New power systems, predominantly based on renewable energy, necessitate active load-side management to effectively alleviate the pressures associated with balancing supply-side fluctuations and demand-side energy requirements. Concurrently, as power markets continue to evolve, both the energy market and ancillary services market offer valuable guidance for the optimal economic dispatch of industrial loads. Although substantial energy-saving potential exists within industrial production processes, their inherent complexity, dynamic nature, and mixed continuous–discrete modal characteristics present significant challenges in achieving accurate and efficient demand-side response. Conversely, the ongoing advancement of industrial internet techniques lays a robust technical foundation for the reliable, stable, and economically efficient operation of new power systems with large-scale industrial load response. This paper starts from the industrial load, discusses the resources and advantages and disadvantages of the industry itself, and carefully distinguishes the advantages and disadvantages of participating in the power market to make decisions. This paper provides a comprehensive review of intelligent optimization and regulation of industrial load flexibility in response to new power systems. Firstly, it synthesizes the three prevalent demand response strategies (load shedding, load shifting, and load substitution), along with their associated regulatory techniques, considering the operational characteristics of various industrial sectors. It then examines the trading strategies and modeling challenges of flexible industrial loads within two power market environments: the energy market and the ancillary services market. Subsequently, using the non-ferrous industry electrolytic process as a case study, it explores the optimization of production process parameters under energy usage planning. Finally, from the perspectives of market, technical innovation, and stakeholder engagement, it highlights the unresolved issues and provides insights into future research directions concerning the intelligent, digital, and market-driven integration of flexible industrial load flexibility. Full article

Multi-functional photovoltaic (PV) inverters incorporate ancillary services to enhance power quality and mitigate stability issues in distribution networks. These next-generation PV inverters will achieve a higher utilization of the inverter’s rated capacity, improving the cost-effectiveness of PV technology. However, the power required to perform ancillary services, such as load compensation capabilities, could exceed the inverter’s capacity, risking the components’ integrity. Therefore, multi-functional control algorithms must limit the power capacity according to the system’s nominal currents. Despite this, most control proposals do not address this issue when load balancing capabilities are included for PV inverter control. This paper proposes a flexible control strategy for three-phase multi-functional PV inverters, considering load balancing functionalities while keeping the inverter currents within safe operating limits. The proposal introduces two control parameters whose variation results in different load compensation capabilities. These parameters can be adapted dynamically according to the inverter rated capacity not used for active power injection and the load compensation requirements. Additionally, a control algorithm is proposed to limit the inverter current according to the nominal values supported by the device. This algorithm also allows setting compensation objectives following a priority scheme in which the injection of the PV active power is prioritized over the load compensation functionalities. Reactive power compensation and load balancing functionalities are also considered at a lower level of hierarchical priority. The proposal was evaluated through experimental tests on a multi-functional PV inverter prototype under various operational conditions. The experimental results show an excellent control strategy performance, achieving the control objectives under unbalanced load conditions. Full article

Grid-connected power inverters are indispensable in modern electrical systems, playing a pivotal role in enhancing the integration of renewable energies into power grids. Their significance, primarily when functioning as grid-forming inverters, extends to maintaining the grid’s inertia and strength—a distinct advancement over traditional grid-following operations. As grid-forming inverters, these devices emulate the characteristics of synchronous generators and can act as robust voltage sources, providing essential ancillary services. This behavior is particularly relevant when integrating energy storage systems on the converters’ direct current side. Among the various inverter topologies, the current source inverter (CSI) has emerged as a promising yet underexplored alternative for grid-forming applications. CSIs, when paired with their AC output filters, can effectively operate as voltage sources, utilizing control strategies that facilitate the integration of renewable energies into the electrical system. Their design inherently manages output current fluctuations, reducing the need for restrictive current limitations or additional protective measures. This paper examines the operational region of CSIs, obtained through detailed modeling, to explore their advantages, challenges, and potential for enhancing grid-connected systems. Analyzing the operating region from the converter model verifies the limits of where the converter can operate in a plane of active and reactive powers. For a small prototype model operating with 7 amperes in DC and 120 V in AC, it is possible to supply or absorb active power exceeding 1000 W and manage maximum reactive power values around 500 VAr, as determined by its operating region. Simulations also confirm that small changes in the control reference, as little as 5%, towards the region’s right limits cause significant oscillations in the dynamic control responses. This research aims to deepen our understanding of CSIs’ operational capabilities and highlight their unique benefits in advancing grid-connected systems and promoting the integration of renewable energy using this technology. Full article

Active Distribution Networks are Multi-Input Multi-Output (MIMO) systems with coupled dynamics, which cause interactions among the control loops of Distributed Energy Resources (DERs). This undesired effect leads to performance degradation of voltage control. To mitigate the effects of this unavoidable coupling, the present paper proposes a systematic design procedure based on the analysis of the interaction’s sources. In detail, each DER is equipped with a double-loop PI to control the active and reactive power output of the voltage source converter, which connects the DER to the network’s node. Furthermore, to guarantee ancillary services, the two loops are coupled by a simple mechanism of cooperation of the active power to voltage regulation realized by a filtered droop law. To achieve voltage regulation with reduced loop interactions, the PI parameters and the filter’s pulse are designed according to a procedure with two sequential steps based on the Internal Model Control (IMC) technique. Simulation studies are finally presented to demonstrate that the proposed design method achieves both reduction of the loop interaction and robust voltage control in the presence of model parameter uncertainty in the MIMO plant, modeling various operating conditions of the ADN, including a step connection of large loads, renewable energy source variations, and changes in the substation transformer ratio. Full article

Static compensators (STATCOMs) are often used in distribution systems to enhance power quality. There is a need to enhance the performance of STATCOM to optimize its utilization and facilitate the provision of additional ancillary services. This paper employs the multilayer discrete noise-eliminating second order generalized integrator (MDNESOGI) to regulate the quasi-impedance source inverter (qZSI)-STATCOM for power exchange with the grid. Compared to conventional second-order generalized integrator (SOGI), MDNESOGI exhibits a higher capability for rejecting DC offset. In instances of abnormal grid operation or system malfunction, the inclusion of DC rejection capability enhances the robustness and reliability of the system. The suggested control algorithm only requires two integrators, three mathematical operators, and a damping factor, making it far easier to implement than transformation-based methods. The distorted load current is broken down into its active and reactive components using this control mechanism. The reference currents are then calculated by multiplying these parts by their corresponding voltage standards. The DC offset is reduced and transient oscillations in the weight component are eliminated by adjusting the damping factor. The suggested algorithm effectively handles power quality tasks like (a) reducing harmonic distortion, (b) compensating for reactive power, (c) adjusting for power factor, and (d) balancing the load under different conditions in the distribution system. The experimental study results are used to examine the stability of the proposed control scheme in both static and dynamic scenarios. In addition, a comparison to traditional methods is provided to demonstrate the new method’s superiority. Experimentation results show that the suggested controller is superior to its contemporaries in all scenarios where power quality is a factor, meeting the IEEE standard requirements. Full article

The electric power system is rapidly transforming to address the urgent need for decarbonization and combat climate change. Integration of renewable energy sources into the power grid is accelerating, creating new challenges such as intermittency and uncertainty. To address these challenges, this paper proposes a new design of automatic generation control (AGC) ancillary service cost allocation based on the causer-pays rule. The proposed design treats reserves as inventory and aims to minimize them by allocating costs among consumers based on the causative factors for AGC operation. Two cost-allocation methods based on the causer-pays principle are introduced. The first method distributes costs according to the changes in loads causing ancillary service operation, while the second method considers opportunity costs. The case study on the IEEE 39 Bus System demonstrates that the proposed methods incentivize consumers to minimize volatility, resulting in reduced reserve requirements for system operation. In particular, the opportunity cost-based approach encourages loads and variable renewable energy (VRE) to actively reduce volatility, resulting in more efficient power system operation. In conclusion, the novel AGC ancillary service cost allocation methods offer a promising strategy for minimizing spinning reserves, increasing the power system’s efficiency, and incentivizing consumers to actively participate in frequency regulation for a more sustainable and reliable electricity market. Full article

This paper presents the topology and control of a photovoltaic inverter with an internal battery storage system in conjunction with droop control designed to perform ancillary services such as frequency and reactive power support (voltage regulation), active power dispatch through a proposal to control the charging and discharging of batteries and harmonic current compensation (active filter) in a microgrid connected to an IEEE 13-bus system. The converter in question consists of two stages, a 3-level NPC DC/AC converter and Boost and Buck-Boost DC/DC converters. The system in question is capable of helping to dampen frequency oscillations, as well as regulating the PCC charging curve by charging or discharging the battery bank. In addition, the proposed system is capable of supplying reactive power to the grid on a permanent basis, thus helping with voltage control. It is also capable of compensating for harmonic currents caused by non-linear loads connected to the PCC. In this context, we can see the multifunctionality of the photovoltaic inverter in helping to mitigate disturbances associated with the power quality, with the differential of charge and discharge control to preserve the useful life of the energy storage system. For this study, Matlab/Simulink software was used to implement and validate the proposed topology and control systems. In the computer simulations carried out, satisfactory results were obtained in relation to the execution of the ancillary services mentioned above, thus demonstrating the viability of the proposed strategy. Full article

Direct power generation near gas fields offers numerous benefits, including optimized economic efficiency and reduced environmental impact. Moreover, building on-site greenhouses emerges as a promising approach to further minimize carbon emissions and residual heat, greatly promoting resource utilization. However, such power plants generally have access to a weak grid due to their remote locations, and they also contain nonlinear local loads, such as the grow lights in the greenhouses. Consequently, the generation system is susceptible to power quality issues, manifested in overvoltage and harmonics. To address these issues, a smart back-to-back converter is employed to interconnect the gas turbine generator and the utility grid. This smart converter not only enhances power quality but also offers potential ancillary services that contribute to the dynamics of the gas generation system, such as damping low-frequency oscillation among parallel-connected generators. In this paper, three control configurations for the back-to-back converter are developed, enabling the coordinated regulation of exported active power, AC voltage, and DC-link voltage in either a grid-following or grid-forming manner. Furthermore, comparative studies are conducted to provide guidelines for selecting an appropriate control strategy that ensures stable operation under various short circuit ratios. A practical gas cogeneration system is chosen to evaluate the performance of the back-to-back converter, and real-time simulations based on RT-LAB are carried out to validate the effectiveness of the methodology. Full article

In order to optimize the extraction of solar energy, photovoltaic sources are commonly operated under the control of the so-called maximum power point (MPPT) strategy. However, as the rate of PV installations increases explosively, traditional MPPT algorithms may cause problems such as frequency deviation and power fluctuations, making system frequency stability a challenge due to the inherent intermittent and stochastic nature of PVs. Consequently, in order to reduce the investment and maintenance costs of storage systems, innovative control is expected for PV sources to provide ancillary services for the system, especially for weak systems such as microgrids. In this paper, a novel active power control (APC) strategy, based on characteristic curve fitting, is proposed to flexibly regulate the PV output power. The transient process performance and robustness of the system are improved with the proposed APC strategy. In conjunction, an f–P droop mechanism is designed to provide a frequency regulating (FR) service for the AC microgrid. The comprehensive control strategy unifies the FR function with the traditional MPPT function in a single control structure, allowing the PV source to operate either in the MPPT mode when the system frequency is nominal or in FR mode when the frequency exceeds it. The transition between MPPT and FR is autonomous and fully decentralized, which improves the PV generation efficiency as well as ensuring generation fairness among different parallel PV sources. Importantly, the proposed control strategy does not require any internal bundled energy within the PV generation system to achieve FR capability, but it effectively collaborates with the system-level energy storage system, thus reducing the necessary battery capacity. A detailed dynamic model of a PV generation system is constructed to validate the feasibility and effectiveness of the proposed control strategy. Full article

Future power systems with a high share of intermittent renewable energy sources (RES) in the energy portfolio will have an increasing need for active power balancing. The integration of controllable and more flexible distributed energy resources (DERs) at the distribution-grid level represents a new solution and a sustainable alternative to conventional generation units for providing balancing services to the transmission system operator (TSO). Considering that the extensive participation of DERs in ancillary services may lead to the violation of limits in the distribution network, the distribution system operator (DSO) needs to have a more active role in this process. In this paper, a framework is presented that allows the DSO, as the central coordinator of the aggregators, to participate in the balancing market (BM) as a balancing service provider (BSP). The developed mathematical model is based on the mixed-integer second-order cone programming (MISOCP) approach and allows for determination of the limits of active power flexibility at the point of the TSO–DSO connection, formation of the dependence of the price/quantity curve, and achievement of the optimal dispatch of each DER after clearing the balancing market. The simulation results are presented and verified on modified IEEE distribution networks. Full article

The advent of distributed renewable energy sources (DRESs) has led to the progressive transformation of traditional distribution networks to active components of the power system. This transformation, however, may jeopardize the reliable grid operation due to the advent of new technical problems, such as network overloading, over-/under-voltage events, abnormal frequency deviation and dynamic instability. In this challenging scenery, the installation of a modern measuring infrastructure has created new sources of data and information that facilitate the provision of ancillary services (ASs) via measurement-based analysis. The ACTIVATE (ancillary services in active distribution networks based on monitoring and control techniques) project aims to design innovative AS solutions for power system operators. These solutions aim to tackle the technical issues emerged by the ever-increasing DRES penetration and their volatile nature. In this context, in ACTIVATE, a holistic system is proposed comprising centralized and decentralized control features to enhance the overall network performance. Additionally, a network monitoring system is designed to support a number of online and offline dynamic analysis applications by exploiting measurements obtained at the transmission, primary and secondary distribution network. This paper presents a validation of the overall system, which is performed by using simulation and power-hardware-in-the-loop results in combined transmission and distribution network models. Full article

The increasing rate of renewable energy penetration in modern power grids has prompted updates to the regulations, standards, and grid codes requiring ancillary services provided by photovoltaic-generating units similar to those applied to conventional generating units. In this work, a comprehensive survey presents a comparison of requirements related to voltage ride through reactive current injection/absorption; active power restoration; frequency stability regulation and active power control; voltage regulation and reactive power control; and the energy quality requisites included in the standards and grid codes of countries around the globe. The survey can be used to observe the differences between the requirements established in the grid codes depending on the power system operating characteristics, development of technology, and renewable energy penetration level. Many of these factors determine the parameters used to establish requisites for different grid codes, making a global standardization of the renewable energy interconnection requirements much harder. Full article

This paper presents a hierarchical cyber-physical multi-agent model for an AC microgrid (MG). A new distributed finite-time secondary controller is designed in the provision of ancillary services, such as voltage and frequency synchronization and active and reactive power regulation. The control algorithm developed is fully distributed and intended to restore the system voltage and frequency to their nominal value finite time. The existing distributed controllers achieve a consensus in an infinite-time horizon, whereas the proposed control provides a quick convergence to a consensus even in the face of disturbances and restores the voltage and frequency in less than 0.25 s. For accurate active and reactive power regulation, a distributed control algorithm is proposed that corrects the power mismatch among neighboring distributed generator units and eventually for the entire MG network. A Lyapunov analysis is used to establish the upper limit on the convergence time. The proposed control scheme is evaluated and compared with the previously reported asymptotic control technique based on a neighborhood tracking error using time-domain simulations under load variation and communication constraints. The controller withstands a communication link delay up to 2 s with a small deviation and settles down to the nominal values within 0.4 s. Further, the convergence analysis shows that the performance of the proposed algorithm depends exclusively on the controller parameters and communication network connectivity, not on the line and load parameters of the AC MG. The proposed controller enables the plug-and-play capability of the AC MG and effectively reduces the load change-induced disturbance. Full article

In addition to active power generation, photovoltaic inverters can be used to provide ancillary services to grids, including reactive power compensation. This paper proposes a metaheuristic approach based on particle swarm optimization for the allocation and sizing of photovoltaic inverters that perform the complementary functions of static synchronous compensator (PV-STATCOM) units. The objective of the aforementioned approach is to reduce the initial investment cost in the acquisition of PV-STATCOM units. The proposed methodology considers both the daily load curve and generation and is applied to a 33-bus test system. The methodology is validated based on an exhaustive search algorithm and tested over 1000 consecutive simulations for the same problem; consequently, the methodology produces low standard deviations and errors, indicating its robustness. The methodology demonstrates an improved grid voltage profile throughout the day when applied to the 33-bus test system. Furthermore, the photovoltaic inverter efficiently performs its main function of active power generation. As a major contribution, the proposed methodology may assist investors in determining the allocation and sizing of PV-STATCOM units to perform the ancillary service of reactive power compensation in grids Full article

The gradual displacement of conventional generation from the energy mix to give way to renewable energy sources represents a paradigm shift in the operation of future power systems: on the one hand, renewable technologies are, in general, volatile and difficult to predict; and on the other hand, they are usually connected to the grid through electronic power converters. This decoupling due to power converters means that renewable generators lack the natural response that conventional generation has to the imbalances between demand and generation that occur during the regular operation of power systems. Renewable generators must, therefore, provide a series of complementary services for the correct operation of power systems in addition to producing the necessary amount of energy. This paper presents an overview of existing methods in the literature that allow photovoltaic generators to participate in the provision of ancillary services, focusing on solutions based on power curtailment by modifying the traditional maximum power point tracking algorithm. Full article
