Search Results (19)

Terahertz (THz) communication is a key technology for sixth-generation (6G) networks, offering ultra-high data rates, low latency, and massive connectivity. However, the THz band faces significant propagation challenges, including high path loss, molecular absorption, and susceptibility to blockage. Reconfigurable intelligent surfaces (RISs) have emerged as an effective solution to overcome these limitations by reconfiguring the wireless environment through passive beam steering. In this work, we propose a novel framework, namely the optimized deep reinforcement learning transformer (ODRL-Transformer), to maximize the sum rate in RIS-assisted THz systems. The framework integrates a Transformer encoder for extracting temporal and contextual features from sequential channel observations, a DRL agent for adaptive beamforming and phase shift control, and a hybrid biogeography-based optimization (HBBO) algorithm for tuning the hyperparameters of both modules. This design enables efficient long-term decisionmaking and improved convergence. Extensive simulations of dynamic THz channel models demonstrate that ODRL-Transformer outperforms other optimization baselines in terms of the sum rate, convergence speed, stability, and generalization. The proposed model achieved an error rate of 0.03, strong robustness, and fast convergence, highlighting its potential for intelligent resource allocation in next-generation RIS-assisted THz networks. Full article

Unmanned Aerial Vehicles (UAVs), commonly known as drones, are becoming increasingly important in multiple areas and various applications, including communication, detection, and monitoring. This review paper examines the development of antennas for UAVs, with a particular focus on miniaturization techniques, polarization strategies, and beamforming solutions. It explores both structural and material-based methods, such as meander lines, slots, high-dielectric substrates, and metasurfaces, which aim to make the antenna more compact without compromising performance. Different antenna types including dipole, monopole, horn, vivaldi, and microstrip patch are explored to identify solutions that meet performance standards while respecting UAV constraints. In terms of polarization strategies, these are often implemented in the feeding network to achieve linear or circular polarization, and beamforming techniques like beam-steering and beam-switching enhance communication efficiency by improving signal directionality. Future research should focus on more lightweight, structurally integrated, and reconfigurable apertures that push miniaturization through conformal substrates and programmable metasurfaces, extending efficient operation from 5/6 GHz into the sub-THz regime and supporting agile beamforming for dense UAV swarms. Full article

Terahertz (THz) antennas are among the critical components required for enabling the transition to sixth-generation (6G) wireless networks. Although research on THz antennas for 6G communication systems has garnered significant attention, a standardized antenna design has yet to be established. This study introduces the modeling of a full-metal transverse slotted waveguide antenna (TSWA) for 6G and beyond. The proposed antenna operates across the upper regions of the V-band and the entire W-band. Designed and simulated using widely adopted full-wave analysis tools, the antenna achieves a peak gain of 17 dBi and a total efficiency exceeding 90% within the band. Additionally, it exhibits pattern-reconfigurable capabilities, enabling main lobe beam steering between 5° and 68° with low side lobe levels. Simulations are conducted to assess the power handling capability (PHC) of the antenna, including both the peak (PPHC) and average (APHC) values. The results indicate that the antenna can handle 17 W of APHC within the W-band and 3.4 W across the 60–160 GHz range. Furthermore, corona discharge and multipaction analyses are performed to evaluate the antenna’s power handling performance under extreme operating conditions. These features make the proposed TSWA a strong candidate for high-performance space applications, 6G communication systems, and beyond. Full article

Recent advancements in hybrid photonic integrated circuits (PICs) for wireless communications are reviewed, with a focus on innovations developed at Fraunhofer HHI. This work leverages hybrid integration technology, which combines indium phosphide (InP) active elements, silicon nitride (Si₃N₄) low-loss waveguides, and high-efficient thermal-optical tunable polymers with micro-optical functions to achieve fully integrated wireless transceivers. Key contributions include (1) On-chip optical injection locking for generating phase-locked optical beat notes at 45 GHz, enabled by cascaded InP phase modulators and hybrid InP/polymer tunable lasers with a 3.8 GHz locking range. (2) Waveguide-integrated THz emitters and receivers, featuring photoconductive antennas (PCAs) with a 22× improved photoresponse compared to top-illuminated designs, alongside scalable 1 × 4 PIN-PD and PCA arrays for enhanced power and directivity. (3) Beam steering at 300 GHz using a polymer-based optical phased array (OPA) integrated with an InP antenna array, achieving continuous steering across 20° and a 10.6 dB increase in output power. (4) Demonstration of fully integrated hybrid wireless transceiver PICs combining InP, Si₃N₄, and polymer material platforms, validated through key component characterization, on-chip optical frequency comb generation, and coherent beat note generation at 45 GHz. These advancements result in compact form factors, reduced power consumption, and enhanced scalability, positioning PICs as an enabling technology for future high-speed wireless networks. Full article

Unmanned aerial vehicles (UAVs) need high data rate connectivity, which is achievable through mm-waves and sub-THz bands. The proposed two-port leaky wave MIMO antenna, employing a coplanar proximity technique that combines capacitive and inductive loading, addresses this need. Featuring mesh-like slots and a vertical slot to mitigate open-stopband (OSB) issues, the antenna radiates broadside and bidirectionally. H-shaped slots on a strip enhance port isolation, and a coffee bean metasurface (MTS) boosts radiation efficiency and gain. Simulations and experiments considering various realistic scenarios, each at varying vertical and horizontal distances, show steered beam patterns, circular polarization (CP), and high-gain properties, with a maximum gain of 13.8 dBi, an axial ratio (AR) <2.9, a diversity gain (DG) >9.98 dB, and an envelope correlation coefficient (ECC) <0.003. This design supports drones-to-ground (D2G), drone-to-drone (D2D), and drone-to-satellite (D2S) communications. Full article

This paper presents a novel periodic grounded coplanar waveguide (GCPW) leaky-wave antenna implemented in an Indium Phosphide (InP) process. The antenna is designed to operate in the 220 GHz–325 GHz frequency range, with the goal of integrating it with an InP uni-traveling-carrier photodiode to realize a wireless transmitter module. Future wireless communication systems must deliver a high data rate to multiple users in different locations. Therefore, wireless transmitters need to have a broadband nature, high gain, and beam-steering capability. Leaky-wave antennas offer a simple and cost-effective way to achieve beam-steering by sweeping frequency in the THz range. In this paper, the first periodic GCPW leaky-wave antenna in the 220 GHz–325 GHz frequency range is demonstrated. The antenna design is based on a novel GCPW leaky-wave unit cell (UC) that incorporates mirrored L-slots in the lateral ground planes. These mirrored L-slots effectively mitigate the open stopband phenomenon of a periodic leaky-wave antenna. The leakage rate, phase constant, and Bloch impedance of the novel GCPW leaky-wave UC are analyzed using Floquet’s theory. After optimizing the UC, a periodic GCPW leaky-wave antenna is constructed by cascading 16 UCs. Electromagnetic simulation results of the leaky-wave antenna are compared with an ideal model derived from a single UC. The two design approaches show excellent agreement in terms of their reflection coefficient and beam-steering range. Therefore, the ideal model presented in this paper demonstrates, for the first time, a rapid method for developing periodic leaky-wave antennas. To validate the simulation results, probe-based antenna measurements are conducted, showing close agreement in terms of the reflection coefficient, peak antenna gain, beam-steering angle, and far-field radiation patterns. The periodic GCPW leaky-wave antenna presented in this paper exhibits a high gain of up to 13.5 dBi and a wide beam-steering range from $-60{}^{°}$ to $35{}^{°}$ over the 220 GHz–325 GHz frequency range. Full article

A novel graphene antenna composed of a graphene dipole and four auxiliary graphene sheets oriented at ${90}^{\circ }$ to each other is proposed and analyzed. The sheets play the role of reflectors. A detailed group-theoretical analysis of symmetry properties of the discussed antennas has been completed. Through electric field control of the chemical potentials of the graphene elements, the antenna can provide a quasi-omnidirectional diagram, a one- or two-directional beam regime, dynamic control of the beam width and, due to the vertical orientation of the dipole with respect to the base substrate, a ${360}^{\circ }$ beam steering in the azimuth plane. An additional graphene layer on the base permits control of the radiation pattern in the $\theta$-direction. Radiation patterns in different working states of the antenna are considered using symmetry arguments. We discuss the antenna parameters such as input reflection coefficient, total efficiency, front-to-back ratio, and gain. An equivalent circuit of the antenna is suggested. The proposed antenna operates at frequencies between 1.75 THz and 2.03 THz. Depending on the active regime defined by the chemical potentials set on the antenna graphene elements, the maximum gain varies from 0.86 to 1.63. Full article

The approaching sixth-generation (6G) communication network will modernize applications and satisfy user demands through implementing a smart and reconfigurable system with a higher data rate and wider bandwidth. The controllable THz waves are highly recommended for the instantaneous development the new technology in wireless communication systems. Recently, reconfigurable intelligent surfaces (RIS), also called codded/tunable programmable metasurfaces, have enabled a conspicuous functionality for THz devices and components for influencing electromagnetic waves (EM) such as beam steering, multi-beam-scanning applications, polarization variation, and beam focusing applications. In this article, we proposed a graphene plasmonic two-port MIMO microstrip patch antenna structure that operates at a 1.9 THz resonance frequency. An E-shape MTM unit cell is introduced to enhance the isolation of the antenna from −35 dB to −54 dB. An implementation of controllable and reconfigurable surfaces based on graphene meta-atoms (G-RIS) placed above the radiating patches with a suitable separated distance to control the radiated beam to steer in different directions (±60°). The reconfigurable process is carried out via changing the (ON/OFF) meta-atoms states to get a specific code with a certain beam direction. The gain enhancement of the antenna can be implemented through an artificial magnetic conductor (AMC) based on graphene material. The G-AMC layer is located underneath the (MIMO antenna, G-RIS layer) to improve the gain from 4.5 dBi to 10 dBi. The suggested antenna structure results are validated with different techniques CST microwave studio and ADS equivalent circuit model. The results have asymptotic values. So, the proposed design of the MIMO antenna that is sandwiched between G-RIS and G-AMC is suitable for IoT applications. Full article

Multifunctional terahertz beam manipulations have attracted much attention because of the potential for wide-scale applications in terahertz imaging, communications, etc. In this work, a grating-like terahertz reflective-type metasurface is designed for terahertz beam manipulations on the basis of a frequency-scanning mechanism. The theoretical calculation based on the grating principle has predicted that the metasurface grating can steer the deflected beam from 59.5° to 47.3° as the frequency of the perpendicularly incident terahertz wave changes between 0.87 and 1.02 THz. The large-deflection-angle frequency-scanning performance is validated by both numerical simulations and experimental tests. The metasurface grating developed in this work possesses the potential for applications in terahertz beam steering and beam-splitting devices. Full article

In this manuscript, we report on a 1 × 4 optical beam forming network (OBFN) chip using optical phase shifters (OPSs) based on thermo-optically controlled optical ring resonators (ORRs) for 1D beam steering at 0.3 THz. The 1 × 4 OBFN chip consists of four OPSs and is fabricated using TriPleX technology. Each of the four OPSs is realized by two cascaded identical ORRs, to reach a phase shift of 2π. To allow transfer of the optical phase shift to the THz domain by optical heterodyning in high-frequency 1.55 µm modified uni-travelling carrier photodiodes, the ORRs are designed such that one carrier of the optical heterodyne signal is at the ORR’s resonance frequency, whereas the second optical heterodyne signal is at its off-resonance. By adjusting the resonance frequencies of the two ORRs in each OPS synchronously, a relative phase variation between two optical heterodyne carriers of up to 2π with a tuning efficiency of 0.058 W/π, is experimentally demonstrated. Due to the dispersive power transmission loss of the ORRs, phase tuning leads to a power variation of the optical heterodyne-generated signals up to 3.8 dB, which is experimentally characterized at 0.295 THz. It is shown numerically that this power variation only has a minor impact on the steering performance of a 1 × 4 phased array. The determined beam direction deviation and maximum absolute radiation power change are smaller than 1° and 2 dB, respectively. By sweeping the phase difference between two adjacent THz antennas in the 1 × 4 phased array, from −120° to 120°, a beam steering range of ~62° is demonstrated numerically at 0.295 THz. Full article

In the past decades, metasurfaces have shown their extraordinary abilities on manipulating the wavefront of electromagnetic wave. Based on the ability, various kinds of metasurfaces are designed to realize new functional metadevices based on wavefront manipulations, such as anomalous beam steering, focus metalens, vortex beams generator, and holographic imaging. However, most of the previously proposed designs based on metasurfaces are fixed once design, which is limited for applications where light modulation needs to be tunable. In this paper, we proposed a design for THz tunable wavefront manipulation achieved by the combination of plasmonic metasurface and phase change materials (PCMs) in THz region. Here, we designed a metal-insulator-metal (MIM) metasurface with the typical C-shape split ring resonator (CSRR), whose polarization conversion efficiency is nearly 90% for circular polarized light (CPL) in the range of 0.95~1.15 THz when PCM is in the amorphous state, but the conversion efficiency turns to less than 10% in the same frequency range when PCM switches into the crystalline state. Then, benefiting from the high polarization conversion contrast of unit cell, we can achieve tunable wavefront manipulation by utilizing the Pancharatnam–Berry (PB) phase between the amorphous and crystalline states. As a proof-of-concept, the reflective tunable anomalous beam deflector and focusing metalens are designed and characterized, and the results further verify their capability for tunable wavefront manipulation in THz range. It is believed that the design in our work may pave the way toward the tunable wavefront manipulation of THz waves and is potential for dynamic tunable THz devices. Full article

Dynamic phase modulation is vital for tuneable focusing, beaming, polarisation conversion and holography. However, it remains challenging to achieve full 360° dynamic phase modulation while maintaining high reflectance or transmittance based on metamaterials or metasurfaces in the terahertz regime. Here, we propose a doubly resonant graphene–metal hybrid metasurface to address this challenge. Simulation results show that by varying the graphene Fermi energy, the proposed metasurface with two shifting resonances is capable of providing dynamic phase modulation covering a range of 361° while maintaining relatively high reflectance above 20% at 1.05 THz. Based on the phase profile design, dynamically tuneable beam steering and focusing were numerically demonstrated. We expect that this work will advance the engineering of graphene metasurfaces for the dynamic manipulation of terahertz waves. Full article

As communication technology is entering the 6G era, a great demand for high-performance devices operating in the terahertz (THz) band has emerged. As an important part of 6G technology, indoor communication requires multi-beam steering and tracking to serve multi-users. In this paper, we have designed a graphene metasurface that can realize multi-beam steering for directional radiations. The designed metasurface consists of graphene ribbons, dielectric spacer, and metal substrate. By designing the graphene ribbons and controlling the applied voltage on them, we have obtained single-, double-, and triple-beam steering. In addition, we have also numerically calculated the far-field distributions of the steered multi-beam with a diffraction distance of 2 m. Our design has potential applications in future indoor directional 6G communications. Full article

To meet the growing demand for wireless capacity, communications in the Terahertz (THz) and optical bands are being broadly explored. Communications within these bands provide massive bandwidth potential along with highly directional beam steering capabilities. While the available bandwidth offers incredible link capacity, the directionality of these technologies offers an even more significant potential for spatial capacity or area spectral efficiency. However, this directionality also implies a challenge related to the network’s ability to quickly establish a connection. In this paper, we introduce a multi-tier heterogeneous (MTH) beamform management strategy that utilizes various wireless technologies in order to quickly acquire a highly directional indoor free space optical communication (FSO) link. The multi-tier design offers the high resolution of indoor FSO while the millimeter-wave (mmWave) system narrows the FSO search space. By narrowing the search space, the system relaxes the requirements of the FSO network in order to assure a practical search time. This paper introduces the necessary components of the proposed beam management strategy and provides a foundational analysis framework to demonstrate the relative impact of coverage, resolution, and steering velocity across tiers. Furthermore, an optimization analysis is used to define the top tier resolution that minimizes worst-case search time as a function of lower tier resolution and top tier range. Full article

Photonic true time delay beam steering on the transmitter side of terahertz time-domain spectroscopy (THz TDS) systems requires many wideband variable optical delay elements and an array of coherently driven emitters operating over a huge bandwidth. We propose driving the THz TDS system with a monolithic mode-locked laser diode (MLLD). This allows us to use integrated optical ring resonators (ORRs) whose periodic group delay spectra are aligned with the spectrum of the MLLD as variable optical delay elements. We show by simulation that a tuning range equal to one round-trip time of the MLLD is sufficient for beam steering to any elevation angle and that the loss introduced by the ORR is less than 0.1 dB. We find that the free spectral ranges (FSRs) of the ORR and the MLLD need to be matched to 0.01% so that the pulse is not significantly broadened by third-order dispersion. Furthermore, the MLLD needs to be frequency-stabilized to about 100 MHz to prevent significant phase errors in the terahertz signal. We compare different element distributions for the array and show that a distribution according to a Golomb ruler offers both reasonable directivity and no grating lobes from 50 GHz to 1 THz. Full article
