Search Results (19)

As the rapid expansion of future mobility systems increases, along with the demand for fast and accurate X-ray security inspections, deep neural network (DNN)-based systems have gained significant attention for detecting prohibited items by constructing high-quality datasets and enhancing detection performance. While Generative AI has been widely explored across various fields, its application in DNN-based X-ray security inspection remains largely underexplored. The accessibility of commercial Generative AI raises safety concerns about the creation of new prohibited items, highlighting the need to integrate synthetic X-ray images into DNN training to improve detection performance, adapt to emerging threats, and investigate its impact on object detection. To address this, we propose a novel machine learning framework that enhances DNN-based X-ray security inspection by integrating real-world X-ray images with Generative AI images utilizing a commercial text-to-image model, improving dataset diversity and detection accuracy. Our proposed framework provides an effective solution to mitigate potential security threats posed by Generative AI, significantly improving the reliability of DNN-based X-ray security inspection systems, as verified through comprehensive evaluations. Full article

Cosmic ray muon tomography is a promising method for the non-invasive inspection of shipping containers and trucks. It leverages the highly penetrating cosmic muons and their interactions with various materials to generate three-dimensional images of large and dense objects, such as inter-modal shipping containers, which are typically opaque to conventional X-ray radiography techniques. One of the key tasks of customs and border security is verifying shipping container declarations to prevent illegal trafficking, and muon tomography offers a viable solution for this purpose. Common imaging methods using muons rely on data analysis of either muon scattering or absorption–transmission. We design a compact muon tomography system with dimensions of 3 × 3 × 3 m³, consisting of 2D position-sensitive detectors. These detectors include plastic scintillators, wavelength-shifting (WLS) fibers, and SiPMs. Through light transport modeling with GEANT4, we demonstrate that the proposed detector design—featuring 1 m × 1 m scintillator plates with 2 mm² square-shaped WLS fibers—can achieve a spatial resolution of approximately 0.7–1.0 mm. Through Monte Carlo simulations, we demonstrate that combining muon scattering and absorption data enables the rapid and accurate identification of cargo materials. In a smuggling scenario where tobacco is falsely declared as paper towel rolls, this combined analysis distinguishes the two with 3 $\sigma$ confidence at a spatial resolution of 1 mm (FWHM) for the muon detector, achieving results within a scanning time of 40 s for a 20-foot shipping container. Full article

X-ray images typically contain complex background information and abundant small objects, posing significant challenges for object detection in security tasks. Most existing object detection methods rely on complex networks and high computational costs, which poses a challenge to implement lightweight models. This article proposes Fine-YOLO to achieve rapid and accurate detection in the security domain. First, a low-parameter feature aggregation (LPFA) structure is designed for the backbone feature network of YOLOv7 to enhance its ability to learn more information with a lighter structure. Second, a high-density feature aggregation (HDFA) structure is proposed to solve the problem of loss of local details and deep location information caused by the necked feature fusion network in YOLOv7-Tiny-SiLU, connecting cross-level features through max-pooling. Third, the Normalized Wasserstein Distance (NWD) method is employed to alleviate the convergence complexity resulting from the extreme sensitivity of bounding box regression to small objects. The proposed Fine-YOLO model is evaluated on the EDS dataset, achieving a detection accuracy of 58.3% with only 16.1 M parameters. In addition, an auxiliary validation is performed on the NEU-DET dataset, the detection accuracy reaches 73.1%. Experimental results show that Fine-YOLO is not only suitable for security, but can also be extended to other inspection areas. Full article

Microelectronics and electronic products are integral to our increasingly connected world, facing constant challenges in terms of quality, security, and provenance. As technology advances and becomes more complex, the demand for automated solutions to verify the quality and origin of components assembled on printed circuit boards (PCBs) is skyrocketing. This paper proposes an innovative approach to detecting and classifying microelectronic components with impressive accuracy and reliability, paving the way for a more efficient and safer electronics industry. Our approach introduces significant advancements by integrating optical and X-ray imaging, overcoming the limitations of traditional methods that rely on a single imaging modality. This method uses a novel data fusion technique that enhances feature visibility and detectability across various component types, crucial for densely packed PCBs. By leveraging the WaferCaps capsule network, our system improves spatial hierarchy and dynamic routing capabilities, leading to robust and accurate classifications. We employ decision-level fusion across multiple classifiers trained on different representations—optical, X-ray, and fused images—enhancing accuracy by synergistically combining their predictive strengths. This comprehensive method directly addresses challenges surrounding concurrency, reliability, availability, and resolution in component identification. Through extensive experiments, we demonstrate that our approach not only significantly improves classification metrics but also enhances the learning and identification processes of PCB components, achieving a remarkable total accuracy of 95.2%. Our findings offer a substantial contribution to the ongoing development of reliable and accurate automatic inspection solutions in the electronics manufacturing sector. Full article

This study addresses the field of X-ray security screening and focuses on synthesising realistic X-ray images using advanced generative models. Insufficient training data in this area pose a major challenge, which we address through innovative data augmentation techniques. We utilise the power of generative adversarial networks (GANs) and conditional GANs (cGANs), in particular the Pix2Pix and Pix2PixHD models, to investigate the generation of X-ray images from various inputs such as masks and edges. Our experiments conducted on a Korean dataset containing dangerous objects relevant to security screening show the effectiveness of these models in improving the quality and realism of image synthesis. Quantitative evaluations based on metrics such as PSNR, SSIM, LPIPS, FID, and FSIM, with scores of 19.93, 0.71, 0.12, 29.36, and 0.54, respectively, show the superiority of our strategy, especially when integrated with hybrid inputs containing both edges and masks. Overall, our results highlight the potential of advanced generative models to overcome the challenges of data scarcity in X-ray security screening and pave the way for more efficient and accurate inspection systems. Full article

In response to the problems of complex background, multi-scale dangerous goods and severe stacking in X-ray security images, this paper proposes a high-accuracy dangerous goods detection algorithm for X-ray security images based on the improvement of YOLOv7. Firstly, by combining the coordinate attention mechanism, the downsampling structure of the backbone network is improved to enhance the model’s target feature localization ability. Secondly, a weighted bidirectional feature pyramid network is used as the feature fusion structure to achieve multi-scale feature weighted fusion and further simplify the network. Then, combined with dynamic snake convolution, a downsampling structure was designed to facilitate the extraction of features at different scales, providing richer feature representations. Finally, drawing inspiration from the idea of group convolution and combining it with Conv2Former, a feature extraction module called a multi-convolution transformer (MCT) was designed to enhance the network’s feature extraction ability by combining multi-scale information. The improved YOLOv7 in this article was tested on the public datasets SIXRay, CLCXray, and PIDray. The average detection accuracy (mAP) of the improved model was 96.3%, 79.3%, and 84.7%, respectively, which was 4.7%, 2.7%, and 3.1% higher than YOLOv7. This proves the effectiveness and universality of the method proposed in this article. Compared to the current mainstream X-ray image dangerous goods detection models, this model effectively reduces the false detection rate of dangerous goods in X-ray security inspection images and has achieved significant improvement in the detection of small and multi-scale targets, achieving higher accuracy in dangerous goods detection. Full article

Identifying the classes and locations of prohibited items is the target of security inspection. However, X-ray security inspection images with insufficient feature extraction, imbalance between easy and hard samples, and occlusion lead to poor detection accuracy. To address the above problems, an object-detection method based on YOLOv8 is proposed. Firstly, an ASFF (adaptive spatial feature fusion) and a weighted feature concatenation algorithm are introduced to fully extract the scale features from input images. In this way, the model can learn further details in training. Secondly, CoordAtt (coordinate attention module), which belongs to the hybrid attention mechanism, is embedded to enhance the learning of features of interest. Then, the slide loss function is introduced to balance the simple samples and the difficult samples. Finally, Soft-NMS (non-maximum suppression) is introduced to resist the conditions containing occlusion. The experimental result shows that mAP (mean average precision) achieves 90.2%, 90.5%, 79.1%, and 91.4% on the Easy, Hard, and Hidden sets of the PIDray and SIXray public test set, respectively. Contrasted with original model, the mAP of our proposed YOLOv8n model increased by 2.7%, 3.1%, 9.3%, and 2.4%, respectively. Furthermore, the parameter count of the modified YOLOv8n model is roughly only 3 million. Full article

Using X-ray imaging in security inspections is common for the detection of objects. X-ray security images have strong texture and RGB features as well as the characteristics of background clutter and object overlap, which makes X-ray imaging very different from other real-world imaging methods. To better detect prohibited items in security X-ray images with these characteristics, we propose EM-YOLOv7, which is composed of both an edge feature extractor (EFE) and a material feature extractor (MFE). We used the Soft-WIoU NMS method to solve the problem of object overlap. To better extract features, the attention mechanism CBAM was added to the backbone. According to the results of several experiments on the SIXray dataset, our EM-YOLOv7 method can better complete prohibited-item-detection tasks during security inspection with detection accuracy that is 4% and 0.9% higher than that of YOLOv5 and YOLOv7, respectively, and other SOTA models. Full article

X-ray package security check systems are widely used in public places, but they face difficulties in accurately detecting prohibited items due to the stacking and diversity of shapes of the objects inside the luggage, posing a threat to personal safety in public places. The existing methods for X-ray image object detection suffer from low accuracy and poor generalization, mainly due to the lack of large-scale and high-quality datasets. To address this gap, a novel large-scale X-ray image dataset for object detection, LSIray, is provided, consisting of high-quality X-ray images of luggage and objects of 21 types and sizes. LSIray covers some common categories that were neglected in previous research. The dataset provides more realistic and rich data resources for X-ray image object detection. To address the problem of poor security inspection, an improved model based on YOLOv8 is proposed, named SC- YOLOv8, consisting of two new modules: CSPnet Deformable Convolution Network Module (C2F_DCN) and Spatial Pyramid Multi-Head Attention Module (SPMA). C2F_DCN uses deformable convolution, which can adaptively adjust the position and shape of the receptive field to accommodate the diversity of targets. SPMA adopts the spatial pyramid head attention mechanism, which can utilize feature information from different scales and perspectives to enhance the representation ability of targets. The proposed method is evaluated through extensive experiments using the LSIray dataset and comparisons with the existing methods. The results show that the method surpasses the state-of-the-art methods on various indicators. Experimenting using the LSIray dataset and the OPIXray dataset, our SC-YOlOv8 model achieves 82.7% and 89.2% detection accuracies, compared to the YOLOv8 model, which is an improvement of 1.4% and 1.2%, respectively. The work not only provides valuable data resources, but also offers a novel and effective solution for the X-ray image security check problem. Full article

Aiming at the problems of multi-scale and serious overlap of dangerous goods in X-ray security-inspection-image samples, an X-ray dangerous-goods-detection algorithm with high detection accuracy is designed based on the improvement of YOLOv4. Using deformable convolution to redesign YOLOv4’s path-aggregation-network (PANet) module, deformable convolution can flexibly change its receptive field based on the shape of the detected object. When the high-level information and low-level information are fused in the PANet module, deformable convolution is used to align features, which can effectively improve the detection accuracy. Then, the Focal-EIOU loss function is introduced, which can solve the problem of the CIOU loss function being prone to causing severe loss-value oscillation when dealing with low-quality samples. During training, the network can converge more quickly and the detection accuracy can be slightly improved. Finally, Soft-NMS was used to improve the non-maximum suppression of YOLOv4, effectively solving the problem of the high overlap rate of hazardous materials in the X-ray security-inspection dataset and improving accuracy. On the SIXRay dataset, this model detected 95.73%, 83.00%, 82.95%, 85.13%, and 80.74% AP for guns, knives, wrenches, pliers, and scissors, respectively, and the detected mAP reached 85.51%. The proposed model can effectively reduce the false-detection rate of dangerous goods in X-ray security images and improve the detection ability of small targets. Full article

In recent years, automatic detection of threats in X-ray baggage has become important in security inspection. However, the training of threat detectors often requires extensive, well-annotated images, which are hard to procure, especially for rare contraband items. In this paper, a few-shot SVM-constraint threat detection model, named FSVM is proposed, which aims at detecting unseen contraband items with only a small number of labeled samples. Rather than simply finetuning the original model, FSVM embeds a derivable SVM layer to back-propagate the supervised decision information into the former layers. A combined loss function utilizing SVM loss is also created as the additional constraint. We have evaluated FSVM on the public security baggage dataset SIXray, performing experiments on 10-shot and 30-shot samples under three class divisions. Experimental results show that compared with four common few-shot detection models, FSVM has the highest performance and is more suitable for complex distributed datasets (e.g., X-ray parcels). Full article

Halide perovskite has remarkable optoelectronic properties, such as high atomic number, large carrier mobility-lifetime product, high X-ray attenuation coefficient, and simple and low-cost synthesis process, and has gradually developed into the next-generation X-ray detection materials. Halide perovskite-based X-ray detectors can improve the sensitivity and reduce the detectable X-ray dose, which is applied in imaging, nondestructive industrial inspection, security screening, and scientific research. In this article, we introduce the fabrication methods of halide perovskite film and the classification and progress of halide perovskite-based X-ray detectors. Finally, the existing challenges are discussed, and the possible directions for future applications are explored. We hope this review can stimulate the further improvement of perovskite-based X-ray detectors. Full article

X-ray security inspection processes have a low degree of automation, long detection times, and are subject to misjudgment due to occlusion. To address these problems, this paper proposes a multi-objective intelligent recognition method for X-ray images based on the YOLO deep learning network and an optimized transformer structure (YOLO-T). We also construct the GDXray-Expanded X-ray detection dataset, which contains multiple types of dangerous goods. Using this dataset, we evaluated several versions of the YOLO deep learning network model and compared the results to those of the proposed YOLO-T model. The proposed YOLO-T method demonstrated higher accuracy for multitarget and hidden-target detection tasks. On the GDXray-Expanded dataset, the maximum mAP of the proposed YOLO-T model was 97.73%, which is 7.66%, 16.47%, and 7.11% higher than that obtained by the YOLO v2, YOLO v3, and YOLO v4 models, respectively. Thus, we believe that the proposed YOLO-T network has good application prospects in X-ray security inspection technologies. In all kinds of security detection scenarios using X-ray security detectors, the model proposed in this paper can quickly and accurately identify dangerous goods, which has broad application value. Full article

X-ray imaging machines are widely used in border control checkpoints or public transportation, for luggage scanning and inspection. Recent advances in deep learning enabled automatic object detection of X-ray imaging results to largely reduce labor costs. Compared to tasks on natural images, object detection for X-ray inspection are typically more challenging, due to the varied sizes and aspect ratios of X-ray images, random locations of the small target objects within the redundant background region, etc. In practice, we show that directly applying off-the-shelf deep learning-based detection algorithms for X-ray imagery can be highly time-consuming and ineffective. To this end, we propose a Task-Driven Cropping scheme, dubbed TDC, for improving the deep image detection algorithms towards efficient and effective luggage inspection via X-ray images. Instead of processing the whole X-ray images for object detection, we propose a two-stage strategy, which first adaptively crops X-ray images and only preserves the task-related regions, i.e., the luggage regions for security inspection. A task-specific deep feature extractor is used to rapidly identify the importance of each X-ray image pixel. Only the regions that are useful and related to the detection tasks are kept and passed to the follow-up deep detector. The varied-scale X-ray images are thus reduced to the same size and aspect ratio, which enables a more efficient deep detection pipeline. Besides, to benchmark the effectiveness of X-ray image detection algorithms, we propose a novel dataset for X-ray image detection, dubbed SIXray-D, based on the popular SIXray dataset. In SIXray-D, we provide the complete and more accurate annotations of both object classes and bounding boxes, which enables model training for supervised X-ray detection methods. Our results show that our proposed TDC algorithm can effectively boost popular detection algorithms, by achieving better detection mAPs or reducing the run time. Full article

At airports, security officers (screeners) inspect X-ray images of passenger baggage in order to prevent threat items (bombs, guns, knives, etc.) from being brought onto an aircraft. Because threat items rarely occur, many airports use a threat-image-projection (TIP) system, which projects pre-recorded X-ray images of threat items onto some of the X-ray baggage images in order to improve the threat detection of screeners. TIP is regulatorily mandated in many countries and is also used to identify officers with insufficient threat-detection performance. However, TIP images sometimes look unrealistic because of artifacts and unrealistic scenarios, which could reduce the efficacy of TIP. Screeners rated a representative sample of TIP images regarding artifacts identified in a pre-study. We also evaluated whether specific image characteristics affect the occurrence rate of artifacts. 24% of the TIP images were rated to display artifacts and 26% to depict unrealistic scenarios, with 34% showing at least one of the two. With two-thirds of the TIP images having been perceived as realistic, we argue that TIP still serves its purpose, but artifacts and unrealistic scenarios should be reduced. Recommendations on how to improve the efficacy of TIP by considering image characteristics are provided. Full article
