Search Results (36)

Five-axis sweep scanning measurement technology, as a novel contact measurement technology, offers excellent reachability and high measurement efficiency for complex parts. However, deviations between the measurement instructions based on the model and the workpiece exist, leading to mismatches between the intended and actual sweep scanning areas, which manifest as displacements of the scanning boundaries and subsequently impact the acquisition of sampling points. When these sampling points are utilized to evaluate the machining quality of workpieces, the accuracy and reliability of the assessment results are compromised. Therefore, by focusing on the phenomenon of boundary displacement in a five-axis sweep scanning measurement, the sampling principle has been analyzed, the constrained sector for the probe tip trajectory in a five-axis scanning measurement has been defined, and the concept of the trajectory constrained sector effect has been proposed for the first time. The constrained sector effect reveals how deviations affect the scanning boundary positions and acquisition of sampling points. Based on the constrained sector effect, the influence of deviations on boundary displacement and sampling point acquisition in single-patch and multiple-patch measurement scenarios is discussed. Furthermore, practical engineering recommendations are provided, aiming to reduce the impact of deviations on the completeness of sampling point acquisition. Full article

In tolerance design for complex mechanical systems, 3D dimension chain analyses are crucial for assembly accuracy. The current methods (e.g., worst-case analysis, statistical tolerance analysis) face limitations from oversimplified assumptions—treating datum features as ideal geometries while ignoring manufacturing-induced spatial distribution of form errors and failing to characterize 3D coupled error constraints. This study proposes a six-dimensional spatial dimension chain (SDC) model based on transfer matrix theory. The key innovations include (1) a six-dimensional model integrating position and orientation vectors, incorporating geometric error propagation constraints for high-fidelity error prediction and tolerance optimization, (2) the characterization of spatially distributed form errors and 3D coupled errors of spatial dimension chain-based multiple mating-surface constraint (SDC-MMSC) using six-degree-of-freedom (6-DoF) geometric error components, reducing the assembly topology complexity while improving the efficiency, and (3) a 6-DoF error characterization method for non-mating-constrained data, providing the theoretical basis for SDC modeling. The experimental validation on an aero-engine casing assembly shows that the SDC model captures multidimensional closed-loop spatial errors, with absolute errors of max–min closed-loop distances below 9.3 μm and coaxiality prediction errors under 8.3%. The SDC-MMSC method demonstrates superiority, yielding normal vector angular errors <0.008° and envelope surface RMSE values <0.006 mm. This method overcomes traditional simplified assumptions, establishing a high-precision, multidimensional distributed-form-error-driven SDC model for complex mechanical systems. Full article

The module division scheme of commercial aircraft and other complex system products has a significant impact on the functionality, performance, and cost of the aircraft. To obtain scientifically rational modular division solutions for commercial aircraft, this study establishes an Analytic Hierarchy Process–Gray Fuzzy Comprehensive Evaluation (AHP-GFCE) model by integrating hierarchical analysis method and gray fuzzy evaluation theory. This model develops a comprehensive evaluation methodology for aircraft modular division schemes. The proposed method was applied to evaluate the structural modular division scheme of the nose structure section of a certain type of aircraft. Results demonstrate that the AHP-GFCE model successfully identified the optimal nose structure modular division scheme. Compared with traditional installation processes, this optimal solution achieves a 40% improvement in overall assembly efficiency and a 25% reduction in total production cycle duration while better aligning with the engineering and manufacturing requirements of nose structure fabrication, thus revealing the superiority of the AHP-GFCE model in modular division evaluation. This research provides novel insights for modular division schemes of complex system products like commercial aircraft, and the methodology can be extended to modular maintenance domains of sophisticated products such as aero-engines. Although there remains room for model refinement, the findings carry significant theoretical and practical implications for modular division of complex system products. Full article

Elastic rings are extensively utilized in aero-engine rotor systems owing to their compact size and ease of assembly, where they play a critical role in vibration suppression during engine operation. The dynamic behavior of elastic rings is governed by their structural parameters, with stiffness being a pivotal factor influencing the rotor system’s performance. This study employs finite element methods to investigate the effects of elastic ring structural parameters, particularly the geometric features of bosses and internal/external assembly clearances, on stiffness nonlinearity, with a focus on its mechanisms and contributing factors. The results reveal that stiffness nonlinearity emerges when the whirling radius exceeds a critical threshold. Specifically, increasing the boss width, reducing the boss height, or augmenting the number of bosses all attenuate stiffness nonlinearity under identical whirling radii. Furthermore, external clearances exhibit a stronger capability to suppress stiffness nonlinearity compared to internal clearances. Engineering insights suggest that maintaining a small clearance fit during assembly effectively mitigates stiffness nonlinearity, thereby enhancing the rotor’s dynamic performance. This study elucidates the stiffness nonlinearity behavior of elastic rings in practical applications and provides actionable guidance for their design and operational optimization in rotor systems. Full article

Addressing the challenge of acquiring depth information in aero-engine assembly scenes using monocular vision, which complicates mixed reality (MR) virtual and real occlusion processing, we propose an ORB-SLAM3-based monocular vision assembly scene virtual and real occlusion processing method. The method proposes optimizing ORB-SLAM3 for matching and depth point reconstruction using the MNSTF algorithm. MNSTF can solve the problems of feature point extraction and matching in weakly textured and texture-less scenes by expressing the structure and texture information of the local images. It is then proposed to densify the sparse depth map using the double-three interpolation method, and the complete depth map of the real scene is created by combining the 3D model depth information in the process model. Finally, by comparing the depth values of each pixel point in the real and virtual scene depth maps, the virtual occlusion relationship of the assembly scene is correctly displayed. Experimental validation was performed with an aero-engine piping connector assembly scenario and by comparing it with Holynski’s and Kinect’s methods. The results showed that in terms of virtual and real occlusion accuracy, the average improvement was 2.2 and 3.4 pixel points, respectively. In terms of real-time performance, the real-time frame rate of this paper’s method can reach 42.4 FPS, an improvement of 77.4% and 87.6%, respectively. This shows that the method in this paper has good performance in terms of the accuracy and timeliness of virtual and real occlusion. This study further demonstrates that the proposed method can effectively address the challenges of virtual and real occlusion processing in monocular vision within the context of mixed reality-assisted assembly processes. Full article

This paper addresses the complex issue of vibration response characteristics resulting from the unbalanced assembly of the double rotors in the 31F aero-engine. The study investigates the vibration response behavior of the dual-rotor system through the adjustment of rotor assembly phase angle. Initially, a dynamic model of the four-disk, five-pivot dual-rotor system is established, with its natural frequencies and vibration modes verified. The influence of size and the position of the unbalance on the vibration amplitude in the dual-rotor system is analyzed. Additionally, the probability distribution of the assembly phase angles for both the compressor and turbine sections of the low-pressure rotor is examined. The results indicate that for the low-pressure rotor exhibiting excessive vibration, adjusting the assembly phase angle of the rotors’ system’s compressor or the turbine section by 180 degrees leads to a vibration qualification rate of 70.1435%. This finding is consistent with the observations from the field experience method used in the former Soviet Union. Finally, corresponding experimental verification is conducted. Full article

In rotating machinery with a multi-stage assembled rotor, such as is found in aero engines, any unbalance present will undergo unknown changes at each stage when rotating the assembly phases of the rotor. Repeated disassembly and adjustments are often required to meet the rotor’s residual unbalance specifications. Therefore, developing a prediction model of this two-sided unbalance for a multi-stage assembled rotor is crucial for improving the first-time assembly pass rate and assembly efficiency. In this paper, we propose a prediction model of the two-sided unbalance seen in the multi-stage assembled rotor of an aero engine. Firstly, a method was proposed to unify the mass feature parameters of each stage’s rotor into a geometric measurement coordinate system, achieving the synchronous transmission of geometric and mass feature parameters during the assembly process of the multi-stage rotor. Building upon this, a linear parameter equation of the actual rotation axis of the multi-stage rotor was established. Based on this axis, the mass eccentricity errors of the rotor were calculated at each stage, further enabling the accurate prediction of two-sided unbalance and its action phase in a multi-stage rotor. The experimental results indicate that the maximum prediction errors of the two-sided unbalance and its action phase for a four-stage rotor are 9.6% and 2.5%, respectively, when using this model, which is a reduction of 53.0% and 38.1% compared to the existing model. Full article

The turbine disk-drum is one of the key components of an aero-engine and its assembly is connected with high-strength refined screws. But due to the uncoordinated rotation and deformation, the screws have abnormal wear damage. Through detailed contact stress analysis of screw body and component level using the finite element method, combined with experimental observation, the mechanism of wear damage of screw surface in screws is determined. It mainly includes the following: Firstly, the finite element method is used to calculate the deformation and stress distribution of the connecting screw of the turbine disk-drum assembly. Then, after the overspeed test, the morphology of the screws disassembled from the disk-drum assembly is evaluated. It was found that the wear degree in the circumferential direction and axial direction of the screw was quite different, that is, the screw wear experiment was consistent with the finite element analysis results. Finally, the influence of different rotation states and screw tightening states on screw wear was compared and analyzed. Conclusions obtained in this paper will be helpful to improve the assembly reliability of turbine drum. Full article

Rotor system of aviation engines is often made of multiple rotors connected by the clutch. Due to manufacturing and assembly errors, there is a clutch misalignment, including the parallel misalignment and the angle misalignment. This misalignment produces additional torque in the operation of the system, leading to an abnormal increase in its oscillation, which causes the rubbing between the stator and the rotor. The rub-collision poses great harm to the safety and stability of the aero-engine. The analytical model of the rotor system with misalignment and rubbing faults is established, and the influence of the rotational speed, the misalignment, and the rubbing on the nonlinear characteristics of the rotor is investigated. Considering the nonlinear Hertz contact force and bearing gap, the model of the inter-shaft bearing is built; the parallel and angle misalignments of clutch are taken into account to analyze the characteristic frequency of the faults. For raising the thrust-to-weight ratio of aviation engines, the hollow shaft is often adopted, and the effect of the wall thickness for the shaft on the nonlinear vibration of the system is also investigated. It is innovative to study the transfer mechanism from wall thickness to the nonlinear vibrational responses of the overall structure. The result indicates that, with the increase in the wall thickness of the shaft, the second critical rotating speed increases, while the first critical rotating speed is almost unchanged. The characteristic frequencies for the three-rotor system with coupling faults are obtained. Despite intuition, the parallel misalignment can inhibit rub-collision vibration to a certain extent. The research has important reference values for the fault recognition and structural optimization of the three-rotor system. Full article

The twin-spool rotor-bearing system plays a crucial role in the aero-engine. The potential manufacturing defect, assembly error, and abnormal working loads in the rotor-bearing system can induce multiple rotor failures, such as bolt looseness and rub impact. However, the prediction of the fault rotor dynamic behavior for the aero-engine remains a difficult frontier in numerical modeling. We present a dynamic model of the twin-spool rotor-bearing system, the failure model of bearing seat loosening, and the failure model of rub impact by using second-type Lagrangian equations, finite element theory, and the Timoshenko beam theory. In particular, to improve the accuracy of the numerical model, the rotating speed control equation and the actual aero-engine parameter are taken into account. An analysis is conducted on the impact of critical failure parameters, such as looseness stiffness and rub impact initial gap, on the vibration behaviors of the essential components of the twin-spool rotor system and on the entire engine. Additionally, this paper examines the twin-spool rotor-bearing system affected by looseness–rub coupled failures. The obtained conclusions can serve as a theoretical foundation for optimizing the structure and diagnosing faults in the aero-engine rotor system. Full article

The drum rotor of an aero-engine is connected by one or multiple mounting edges through bolts, and their dynamics are significantly influenced by the preload state of the bolts. Long working hours in challenging environments can result in the deterioration of bolt pre-tightening during assembly or service, which impacts the rotor’s dynamic stability and overall performance. Currently, there are no available methods for detecting the dynamic characteristics of the drum connection components. This paper analyzes the impact of the natural characteristics of the drum composite structure of a high-pressure aero-engine turbine based on the refined finite element method when the preloading state changes. Two conditions of deviation and uneven stiffness distribution were applied to the connected components of the drum. The analysis focused on the impact of the pre-tightening state on its natural frequency. After analyzing the feasibility of identifying the pre-tightening state, two methods are proposed. These methods focus on changes in natural frequency and mode shape, specifically the sensitive natural frequency change method and the mode step change method. The methods proposed in this paper can serve as a reference for evaluating the quality of assembling complex disc–drum structures with multiple bolt connections. Full article

The interference fit connection structure is widely employed in various industries. Different from the conventional connection structure, the aero-engine rotor connection has a spigot-bolt structure. The quality of the shrink-fitting assembly process directly affects the final assembly performance of the rotor. The complexity of the connection structure and the time-varying thermal deformation bring great challenges in analyzing the formation patterns of connection performance. However, existing methods of interference connection analysis are mainly used in the wide range of interference connection structures, which makes them difficult to apply in low height interference connection for aero-engine rotors. This paper introduces a thermomechanical interference fit pressure model. First, a theoretical model for interference fit pressure considering temperature-variable loads is established to obtain the time-varying pressure during the assembly process. Second, a finite element model is established to explore the influence of interference and temperature loads on the spigot pressure and the mounting edge deformation. Finally, the experiments validate the accuracy of both the theoretical model and the finite element analysis. The results indicate that during the shrink-fitting assembly process, the interference fit pressure exhibits a nonlinear evolution trend, and the warping deformation of the mounting edge is a result of the combined influence of temperature and interference fit pressure. The law found in this paper has an application prospect in the process parameter setting of shrink-fitting assembly for special structures. Full article

Free-form surface parts are widely used in industries, and they consist of intricate 3D surfaces such as molds, impellers, and turbine blades that possess complex geometrical contours and demand high precision. Proper tool orientation is crucial for ensuring the efficiency and accuracy of five-axis computer numerical control (CNC) machining. Multi-scale methods have received much attention and have been widely used in various fields. They have been proven to be instrumental and can obtain fruitful outcomes. Ongoing research on multi-scale tool orientation generation methods, which aim to acquire tool orientations that satisfy both macro- and micro-scale requirements, is significantly important for improving the machining quality of workpiece surfaces. This paper proposes a multi-scale tool orientation generation method that considers both the machining strip width and roughness scales. This method also ensures a smooth tool orientation and avoids interference in the machining process. First, the correlation between the tool orientation and rotational axis is analyzed, and feasible area calculation and tool orientation adjustment methods are introduced. Then, the paper introduces the calculation method for machining strip widths on the macro-scale and the roughness calculation method on the micro-scale. Besides, tool orientation adjustment methods for both scales are proposed. Next, a multi-scale tool orientation generation method is developed to generate tool orientations that meet the macro- and micro-scale requirements. Finally, to verify the effectiveness of the proposed multi-scale tool orientation generation method, it is applied to the machining of a free-form surface. Experimental verification results have shown that the tool orientation generated by the proposed method can obtain the expected machining strip width and roughness, meeting both macro- and micro-scale requirements. Therefore, this method has significant potential for engineering applications. Full article

This work aims to study the dynamic characteristics of an entire aero-engine casing by experiments using a new type of rotating exciter. New vibration sensor layout rules are proposed according to experimental results and vibration transmission characteristics. The vibration response of the aero-engine casing is carried out, and the vibration response of different casing measuring points is also studied. The finite element model of the engine casing’s structure is established to obtain the natural frequency of the whole aero-engine casing, which agrees well with the experimental measurement. We find that the vibration acceleration transmission value of the radial measuring point of bearing No. 1, but not the fan sensor, is more suitable for detecting the running state of the fan rotor. In addition, the sensor in the intermediate casing can detect the vibration of the high-pressure rotor. Bolt loosening of the flange has little effect on the vibration transmission characteristics of the casing. This work aims to provide experimental data of whole aero-engine vibration characteristics with a new rotating exciter for the vibration test, which can help optimize the location of the vibration transducer for the engine and the assembly technology design for the whole engine structure. Full article

This paper describes the effort of designing an unconventional exhaust manifold for a marine gas turbine engine, with an integrated passive ventilation port for cooling the engine housing. The study is part of a larger program to substitute the propulsion gas turbines for the T22R defense frigate and make the proper aerodynamic adaptations. The system in question is unique, in the sense that it uses the exhaust gas momentum to entrain outside air and ventilate the engine enclosure. In achieving this, RANS computation was used to test various concepts and dimensions for the ventilation system. Based on these analyses, the design that provided adequate air circulation with minimum pressure losses was chosen and the parts were integrated in the overall assembly. The experimental campaign performed on the entire aero-package showed good synergies of the ventilation system with the other adaptations and the engine itself. Performance was evaluated with pressure and temperature probes distributed around the aero-package and were found to be within 3.5% of the data predicted by CFD. This brings further studies closer to a technology readiness level vital for insitu testing on board the ship itself. Full article
