Search Results (18)

Terahertz synthetic aperture radar (SAR) can achieve high-resolution imaging of the target area through a large bandwidth, while squint imaging can flexibly detect the target area by adjusting the beam direction. However, the two-dimensional coupling effect intensifies under squint conditions, making it challenging for traditional frequency domain algorithms for high-resolution imaging. This paper analyzes the Doppler variations and proposes a two-dimensional decoupling algorithm for squint SAR imaging in the terahertz band. The proposed algorithm decouples in the time domain and combines the improved frequency scaling operation with the azimuthal nonlinear frequency scaling operation to obtain the focused SAR image. Compared to the Range Doppler algorithm and nonlinear frequency scaling algorithm, the simulation and experimental results verified the effectiveness of the proposed algorithm, which demonstrates the application potential for squint SAR imaging in the terahertz band. Full article

The continuous progress of synthetic aperture radar (SAR) imaging has led to a growing emphasis on the challenges involved in data acquisition and processing. And the challenges in data acquisition and processing have become increasingly prominent. However, traditional SAR imaging models are limited by their large demand for data sampling and slow image reconstruction speeds, which is particularly prominent in large-scale scene applications. To overcome these limitations, this study proposes an innovative L₁-Total Variation (TV) regularization sparse SAR imaging algorithm. The submitted algorithm constructs an imaging operator and an echo simulation operator to achieve decoupling in the azimuth and range dimensions, respectively, as well as to reduce the requirement for sampling data. In addition, a Newton acceleration iterative method is introduced to the optimization process, aiming to accelerate the speed of image reconstruction. Comparative analysis and experimental validation indicate that the proposed sparse SAR imaging algorithm outperforms conventional methods in resolution, target localization, and clutter suppression. The results suggest strong potential for rapid scene reconstruction and real-time monitoring in complex environments. Full article

Sparse Synthetic Aperture Radar (SAR) imaging has garnered significant attention due to its ability to suppress azimuth ambiguity in under-sampled conditions, making it particularly useful for high-resolution wide-swath (HRWS) SAR systems. Traditional compressed sensing-based sparse SAR imaging algorithms are hindered by range–azimuth coupling induced by range cell migration (RCM), which results in high computational cost and limits their applicability to large-scale imaging scenarios. To address this challenge, the approximated observation-based sparse SAR imaging algorithm was developed, which decouples the range and azimuth directions, significantly reducing computational and temporal complexities to match the performance of conventional matched filtering algorithms. However, this method requires iterative processing and manual adjustment of parameters. In this paper, we propose a novel deep neural network-based sparse SAR imaging method, namely the Self-supervised Azimuth Ambiguity Suppression Network (SAAS-Net). Unlike traditional iterative algorithms, SAAS-Net directly learns the parameters from data, eliminating the need for manual tuning. This approach not only improves imaging quality but also accelerates the imaging process. Additionally, SAAS-Net retains the core advantage of sparse SAR imaging—azimuth ambiguity suppression in under-sampling conditions. The method introduces self-supervision to achieve orientation ambiguity suppression without altering the hardware architecture. Simulations and real data experiments using Gaofen-3 validate the effectiveness and superiority of the proposed approach. Full article

Reflectance anisotropy in remote sensing images can complicate the interpretation of spectral signature, and extracting precise structural information under these pixels is a promising approach. Low-altitude unmanned aerial vehicle (UAV) systems can capture high-resolution imagery even to centimeter-level detail, potentially simplifying the characterization of leaf anisotropic reflectance. We proposed a novel maize point cloud generation method that combines an advanced UAV cross-circling oblique (CCO) photography route with the Structure from the Motion-Multi-View Stereo (SfM-MVS) algorithm. A multi-spectral point cloud was then generated by fusing multi-spectral imagery with the point cloud using a DSM-based approach. The Rahman–Pinty–Verstraete (RPV) model was finally applied to establish maize leaf-level anisotropic reflectance models. Our results indicated a high degree of similarity between measured and estimated maize structural parameters (R² = 0.89 for leaf length and 0.96 for plant height) based on accurate point cloud data obtained from the CCO route. Most data points clustered around the principal plane due to a constant angle between the sun and view vectors, resulting in a limited range of view azimuths. Leaf reflectance anisotropy was characterized by the RPV model with R² ranging from 0.38 to 0.75 for five wavelength bands. These findings hold significant promise for promoting the decoupling of plant structural information and leaf optical characteristics within remote sensing data. Full article

Airborne radar forward-looking imaging holds significant promise for applications such as autonomous navigation, battlefield reconnaissance, and terrain mapping. However, traditional methods are hindered by complex system design, azimuth ambiguity, and low resolution. This paper introduces a distributed array collaborative, forward-looking imaging approach, where multiple aircraft with linear arrays fly in parallel to achieve coherent imaging. We analyze signal model characteristics and highlight the limitations of conventional algorithms. To address these issues, we propose a high-resolution imaging algorithm that combines an enhanced missing-data iterative adaptive approach with aperture interpolation technique (MIAA-AIT) for effective signal recovery in distributed arrays. Additionally, a novel reference range cell migration correction (reference RCMC) is employed for precise range–azimuth decoupling. The forward-looking algorithm effectively transforms distributed arrays into a virtual long-aperture array, enabling high-resolution, high signal-to-noise ratio imaging with a single snapshot. Simulations and real data tests demonstrate that our method not only improves resolution but also offers flexible array configurations and robust performance in practical applications. Full article

Traditional near-field synthetic aperture radar (SAR) imaging algorithms reveal target features by exploiting signal amplitude and phase information. However, electromagnetic wave propagation is constrained by short distance. Therefore, the spherical wave approximation needs to be considered. In addition, it is also limited by equipment ambient noise, azimuth-distance coupling, wave scattering, and transmission power. Both the amplitude and phase of the signal suffer from the interference of multiple clutter, so they cannot be effectively utilized. To address these issues, this paper introduces a covering penetration detection system based on an improved Range Migration Algorithm (IMRMA) imaging method. Firstly, the proposed method minimizes interferences from the front end of the system using an optimized window to balance denoising and information preservation. Next, interval non-uniform interpolation, instead of Stolt interpolation decoupling, is employed to reduce the computational overhead significantly. To minimize the effects due to wave scattering and propagation loss, distance information is enhanced using amplitude and phase compensation. This reduces scattering effects and enhances image quality. An experimental system is constructed based on a vector network analyzer (VNA) to image the target. The proposed method takes about half the time of traditional RMA. The PSNR in the chunky bowl experiment is higher than 14 dB, which is higher than all the compared methods in the paper. The test results show that the designed system and the reported method can effectively achieve high-resolution images by strengthening the target intensity and suppressing the environmental artifacts. Full article

Large-scale, diverse, and high-quality data are the basis and key to achieving a good generalization of target detection and recognition algorithms based on deep learning. However, the existing methods for the intelligent augmentation of synthetic aperture radar (SAR) images are confronted with several issues, including training instability, inferior image quality, lack of physical interpretability, etc. To solve the above problems, this paper proposes a feature-level SAR target-data augmentation method. First, an enhanced capsule neural network (CapsNet) is proposed and employed for feature extraction, decoupling the attribute information of input data. Moreover, an attention mechanism-based attribute decoupling framework is used, which is beneficial for achieving a more effective representation of features. After that, the decoupled attribute feature, including amplitude, elevation angle, azimuth angle, and shape, can be perturbed to increase the diversity of features. On this basis, the augmentation of SAR target images is realized by reconstructing the perturbed features. In contrast to the augmentation methods using random noise as input, the proposed method realizes the mapping from the input of known distribution to the change in unknown distribution. This mapping method reduces the correlation distance between the input signal and the augmented data, therefore diminishing the demand for training data. In addition, we combine pixel loss and perceptual loss in the reconstruction process, which improves the quality of the augmented SAR data. The evaluation of the real and augmented images is conducted using four assessment metrics. The images generated by this method achieve a peak signal-to-noise ratio (PSNR) of 21.6845, radiometric resolution (RL) of 3.7114, and dynamic range (DR) of 24.0654. The experimental results demonstrate the superior performance of the proposed method. Full article

L_q (0 < q ≤ 1) regularization has been confirmed effective when applied to sparse SAR imaging. However, the inaccuracies caused by motion errors in the observation model will lead to various degradations and defocus in the reconstructed image. For high-resolution and light-small SAR systems, the range-variant motion errors will decrease the accuracy of range cell migration correction (RCMC), and residual range cell migration (RCM) will exceed multiple range resolution cells and degrade the image quality substantially. Aiming at this problem, in this paper, a novel azimuth-range decoupled sparse SAR imaging method with coarse-to-fine range-variant motion errors and residual RCM correction method is proposed. First, a one-step motion compensation (MOCO) operator is proposed using the inertial navigation systems (INS)/global positioning systems (GPS) information, which can significantly reduce the residual RCM and improve the reconstruction accuracy. Second, a fine high-order phase-error correction method is performed to correct the range and cross-range-varying phase errors using a joint imaging and phase-error estimation scheme, which will further improve the image focusing quality. Experimental results indicate the effectiveness of the proposed method. Full article

The orbital angular momentum (OAM) of a vortex electromagnetic wave (VEW) has gained attention as a newly explored information carrier. OAM modes provide vortex azimuth resolution, which is a new degree of freedom (DOF) in radar application. Due to the special characteristics of the vortex azimuth domain, VEW shares compound Doppler information of two-dimensional (2D) speed. This paper proposes a 2D target velocity estimation method for VEW radar. The Doppler effect of VEW is first analyzed. Based on the relativity of tangential speed and OAM mode, a pulse-by-pulse OAM mode-changing strategy is designed. Then, a modified Radon–Fourier transformation (RFT) is proposed to estimate the compound Doppler frequency while range migration is compensated. In addition, decoupling and ambiguity-solving procedures are applied to the compound Doppler frequency estimation to obtain tangential and radial speed estimations separately. According to the simulation analyses, the effectiveness of the proposed method is verified. Full article

This paper investigates the estimation of parameters—including the elevation angle, azimuth angle, polarization auxiliary angle, polarization phase difference, frequency and range of near-field sources in a Polarimetric Uniform Linear Array (P-ULA) with defective electromagnetic vector sensors. The cross-distribution dipole pairs are alternately placed in the xoy plane and yoz plane, respectively, and the whole array is divided into two subarrays, where subarray 1 consists of all of the dipole pairs placed in the xoy plane, while the dipole pairs placed in yoz plane are gathered in subarray 2. Specifically, the polarization auxiliary angle and the polarization phase difference, as well as the elevation and azimuth angles of the sources, are firstly estimated based on the Fourth-Order Cumulant (FOC) matrix in each subarray. Moreover, a decoupling method is developed to obtain the elevation and azimuth. Subsequently, the frequency and range are estimated based on the FOC matrix. Then, the parameter pair matching method is performed in order to match the pairs. Finally, an analysis of the Cramér-Rao Bound (CRB) is provided, and comparisons of the root mean square error with respect to the different input signal-to-noise ratios and number of snapshots, among different estimation methods, are implemented in the environment of additive white gaussian noise. The simulation results are provided in order to verify the effectiveness and feasibility of the proposed method for multi-dimensional parameter estimation. Full article

The synthetic aperture radar (SAR) images of a moving target may be out of focus, given the motions of a non-cooperative target. Doppler ambiguities, including the Doppler center blur and spectrum ambiguity, will easily appear due to the limitations of pulse repetition frequency, which causes difficulty in moving-target imaging. Therefore, a robust fast Doppler ambiguity approach for SAR imaging of a ground-based moving target using range azimuth joint processing (RAJP) is presented. Firstly, the use of RAJP, based on a two-dimensional cross-correlation function and linear range cell migration (LRCM) compensation function, is proposed to simultaneously obtain the first- and second-order phase parameters in the fast-time and azimuth-frequency domains. Then, a corresponding azimuth reference function is constructed to image the moving target. Additionally, a principal component analysis-based operation is introduced to solve the mismatch with the LRCM compensation function. The couplings between the range and azimuth and between the first- and second-order parameters can be simultaneously decoupled by the proposed RAJP operation, which simplifies the processing steps. The developed approach can simultaneously obtain the first- and second-order parameters in the fast-time and azimuth-frequency domains, which avoids the propagation error of parameter estimation caused by the stepwise processing operation. The proposed method is relatively fast, given the need for fewer processing steps. The presented approach is robust in terms of Doppler ambiguity and handles the blind speed sidelobe well. In this study, simulated and real data are processed to verify the proposed approach. Full article

This study conducts an in-depth evaluation of imaging algorithms and software and hardware architectures to meet the capability requirements of real-time image acquisition systems, such as spaceborne and airborne synthetic aperture radar (SAR) systems. By analysing the principles and models of SAR imaging, this research creatively puts forward the fully parallel processing architecture for the back projection (BP) algorithm based on Field-Programmable Gate Array (FPGA). The processing time consumption has significant advantages compared with existing methods. This article describes the BP imaging algorithm, which stands out with its high processing accuracy and two-dimensional decoupling of distance and azimuth, and analyses the algorithmic flow, operation, and storage requirements. The algorithm is divided into five core operations: range pulse compression, upsampling, oblique distance calculation, data reading, and phase accumulation. The architecture and optimisation of the algorithm are presented, and the optimisation methods are described in detail from the perspective of algorithm flow, fixed-point operation, parallel processing, and distributed storage. Next, the maximum resource utilisation rate of the hardware platform in this study is found to be more than 80%, the system power consumption is 21.073 W, and the processing time efficiency is better than designs with other FPGA, DSP, GPU, and CPU. Finally, the correctness of the processing results is verified using actual data. The experimental results showed that 1.1 s were required to generate an image with a size of 900 × 900 pixels at a 200 MHz clock rate. This technology can solve the multi-mode, multi-resolution, and multi-geometry signal processing problems in an integrated manner, thus laying a foundation for the development of a new, high-performance, SAR system for real-time imaging processing. Full article

Sparse signal processing theory has been applied to synthetic aperture radar (SAR) imaging. In compressive sensing (CS), the sparsity is usually considered as a known parameter. However, it is unknown practically. For many functions of CS, we need to know this parameter. Therefore, the estimation of sparsity is crucial for sparse SAR imaging. The sparsity is determined by the size of regularization parameter. Several methods have been presented for automatically estimating the regularization parameter, and have been applied to sparse SAR imaging. However, these methods are deduced based on an observation matrix, which will entail huge computational and memory costs. In this paper, to enhance the computational efficiency, an efficient adaptive parameter estimation method for sparse SAR imaging is proposed. The complex image-based sparse SAR imaging method only considers the threshold operation of the complex image, which can reduce the computational costs significantly. By utilizing this feature, the parameter is pre-estimated based on a complex image. In order to estimate the sparsity accurately, adaptive parameter estimation is then processed in the raw data domain, combining with the pre-estimated parameter and azimuth-range decouple operators. The proposed method can reduce the computational complexity from a quadratic square order to a linear logarithm order, which can be used in the large-scale scene. Simulated and Gaofen-3 SAR data processing results demonstrate the validity of the proposed method. Full article

For the multireceiver synthetic aperture sonar (SAS), the point target reference spectrum (PTRS) in the two-dimensional (2D) frequency domain and azimuth modulation in the range Doppler domain were first deduced based on a numerical evaluation method and accurate time delay. Then, the difference between the PTRS and azimuth modulation generated the coupling term in the 2D frequency domain. Compared with traditional methods, the PTRS, azimuth modulation and coupling term was better at avoiding approximations. Based on three functions, an imaging algorithm is presented in this paper. Considering the fact that the coupling term is characterized by range variance, the range-dependent sub-block processing method was exploited to perform the decoupling. Simulation results showed that the presented method improved the imaging performance across the whole swath in comparison with existing multireceiver SAS processor. Furthermore, real data was used to validate the presented method. Full article

Wide angle synthetic aperture radar (WASAR) receives data from a large angle, which causes the problem of aspect dependent scattering. $L_1$ regularization is a common compressed sensing (CS) model. The $L_1$ regularization based WASAR imaging method divides the whole aperture into subapertures and reconstructs the subaperture images individually. However, the aspect dependent scattering recovery of it is not accurate. The subaperture images of WASAR can be regarded as the SAR video. The support set among the different frames of SAR video are highly overlapped. Least squares on compressed sensing residuals (LS-CS-Residuals) can reconstruct the time sequences of sparse signals which change slowly with time. This is to replace CS on the observation by CS on the least squares (LS) residual computed using the prior estimate of the support. In this paper, we introduce LS-CS-Residual into WASAR imaging. In the iteration of LS-CS-Residual, the azimuth-range decoupled operators are used to avoid the huge memory cost. Real data processing results show that LS-CS-Residual can estimate the aspect dependent scatterings of the targets more accurately than CS based methods. Full article
