Soil moisture is a key factor in the water and heat exchange and energy transformation of the ecological systems and is of critical importance to the accurate obtainment of the soil moisture content for supervising water resources and protecting regional and global eco environments. In this study, we selected the soil moisture monitoring networks of Naqu, Maqu, and Tianjun on the Qinghai–Tibetan Plateau as the research areas, and we established a database of surface microwave scattering with the AIEM (advanced integral equation model) and the mathematical expressions for the backscattering coefficient, soil moisture, and surface roughness of the VV and VH polarizations.We proposed the soil moisture retrieval models of empirical and machine learnings algorithms (backpropagation neural network (BPNN), support vector machine (SVM), K-nearest neighbors (KNN), and random forest (RF)) for the ascending and descending orbits using Sentinel-1 and measurement data, and we also validated the accuracies of the retrieval model in the research areas. According to the results, there is a substantial logarithmic correlation among the backscattering coefficient, soil moisture, and combined roughness. Generally, we can use empirical models to estimate the soil moisture content, with an R² of 0.609, RMSE of 0.08, and MAE of 0.064 for the ascending orbit model and an R² of 0.554, RMSE of 0.086, and MAE of 0.071 for the descending orbit model. The soil moisture contents are underestimated when the volumetric water content is high. The soil moisture retrieval accuracy is improved with machine learning algorithms compared to the empirical model, and the performance of the RF algorithm is superior to those of the other machine learning algorithms. The RF algorithm also achieved satisfactory performances for the Maqu and Tianjun networks. The accuracies of the inversion models for the ascending orbit in the three soil moisture monitoring networks were better than those for the descending orbit. Full article

The variability of surface roughness may lead to relatively large dynamic of backscatter coefficient observed by the synthetic aperture radar (SAR), which complicates the soil moisture (SM) retrieval process based on active remote sensing. The effective roughness parameters are commonly used for parameterizing the soil scattering models, the values of which are often assumed to be constant during different study periods for the same site. This paper investigates the reasonableness of this hypothesis from the perspective of backscatter coefficient simulation and SM retrieval using high resolution SAR data. Three years of Sentinel-1A data from 2016 to 2018 were collected over a sparsely vegetated field within the REMEDHUS SM monitoring network. The advanced integral equation model (AIEM) and Dobson dielectric mixing model were combined for optimizing the effective roughness parameters, as well as simulating the backscatter coefficient and retrieving the SM. The effective roughness parameters were optimized at different temporal periods, such as 2016, 2017, 2018, 2016 + 2017, 2017 + 2018, and 2016 + 2017 + 2018, to analyze their temporal dynamics. It was found that: (1) the effective roughness parameters optimized at different temporal periods are very close to each other; (2) the simulated backscatter from AIEM is consistent with Sentinel-1A observation with root mean square errors (RMSEs) between 1.133 and 1.163 dB and correlation coefficient ® value equals to 0.616; (3) the seasonal dynamics ofin situ SM is well-captured by the retrieved SM with R values floating at 0.685 and RMSEs ranging from 0.049 to 0.052 m³/m³; and (4) inverse of the AIEM with the implementation of effective roughness parameters achieves better performance for SM retrieval than the change detection method. These findings demonstrate that the assumption on the constant effective roughness parameters during the study period of at least three years is reasonable. Full article

Soil moisture (SM) retrieval over agricultural fields using synthetic aperture radar (SAR) data is often hindered by the vegetation layer and soil roughness. Most SM inversion algorithms require in situ SM data for a calibration to eliminate these two disturbing factors, while collecting in situ data is a project that consumes a lot of manpower and resources. This paper aims to tentatively develop an inversion algorithm for retrieving SM in the absence of in situ SM in areas covered by winter wheat vegetation. Based on the analysis of the data set simulated by the Michigan Microwave Canopy Scattering (MIMICS) model, an improved ratio model is proposed to remove the effect of the vegetation layer. Through the parameterization of the advanced integral equation model (AIEM), the effect of the soil roughness on the inversion of soil moisture is eliminated. The spatial distribution of SM in winter wheat fields is obtained using the Sentinel-1 SAR and Sentinel-2 images. The comparison results between the inverted SM and the in situ measured data reveal a good correlation (R = 0.85, RMSE = 0.032 cm³·cm⁻³), and the result confirms that the algorithm developed only based on theoretical models can also effectively monitor the spatial changes of SM over winter wheat fields. Full article

A novel multi-parameter inversion method is proposed for the Advanced Integral Equation Model (AIEM) by using bi-directional deep neural network. There is a very complex nonlinear relationship between the surface parameters (dielectric constant and roughness) and radar backscattering coefficient. The traditional inverse neural network, which is constructed by using the backscattering coefficients as the input and the surface parameters as the output, leads to bad convergence and wrong results. This is because many sets of surface parameters can get the same backscattering coefficient. Therefore, the proposed bi-directional deep neural network starts with building an AIEM-based forward deep neural network (AIEM-FDNN), whose inputs are the surface parameters and outputs are the backscattering coefficients. In this way, the weights and biases of the forward deep neural network can be optimized and predicted, which can be used for the backward deep neural network (AIEM-BDNN). Then, the multi-parameters are updated by minimizing the loss between the output backscattering coefficients with the measured ones. By inserting a sigmoid function between the input and the first hidden layer, the input multi-parameters can be efficiently approximated and continuously updated. As a result, both the forward and backward deep neural networks can be built with these weights and biases. By sharing the weights and biases of the forward network, the training of the inverse network is avoided. The bi-directional deep neural network can not only predict the backscattering coefficient but can also inverse the surface parameters. Numerical results are given to demonstrate that the RMSE of the backscattering coefficients calculated by the proposed bi-directional neural network can be reduced to 0.1%. The accuracy of the inversion parameters, including the real and imaginary parts of the dielectric constant, the root mean square height and the correlation length, can be improved to 97.56%, 91.14%, 99.04% and 98.45%, respectively. At the same time, the bi-directional neural network also has good accuracy for the inversion of the POLARSCAT measured data. Full article

Conventional direction-of-arrival (DOA) estimation methods are primarily used in point source scenarios and based on array signal processing. However, due to the local scattering caused by sea surface, signals observed from radar antenna cannot be regarded as a point source but rather as a spatially dispersed source. Besides, with the advantages of flexibility and comparably low cost, synthetic aperture radar (SAR) is the present and future trend of space-based systems. This paper proposes a novel DOA estimation approach for SAR systems using the simulated radar measurement of the sea surface at different operating frequencies and wind speeds. This article’s forward model is an advanced integral equation model (AIEM) to calculate the electromagnetic scattered from the sea surface. To solve the DOA estimation problem, we introduce a convolutional neural network (CNN) framework to estimate the transmitter’s incident angle and incident azimuth angle. Results demonstrate that the CNN can achieve a good performance in DOA estimation at a wide range of frequencies and sea wind speeds. Full article

The objective of this paper is to propose a combined approach for the high-precision mapping of soil moisture during the wheat growth cycle based on synthetic aperture radar (SAR) (Radarsat-2) and optical satellite data (Landsat-8). For this purpose, the influence of vegetation was removed from the total backscatter by using the modified water cloud model (MWCM), which takes the vegetation fraction ($f_{veg}$) into account. The VV/VH polarization radar backscattering coefficients database was established by a numerical simulation based on the advanced integrated equation model (AIEM) and the cross-polarized ratio of the Oh model. Then the empirical relationship between the bare soil backscattering coefficient and both the soil moisture and the surface roughness was developed by regression analysis. The surface roughness in this paper was described by using the effective roughness parameter and the combined roughness form. The experimental results revealed that using effective roughness as the model input instead of in-situ measured roughness can obtain soil moisture with high accuracy and effectively avoid the uncertainty of roughness measurement. The accuracy of soil moisture inversion could be improved by introducing vegetation fraction on the basis of the water cloud model (WCM). There was a good correlation between the estimated soil moisture and the observed values, with a root mean square error (RMSE) of about 4.14% and the coefficient of determination ($R^2$) about 0.7390. Full article

Soil moisture is an important variable in ecological, hydrological, and meteorological studies. An effective method for improving the accuracy of soil moisture retrieval is the mutual supplementation of multi-source data. The sensor configuration and band settings of different optical sensors lead to differences in band reflectivity in the inter-data, further resulting in the differences between vegetation indices. The combination of synthetic aperture radar (SAR) data with multi-source optical data has been widely used for soil moisture retrieval. However, the influence of vegetation indices derived from different sources of optical data on retrieval accuracy has not been comparatively analyzed thus far. Therefore, the suitability of vegetation parameters derived from different sources of optical data for accurate soil moisture retrieval requires further investigation. In this study, vegetation indices derived from GF-1, Landsat-8, and Sentinel-2 were compared. Based on Sentinel-1 SAR and three optical data, combined with the water cloud model (WCM) and the advanced integral equation model (AIEM), the accuracy of soil moisture retrieval was investigated. The results indicate that, Sentinel-2 data were more sensitive to vegetation characteristics and had a stronger capability for vegetation signal detection. The ranking of normalized difference vegetation index (NDVI) values from the three sensors was as follows: the largest was in Sentinel-2, followed by Landsat-8, and the value of GF-1 was the smallest. The normalized difference water index (NDWI) value of Landsat-8 was larger than that of Sentinel-2. With reference to the relative components in the WCM model, the contribution of vegetation scattering exceeded that of soil scattering within a vegetation index range of approximately 0.55–0.6 in NDVI-based models and all ranges in NDWI1-based models. The threshold value of NDWI2 for calculating vegetation water content (VWC) was approximately an NDVI value of 0.4–0.55. In the soil moisture retrieval, Sentinel-2 data achieved higher accuracy than data from the other sources and thus was more suitable for the study for combination with SAR in soil moisture retrieval. Furthermore, compared with NDVI, higher accuracy of soil moisture could be retrieved by using NDWI1 (R² = 0.623, RMSE = 4.73%). This study provides a reference for the selection of optical data for combination with SAR in soil moisture retrieval. Full article

This paper proposes a combined approach comprising a set of methods for the high-precision mapping of soil moisture in a study area located in Jiangsu Province of China, based on the Chinese C-band synthetic aperture radar data of GF-3 and high spatial-resolution optical data of GF-1, in situ experimental datasets and background knowledge. The study was conducted in three stages: First, in the process of eliminating the effect of vegetation canopy, an empirical vegetation water content model and a water cloud model with localized parameters were developed to obtain the bare soil backscattering coefficient. Second, four commonly used models (advanced integral equation model (AIEM), look-up table (LUT) method, Oh model, and the Dubois model) were coupled to acquire nine soil moisture retrieval maps and algorithms. Finally, a simple and effective optimal solution method was proposed to select and combine the nine algorithms based on classification strategies devised using three types of background knowledge. A comprehensive evaluation was carried out on each soil moisture map in terms of the root-mean-square-error (RMSE), Pearson correlation coefficient (PCC), mean absolute error (MAE), and mean bias (bias). The results show that for the nine individual algorithms, the estimated model constructed using the AIEM (m_v1) was significantly more accurate than those constructed using the other models (RMSE = 0.0321 cm³/cm³, MAE = 0.0260 cm³/cm³, and PCC = 0.9115), followed by the Oh model (m_v5) and LUT inversion method under HH polarization (m_v2). Compared with the independent algorithms, the optimal solution methods have significant advantages; the soil moisture map obtained using the classification strategy based on the percentage content of clay was the most satisfactory (RMSE = 0.0271 cm³/cm³, MAE = 0.0225 cm³/cm³, and PCC = 0.9364). This combined method could not only effectively integrate the optical and radar satellite data but also couple a variety of commonly used inversion models, and at the same time, background knowledge was introduced into the optimal solution method. Thus, we provide a new method for the high-precision mapping of soil moisture in areas with a complex underlying surface. Full article

Soil moisture is an essential variable in the land surface ecosystem, which plays an important role in agricultural drought monitoring, crop status monitoring, and crop yield prediction. High-resolution radar data can be combined with optical remote-sensing data to provide a new approach to estimate high-resolution soil moisture over vegetated areas. In this paper, the Sentinel-1A data and the Moderate Resolution Imaging Spectroradiometer (MODIS) data are combined to retrieve soil moisture over agricultural fields. The advanced integral equation model (AIEM) is utilized to calculate the scattering contribution of the bare soil surface. The water cloud model (WCM) is applied to model the backscattering coefficient of vegetated areas, which use two vegetation parameters to parameterize the scattering and attenuation properties of vegetation. Four different vegetation parameters extracted from MODIS products are combined to predict the scattering contribution of vegetation, including the leaf area index (LAI), the fraction of photosynthetically active radiation (FPAR), normalized difference vegetation index (NDVI), and the enhanced vegetation index (EVI). The effective roughness parameters are chosen to parameterize the AIEM. The Sentinel-1A and MODIS data in 2017 are used to calibrate the coupled model, and the datasets in 2018 are used for soil moisture estimation. The calibration results indicate that the Sentinel-1A backscattering coefficient can be accurately predicted by the coupled model with the Pearson correlation coefficient (R) ranging from 0.58 to 0.81 and a root mean square error (RMSE) ranging from 0.996 to 1.401 dB. The modeled results show that the retrieved soil moisture can capture the seasonal dynamics of soil moisture with R ranging from 0.74 to 0.81. With the different vegetation parameter combinations used for parameterizing the scattering contribution of the canopy, the importance of suitable vegetation parameters for describing the scattering and attenuation properties of vegetation is confirmed. The LAI is recommended to characterize the scattering properties. There is no obvious clue for selecting vegetation descriptors to characterize the attenuation properties of vegetation. These promising results confirm the feasibility and validity of the coupled model for soil moisture retrieval from the Sentinel-1A and MODIS data. Full article

As an essential ecological parameter, soil moisture is important for understanding the water exchange between the land surface and the atmosphere, especially in the Loess Plateau (China). Although Synthetic Aperture Radar (SAR) images can be used for soil moisture retrieval, it is still a challenge to mitigate the impacts of complex terrain over hilly areas. Therefore, the objective of this paper is to propose an improved approach for soil moisture estimation in gully fields based on the joint use of the Advanced Integral Equation Model (AIEM) and the Incidence Angle Correction Model (IACM) from Sentinel-1A observations. AIEM is utilized to build a simulation database of microwave backscattering coefficients from various radar parameters and surface parameters, which is the data basis for the retrieval modeling. IACM is proposed to correct the deviation between the local incidence angle at the scatterer and the radar viewing angle. The study area is located in the Loess Plateau of China, where the main land cover is mostly bare land and the terrain is complex. The Sentinel-1A SAR data in C-band with dual polarization acquired on October 19th, 2017 was adopted to extract the VV&VH polarimetric backscattering coefficients. The in situ measurements of soil moisture were collected on the same day of the SAR acquisition, for evaluating the accuracy of the SAR-derived soil moisture. The results showed that, firstly, the estimated soil moisture with volumetric content between 0% and 20% was in the majority. Subsequently, both the RMSE of estimation values (0.963%) and the standard deviation of absolute errors (0.957%) demonstrated a good accuracy of the improved approach. Moreover, the evaluation of IACM confirmed that the improved approach coupling IACM and AIEM was more efficient than employing AIEM solely. In conclusion, the proposed approach has a strong ability to estimate the soil moisture in the gully fields of the Loess Plateau from Sentinel-1A data. Full article

Timely and accurate soil moisture information is of great importance in agricultural monitoring. The Gaofen-3 (GF-3) satellite, the first C-band multi-polarization synthetic-aperture radar (SAR) satellite in China, provides valuable data sources for soil moisture monitoring. In this study, a soil moisture retrieval algorithm was developed for the GF-3 satellite based on a backscattering coefficient simulation database. We adopted eight optical vegetation indices to determine the relationships between these indices and vegetation water content (VWC) by combining Landsat-8 data and field measurements. A backscattering coefficient database was built using an advanced integral equation model (AIEM). The effects of vegetation on backscattering coefficients were corrected using the water cloud model (WCM) to obtain the bare soil backscattering coefficient ( ${\sigma }_{soil}^{°}$ ). Then, soil moisture retrievals were obtained at HH, VV and HH+VV combination respectively by minimizing the observed bare soil backscattering coefficient ( ${\sigma }_{soil}^{°}$ ) and the AIEM-simulated backscattering coefficient ( ${\sigma }_{\mathit{\text{soil-simu}}}^{°}$ ). Finally, the proposed algorithm was validated in agriculture region of wheat and corn in China using ground soil moisture measurements. The results showed that the normalized difference infrared index (NDII) had the best fit with measured VWC values (R = 0.885) among the eight vegetation water indices; thus, it was adopted to correct the effects of vegetation. The proposed algorithm using GF-3 satellite data performed well in soil moisture retrieval, and the scheme combining HH and VV polarization exhibited the highest accuracy, with a root mean square error (RMSE) of 0.044 m³m⁻³, followed by HH polarization (RMSE = 0.049 m³m⁻³) and VV polarization (RMSE = 0.053 m³m⁻³). Therefore, the proposed algorithm has good potential to operationally estimate soil moisture from the new GF-3 satellite data. Full article

The spatiotemporal pattern of soil moisture is of great significance for the understanding of the water exchange between the land surface and the atmosphere. The two-satellite constellation of the Sentinel-1 mission provides C-band synthetic aperture radar (SAR) observations with high spatial and temporal resolutions, which are suitable for soil moisture monitoring. In this paper, we aim to assess the capability of pattern analysis based on the soil moisture retrieved from Sentinel-1 time-series data of Dahra in Senegal. The look-up table (LUT) method is used in the retrieval with the backscattering coefficients that are simulated by the advanced integrated equation Model (AIEM) for the soil layer and the Michigan microwave canopy scattering (MIMICS) model for the vegetation layer. The temporal trend of Sentinel-1A soil moisture is evaluated by the ground measurements from the site at Dahra, with an unbiased root-mean-squared deviation (ubRMSD) of 0.053 m³/m³, a mean average deviation (MAD) of 0.034 m³/m³, and an R value of 0.62. The spatial variation is also compared with the existing microwave products at a coarse scale, which confirms the reliability of the Sentinel-1A soil moisture. The spatiotemporal patterns are analyzed by empirical orthogonal functions (EOF), and the geophysical factors that are affecting soil moisture are discussed. The first four EOFs of soil moisture explain 77.2% of the variance in total and the primary EOF explains 66.2%, which shows the dominant pattern at the study site. Soil texture and the normalized difference vegetation index are more closely correlated with the primary pattern than the topography and temperature in the study area. The investigation confirms the potential for soil moisture retrieval and spatiotemporal pattern analysis using Sentinel-1 images. Full article

L-band active microwave remote sensing is one of the most important technical methods of ocean environmental monitoring and dynamic parameter retrieval. Recently, a unique negative upwind-crosswind (NUC) asymmetry of L-band ocean backscatter over a low wind speed range was observed. To study the directional features of L-band ocean surface backscattering, a new directional spectrum model is proposed and built into the advanced integral equation method (AIEM). This spectrum combines Apel’s omnidirectional spectrum and an improved empirical angular spreading function (ASF). The coefficients in the ASF were determined by the fitting of radar observations so that it provides a better description of wave directionality, especially over wavenumber ranges from short-gravity waves to capillary waves. Based on the improved spectrum and the AIEM scattering model, L-band NUC asymmetry at low wind speeds and positive upwind-crosswind (PUC) asymmetry at higher wind speeds are simulated successfully. The model outputs are validated against Aquarius/SAC-D observations under different incidence angles, azimuth angles and wind speed conditions. Full article

The spatiotemporal distribution of soil moisture over the Tibetan Plateau is important for understanding the regional water cycle and climate change. In this paper, the surface soil moisture in the northeastern Tibetan Plateau is estimated from time-series VV-polarized Sentinel-1A observations by coupling the water cloud model (WCM) and the advanced integral equation model (AIEM). The vegetation indicator in the WCM is represented by the leaf area index (LAI), which is smoothed and interpolated from Terra Moderate Resolution Imaging Spectroradiometer (MODIS) LAI eight-day products. The AIEM requires accurate roughness parameters, which are parameterized by the effective roughness parameters. The first halves of the Sentinel-1A observations from October 2014 to May 2016 are adopted for the model calibration. The calibration results show that the backscattering coefficient (σ°) simulated from the coupled model are consistent with those of the Sentinel-1A with integrated Pearson’s correlation coefficients R of 0.80 and 0.92 for the ascending and descending data, respectively. The variability of soil moisture is correctly modeled by the coupled model. Based on the calibrated model, the soil moisture is retrieved using a look-up table method. The results show that the trends of the in situ soil moisture are effectively captured by the retrieved soil moisture with an integrated R of 0.60 and 0.82 for the ascending and descending data, respectively. The integrated bias, mean absolute error, and root mean square error are 0.006, 0.048, and 0.073 m³/m³ for the ascending data, and are 0.012, 0.026, and 0.055 m³/m³ for the descending data, respectively. Discussions of the effective roughness parameters and uncertainties in the LAI demonstrate the importance of accurate parameterizations of the surface roughness parameters and vegetation for the soil moisture retrieval. These results demonstrate the capability and reliability of Sentinel-1A data for estimating the soil moisture over the Tibetan Plateau. It is expected that our results can contribute to developing operational methods for soil moisture retrieval using the Sentinel-1A and Sentinel-1B satellites. Full article

Due to the difficulty in accurately interpreting surface emissivity spectra, problems remain in the application of passive microwave satellite observations over land surfaces. This study develops a parameterized soil surface emissivity model to quantify the microwave emissivity accurately and rapidly for Gaussian-correlated rough surfaces. We first analyze the sensitivity of surface emissivity to parameters using the advanced integral equation model (AIEM) simulated data. On the basis of the analysis and previous empirical models, two function factors that consider the polarization dependence of surface reflectivity are developed in the parameterized soil surface emissivity model. These factors also comprehensively account for the effects of surface roughness, soil moisture, and incident angle. A comparison with the AIEM simulated data indicates that the absolute error of effective reflectivity estimated by the parameterized soil surface emissivity model is small with a magnitude of 10⁻². Validation through experimental measurements suggests that a good agreement could be obtained. The parameterized soil surface emissivity model is applied to simulate satellite measurements of the Advanced Microwave Scanning Radiometer-Earth Observing System (AMSR-E). Compared with the commonly-used microwave land emissivity model developed by Weng et al. (2001), the simulation results using the parameterized soil surface emissivity model yield a lower root-mean-square error (RMSE) and the overall errors are reduced, particularly for horizontal polarization. The newly-developed parameterized soil surface emissivity model should be useful in improving our understanding and modeling the measurements of passive microwave radiometers. Full article
