Search Results (94)

To investigate the slope instability caused by differential frost heaving mechanisms from the slope crest to the toe during frost heave processes, this study takes a typical silty clay slope in Xinjiang, China, as the research object. Through indoor triaxial consolidated undrained shear tests, eight sets of natural and frost-heaved specimens were prepared under confining pressure conditions ranging from 100 to 400 kPa. The geotechnical parameters of the soil in both natural and frost-heaved states were obtained, and a spatiotemporal thermo-hydro-mechanical coupled numerical model was established to reveal the dynamic evolution law of anchor rod axial forces and the frost heave response mechanism between the frame and slope soil. The analytical results indicate that (1) the frost heave process is influenced by slope boundaries, resulting in distinct spatial variations in the temperature field response across the slope surface—namely pronounced responses at the crest and toe but a weaker response in the mid-slope. (2) Under the coupled drive of the water potential gradient and gravitational potential gradient, the ice content in the toe area increases significantly, and the horizontal frost heave force exhibits exponential growth, reaching its peak value of 92 kPa at the toe in February. (3) During soil freezing, the reverse stress field generated by soil arching shows consistent temporal variation trends with the temperature field. Along the height of the soil arch, the intensity of the reverse frost heave force field displays a nonlinear distribution characteristic of initial strengthening followed by attenuation. (4) By analyzing the changes in anchor rod axial forces during frost heaving, it was found that axial forces during the frost heave period are approximately 1.3 times those under natural conditions, confirming the frost heave period as the most critical condition for frame anchor design. Furthermore, through comparative analysis with 12 months of on-site anchor rod axial force monitoring data, the reliability and accuracy of the numerical simulation model were validated. These research outcomes provide a theoretical basis for the design of frame anchor support systems in seasonally frozen regions. Full article

Study design: The advent of the Matrix Wave^TM System (Depuy-Synthes)—a bone-anchored Mandibulo-Maxillary Fixation (MMF) System—merits closer consideration because of its peculiarities. Objective: This study alludes to two preliminary stages in the evolution of the Matrix Wave^TM MMF System and details its technical and functional features. Results: The Matrix Wave^TM System (MWS) is characterized by a smoothed square-shaped Titanium rod profile with a flexible undulating geometry distinct from the flat plate framework in Erich arch bars. Single MWS segments are Omega-shaped and carry a tie-up cleat for interarch linkage to the opposite jaw. The ends at the throughs of each MWS segment are equipped with threaded screw holes to receive locking screws for attachment to underlying mandibular or maxillary bone. An MWS can be partitioned into segments of various length from single Omega-shaped elements over incremental chains of interconnected units up to a horseshoe-shaped bracing of the dental arches. The sinus wave design of each segment allows for stretch, compression and torque movements. So, the entire MWS device can conform to distinctive spatial anatomic relationships. Displaced fragments can be reduced by in-situ-bending of the screw-fixated MWS/Omega segments to obtain accurate realignment of the jaw fragments for the best possible occlusion. Conclusion: The Matrix Wave^TM MMF System is an easy-to-apply modular MMF system that can be assembled according to individual demands. Its versatility allows to address most facial fracture scenarios in adults. The option of “omnidirectional” in-situ-bending provides a distinctive feature not found in alternate MMF solutions. Full article

To elucidate evolutionary characteristics of the surrounding rock failure mechanism in a double-roadway layout, this work is grounded on in the research context of the Jinjitan Coal Mine, focusing on the deformation and failure mechanisms of double roadways. This paper addresses the issue of resource wastage resulting from the excessive dimensions of coal pillars in prior periods by employing a research methodology that integrates theoretical analysis, numerical simulation, and field monitoring to systematically examine the movement characteristics of overlying rock in the working face. On that basis, the size of coal pillar is optimized. The advance’s stress transfer law and deformation distribution characteristics of the return air roadway and transport roadway are studied. The cause of the asymmetric deformation of roadway retention is explained. A differentiated design is conducted on the support parameters of double-roadway bolts and cables under strong dynamic pressure conditions. The study indicates that a 16 m coal pillar results in an 8 m elastic zone at its center, balancing stability with optimal resource extraction. In the basic top-sloping double-block conjugate masonry beam structure, the differing stress levels between the top working face’s transport roadway and the lower working face’s return air roadway are primarily due to the varied placements of key blocks. In the return air roadway, floor heave deformation is managed using locking anchor rods, while roof subsidence is controlled with a constant group of large deformation anchor cables. The displacement of surrounding rock increases under the influence of both leading and lagging pressures from the previous working face, although the change is minimal. There is a significant correlation between roadway deformation and support parameters and coal pillar size. With a 16 m coal pillar, differential support of the double roadway lowers the return air roadway deformation by 30%, which improves the mining rate and effectively controls the deformation of the roadway. Full article

As open-pit mining extends to greater depths, slope stability is becoming a critical factor in ensuring safe production. This issue is particularly pronounced in geological settings with weak interlayers, where sudden slope failures are more likely to occur, demanding precise and reliable stability assessment methods. In this study, a typical open-pit slope with weak interlayers was investigated. Acoustic testing and ground-penetrating radar were employed to identify rock mass structural features and delineate loose zones, enabling detailed rock mass zoning and the development of numerical simulation models for stability analysis. The results indicate that (1) the slope exhibits poor overall integrity, dominated by blocky to fragmented structures with well-developed joints and significant weak interlayers, posing a severe threat to stability; (2) in the absence of support, the slope’s dissipated energy, displacement, and plastic zone volume all exceeded the failure threshold (Δ < 0), and the safety factor was only 0.962, indicating a near-failure state; after implementing support measures, the safety factor increased to 1.31, demonstrating a significant improvement in stability; (3) prior to excavation, the energy damage index (ds) in the 1195–1240 m platform zone reached 0.82, which dropped to 0.48 after reinforcement, confirming the effectiveness of support in reducing energy damage and enhancing slope stability; (4) field monitoring data of displacement and anchor rod forces further validated the stabilizing effect of the support system, providing strong assurance for safe mine operation. By integrating cusp catastrophe theory with energy-based analysis, this study establishes a comprehensive evaluation framework for slope stability under complex geological conditions, offering substantial practical value for deep open-pit mining projects. Full article

In the past ten years, many coal mines have encountered the problem of a premature failure of anchor rod materials. Through field investigation and laboratory research, it was found that the premature failure of these bolt materials is mostly caused by mine water corrosion. In this paper, a Zn-Y₂O₃-Al₂O₃ composite coating was prepared by an electrodeposition method for the corrosion protection of underground anchors. Through the single-factor experiment method, the co-deposition process of Zn²⁺ nano-Y₂O₃ and nano-Al₂O₃ particles was studied. Microhardness was used as the index to determine the optimum preparation process for the composite coatings. Combined with FSEM and XRD tests, the results showed that the synergistic effect of nano-Y₂O₃ and nano-Al₂O₃ particles made the coating grain refined and reduced the coating defects. The hardness of the coating increased from 98.7 Hv to 347.9 Hv, and the hardness and wear resistance of the coating were improved. The hydrophobicity of the Zn-Y₂O₃-Al₂O₃ composite coating was improved, and its static contact angle was 93.28°. The corrosion resistance of the composite coating was studied through electrochemical impedance spectroscopy, the Tafel curve, corrosion morphology, and weight loss. Under the synergistic effect of nano-Y₂O₃ and nano-Al₂O₃ particles, the self-corrosion current density decreased from 4.21 × 10⁻⁴ A/cm² to 1.06 × 10⁻⁵ A/cm², which confirmed that the Zn-Y₂O₃-Al₂O₃ composite coating had better corrosion resistance and durability. After soaking in mine water for 63 days, the Zn-Y₂O₃-Al₂O₃ composite coating had no obvious shedding on the surface and was well preserved. The practical application results show that it has excellent corrosion resistance and durability. The Zn-Y₂O₃-Al₂O₃ nano-composite coating material has significant potential advantages in the field of corrosion resistance of underground anchor rods. Full article

As the lifespan of many anchored slope reinforcements in China approaches its end, there is an increased need for secondary reinforcement. This study addresses the interaction between new and existing anchors, a critical but challenging aspect. The study introduces the Anchor Rod Modified Newmark Sliding Block Method (AMNB), which enhances the traditional Newmark Sliding Block Method (NSBM) by incorporating maximum anchor rod tension, dynamic tension changes, and group anchor effects. This improvement enhances the prediction of seismic displacement in slopes with multiple anchors. The AMNB method represents an innovation in slope stability analysis, as it is the first to integrate these dynamic and interactive factors into a unified framework. Validation through comparison with established seismic permanent displacement calculations and the analysis of three typical seismic motions show the AMNB’s effectiveness in capturing dynamic behaviors under seismic excitation. Additionally, numerical simulations using FLAC3D were conducted to validate the proposed method. The results indicate that considering group anchor effects and dynamic tension changes reduces the predicted seismic permanent displacement by up to 10% compared to traditional methods. The proposed AMNB method aligns more closely with the numerical simulation results. The findings indicate that group anchor effects negatively impact anchor forces, dynamic yield accelerations, and seismic displacements, leading to lower anchor tensions and dynamic yield accelerations. This, in turn, results in larger final slope permanent displacements under the same conditions. Full article

The disadvantages of traditional bolt support technology relying too much on engineering experience in slope engineering in China are becoming more and more obvious. Aiming at this problem, this paper establishes an intelligent bolt pull-out test system based on the Internet of Things, monitors the whole process of a bolt pull-out test, determines the ultimate pull-out bearing capacity, and grasps the friction of a bolt in real time. Based on the local common deformation theory, the force of the bolt is analyzed theoretically. The results show that the stress process of bolt rod end tension–rod end displacement is divided into quasi-elastic stage, strengthening stage and failure stage. The stress history of bolts with different anchorage lengths is the same, but the curve shape changes from steep to slow with the increase in anchorage length. Increasing the length of the long bolt can increase the ultimate pull-out bearing capacity of the bolt. Full article

The EFR3 (Eighty-Five Requiring 3) protein and its homologs are rather poorly understood eukaryotic plasma membrane peripheral proteins. They belong to the armadillo-like family of superhelical proteins. In higher vertebrates two paralog genes, A and B were found, each expressing at least 2–3 protein isoforms. EFR3s are involved in several physiological functions, mostly including phosphatidyl inositide phosphates, e.g., phototransduction (insects), GPCRs, and insulin receptors regulated processes (mammals). Mutations in the EFR3A were linked to several types of human disorders, i.e., neurological, cardiovascular, and several tumors. Structural data on the atomic level indicate the extended superhelical rod-like structure of the first two-thirds of the molecule with a typical armadillo repeat motif (ARM) in the N-terminal part and a triple helical motif in its C-terminal part. EFR3s’ best-known molecular function is anchoring the giant phosphatidylinositol 4-kinase A complex to the plasma membrane crucial for cell signaling, also linked directly to the KRAS mutant oncogenic function. Another function connected to the newly uncovered interaction of EFR3A with flotillin-2 may be the participation of the former in the organization and regulation of the membrane raft domain. This review presents EFR3A as an intriguing subject of future studies. Full article

The aim of this experimental study was to develop and evaluate the effectiveness of a new strengthening system for reinforced concrete slabs employing external jackets consisting of ultra-high-performance fiber-reinforced-concrete (UHPFRC) and mechanical anchor systems. The issue of debonding between old and fresh concrete layers, as well as the efficiency of utilizing CFRP rods, is the primary challenge of applying the UHPFRC jackets with embedded CFRP rods. In this study, we propose a novel retrofitting technique for implementing a mechanical anchor system to improve the binding of fresh UHPFRC jackets with old RC slabs. An experimental test was conducted by subjecting three slabs to cyclic loads by utilizing a dynamic actuator: a reference slab, a retrofitted slab with an external UHPFRC layer, and a retrofitted slab with an external UHPFRC layer incorporating CFRP bars. Furthermore, finite element models (FEMs) were utilized to investigate the responses of the retrofitted slabs and compare the novel method with traditional strengthening techniques, including near-surface-mounted (NSM) CFRP rods, externally bonded CFRP strips, and epoxy-bonded UHPFRC jackets, as well as two models that were the same as the experimental strengthened slab specimens except for the fact that they did not have a mechanical anchor system. Additionally, analytical mechanistic models were employed to determine the flexural moment capacity of the RC slabs. The experimental findings demonstrated that the proposed strengthening strategy considerably prevented premature debonding and enhanced the maximum load of retrofitted RC slabs by over 82%. Also, the FEM and analytical results are significantly consistent with the experimental outcomes. In conclusion, the newly suggested strengthening technique is a reliable system for enhancing the efficacy of slabs, effectively preventing early debonding between existing and new components. Full article

The diagnosis of post-stressed anchor rods is essential for maintaining the service and ensuring the safety of Electricité de France (EDF) structures. These rods are critical for the mechanical strength of structures and electromechanical components. Currently, the standard method for estimating the effective tension of post-stressed tie rods with a free length involves measuring the residual force using a hydraulic jack. However, this method can be costly, impact the structure’s operation, and pose risks to employees. Until now, there has been no reliable on-field approach to estimating residual tension using a lightweight setup. This research introduces a nondestructive method using multimodal ultrasonic guided waves to evaluate the residual tension of anchor rods with a few centimeters free at one end. The methodology was developed through both laboratory experiments and simulations. This new method allows for the extraction of dispersion curves for the first three modes, bending, torsional, and longitudinal, using time–frequency analysis and enables the estimation of the steel bar’s properties. Future work will focus on applying this methodology in the field. Full article

This research aimed to detect the defects of anchoring agents’ empty slurries in anchor support. The influence of anchoring defects on the propagation law of stress waves was comprehensively investigated using laboratory tests, theoretical calculations, and other methods. The characteristic modal components with symmetry and periodicity laws were extracted by adopting a variable modal decomposition (VMD) signal decomposition method. It was found that the bottom reflection time of stress waves had an inverse function relationship with the length of the anchorage flaw. The average propagation speed of the stress wave in the free rod was obtained as 5150 m/s, and the average consolidation wave speed was 4198 m/s. The calculation method of the bolt flaw length was finally proposed. After experimental verification, the average error rate was 2.65%, which meets the requirement of testing accuracy in the engineering field, which provides a guarantee for safe production. Full article

In deep oil and gas wells, sucker rod strings (SRS) frequently experience breakage and eccentric wear problems. To address this engineering challenge, this study establishes a new coupled three-dimensional (3D) mechanical-mathematical model for sucker rod strings in 3D curved wellbores. The model comprehensively considers well trajectory, rod string structure, and external excitation, analysing the influences of elastic force, inertial force, and friction force on the sucker rod micro-elements. The formulated differential equations are discretised using the central difference method to obtain the configuration of each point on SRS and the 3D distribution of stress and strain, thereby determining the eccentric wear points between the rod and tube. A numerical solution program was developed and successfully applied in the Daqing oilfield. Results from two case studies demonstrate significant improvements: for A1# well, the system efficiency increased from 16% to 20%, while for A2# well, the pump efficiency improved from 39.8% to 58.9% and system efficiency from 33.4% to 35%. The model overcomes previous limitations by considering rod torque, 3D curved tubing spatial coordinates, tubing non-anchoring effects, and forced buckling influence, providing a theoretical basis for dynamic calculations of sucker rod pumping systems in 3D curved wells. Full article

Background: This is a retrospective study. The aim of this study is to report the results of bipolar minimally invasive fusionless surgery for scoliosis in Rett syndrome with a minimum follow-up of 2 years. Conservative treatment is often not effective in Rett syndrome scoliosis. Posterior spinal fusion (PSF) has a high rate of complications; early surgery using traditional growing rods (TGRs) controls the deformity while preserving spinal and thoracic growth before arthrodesis. The need for surgical rod lengthening still has a high rate of complications and costs. Methods: We recorded the clinical and radiological outcomes of 22 consecutive patients with Rett scoliosis who underwent bipolar fusionless surgery with a mean follow-up of 56 months (24–99). We performed a bilateral construct with rods (with or without a self-sliding device) anchored proximally with four hook claws distally to the pelvis by ilio-sacral (IS) screws through a minimally invasive approach. Results: The Cobb angle was reduced from 74.4° initially to 28.9° postoperatively and to 25.7° at the last follow-up, which corresponds to a 65% correction of the initial deformity. The gain was maintained at the last follow-up. None of the patients required spinal fusion at skeletal maturity (55% of our patients reached skeletal maturity). There was a gain in body weight (27.97 kg at preoperative time and 33.04 kg at postoperative time). The surgical complication rate was 32%. Conclusions: We recorded the stable correction of deformities and weight gain over time using the bipolar minimally invasive fusionless technique with a reduced rate of complication compared to arthrodesis. The arthrodesis was not necessary at skeletal maturity, thanks to the delayed natural ankylosis of a fixed spine. Full article

The genus Ancistrohaptor was proposed to accommodate monopisthocotylans flatworms parasitic on the gills of species of the genus Triportheus in Manaus, Amazonas state, Brazil. Its main characteristics are (a) an accessory piece of the male copulatory organ composed of two distinct parts; (b) dextral or dextroventral vaginal openings; and (c) large ventral anchors with elongated shafts. A new species of Ancistrohaptor was found to parasitize the gills of Triportheus signatus collected from the Salgado River, Ceará State, Brazil. A new species of Monopisthocotyla was collected and described. Ancistrohaptor forficata sp. n. is primarily characterized by having a male copulatory organ with less than one turn, the presence of an articulated accessory piece with a concave rod-shaped termination, and a free accessory piece that is clamp shaped and bifurcated, as well as a dorsal bar with shading present in its medial part. This is the fourth species description of the genus Ancistrohaptor for fish of the genus Triportheus and the first record for T. signatus and the aquatic ecosystems of the Caatinga domain. Full article

With the further development of China’s coal resources, mining operations are constantly transferred to the deep soft rock. As such, the mine roadway is under the action of high geostress, the surrounding rock body engineering properties are poor, the overall strength is low, the traditional support method struggles to meet the needs of safe production, and the surrounding rock control has become a major technical challenge. This paper relies on the actual project, analyzes the destabilization mechanism of the roadway, analyzes the deformation of the peripheral rock of the deep roadway, determines the physical and mechanical parameters of the peripheral rock through indoor tests, establishes numerical analysis model, proposes to adopt the joint support scheme of anchor rods + anchor cables + a 36U-type steel metal bracket + a laying net + a laying mat + filling behind the wall, and monitors the displacement of peripheral rock of the roadway on a regular basis by using the numerical display convergence meter, and then obtains the displacement of the peripheral rock of the roadway after excavation as well as under the influence of the quarrying movement. Under the influence of the roadway perimeter rock displacement, we evaluate the reasonableness of the support program, as well as the safe and effective control of the roadway perimeter rock, to achieve the ideal roadway perimeter rock support and control effect. Full article
