Rail corrugation intensifies wheel–rail vibrations, often leading to damage in vehicle–track system components within affected sections. This paper proposes a novel method for identifying rail corrugation, which combines Complete Ensemble Empirical Mode Decomposition with Adaptive Noise (CEEMDAN), permutation entropy (PE), and Smoothed Pseudo Wigner–Ville Distribution (SPWVD). Initially, vertical acceleration data from the axle box are decomposed using CEEMDAN to extract intrinsic mode functions (IMFs) with distinct frequencies. PE is used to evaluate the randomness of each IMF component, discarding those with high permutation entropy values. Subsequently, correlation analysis is performed on the retained IMFs to identify the component most strongly correlated with the original signal. The selected component is subjected to SPWVD time–frequency analysis to identify the location and wavelength of the corrugation occurrence. Filtering is applied to the IMF based on the frequency concentration observed in the time–frequency analysis results. Then, frequency–domain integration is performed to estimate the rail’s corrugation depth. Finally, the algorithm is validated and analyzed using both simulated data and measured data. Validation results show that this approach reliably identifies the wavelength and depth characteristics of rail corrugation. Additionally, the time–frequency analysis results reveal variations in the severity of corrugation damage at different locations. Full article

Detecting track geometry and rail surface defects using on-board vehicle monitoring systems is a key issue for rail infrastructure managers to increase availability and reliability while reducing the costs associated with monitoring and maintenance. Rail corrugation is one of the most common rail surface defects which grows in almost all metro, conventional and high-speed lines. This paper focuses on the development of a methodology to detect rail corrugation using axle box acceleration measurements acquired on an in-service high-speed vehicle. The main purpose of the proposed methodology is to distinguish the effect of rail corrugation on the accelerations from the other excitations that can be observed in the same wavelength range. For this purpose, the accelerations are analysed by calculating the fast Fourier transform and the spectrogram. Based on the characteristics of each excitation, the effects of modes of vibration, resonances, bridges, switches, and wheel defects are identified. From the remaining effects, which have congruent characteristics, a hypothesis of rail corrugation is formulated. The hypothesis is consolidated with multibody dynamics simulations and by comparing the corrugation indicators provided by the railway infrastructure company. Full article

The operating state of axle box bearings is crucial to the safety of high-speed trains, and the vibration acceleration signal is a commonly used bearing-health-state monitoring signal. In order to extract hidden characteristic frequency information from the vibration acceleration signal of axle box bearings for fault diagnosis, a method for extracting the fault characteristic frequency based on principal component analysis (PCA) fusion and the optimal bandpass filtered denoising signal analytic energy operator (AEO) demodulation spectrum is proposed in this paper. PCA is used to measure the dimension reduction and fusion of three-direction vibration acceleration, reducing the interference of irrelevant noise components. A new type of multi-channel bandpass filter bank is constructed to obtain filtering signals in different frequency intervals. A new, improved average kurtosis index is used to select the optimal filtering signals for different channel filters in a bandpass filter bank. A dimensionless characteristic index characteristic frequency energy concentration coefficient (CFECC) is proposed for the first time to describe the energy prominence ability of characteristic frequency in the spectrum and can be used to determine the bearing fault type. The effectiveness and applicability of the proposed method are verified using the simulation signals and experimental signals of four fault bearing test cases. The results demonstrate the effectiveness of the proposed method for fault diagnosis and its advantages over other methods. Full article

A squat is a type of fatigue defect caused by short-wavelength rotational contact; if squats are detected early, the maintenance cost of the track can be effectively reduced. In this paper, a method for the early detection of squats is presented based on ABA (axle box acceleration) and frequency signal processing techniques. To increase the measurement sensitivity for the squat, ABA was used to measure the longitudinal vibration. Compared to vertical ABA, longitudinal ABA does not include vibrations from rail fasteners and sleepers, so it is possible to effectively measure the vibration signal in relation to the impact of the rail. In this paper, vibration data were measured and analyzed by installing a 3-axis accelerometer on the wheel axle of the KTX; squat signals were more effectively extracted using the longitudinal vibration measurement presented above. The algorithm to detect the position of squats was developed based on wavelet spectrum analysis. This study was verified for the section of a domestic high-speed line, and as a result of conducting field verification for this section, squats were detected with a hit rate of about 88.2%. The main locations where the squats occurred were the rail welds and the joint section, and it was confirmed that unsupported sleepers occurred at locations where the squats occurred in some sections. Full article

Nowadays, railway track monitoring strategies are based on the use of railway inspection vehicles and wayside dynamic monitoring systems. The latter sometimes requires traffic disruption, as well as higher time and cost-consumption activities, and the use of dedicated inspection vehicles is less economical and efficient as the use of in-service vehicles. Furthermore, the use of non-automated algorithms faces challenges when it comes to early damage detection in railway infrastructure, considering operational, environmental, and big data aspects, and may lead to false alarms. To overcome these challenges, the application of artificial intelligence (AI) algorithms for early detection of track defects using accelerations, measured by dynamic monitoring systems in in-service railway vehicles is attracting the attention of railway managers. In this paper, an AI-based methodology based on axle box acceleration signals is applied for the early detection of distributed damage to track in terms of the longitudinal level and lateral alignment. The methodology relies on feature extraction using an autoregressive model, data normalization using principal component analysis, data fusion and feature discrimination using Mahalanobis distance and outlier analysis, considering eight onboard accelerometers. For the numerical simulations, 75 undamaged and 45 damaged track scenarios are considered. The alert limit state defined in the European Standard for assessing track geometry quality is also assumed as a threshold. It was found that the detection accuracy of the AI-based methodology for different sensor layouts and types of damage is greater than 94%, which is acceptable. Full article

The vehicle–track interaction generates forces and consequently vibrations in the environment. The interaction has been analysed by the simultaneous measurements of vehicle, track and ground vibrations during test runs with varied train speeds. The special effects of the passage over a bridge and through a tunnel are studied and compared with the measurements on a conventional ballasted surface line. The maximum amplitudes, narrow band and one-third octave band spectra are presented for the axle-box accelerations and for the track, bridge and ground vibrations. The different frequencies and frequency bands are related to wheel out-of-roundness, track alignment errors, the sleeper passage and the wheelset–track resonance. An axle impulse component has been observed at the track, at the near-field soil and as a scattered version in the far field. Specific results can be found for the bridge track, where clearly speed-dependent bridge resonances occur due to the axle sequence of the train, and for the tunnel track where soft rail pads are responsible for a strong amplification around the wheelset–track resonance. On the other hand, the axle impulses are strongly reduced by the tunnel track, and the scattered axle impulse component is not as relevant as for the surface track. As a consequence, a strong mid-frequency amplitude reduction of the tunnel compared to the surface line has been measured for low and high train speeds by the Federal Institute of Material Research and Testing (BAM) and by other institutes. Full article

The steel rail and wheel in the railway system offer a high precision and smooth-running surface. Nevertheless, the point of contact between the rail and wheel presents a critical area that can give rise to rail corrugation. This phenomenon can potentially elevate sound and vibration levels in the vicinity considerably, necessitating advanced monitoring and assessment measures. Recently, many efforts have been directed towards utilizing in-service trains for evaluating rail corrugation, and the evaluation has primarily relied on axle-box acceleration (ABA). However, the ABA measurements require a higher threshold for vibration detection. This study introduces a novel approach to rail corrugation detection by carriage floor acceleration (CFA), aimed at lowering the detection threshold. The method capitalizes on the acceleration data sensed on the carriage floor, which is induced by the sound pressure (e.g., sound-field excitation) generated at the wheel–rail contact point. An exploration of the correlation between these datasets is undertaken by simultaneously measuring both ABA and CFA. Moreover, a pivotal aspect of this research is the development of the eigenfrequency rail corrugation index (E-RCI), a mechanism that culminates energy around specific eigenfrequencies by CFA. Through this index, a focused analysis of rail corrugation patterns is facilitated. The study further delves into the stability, repeatability, and sensitivity of the E-RCI via varied measurement scenarios. Ultimately, the CFA-based rail corrugation identification is verified, establishing its practical applicability and offering a distinct approach to detecting and characterizing rail corrugation phenomena. This study has introduced an innovative methodology for rail corrugation detection using CFA, with the principal objective of lowering the detection threshold. This approach offers an efficient measurement technique for identifying rail corrugation areas, thereby potentially reducing maintenance costs and enhancing efficiency within the railway industry. Full article

Wheel burn can affect the wheel–rail contact state and ride quality. With long-term operation, it can cause rail head spalling or transverse cracking, which will lead to rail breakage. By analyzing the relevant literature on wheel burn, this paper reviews the characteristics, mechanism of formation, crack extension, and NDT methods of wheel burn. The results are as follows: Thermal-induced, plastic-deformation-induced, and thermomechanical-induced mechanisms have been proposed by researchers; among them, the thermomechanical-induced wheel burn mechanism is more probable and convincing. Initially, the wheel burns appear as an elliptical or strip-shaped white etching layer with or without deformation on the running surface of the rails. In the latter stages of development, this may cause cracks, spalling, etc. Magnetic Flux Leakage Testing, Magnetic Barkhausen Noise Testing, Eddy Current Testing, Acoustic Emission Testing, and Infrared Thermography Testing can identify the white etching layer, and surface and near-surface cracks. Automatic Visual Testing can detect the white etching layer, surface cracks, spalling, and indentation, but cannot detect the depth of rail defects. Axle Box Acceleration Measurement can be used to detect severe wheel burn with deformation. Full article

Monitoring information can facilitate the condition assessment of railway infrastructure, via delivery of data that is informative on condition. A primary instance of such data is found in Axle Box Accelerations (ABAs), which track the dynamic vehicle/track interaction. Such sensors have been installed on specialized monitoring trains, as well as on in-service On-Board Monitoring (OBM) vehicles across Europe, enabling a continuous assessment of railway track condition. However, ABA measurements come with uncertainties that stem from noise corrupt data and the non-linear rail–wheel contact dynamics, as well as variations in environmental and operational conditions. These uncertainties pose a challenge for the condition assessment of rail welds through existing assessment tools. In this work, we use expert feedback as a complementary information source, which allows the narrowing down of these uncertainties, and, ultimately, refines assessment. Over the past year, with the support of the Swiss Federal Railways (SBB), we have assembled a database of expert evaluations on the condition of rail weld samples that have been diagnosed as critical via ABA monitoring. In this work, we fuse features derived from the ABA data with expert feedback, in order to refine defection of faulty (defect) welds. Three models are employed to this end; Binary Classification and Random Forest (RF) models, as well as a Bayesian Logistic Regression (BLR) scheme. The RF and BLR models proved superior to the Binary Classification model, while the BLR model further delivered a probability of prediction, quantifying the confidence we might attribute to the assigned labels. We explain that the classification task necessarily suffers high uncertainty, which is a result of faulty ground truth labels, and explain the value of continuously tracking the weld condition. Full article

A large part of the noise emissions from rail traffic originates from rolling noise. This is significantly determined by the surface roughness of the wheel and the rail. To quantitatively assess the noise generation from the wheel–rail contact, it is necessary to measure the surface roughness of the rail network. Direct measurements via trolley devices are usually associated with the need for a free track and limitation in velocity. Indirect measurements of rail roughness, such as measuring axle-box accelerations, enable operation during regular passage but only estimate the acoustic roughness. In this study, the potential of an optical and consequently contact-free measurement method using laser triangulation sensors to measure rail roughness from the train is investigated. The approach can combine the advantage of operation during regular passage with the characteristics of a direct measurement, enabling large-scale monitoring of the rail network. A measurement run with a train was carried out on a meter-gauge track at speeds up to $80{ \mathrm{km} \mathrm{h}}^{-1}$ The results of the optical measurement approach were compared with a tactile reference measurement on the track. The results show good agreement of the new measurement setup for dry rail surface conditions at $50 {\mathrm{km} \mathrm{h}}^{-1}$, with a mean deviation of $1.48 \mathrm{dB}$. Full article

This paper investigates the possibility of developing a new method for fault detection of a damper in the primary suspension of the railway vehicle, based on the analysis of the vertical vibration’s response of the bogie. To this purpose, experimental data are used, along with results from numerical simulations regarding the Root Mean Square (RMS) accelerations measured/simulated in four reference bogie points—two points on the chassis, against the suspension, and two points located against the axle boxes. The experimental data are utilized to define the normal area of operating and the damper failure area in the bogie primary suspension, as well as a basis for validating the results of numerical simulations. The numerical simulations are developed on the basis of two original models of the vehicle–track system, rigid-flexible coupled type, which take into account the elasticity of the vehicle carbody and the elasticity of the wheel-rail contact: a reference model with 15 degrees of freedom, for simulating the bogie response to vertical vibrations for the normal operating of the primary suspension dampers, and an extended model with 20 degrees of freedom, for simulating the bogie vibration response to the failure damper of a primary suspension. The presented results show that there are clear premises on the possibilities of developing a fault detection method of any of the four dampers of the primary suspension corresponding to a vehicle bogie, based on the RMS accelerations measured only in two reference points of the bogie. Full article

The paper is created within a project which aims to design a system of active wheelset steering for an electric four-axle locomotive. The wheelset steering system enables reduction in forces acting in the wheel-rail contacts in a curved track and consequently a reduction in wear and maintenance costs of both vehicles and rails is achieved. The project consists of three main parts: computer simulations, scaled roller rig experiments, and field tests. The paper is focused on the fundamental aspects of the first and the second part on the project. Track curvature estimation based on the rotation of the bogies towards the car body is proposed and assessed by computer simulations across varying track radiuses, vehicle speeds, and friction conditions. The scaled roller rig has been innovated in order to simulate bogie run in a curved track with uncompensated value of lateral acceleration and instrumented with a system of measurement of lateral wheel-rail forces. The experimental bogie has been equipped with systems of active wheelset steering and measurement of axle-box forces. The experiment setup, newly developed and applied systems of forces measurement and wireless signal transmission, and results of the first experiments are described in detail. Performed computer simulations and scaled roller rig experiments show that active wheelset steering is effective and practically implementable method of reducing guiding forces acting between railway vehicle wheels and rails in a curved track. Full article

In this study, a method for detecting the railway surface defects called “squats” using the ABA (Axle Box Acceleration) measurement of trains was proposed. ABA prototype design, implementation, and field tests were conducted to derive and verify the results. The field test was performed using a proven precision measurement system, and the measured data were signal-processed using a Matlab program. The algorithm used to determine the position of the squats was developed based on wavelet spectrum analysis. This study was verified for a section of a domestic general line and, following field verification for the section, squats was detected with a hit rate of about 88.2%. The main locations where the squats occurred were the rail welds and the joint section, and it was confirmed that in some sections, unsupported sleepers occurred at the locations where the squats occurred. Full article

Continuous wheel condition monitoring is indispensable for the early detection of wheel defects. In this paper, we provide an approach based on cepstral analysis of axle-box accelerations (ABA). It is applied to the data in the spatial domain, which is why we introduce a new data representation called navewumber domain. In this domain, the wheel circumference and hence the wear of the wheel can be monitored. Furthermore, the amplitudes of peaks in the navewumber domain indicate the severity of possible wheel defects. We demonstrate our approach on simple synthetic data and real data gathered with an on-board multi-sensor system. The speed information obtained from fusing global navigation satellite system (GNSS) and inertial measurement unit (IMU) data is used to transform the data from time to space. The data acquisition was performed with a measurement train under normal operating conditions in the mainline railway network of Austria. We can show that our approach provides robust features that can be used for on-board wheel condition monitoring. Therefore, it enables further advances in the field of condition based and predictive maintenance of railway wheels. Full article

The increasing need for repairs of polygonized wheels on high-speed railways in China is becoming problematic. At high speeds, polygonized wheels cause abnormal vibrations at the wheel-rail interface that can be detected via axle-box accelerations. To investigate the quantitative relationship between axle-box acceleration and wheel polygonization in both the time and frequency domains and under high-speed conditions, a dynamics model was developed to simulate the vehicle-track coupling system and that considers both wheel and track flexibility. The calculated axle-box accelerations were analyzed by using the improved ensemble empirical mode decomposition and Wigner-Ville distribution time-frequency method. The numerical results show that the maximum axle-box accelerations and their frequencies are quantitatively related to the harmonic order and out-of-roundness amplitude of polygonized wheels. In addition, measuring the axle-box acceleration enables both the detection of wheel polygonization and the identification of the degree of damage. Full article
