Water environmental carrying capacity (WECC) is an important support for social and economic development and is closely related to regional production and consumption patterns. Exploring the level of WECC and its evolution trend is very urgent for the scientific formulation of targeted early warning control strategies. Therefore, this study first constructs the index system of WECC with a DPSIR model, and conducts the quantitative evaluation by combining the Kantiray Weighting method and the TOPSIS method. Then, the Kernel Density Estimation method and the Markov Chain model are applied to explore the spatiotemporal variation characteristics of WECC and predict its evolution trend. Finally, a case study of 17 municipal administrative regions in Hubei Province is carried out. The main findings are as follows: (1) The WECC status in Hubei Province during 2013–2022 was generally satisfactory and showed a trend of fluctuating improvement. (2) The spatial agglomeration effect of WECC in Hubei Province was significant, showing a distribution pattern of “high-high” agglomeration and “low-low” agglomeration. The improvement of the WECC in eastern Hubei was obvious, while that in central Hubei was slower, and the cities with a lower level of WECC had a more significant improvement effect. (3) Overall, the WECC of cities in Hubei Province tends to shift to a higher level. In a short period of time, the grade improvement of urban WECC in Hubei Province is more likely to occur between adjacent grades. With the increase in time span, the probability of this transition rises gradually. This study has proposed a set of methods for the evaluation and prediction of WECC status, which can provide important decision-making guidance for the early warning and regulation of regional differentiated WECC. Full article

With the increasing penetration of renewable energy, power system frequency stability faces multiple challenges. In addition to the decline of system inertia traditionally provided by synchronous machines, uncertainties such as wind power forecast errors, converter control characteristics, and stochastic load fluctuations further exacerbate the system’s sensitivity to power disturbances, increasing the risks of frequency deviation and instability. Among these factors, insufficient inertia is widely recognized as one of the most direct and critical drivers of the initial frequency response. This study focuses on this issue and explores the use of battery energy storage system (BESS) parameter optimization to enhance system stability. To this end, a simulation platform was developed in PSS^®E V34 based on the IEEE New England 39-bus system, incorporating three wind turbines and two BESS units. The WECC generic models were adopted, and three wind disturbance scenarios were designed, including (i) disconnection of a single wind turbine, (ii) derating of two turbines to 50% output, and (iii) derating of three turbines to 50% output. In this study, a one-at-a-time (OAT) sensitivity analysis was first performed to identify the key parameters affecting frequency response, followed by optimization using an improved particle swarm optimization (IPSO) algorithm. The simulation results show that the minimum system frequency was 59.888 Hz without BESS control, increased to 59.969 Hz with non-optimized BESS control, and further improved to 59.976 Hz after IPSO. Compared with the case without BESS, the overall improvement was 0.088 Hz, of which IPSO contributed an additional 0.007 Hz. These results clearly demonstrate that IPSO can significantly strengthen the frequency support capability of BESS and effectively improve system stability under different wind disturbance scenarios. Full article

Island electrical networks often face stability and resilience issues due to their weakly meshed structure, which lowers system inertia and compromises supply continuity. This challenge is further intensified by the increasing integration of renewable energy sources, promoted by decarbonization goals, whose intermittent and variable nature complicates grid stability management. To address this, Red Eléctrica de España—the transmission system operator of Spain—has planned several improvements in the Canary Islands, including the installation of new wind farms and a second transmission circuit on the island of La Palma. This new infrastructure will complement the existing one and ensure system stability in the event of N-1 contingencies. This article evaluates the stability of the island’s electrical network through dynamic simulations conducted in PSS^®E, analyzing four distinct fault scenarios across three different grid configurations (current, short-term upgrade and long-term upgrade with wind integration). Generator models are based on standard dynamic parameters (WECC) and calibrated load factors using real data from the day of peak demand in 2021. Results confirm that the planned developments ensure stable system operation under severe contingencies, while the integration of wind power leads to a 33% reduction in diesel generation, contributing to improved environmental and operational performance. Full article

The fuel cell electric vehicle (FCEV) is a promising transportation technology for resolving the air pollution and climate change issues in the United States. However, a large-scale penetration of FCEVs would require a sustained supply of hydrogen which does not exist now. Water electrolysis can produce hydrogen reliably and sustainably if the electricity grid is clean, but the impacts of FCEVs on the electricity grid are unknown. In this paper, we develop a comprehensive framework to model FCEV-driving and -refueling behaviors, the water electrolysis process, and electricity grid operation. We chose the Western Electricity Coordinating Council (WECC) region for this case study. We modeled the existing WECC electricity grids and accounted for the additional electricity loads from FCEVs using a Production Cost Model (PCM). Additionally, the hydrogen need for five million FCEVs leads to a 3% increase in electricity load for WECC. Our results show that an inflexible hydrogen-producing process leads to a 1.55% increase to the average cost of electricity, while a flexible scenario leads to only a 0.9% increase. On the other hand, oversized electrolyzers could take advantage of cheaper electricity generation opportunities, thus lowering total system costs. Full article

The growing integration of renewable energy sources, such as photovoltaic and wind systems, into energy grids has underscored the need for reliable control mechanisms to mitigate the inherent intermittency of these sources. According to the Brazilian grid operator (ONS), there have been cascading disconnections in renewable energy distributed systems (REDs) in recent years, highlighting the need for robust control models. This article addresses this issue by presenting the validation of an active power ramp rate control (PRRC) function for a PV plant coupled with a Battery Energy Storage System (BESS) using WECC generic models. The proposed model underwent rigorous validation over an extended analysis period, demonstrating good accuracy using the Root Mean Squared Error (RMSE) and an R-squared (R²) metrics for the active power injected at the Point of Connection (POI), PV active power, and BESS State of Charge (SOC), providing valuable insights for medium and long-term analyses. The ramp rate control module was implemented within the plant power controller (PPC), leveraging second-generation Renewable Energy Systems (RES) models developed by the Western Electricity Coordination Council (WECC) as a foundational framework. We conducted simulations using the Anatem software, comparing the results with real-world data collected at 100 ms to 1000 ms intervals from a PV plant equipped with a BESS in Brazil. The proposed model underwent rigorous validation over an extended analysis period, with the presented results based on two days of measurements. The positive sequence model used to represent this control demonstrated good accuracy, as confirmed by metrics such as the Root Mean Squared Error (RMSE) and R-squared (R²). Furthermore, the article underscores the critical role of accurately accounting for the power sampling rate when calculating the ramp rate. Full article

In recent years, there has been a significant uptick in the integration of Inverter-Based Resources (IBRs) into the power grid, driven by the global shift toward renewable energy sources. The Western Electricity Coordinating Council (WECC) has developed standardized models for these inverters to facilitate their representation in system studies, playing a crucial role in evaluating IBRs, especially those modeled as grid-following inverters (GFLs). However, with the increasing prevalence of IBRs, the adjustment of grid interaction between grid-forming inverters (GFMs) and GFLs should be considered in terms of frequency stability assessment. This study investigates the optimization of synchronous generators and IBR operations in more detail. The IBR operation is evaluated with considerations for ratio and penetration. The findings suggest that with over 50% IBR penetration, GFL capacity should be reduced, and GFM capacity should be over 35% of IBR to maintain grid frequency stability. Moreover, this study also explains advanced prediction of frequency nadir, particularly the optimal ratio of WECC generic and GFM through the least squares method. Furthermore, the small-signal dynamic characteristics of WECC are studied at various gain values to investigate frequency droop control. Full article

As the proportion of renewable energy generation systems increases, traditional power generation facilities begin to face challenges, such as reduced output power and having the power turned off. The challenges are causing changes in the structure of the power system. Renewable energy sources, mainly wind and solar energy cannot provide stable inertia and frequency regulation capability. Ultimately, the power system’s emergency response capability to face an N-1 is reduced, which leads to a reduction in system stability. Therefore, the application technology of the battery energy storage system is used to support the impact of changes in the new power system structure. This paper designed control technologies based on the WECC second-generation generic model, namely, dynamic regulation, steady regulation, and virtual inertia regulation. The models and control strategies are verified on Taiwan’s 2025 power system target conditions, which consider the expected capacities for battery energy storage systems, and renewable energy sources with different load and N-1 fault levels. According to the simulation results, the capabilities of the RoCoF limitation, frequency nadir, frequency recovery, and system oscillation regulation are evaluated in the proposed strategies. Finally, the analysis results can help power operators make informed decisions when selecting and deploying battery energy storage systems. Full article

With attention increasing towards worldwide ecological conservation, the energy policies of various countries are moving towards renewable energy systems, primarily with solar and wind as the primary power sources. The Western Electricity Coordinating Council (WECC) has developed a generic model as a simulation framework for a typical solar wind generation system to analyze the response of the actual equipment. In this paper, we propose a parameter tuning process for a generic model controller that combines Latin hypercube sampling and Pareto optimization to enable a generic model to effectively match the output of an actual inverter device. Different operating scenarios were considered to match the dynamic characteristics of the inverter device using the multi-objective particle swarm algorithm (MOPSO) along with Pareto optimization. The effectiveness of the proposed parameter tuning process was verified on a user-defined test system and, later, the IEEE 39 bus system with a large solar power facility. Full article

Achieving clean energy goals will require significant advances in regard to addressing the computational needs for next-generation renewable-dominated power grids. One critical obstacle that lies in the way of transitioning today’s power grid to a renewable-dominated power grid is the lack of a faster-than-real-time stability assessment technology for operating a fast-changing power grid. This paper proposes an artificial intelligence (AI) -based method that predicts the system’s stability margin information (e.g., the frequency nadir in the frequency stability assessment and the critical clearing time (CCT) value in the transient stability assessment) directly from the system operating conditions without performing the conventional time-consuming time-domain simulations over detailed dynamic models. Since the AI method shifts the majority of the computational burden to offline training, the online evaluation is extremely fast. This paper has tested the AI-based stability assessment method using multiple dispatch cases that are converted and tuned from actual dispatch cases of the Western Electricity Coordinating Council (WECC) system model with more than 20,000 buses. The results show that the AI-based method could accurately predict the stability margin of such a large power system in less than 0.2 milliseconds using the offline-trained AI agent. Therefore, the proposed method has great potential to achieve faster-than-real-time stability assessment for practical large power systems while preserving sufficient accuracy. Full article

Water environment carrying capacity (WECC) is an effective indicator that can help resolve the contradiction between social and economic development and water environment pollution. Considering the complexity of the water environment and socioeconomic systems in Northeast China, this study establishes an evaluation index system and a system dynamics (SD) model of WECC in Fushun City, Liaoning, China, through the combination of the fuzzy analytic hierarchy process and SD. In consideration of the uncertainty of the future development of society, the Monte Carlo and scenario analysis methods are used to simulate the WECC of Fushun City. Results show that if the current social development mode is maintained, then the WECC in Fushun will have a slow improvement in the future, and a “general” carrying state with a WECC index of 0.566 in 2025 will be developed. Moreover, focusing on economic development (Scheme 1 with a WECC index of [0.22, 0.45] in 2025) or environmental protection (Scheme 2 with a WECC index of [0.48, 0.68] in 2025) cannot effectively improve the local water environment. Only by combining the two coordinated development modes (Scheme 3) can WECC be significantly improved and achieve “general” or “good” carrying state with a WECC index of [0.59, 0.79]. An important development of this study is that the probability of each scheme’s realization can be calculated after different schemes are formulated. In turn, the feasibility of the scheme will be evaluated after knowing the probability, so as to determine the path suitable for local development. This is of great significance for future urban planning. Full article

In recent years, there has been a growing need for accurate models that describe the dynamics of renewable energy sources, especially photovoltaic sources and wind turbines. In light of this gap, this work focuses on the validation of standard dynamic models developed by the Western Electricity Coordinating Council (WECC), using actual measurements from the Western Texas and Southern California transmission networks. The tests are based on the North American Electric Reliability Corporation compliance standards and include dynamic stability tests for volt-varcontrol and primary frequency response. Through an extensive set of field tests, we show that the WECC generic models can be used to simulate real dynamic phenomena in large-scale solar photovoltaic power plants, and we propose guidelines for correct usage of these models. The results show that the WECC models are especially accurate when the photovoltaic system is connected with a low impedance to the main network. We also show that the tested WECC models successfully predict the frequency response of an actual grid event that occurred in the Electric Reliability Council of Texas and which resulted in a loss of nearly 1.365 GW. This result supports the use of these models in the study of large-scale dynamic phenomena that include renewable energy sources. Full article

Power systems are currently witnessing a high wind-power penetration due to the development and commissioning of an increasing number of wind-power plants. This new scenario inevitably changes the way power systems are operated, mainly due to the uncertainties associated with wind, with the proper integration of this renewable energy source into the grid emerging as a new challenge. Unlike other highly flexible energy sources that can be used on demand according to the market needs, wind energy production is intermittent and non-dispatchable. In this context, transient stability analyses through the dynamic simulation of wind-turbine models and wind-power plants must be carried out. Moreover, as many countries have their own grid codes, the compliance requirements to connect wind farms to the network may be significantly different, depending on the specific region. In light of the above, this paper addresses the submission to Spanish Operation Procedure 12.3 (PO 12.3), for the first time, of one of the most advanced wind-turbine models, the generic Type 3 or doubly fed induction generator defined by the Western Electricity Coordinating Council (WECC) Second-Generation guidelines. The results show, on the one hand, the notable effect of the transformer inrush current, which influences the accuracy of the behavior of the generic wind-turbine model, and, on the other hand, the inability of the generic model to represent the transient periods of actual wind turbines. However, when the validation criteria is applied at the low-voltage measurement point, the WECC model fully complies with Spanish grid code PO 12.3. Full article

The impact of Type 4 wind turbine generator (WTG)-based 10 million megawatt clusters (TMMC) on small-signal dynamics of power systems was investigated using the second-generation generic models (GM) of Western Electricity Coordinating Council (WECC). A WTG participation index (WTG PI) was defined to investigate the impact of Type 4 WTGs on the traditional interarea electromechanical modes. To identify the new electromechanical modes dominated by Type 4 WTGs, an identification factor (IF) was also defined using participation factors. Given the increasing penetration of Type 4 WTGs replacing synchronous generators, the changed law of damping and frequencies of the traditional interarea modes was also investigated using the WTG PI. One new type of electromechanical mode dominated by Type 4 WTGs was identified by using the defined IF. These new modes can be divided into two categories: strong-interaction modes and weak-interaction modes, depending on the number of participating WTGs. The strong-interaction modes dominated by Type 4 WTGs can result in widely spread power oscillations in power systems. The results of small-signal analysis were validated by time domain simulation and mode detection. Full article
