Search Results (11)

Laser–MIG hybrid welding–brazing was performed to join TC4 titanium alloy and 5083 aluminum alloy with ER5356, ER4043 and ER2319 filler wires. The effects of the different filler wires on the microstructural features and mechanical properties of Ti/Al welded–brazed butt joints were investigated in detail. The wetting and spreading effect of the ER4043 filler wire was the best, especially on the weld’s rear surface. Serrated-shaped and rod-like IMCs were generated at the top region of the interface of the joint with ER4043 filler wire, but rod-like IMCs did not appear at the joints with the other filler wires. Only serrated-shaped IMCs appeared in the middle and bottom regions for the three filler wires. The phase compositions of all the IMCs were inferred as being made up of TiAl₃. The average thickness of the IMC layer of joints with the ER5356 and ER2319 filler wires was almost the same and thinner than that of the joint with the ER4043 filler wire. The average thickness was largest in the middle region and smallest in the bottom region for all the joints with the three filler wires. The average microhardness in the weld metal of ER5356, ER4043 and ER2319 filler wires could reach up to 77.7 HV, 91.2 HV and 85.4 HV, respectively. The average tensile strength of joints with the ER5356, ER4043 and ER2319 filler wires was 106 MPa, 238 MPa and 192 MPa, respectively. The tensile samples all fractured at the IMC interface and showed a mixed brittle–ductile fracture feature. These research results could help confirm the appropriate filler wire for the laser–MIG hybrid welding–brazing of Ti/Al dissimilar butt joints. Full article

TC4 titanium alloy and 5083 aluminum alloy with different groove shapes were joined by laser-MIG hybrid welding–brazing using ER4043 filler wire. The effects of groove shape on the weld formation, intermetallic compounds and tensile property of the Ti/Al butt joints were investigated. The welds without obvious defects could be obtained with grooves of I-shape and V-shape on Ti side, while welds quality with grooves of V-shape on Al side and V-shape on both sides were slightly worse. The interfacial intermetallic compounds (IMCs) on the brazing interface were homogeneous in the joints with groove of V-shape on Ti side, and V-shape on both sides, which had similar thickness and were both composed of TiAl₃. Unlike the IMCs mainly composed of TiAl₃ at the I-shape groove interface, TiAl₃, TiAl, and Ti₃Al constituted the IMCs at the V-shape on Al side interface. The average tensile strength of Ti/Al joints with groove of I-shape was the highest at 238 MPa, and was lowest at 140 MPa with groove of V-shape on Al side. The tensile samples mainly fractured at IMCs interface and the fractured surfaces all exhibited mixed brittle–ductile fracture mode. Based on the above research results, I-shape groove was recommended for laser-arc hybrid welding–brazing of 4 mm thick Ti/Al dissimilar butt joints. Full article

The effects of point defects on the mechanical and thermal conductivity of aluminum at room temperature have been investigated based on the first-principles calculations combined with the Boltzmann equation and the Debye model. The calculated results showed the equilibrium lattice constants a₀ of all RE_Al are larger than that of Al, and the defective formation energy E_f of all RE_Al is lower than that of V_Al. Both a₀ and E_f increase from Sc to La and then decrease linearly to Lu. The effects of solute atoms on the mechanical properties of the Al matrix were further calculated, and compared with Al, it is found that the RE_Al defects decrease the elastic constant C_ij, Cauchy pressure C₁₂–C₄₄, bulk modulus B, shear modulus G, Young’s modulus E, B/G and Poisson’s ratio ν of Al, except for C₄₄ of RE_Al (RE = La-Nd). With the increase of atomic number, the C₁₁ and E of Al-containing RE_Al decrease from Sc to La and then slowly increase to Lu, whereas C₁₂, C_44, B, and G have little change. Meanwhile, the values of C₁₂–C₄₄ and B/G of Al-containing RE_Al increase from Sc to Ce, and it slightly change after Ce, while ν is nearly unchanged. All defects containing Al present nonuniform and ductility. Finally, the effects of rare earth (RE) atoms on the thermal conductivity (TC) of Al alloys have been investigated based on the first-principles calculations. The reduction of TC of Al alloys by RE solute atoms RE_Al is much greater than that by the L1₂ Al₃RE phase with the same concentration of RE, which is in good agreement with the experiments. With the RE atomic number increasing, the total TC κ of the Al-RE solid solution decreases from Sc to La firstly and then increases linearly to Lu. Moreover, the decrement of TC Δκ of the Al matrix by early RE_Al (RE = La-Sm) is larger than that by V_Al, while the later RE_Al (RE = Gd-Lu) shows the opposite influence. Full article

Titanium alloy is an important material for the manufacture of key components of deep-sea submersibles. High-power vacuum laser welding is an important method for welding TC4 thick plate (40–120 mm) structures. However, due to the low melting point of aluminum, its uneven distribution in the weld caused by evaporation during welding affects the quality of joints. This paper conducted experimental and simulation studies to investigate the effect of process parameters on multi-component evaporation and uneven aluminum distribution. Based on a three-dimensional model of vacuum laser welding, the mechanism of the uneven distribution of aluminum in the weld is explained. The results show that the uneven distribution of aluminum in the weld is mainly related to the metal vapor behavior and keyhole morphology. As the welding speed rises from 1 m/min to 3 m/min, the proportion of aluminum in the metal vapor and the degree of compositional unevenness increase. When the laser power increases from 6 kW to 18 kW, the proportion of aluminum in the metal vapor and degree of unevenness increase, peak at 12 kW, and then decrease. This work facilitates the selection of suitable process parameters to reduce aluminum evaporation during the high-power vacuum welding of Ti-6Al-4V alloys. Joints with a more stable performance can be obtained by avoiding the uneven distribution of aluminum. Full article

Foreign object damage (FOD) is a common mode of failure in high-speed rotating machinery, such as aircraft engines. Therefore, research on FOD is crucial for ensuring blade integrity. FOD induces residual stress on the surface and within the blade, impacting its fatigue strength and service life. Therefore, this paper utilizes material parameters determined by existing experiments, based on the Johnson–Cook (J-C) constitutive model, to numerically simulate impact damage inflicted on specimens, compare and analyze the residual stress distribution of impact pits, and investigate the influence law of foreign object characteristics on blade residual stress. TC4 titanium alloy, 2A12 aluminum alloy, and Q235 steel were selected as foreign objects, and dynamic numerical simulations of the blade impact process were performed to explore the effects of different types of metal foreign objects. This study analyzes the influence of different materials and foreign objects on the residual stress generated by blade impact through numerical simulation, examining the distribution of residual stress in different directions. The findings indicate that the generated residual stress increases with the density of the materials. Additionally, the geometry of the impact notch is also influenced by the density difference between the impact material and the blade. The distribution of the residual stress field reveals that the maximum residual tensile stress in the blade is related to the density ratio, and the residual tensile stress in the axial and circumferential direction is relatively large. It is important to note that a significant residual tensile stress has a detrimental effect on the fatigue strength. Full article

Titanium alloys have become the material of choice for marine parts manufacturing due to their high specific strength and excellent resistance to seawater corrosion. However, it is still challenging for a single titanium alloy to meet the comprehensive specifications of a structural component. In this study, we have applied a molecular dynamics approach to simulate the aging phase transformation, K-TIG welding process, and mechanical properties of the TC4-TA17 (Ti6Al4V-Ti4Al2V) alloy. The results show that during the aging phase transformation process, changes in the structure of the titanium alloys are mainly manifested in the precipitation of a new phase from the sub-stable β-phase, and after the state stabilization, the α-phase content reaches 45%. Moreover, during the melting and diffusion process of TC4-TA17, aluminum atoms near the interface diffuse, followed by titanium atoms, while relatively few vanadium atoms are involved in the diffusion. Finally, the results of tensile simulations of the TC4-TA17 alloy after welding showed that stress values can reach up to 9.07 GPa and that the mechanical properties of the alloy in the weld zone are better than those of the single alloys under the same conditions. This study will provide theoretical support for the optimization of process parameters for TC4-TA17 alloy welding. Full article

The brazing of Titanium alloy to Aluminum alloy is of great significance for lightweight application, but the stable surface oxide film limits it. In our work, the surface oxide film was removed by the ion bombardment, the deposited Cu layer by magnetron sputtering was selected as an interlayer, and then the contact reactive brazing of TC4 alloy to Al7075 alloy was realized. The microstructure and joining properties of TC4/Al7075 joints obtained under different parameters were observed and tested, respectively. The results revealed that the intermetallic compounds in the brazing seam reduced with the increased brazing parameters, while the reaction layer adjacent to TC4 alloy continuously thickened. The shear strength improved first and then decreased with the changing of brazing parameters, and the maximum shear strength of ~201.45 ± 4.40 MPa was obtained at 600 °C for 30 min. The fracture path of TC4/Al7075 joints changed from brittle fracture to transgranular fracture, and the intergranular fracture occurred when the brazing temperature was higher than 600 °C and the holding time exceeded 30 min. Our work provides theoretical and technological analyses for brazing TC4/Al7075 and shows potential applications for large-area brazing of titanium/aluminum. Full article

Titanium alloys have been widely used in aerospace engineering due to their excellent mechanical properties, especially their strength-to-weight ratio. In addition, Ti6Al4V (TC4) alloy is the most widely used among α+β alloys. The main three elements of TC4 alloy are titanium (Ti), aluminum (Al) and vanadium (V). Since the boiling point of aluminum is much lower than the melting point of the other two elements, the consistency of TC4 alloy during smelting, additive manufacturing and surface treatment is difficult to control. Therefore, in order to study the difficult problem of composition control in TC4 alloy production, we measured the vacuum evaporation of Al, Ti and V in Ti-Al, V-Al and TC4 alloys, and tracked the changes of molten pool temperature, heating time and weight. According to the results, the Al started to evaporate near 1300 ± 10 °C in vacuum and totally evaporated after 225 s heating to 1484 °C at 10⁻² Pa. However, V and Ti barely evaporated below 2000 °C. The Al in Ti-Al alloy started to evaporate at 1753 ± 10 °C and lost 20.6 wt.% aluminum during 500 s at 1750~1957 °C. The Al in V-Al alloy started to evaporate at 1913 ± 10 °C and lost 26.4 wt.% aluminum during 543s at 1893~2050 °C. The Al in TC4 alloy started to evaporate at 1879 ± 10 °C and lost 79.6 wt. % aluminum after 113 s at 1879~1989 °C. The results indicate that smelting TC4 alloy with Ti-Al and V-Al alloys by EBM below 1900 °C improves the consistency and performance. Additionally, the lowest loss of Al occurred in the additive manufacturing of TC4 alloy below 1900 °C. Full article

A new procedure was presented with the objective of proving that it is the generalization of current attempts in designing compressed members and structures which is able to solve cases where other authors have problems. It is the further development of the former methods published by Chladný, Baláž, Agüero et al., which are based on the shape of the elastic critical buckling mode of the structure. Chladný’s method was accepted by CEN/TC 250 working groups creating Eurocodes. Both current Eurocodes EN 1993-1-1:2005 and EN 1999-1-1:2007 in their clauses 5.3.2(11) enable applying the geometrical equivalent unique global and local initial (UGLI) imperfection. The imperfection has the shape of the elastic critical buckling mode with amplitude defined in 5.3.2(11). UGLI imperfection is an alternative to the global sway and local bow initial imperfections defined in 5.3.2(3) and to the imperfections described in the clause 5.3.2(6). The determination of the location and value of UGLI imperfection proved to be onerous by some authors, especially in cases of members with variable cross-sections or/and axial forces. The paper also provides for special cases a procedure to detect the critical cross-section along the member which is defined as the one in which the utilization factor obtains maximum values. The new approach is validated by the investigation of five complex structures made of steel and one made of aluminum alloy solved by other authors. Comparisons of the results with those of other authors and with the Geometrically and Materially Nonlinear Analysis with Imperfections (GMNIA) results showed very good agreements with negligible differences. The information concerning the differences between current Eurocodes EN 1993-1-1:2005 and EN 1999-1-1:2007 is provided. Working drafts of Eurocodes of new generation prEN 1993-1-1:2020 and prEN 1999-1-1:2020 are also commented on. Full article

Precise, economical and sustainable cutting operations are highly desirable in the advanced manufacturing environment. For this aim, the present study investigated the influence of cutting parameters (i.e., the cutting speed (c), feed rate (f), depth of cut (d) and positive rake angle (p)) and sustainable cutting conditions (dry and minimum quantity lubricant (MQL)) on cutting forces (i.e., feed force (F_f), tangential forces (F_t), radial force (F_r) and resultant cutting forces (F_c) and shape deviations (i.e., circularity and cylindricity) of a 6026-T9 aluminum alloy. The type of lubricant and insert used are virgin olive oil and uncoated tungsten carbide tool. Turning experiments were performed on a TAKISAWA TC-1 CNC lathe machine and cutting forces were measured with the help of a Kistler 9257B dynamometer. Shape deviations were evaluated by means of a Tesa Micro-Hite 3D DCC 474 coordinate measuring machine (CMM). Experimental runs were planned based on Taguchi mixture orthogonal array design L16. Analysis of variance (ANOVA) was performed to study the statistical significance of cutting parameters. Taguchi based signal to noise (S/N) ratios are applied for optimization of single response, while for optimization of multiple responses Taguchi based signal to noise (S/N) ratios coupled with multi-objective optimization on the basis of ratio analysis (MOORA) and criteria importance through inter-criteria correlation (CRITIC) are employed. ANOVA results revealed that feed rate, followed by a depth of cut, are the most influencing and contributing factors for all components of cutting forces (F_f, F_t, F_r, and F_c) and shape deviations (circularity and cylindricity). The optimized cutting parameters obtained for multi responses are c = 600 m/min, f = 0.1 mm/rev, d = 1 mm and p = 25°, while for cutting conditions, MQL is optimal. Full article

The tool coating and cooling strategy are two key factors when machining difficult-to-cut materials such as titanium alloy. In this paper, diamond coating was deposited on a commercial carbide insert as an attempt to increase the machinability of TC11 alloy during the turning process. An uncoated carbide insert and a commercial Al₂O₃/TiAlN-coated tool were also tested as a comparison. Furthermore, MQL was applied to improve the cutting condition. Cutting performances were analyzed by cutting force, cutting temperate and surface roughness measurements. Tool wears and tool lives were evaluated to find a good matchup between the tool coating and cooling strategy. According to the results, using MQL can slightly reduce the cutting force. By applying MQL, cutting temperatures and tool wears were reduced by a great amount. Besides, MQL can affect the tool wear mechanism and tool failure modes. The tool life of an Al₂O₃/TiAlN-coated tool can be prolonged by 88.4% under the MQL condition. Diamond-coated tools can obtain a good surface finish when cutting parameters and lubrication strategies are properly chosen. Full article
