Due to the mismatch of line impedance, the traditional droop control of parallel inverters in microgrids has limitations. It is difficult to achieve uniform distribution of reactive power and reduce voltage deviation. This paper proposes a droop control strategy that combines adaptive droop coefficients with secondary voltage compensation. Simulation experiments were carried out on the MATLAB R2021b/Simulink platform, and this strategy was compared with three other methods. The proposed strategy has achieved excellent results: The reactive power sharing speed has been increased by $80\%$ (reduced from 0.5 s of the adaptive virtual impedance method to 0.1 s), which improves the system response efficiency. The amplitude of the output voltage has increased from 306 V to 311 V, improving the voltage quality. This strategy outperforms other methods in terms of reactive power sharing, response speed, stability, and anti-interference ability. The simulation results verify the effectiveness of the proposed droop control strategy. Full article

The rapid proliferation of EVs has ushered in a transformative era for the power industry, characterized by increased demand volatility and grid frequency instability. In response to these challenges, this paper introduces a novel approach that combines fuzzy logic with adaptive inertia control to improve the frequency stability of grids amidst large-scale electric vehicle (EV) integration. The proposed methodology not only adapts to varying charging scenarios but also strikes a balance between steady-state and dynamic performance considerations. This research establishes a solid theoretical foundation for the inertia-adaptive virtual synchronous generator (VSG) concept and introduces a pioneering fuzzy inertia-based VSG methodology. Additionally, it incorporates adaptive output scaling factors to enhance the robustness and adaptability of the control strategy. These contributions offer valuable insights into the evolving landscape of adaptive VSG strategies and provide a pragmatic solution to the pressing challenges arising from the integration of large-scale EVs, ultimately fostering the resilience and sustainability of contemporary power systems. Finally, simulation results illustrate that the new proposed fuzzy adaptive inertia-based VSG method is effective and has superior advantages over the traditional VSG and droop control strategies. Specifically, the proposed method reduces the maximum frequency change by 25% during load transitions, with a peak variation of 0.15 Hz compared to 0.2 Hz for the traditional VSG. Full article

In the off-grid photovoltaic DC microgrid, traditional droop control encounters challenges in effectively adjusting the droop coefficient in response to varying power fluctuation frequencies, which can be influenced by factors such as line impedance. This paper introduces a novel Multi-strategy Harris Hawk Optimization Algorithm (MHHO) that integrates variable universe fuzzy control theory with droop control to develop an adaptive variable universe fuzzy droop control strategy. The algorithm employs Fuch mapping to evenly distribute the initial population across the solution space and incorporates logarithmic spiral and improved adaptive weight strategies during both the exploration and exploitation phases, enhancing its ability to escape local optima. A comparative analysis against five classical meta-heuristic algorithms on the CEC2017 benchmarks demonstrates the superior performance of the proposed algorithm. Ultimately, the adaptive variable universe fuzzy droop control based on MHHO dynamically optimizes the droop coefficient to mitigate the negative impact of internal system factors and achieve a balanced power distribution between the battery and super-capacitor in the DC microgrid. Through MATLAB/Simulink simulations, it is demonstrated that the proposed adaptive variable universe fuzzy droop control strategy based on MHHO can limit the fluctuation range of bus voltage within ±0.75%, enhance the robustness and stability of the system, and optimize the charge and discharge performance of the energy storage unit. Full article

In isolated operation, DC microgrids require multiple distributed energy storage units (DESUs) to accommodate the variability of distributed generation (DG). The traditional control strategy has the problem of uneven allocation of load current when the line impedance is not matched. As the state-of-charge (SOC) balancing proceeds, the SOC difference gradually decreases, leading to a gradual decrease in the balancing rate. Thus, an improved SOC droop control strategy is introduced in this paper, which uses a combination of power and exponential functions to improve the virtual impedance responsiveness to SOC changes and introduces an adaptive acceleration factor to improve the slow SOC balancing problem. We construct a sparse communication network to achieve information exchange between DESU neighboring units. A global optimization controller employing the consistency algorithm is designed to mitigate the impact of line impedance mismatch on SOC balancing and current allocation. This approach uses a single controller to restore DC bus voltage, effectively reducing control connections and alleviating the communication burden on the system. Lastly, a simulation model of the DC microgrid is developed using MATLAB/Simulink R2021b. The results confirm that the proposed control strategy achieves rapid SOC balancing and the precise allocation of load currents in various complex operational scenarios. Full article

Wind power is currently the most mature representative of sustainable energy generation technology, which has been developed and utilized on a large scale worldwide. The random and fluctuating nature of wind power output poses a threat to the secure and stable operation of the system. Consequently, the transmission of wind power has garnered considerable attention as a crucial factor in mitigating the challenges associated with wind power integration. In this paper, an artificial-intelligence-aided frequency coordination control strategy applicable to wind power transmission systems based on hybrid DC transmission technology is proposed. The line commutated converter (LCC) station at the sending end implements the strategy of auxiliary frequency control (AFC) and automatic generation control (AGC) to cooperate with each other in order to assist the system frequency regulation. The AFC controller is designed based on the variable forgetting factor recursive least squares (VFF-RLS) algorithm for system identification. First, the VFF-RLS algorithm is used to identify the open-loop transfer function of the system. Then, the AFC controller is designed based on the root locus method to achieve precise control of the system frequency. The DC line power modulation quantity is introduced in the AGC to automatically track the active power fluctuation and frequency deviation of the system. The AGC utilizes the classical proportional-integral (PI) control. By selecting the integrated time absolute error (ITAE) performance index to construct the reward function, and using a deep Q-network (DQN) for controller parameter optimization, it achieves improved regulation performance for the AGC. The voltage source converter (VSC) station at the receiving end implements an adaptive DC voltage droop control (ADC)strategy. Finally, the effectiveness and robustness of the proposed frequency control strategy are verified through simulation experiments. Full article

The prerequisite for the normal operation of a flexible high-voltage direct current (HVDC) transmission system is the maintenance of the stability of the direct current (DC)-side voltage, and droop control has a good dynamic regulation capability. In this paper, we first study the operating characteristics of droop control and derive its equivalent circuit, as well as the power distribution equation for droop control with a four-terminal system as an example. Then, based on this, an improved droop control method is proposed so that the droop factor can be adaptively adjusted according to the power change and provide corresponding characteristics under different operating conditions to enhance the power regulation capability of the controller under high power fluctuations. Finally, a power systems computer-aided design (PSCAD) electromagnetic transient model of the four-terminal, flexible, high-voltage DC transmission system was established and verified by simulation results. Full article

As the penetration rate of wind power systems is rising, which causes the overall system’s inertia to decline, the power system’s capacity to regulate frequency will be negatively affected. Therefore, this paper investigates the inertia control of doubly fed induction generation, and an energy storage system is installed in the wind farm to respond to the frequency deviation. First, a fuzzy control-based virtual inertia adaptive control strategy is presented. The goal of dynamic adjustment of the virtual inertia coefficient is realized by taking into account the uncertain factors of wind speed and frequency change rate. A recovery strategy based on the energy storage system’s level of charge is employed to prevent overcharging and over-discharging of the battery. Then, a weight factor based on frequency deviation is introduced to combine the droop output of the energy storage system with the virtual inertia output of the doubly fed induction generation, and the joint output mode of the wind storage system is determined in each stage of primary frequency regulation. Finally, the simulation verification is performed using the wind storage system simulation model created by MATLAB. The comparison results with other control methods prove that the proposed method is effective. Full article

To solve the problem of large DC voltage deviation caused by the power fluctuations and poor power distribution characteristics of converters in a voltage source converter multi-terminal DC (VSC-MTDC) system based on traditional droop control, this paper proposes an adaptive exponential droop control strategy. This strategy introduces the relative power deviation factor of the converter, and replaces the traditional linear droop control curve with a nonlinear exponential curve. Under different working conditions, the converter adaptively adjusts the droop control coefficient of the converter according to the relative power deviation factor to realize stability for the DC voltage and a reasonable power distribution for the MTDC system. A simulation model of a three-terminal VSC-MTDC was established in MATLAB/Simulink, and the feasibility and effectiveness of the proposed strategy were verified. Full article

Recently, virtual synchronous generators (VSGS) are a hot topic in the area of microgrid control. However, the traditional fixed-parameter-based VSG control methods have an obvious disadvantage. Namely, if the damping value is set to be small, the amplitude of frequency deviations under external power disturbances is large, meaning that the frequency suppression capacity is insufficient, but if the damping value is large, the dynamics of the system will be greatly sacrificed. To solve the problem, taking the dynamic characteristics and the maximum allowable frequency deviation (MAFD) into account, in this paper an improved fuzzy adaptive damping-based VSG control strategy is proposed to simultaneously attenuate the microgrid frequency fluctuations and guarantee the system dynamics. Firstly, in order to address the necessity of using an adaptive damping-based VSG, the structure of a fixed-parameter VSG method that incorporates the f-p/Q-V droop controllers is introduced, based on which a small signal model is established to discuss the impacts of the virtual damping on the frequency response characteristics concerning the different penetration levels of power disturbances. Then, considering the dynamics and MAFD, a fuzzy adaptive controller is constructed relying on the well-designed membership functions, control rules and output scaling factors. The main feature of the improved fuzzy controller is that two alternative output scaling factors are employed to allow the system to be overdamped when the frequency deviation is large and undamped when the frequency deviation is small, balancing the frequency response dynamics and stability characteristics. To verify the effectiveness of the proposed fuzzy adaptive damping-based VSG technique, a computer simulation is conducted on a microgrid system in MATLAB/Simulink, and the obtained results are compared with the conventional droop control and fixed-parameter based VSGs. By using the proposed fuzzy adaptive damping-based VSG control method, the peak frequency deviations under the large power disturbances would become at least 8% lower compared to the traditional droop control and fixed-parameter VSG control, and meanwhile, the frequency response speed is fast when the disturbance stands at a low position. Consequently, it is valuable to promote the proposed techniques in engineering. Full article

The “Patagonian Sheepdog” is a local working dog breed that was produced by selection from European working sheepdogs that arrived in the Magallanes region of southern Chile in the late nineteenth and early twentieth centuries. Currently, the Patagonian Sheepdog is most commonly found in the Chilean Patagonian region (43°12’ S to 56°30’ S), where it plays a fundamental role as a working dog in sheep and, to some extent, in cattle farming. Dog types that may have contributed to the Patagonian Sheepdog include the Old Welsh Grey and other old UK herding dogs. The modern Patagonian Sheepdog has been selectively bred by local sheep farmers to produce a herding dog that is well adapted to the area: a medium body size, long or semi-long fur, drooping or semi-erect ears, a docile character, and a great aptitude for sheep herding. Morphological studies have determined the body measurements, zoometric indices, coat color, and marking for Patagonian Sheepdogs. The objective of this investigation was to collect historical information related to the presence of this dog in Chilean Patagonia, providing general aspects of the morphology and behavior, all key factors for the recognition and conservation of this little-known herding dog. Full article

To solve the problems of DC voltage control and power allocation in the hybrid multi-terminal high voltage direct current system effectively, a DC voltage adaptive droop control strategy based on DC voltage-current characteristics is proposed. Based on adjustment of the droop coefficient of the converter station, the proposed control strategy introduces the influence factor of the droop coefficient, which considers the dynamic power margin of the converter station according to the direction of DC current variation in the converter station. When changes in the hybrid multi-terminal high voltage direct current system power flow occur, the droop coefficient of the converter station can be adjusted by the influence factor of the droop coefficient, so that the converter station can participate in power regulation according to its own power regulating ability. Consequently, the proposed control strategy can reasonably allocate the active power and minimize the deviation of the DC voltage. Besides, the stability analysis of the proposed control strategy is also carried out. Simulation results have verified the feasibility and effectiveness of the proposed control strategy. Full article

DC microgrid systems that integrate energy distribution, energy storage, and load units can be viewed as examples of reliable and efficient power systems. However, the isolated operation of DC microgrids, in the case of a power-grid failure, is a key factor limiting their development. In this paper, we analyze the six typical operation modes of an off-grid DC microgrid based on a photovoltaic energy storage system (PV-ESS), as well as the operational characteristics of the different units that comprise the microgrid, from the perspective of power balance. We also analyze the key distributed control techniques for mode transformation, based on the demands of the different modes of operation. Possible reasons for the failure of PV systems under the control of a voltage stabilizer are also explored, according to the characteristics of the PV output. Based on this information, we propose a novel control scheme for the seamless transition of the PV generation units between the maximum PV power tracking and steady voltage control processes, to avoid power and voltage oscillations. Adaptive drooping and stabilization control of the state of charge of the energy storage units are also considered, for the protection of the ESS and for reducing the possibilities of overcharging and/or over-discharging. Finally, various operation conditions are simulated using MATLAB/Simulink, to validate the performance of the proposed control strategy. Full article

Solid State Transformers (SST) are attracting considerable attention due to their great application potential in future smart grids. It is an essential technology capable of promoting the modernization of the electric power distribution system and it is considered a key element for interfacing future microgrid systems to medium voltage utility grids, allowing plug-and-play integration with multiple renewable energy sources, storage devices and DC power systems. Its main advantages in relation to conventional transformers are substantial reduction of volume and weight, fault isolation capability, voltage regulation, harmonic filtering, reactive power compensation and power factor correction. A three-stage modular cascaded topology has been considered as an adequate candidate for the SST implementation, consisting of multiple power modules with input series and output parallel connection. The modular structure presents many advantages, e.g., redundancy, flexibility, lower current harmonic content and voltage stress on the power switches, however component tolerances and mismatches between modules can lead to DC link voltage imbalance and unequal power sharing that can damage the solid state transformer. This paper proposes a decentralized strategy based on adaptive droop control capable of promoting voltage and power balance among modules of a modular cascaded SST, without relying on a communication network. The behavior of the proposed strategy is assessed through a MATLAB/Simulink simulation model of an 100 kVA SST and shows that power and voltage balance are attained through inner power distribution of the SST modules, being transparent to elements connected to the transformer input and output ports. Besides that, real-time simulation results are presented to validate the proposed control strategies. The performance of embedded algorithms is evaluated by the implementation of the SST in a real-time simulation hardware, using a Digital Signal Processor (DSP) and high level programming. Full article
