of self-secondaries on lunar crater chronology is required. Full article

Recent instances of the destruction of cultural assets in conflict zones have demonstrated the need to develop methods which will allow for the assessment of damage to heritage stone in the field. In particular, non-destructive methods would be invaluable when working on sites damaged by contemporary ballistics. Permeability (TinyPerm 3) and surface hardness (Equotip) surveys of stone damaged by 7.62 × 39 mm (AK-47) projectiles were undertaken to determine the ability of these methods to identify the spatial distribution of damage patterns such as shear faces and surface fractures. Results demonstrate the ability of surface hardness surveys to distinguish between non-impacted surfaces of the target stone and surfaces which shattered/sheared upon impact. Whilst spatial distribution analysis (“heat mapping”) of Equotip data did not correlate directly with surface fractures, permeability data heat maps were found to be indicative of surface fracture distribution. The data suggests that compaction of the stone matrix at the impact crater results in a lesser reduction of hardness in this area relative to the wider damaged surface. Surveys of impacted stone using the methods outlined here can identify damage patterns that are not visible to the naked eye, thus aiding in damage identification on fragile sites. Full article
