When a CMOS (Complementary Metal–Oxide–Semiconductor) imaging system operates at a high frame rate or a high line rate, the exposure time of the imaging system is limited, and the acquired image data will be dark, with a low signal-to-noise ratio and unsatisfactory sharpness. Therefore, in order to improve the visibility and signal-to-noise ratio of remote sensing images based on CMOS imaging systems, this paper proposes a low-light remote sensing image enhancement method and a corresponding ZYNQ (Zynq-7000 All Programmable SoC) design scheme called the BGIR (Bilateral-Guided Image Restoration) algorithm, which uses an improved multi-scale Retinex algorithm in the HSV (hue–saturation–value) color space. First, the RGB image is used to separate the original image’s H, S, and V components. Then, the V component is processed using the improved algorithm based on bilateral filtering. The image is then adjusted using the gamma correction algorithm to make preliminary adjustments to the brightness and contrast of the whole image, and the S component is processed using segmented linear enhancement to obtain the base layer. The algorithm is also deployed to ZYNQ using ARM + FPGA software synergy, reasonably allocating each algorithm module and accelerating the algorithm by using a lookup table and constructing a pipeline. The experimental results show that the proposed method improves processing speed by nearly 30 times while maintaining the recovery effect, which has the advantages of fast processing speed, miniaturization, embeddability, and portability. Following the end-to-end deployment, the processing speeds for resolutions of 640 × 480 and 1280 × 720 are shown to reach 80 fps and 30 fps, respectively, thereby satisfying the performance requirements of the imaging system. Full article

The increasing complexity of algorithms in embedded applications has amplified the demand for high-performance computing. Heterogeneous embedded systems, particularly FPGA-based systems-on-chip (SoCs), enhance execution speed by integrating hardware accelerator intellectual property (IP) cores. However, traditional low-level IP-core design presents significant challenges. High-level synthesis (HLS) offers a promising alternative, enabling efficient FPGA development through high-level programming languages. Yet, effective methodologies for designing and evaluating heterogeneous FPGA-based SoCs remain crucial. This study surveys HLS tools and design concepts and presents the development of the AHA IP cores, a set of five benchmarking accelerators for rapid Zynq-based SoC evaluation. These accelerators target compute-intensive tasks, including matrix multiplication, Fast Fourier Transform (FFT), Advanced Encryption Standard (AES), Back-Propagation Neural Network (BPNN), and Artificial Neural Network (ANN). We establish a streamlined design flow using AMD-Xilinx tools for rapid prototyping and testing FPGA-based heterogeneous platforms. We outline criteria for selecting algorithms to improve speed and resource efficiency in HLS design. Our performance evaluation across various configurations highlights performance–resource trade-offs and demonstrates that ANN and BPNN achieve significant parallelism, while AES optimization increases resource utilization the most. Matrix multiplication shows strong optimization potential, whereas FFT is constrained by data dependencies. Full article

We developed a license plate recognition platform based on the Zynq-7000 SoC. A field-programmable gate array (FPGA) was used to build a low-power, high-speed neural network. The system leveraged the ARM processor for initial image processing and used standard license plate characters as a training dataset. After filtering and processing, the images were resized to 28 × 28 pixels in the grayscale format and then transmitted to the FPGA for high-speed recognition. The digital circuit in the FPGA was implemented using Verilog in a deep learning neural network architecture, with the neurons configured as (57, 12, 57, 36) in a hidden layer. The model was trained for 60 epochs. The neural network was also trained with a dataset consisting of 26 English alphabet characters and 10 digits, augmented using image dilation and erosion. Recognition accuracy was 83.33%. Using Vivado, the system was successfully deployed on the Zynq-7000 SoC, demonstrating its potential in intelligent applications. Full article

Tree crown detection of high-resolution UAV forest remote sensing images using computer technology has been widely performed in the last ten years. In forest resource inventory management based on remote sensing data, crown detection is the most important and essential part. Deep learning technology has achieved good results in tree crown segmentation and species classification, but relying on high-performance computing platforms, edge calculation, and real-time processing cannot be realized. In this thesis, the UAV images of coniferous Pinus tabuliformis and broad-leaved Salix matsudana collected by Jingyue Ecological Forest Farm in Changping District, Beijing, are used as datasets, and a lightweight neural network U-Net-Light based on U-Net and VGG16 is designed and trained. At the same time, the IP core and SoC architecture of the neural network accelerator are designed and implemented on the Xilinx ZYNQ 7100 SoC platform. The results show that U-Net-light only uses 1.56 MB parameters to classify and segment the crown images of double tree species, and the accuracy rate reaches 85%. The designed SoC architecture and accelerator IP core achieved 31 times the speedup of the ZYNQ hard core, and 1.3 times the speedup compared with the high-end CPU (Intel CoreTM i9-10900K). The hardware resource overhead is less than 20% of the total deployment platform, and the total on-chip power consumption is 2.127 W. Shorter prediction time and higher energy consumption ratio prove the effectiveness and rationality of architecture design and IP development. This work departs from conventional canopy segmentation methods that rely heavily on ground-based high-performance computing. Instead, it proposes a lightweight neural network model deployed on FPGA for real-time inference on unmanned aerial vehicles (UAVs), thereby significantly lowering both latency and system resource consumption. The proposed approach demonstrates a certain degree of innovation and provides meaningful references for the automation and intelligent development of forest resource monitoring and precision agriculture. Full article

Breast cancer detection is a critical task in healthcare, requiring fast, accurate, and efficient diagnostic tools. However, the high computational demands and latency of deep learning models in medical imaging present significant challenges, especially in resource-constrained environments. This paper addresses these challenges by presenting an FPGA hardware accelerator tailored for breast cancer classification, leveraging the Zynq XC7Z020 SoC. The system integrates FPGA-accelerated layers with an ARM Cortex-A9 processor to optimize both performance and resource efficiency. We developed modular IP cores, including Conv2D, Average Pooling, and ReLU, using Vivado HLS to maximize FPGA resource utilization. By adopting 8-bit fixed-point arithmetic, the design achieves a 15.8% reduction in execution time compared to traditional CPU-based implementations while maintaining high classification accuracy. Additionally, our optimized approach significantly enhances energy efficiency, reducing power consumption from 3.8 W to 1.4 W a 63.15% reduction. This improvement makes our design highly suitable for real-time, power-sensitive applications, particularly in embedded and edge computing environments. Furthermore, it underscores the scalability and efficiency of FPGA-based AI solutions for healthcare diagnostics, enabling faster and more energy-efficient deep learning inference on resource-constrained devices. Full article

With the rapid development of lightweight network models and efficient hardware deployment techniques, the demand for real-time semantic segmentation in areas such as autonomous driving and medical image processing has increased significantly. However, realizing efficient semantic segmentation on resource-constrained embedded platforms still faces many challenges. As a classical lightweight semantic segmentation network, ENet has attracted much attention due to its low computational complexity. In this study, we optimize the ENet semantic segmentation network to significantly reduce its computational complexity through structural simplification and 8-bit quantization and improve its hardware compatibility through the optimization of on-chip data storage and data transfer while maintaining 51.18% mIoU. The optimized network is successfully deployed on hardware accelerator and SoC systems based on Xilinx ZYNQ ZCU104 FPGA. In addition, we optimize the computational units of transposed convolution and dilated convolution and improve the on-chip data storage and data transfer design. The optimized system achieves a frame rate of 130.75 FPS, which meets the real-time processing requirements in areas such as autonomous driving and medical imaging. Meanwhile, the power consumption of the accelerator is 3.479 W, the throughput reaches 460.8 GOPS, and the energy efficiency reaches 132.2 GOPS/W. These results fully demonstrate the effectiveness of the optimization and deployment strategies in achieving a balance between computational efficiency and accuracy, which makes the system well suited for resource-constrained embedded platform applications. Full article

Electromyography (EMG) signals are fundamental in neurorehabilitation as they provide a non-invasive means of capturing the electrical activity of muscles, enabling precise detection of motor intentions. This capability is essential for controlling assistive devices, such as therapeutic exoskeletons, that aim to restore mobility and improve motor function in patients with neuromuscular impairments. The integration of EMG into neurorehabilitation systems allows for adaptive and patient-specific interventions, addressing the variability in motor recovery needs. However, achieving the high fidelity, low latency, and robustness required for real-time control of these devices remains a significant challenge. This paper introduces a novel multi-channel electromyography (EMG) acquisition system implemented on a System-on-Chip (SoC) architecture for robotic neurorehabilitation. The system employs the Zynq-7000 SoC, which integrates an Advanced RISC Machine (ARM) processor, for high-level control and an FPGA for real-time signal processing. The architecture enables precise synchronization of up to eight EMG channels, leveraging high-speed analog-to-digital conversion and advanced filtering techniques implemented directly at the measurement site. By performing filtering and initial signal processing locally, prior to transmission to other subsystems, the system minimizes noise both through optimized processing and by reducing the distance to the muscle, thereby significantly enhancing the signal-to-noise ratio (SNR). A dedicated communication interface ensures low-latency data transfer to external controllers, crucial for adaptive control loops in exoskeletal applications. Experimental results validate the system’s capability to deliver high signal fidelity and low processing delays, outperforming commercial alternatives in terms of flexibility and scalability. This implementation provides a robust foundation for real-time bio-signal processing, advancing the integration of EMG-based control in neurorehabilitation devices. Full article

Drowsiness detection is crucial for ensuring the safety of individuals engaged in high-risk activities. Numerous studies have explored drowsiness detection techniques based on EEG signals, but these have typically been validated on computers, which limits their portability. In this paper, we introduce the design and implementation of a drowsiness detection technique utilizing EEG signals, executed on a Zynq7020 System on Chip (SoC) as part of a Pynq-Z2 module. This approach is more suitable for portable applications. We have implemented the Discrete Wavelet Transform (DWT) and feature extraction functions as intellectual property (IP) cores, while other functions run on the ARM processor of the Zynq7020. Full article

Marine diesel engines are the preferred power equipment for ships and are the most important component among the numerous electromechanical devices on board. Accidents involving these engines can potentially cause immeasurable damage to the vessel, making fault detection in marine diesel engines crucial. This design enables the detection and reporting of faults in marine diesel engines at the earliest possible time through the computation of convolutional neural networks, which is of great significance for ensuring the safe navigation of ships. For this functionality, the Xilinx ZYNQ-7000 XC7Z010 is selected as the main control chip, and the LoRa wireless network is used as the transmission module. The FreeRTOS embedded operating system is ported, with sensor data collection completed on the PS side of the ZYNQ chip and algorithm acceleration calculations on the PL side. Data are then transmitted to the host computer via the LoRa module paired with a custom protocol. Experimental test results show that the program provides stable data transmission, with each module of the algorithm generally accelerating by more than 95% and an accuracy rate of 92.86%. Additionally, the host computer can display the received data in real time. The custom protocol’s header also allows for precise judgments about the completeness and origin of messages, facilitating the expansion of other SOC’s message uplink and the host computer’s message downlink. Full article

Robotic exploration in dynamic and complex environments requires advanced adaptive mapping strategies to ensure accurate representation of the environments. This paper introduces an innovative grid flex-graph exploration (GFGE) algorithm designed for single-robot mapping. This hardware-scheme-based algorithm leverages a combination of quad-grid and graph structures to enhance the efficiency of both local and global mapping implemented on a field-programmable gate array (FPGA). This novel research work involved using sensor fusion to analyze a robot’s behavior and flexibility in the presence of static and dynamic objects. A behavior-based grid construction algorithm was proposed for the construction of a quad-grid that represents the occupancy of frontier cells. The selection of the next exploration target in a graph-like structure was proposed using partial reconfiguration-based frontier-graph exploration approaches. The complete exploration method handles the data when updating the local map to optimize the redundant exploration of previously explored nodes. Together, the exploration handles the quadtree-like structure efficiently under dynamic and uncertain conditions with a parallel processing architecture. Integrating several algorithms into indoor robotics was a complex process, and a Xilinx-based partial reconfiguration approach was used to prevent computing difficulties when running many algorithms simultaneously. These algorithms were developed, simulated, and synthesized using the Verilog hardware description language on Zynq SoC. Experiments were carried out utilizing a robot based on a field-programmable gate array (FPGA), and the resource utilization and power consumption of the device were analyzed. Full article

Event-driven data acquisition is used to capture information from fast transient phenomena typically requiring a high sampling speed. This is an important requirement in the ITER Neutral Beam Test Facility for the development of one of the heating systems of the ITER nuclear fusion experiment. The Red Pitaya board has been chosen for this project because of its versatility and low cost. Versatility is provided by the hosted Zynq System on Chip (SoC), which allows full configuration of the module architecture and the OpenSource architecture of Red Pitaya. Price is an important factor, because the boards are installed in a hostile environment where devices can be damaged by EMI and radiation. A flexible solution for event-driven data acquisition has been developed in the Zynq SoC and interfaced to the Linux-based embedded ARM processor. It has been successfully adopted in a variety of data acquisition applications in the test facility. Full article

High repetition rate lidar is typically equipped with a low-energy, high repetition rate laser, and small aperture telescopes. Therefore, it is small, compact, low-cost, and can be networked for observation. However, its data acquisition and control functions are generally not specially designed, and the data acquisition, storage, and control programs need to be implemented on an IPC (Industrial Personal Computer), which increases the complexity and instability of the lidar system. Therefore, this paper designs an integrated off-line echo signal acquisition system (IOESAS) for lidar developed based on SoC FPGA (System-On-Chip Field Programmable Gate Array). Using a hardware–software co-design approach, the system is implemented in a heterogeneous multi-core chip ZYNQ-7020 (integrated FPGA and ARM). The FPGA implements dual-channel echo data acquisition (gated counting and hardware accumulation). At the same time, the ARM performs laser control and monitoring, laser pointing control, pulse energy monitoring, data storage, and wireless transmission. Offline data acquisition and control software was developed based on LabVIEW, which can remotely control the status of the lidar and download the echo data stored in IOESAS. To verify the performance of the data acquisition system, IOESAS was compared with the photon counting card P7882 and MCS-PCI, respectively. The test results show that they are in good agreement; the linear correlation coefficients were 0.99967 and 0.99884, respectively. IOESAS was installed on lidar outdoors for continuous detection, and the system was able to work independently and stably in different weather conditions, and control functions were tested normally. The gating delay and gating width time jitter error are ±5 ns and ±2 ns, respectively. The IOESAS is now used in several small lidars for networked observations. Full article

In positron emission tomography (PET), parallax errors degrade spatial resolution. The depth of interaction (DOI) information provides the position in the depth of the scintillator interacting with the γ-rays, thus reducing parallax errors. A previous study developed a Peak-to-Charge discrimination (PQD), which can separate spontaneous alpha decay in LaBr₃:Ce. Since decay constant of GSO:Ce depends on Ce concentration, the PQD is expected to discriminate GSO:Ce scintillators with different Ce concentration. In this study, the PQD-based DOI detector system was developed, which can be processed online and implemented in PET. A detector was composed of four layers of GSO:Ce crystals and a PS-PMT. The four crystals were obtained from both the top and bottom of ingots with a nominal Ce concentration of 0.5 mol% and 1.5 mol%. The PQD was implemented on the Xilinx Zynq-7000 SoC board with 8ch Flash ADC to gain real-time processing, flexibility, and expandability. The results showed that the mean Figure of Merits in 1D between four scintillators are 1.5, 0.99, 0.91 for layers between 1st–2nd, 2nd–3rd, and 3rd–4th respectively, and the mean Error Rate in 1D between four scintillators are 3.50%, 2.96%, 13.3%, and 1.88% for layers 1, 2, 3, and 4, respectively. In addition, the introduction of the 2D PQDs resulted in the mean Figure of Merits in 2D greater than 0.9 and the mean Error Rate in 2D less than 3% in all layers. Full article

The continuous scaling of electronic components has led to the development of high-performance microprocessors that are suitable even for safety-critical applications where radiation-induced errors such as Single Event Effects (SEEs) can have a significant impact on the performance and reliability of the system. This work is dedicated to investigating the reliability of systems based on programmable hardware and Real-time operating Systems (RTOS) in the presence of architectural faults induced by soft errors in the configuration memory of the programmable hardware. We performed a proton radiation test campaigned at PSI radiation facility to identify the fault model affecting the configuration memory of Xilinx Zynq-7020 reconfigurable AP-Soc Device. The identified fault model in terms of SEU and MBU clusters has been used to evaluate the impact of proton-induced faults on applications running within FreeRTOS on a Microblaze soft processor. A Single Event Multiple Upset fault model resulting from a proton test is presented, focusing on characteristics such as shape, size, and frequency of observed cluster of errors. We conduct two fault injection campaigns and analyze the results to assess the effect of cluster size on system reliability. Moreover, we discuss software exceptions caused by faults that can affect the hardware structure of the soft processor. Full article

This study proposes a heterogeneous hardware-based framework for network intrusion detection using lightweight artificial neural network models. With the increase in the volume of exchanged data, IoT networks’ security has become a crucial issue. Anomaly-based intrusion detection systems (IDS) using machine learning have recently gained increased popularity due to their generation’s ability to detect unseen attacks. However, the deployment of anomaly-based AI-assisted IDS for IoT devices is computationally expensive. A high-performance and ultra-low power consumption anomaly-based IDS framework is proposed and evaluated in this paper. The framework has achieved the highest accuracy of 98.57% and 99.66% on the UNSW-NB15 and IoT-23 datasets, respectively. The inference engine on the MAX78000EVKIT AI-microcontroller is 11.3 times faster than the Intel Core i7-9750H 2.6 GHz and 21.3 times faster than NVIDIA GeForce GTX 1650 graphics cards, when the power drawn was 18mW. In addition, the pipelined design on the PYNQ-Z2 SoC FPGA board with the Xilinx Zynq xc7z020-1clg400c device is optimised to run at the on-chip frequency (100 MHz), which shows a speedup of 53.5 times compared to the MAX78000EVKIT. Full article
