Search Results (28)

Recovery from disasters is the complex process requiring coordinated measures to restore infrastructure, services and quality of life. While remote sensing is a well-established means for damage assessment, so far very few studies have shown how satellite imagery can be used by technical officers of affected countries to provide crucial, up-to-date information to monitor the reconstruction progress and natural restoration. To address this gap, the present study proposes a multi-temporal observatory method relying on GIS, change detection techniques and open and free multi-sensor satellite imagery to generate thematic maps documenting, over time, the impact and recovery from hydrological disasters such as hurricanes, tropical storms and induced flooding. The demonstration is carried out with regard to Hurricane Matthew, which struck Haiti in October 2016 and triggered a humanitarian crisis in the Sud and Grand’Anse regions. Synthetic Aperture Radar (SAR) amplitude change detection techniques were applied to pre-, cross- and post-disaster Sentinel-1 image pairs from August 2016 to September 2020, while optical Sentinel-2 images were used for verification and land cover classification. With regard to inundated areas, the analysis allowed us to determine the needed time for water recession and rural plain areas to be reclaimed for agricultural exploitation. With regard to buildings, the cities of Jérémie and Les Cayes were not only the most impacted areas, but also were those where most reconstruction efforts were made. However, some instances of new settlements located in at-risk zones, and thus being susceptible to future hurricanes, were found. This result suggests that the thematic maps can support policy-makers and regulators in reducing risk and making the reconstruction more resilient. Finally, to evaluate the replicability of the proposed method, an example at a country-scale is discussed with regard to the June 2023 flooding event. Full article

Rapid rises in water levels due to heavy rainfall can lead to the accumulation of floating debris, posing significant challenges for both water quality and resource management. However, real-time monitoring of floating debris remains difficult due to the discrepancy between meteorological conditions and the timing of debris accumulation. To address this limitation, this study proposes an amplitude change detection (ACD) model based on time-series synthetic aperture radar (SAR) imagery, which is less affected by weather conditions. The model statistically distinguishes floating debris from open water based on their differing scattering characteristics. The ACD approach was applied to 18 pairs of Sentinel-1 SAR images acquired over Daecheong Reservoir from June to September 2024. A stringent type I error threshold (α < 1 × 10⁻⁸) was employed to ensure reliable detection. The results revealed a distinct cumulative effect, whereby the detected debris area increased immediately following rainfall events. A positive correlation was observed between 10-day cumulative precipitation and the debris-covered area. For instance, on 12 July, a floating debris area of 0.3828 km² was detected, which subsequently expanded to 0.4504 km² by 24 July. In contrast, on 22 August, when rainfall was negligible, no debris was detected (0 km²), indicating that precipitation was a key factor influencing the detection sensitivity. Comparative analysis with optical imagery further confirmed that floating debris tended to accumulate near artificial barriers and narrow channel regions. Overall, this study demonstrates that this spatial pattern suggests the potential to use detection results to estimate debris transport pathways and inform retrieval strategies. Full article

For change detection in synthetic aperture radar (SAR) imagery, amplitude change detection (ACD) and coherent change detection (CCD) are widely employed. However, time-series SAR data often contain noise and variability introduced by system and environmental factors, requiring mitigation. Additionally, the stability of SAR signals is preserved when calibration accounts for temporal and environmental variations. Although ACD and CCD techniques can detect changes, spatial variability outside the primary target area introduces complexity into the analysis. This study presents a robust change detection methodology designed to identify urban changes using KOMPSAT-5 time-series data. A comprehensive preprocessing framework—including coregistration, radiometric terrain correction, normalization, and speckle filtering—was implemented to ensure data consistency and accuracy. Statistical homogeneous pixels (SHPs) were extracted to identify stable targets, and coherence-based analysis was employed to quantify temporal decorrelation and detect changes. Adaptive thresholding and morphological operations refined the detected changes, while small-segment removal mitigated noise effects. Experimental results demonstrated high reliability, with an overall accuracy of 92%, validated using confusion matrix analysis. The methodology effectively identified urban changes, highlighting the potential of KOMPSAT-5 data for post-disaster monitoring and urban change detection. Future improvements are suggested, focusing on the stability of InSAR orbits to further enhance detection precision. The findings underscore the potential for broader applications of the developed SAR time-series change detection technology, promoting increased utilization of KOMPSAT SAR data for both domestic and international research and monitoring initiatives. Full article

The rapid detection of landslide phenomena that may be triggered by extreme rainfall events is a critical point concerning timely response and the implementation of mitigation measures. The main goal of the present study is to identify susceptible areas by estimating changes in the Normalized Difference Vegetation Index (NDVI), Normalized Difference Moisture Index (NDMI), Bare Soil Index (BSI), and Synthetic Aperture Radar (SAR) amplitude ratio before and after extreme rainfall events. The developed methodology was utilized in a case study of Storm Daniel, which struck central Greece in September 2023, with a focus on the Mount Pelion region on the Pelion Peninsula. Using Google Earth Engine, we processed satellite imagery to calculate these indices, enabling the assessment of vegetation health, soil moisture, and exposed soil areas, which are key indicators of landslide activity. The methodology integrates these indices with a Weight of Evidence (WofE) model, previously developed to identify regions of high and very high landslide susceptibility based on morphological parameters like slope, aspect, plan and profile curvature, and stream power index. Pre- and post-event imagery was analyzed to detect changes in the indices, and the results were then masked to focus only on high and very high susceptibility areas characterized by the WofE model. The outcomes of the study indicate significant changes in NDVI, NDMI, BSI values, and SAR amplitude ratio within the masked areas, suggesting locations where landslides were likely to have occurred due to the extreme rainfall event. This rapid detection technique provides essential data for emergency services and disaster management teams, enabling them to prioritize areas for immediate response and recovery efforts. Full article

In response to the conflicting demands between real-time satellite communication and high-resolution synthetic aperture radar (SAR) imaging, we propose a method that aligns the data transmission rate with the imaging data volume. This approach balances SAR performance with the requirements for real-time data transmission. To meet the need for mobile user terminals to access real-time SAR imagery data of their surroundings without depending on large traditional ground data transmission stations, we developed an application system based on filter bank multicarrier offset quadrature amplitude modulation (FBMC-OQAM). To address the interference problem with SAR signals’ transmission and reception, we developed a signal sequence based on spaceborne SAR echo and data transmission and reception. This system enables SAR and data transmission signals to share the same frequency band, radio frequency transmission system, and antenna, creating an integrated sensing and communication system. Simulation experiments showed that, compared to the equal power allocation scheme for subcarriers, the echo image signal-to-noise ratio (SNR) improved by 2.79 dB and the data transmission rate increased by 24.075 Mbps. Full article

High-resolution and wide-swath (HRWS) synthetic aperture radar (SAR) imaging with azimuth multi-channel always suffers from channel phase and amplitude errors. Compared with spatial-invariant error, the range-dependent channel phase error is intractable due to its spatial dependency characteristic. This paper proposes a novel parameterized channel equalization approach to reconstruct the unambiguous SAR imagery. First, a linear model is established for the range-dependent channel phase error, and the sharpness of the reconstructed Doppler spectrum is used to measure the unambiguity quality. Furthermore, the intrinsic relationship between the channel phase errors and the sharpness is revealed, which allows us to estimate the optimal parameters by maximizing the sharpness of the reconstructed Doppler spectrum. Finally, the results from real-measured data show that the suggested method performs exceptionally for ambiguity suppression in HRWS SAR imaging. Full article

Urban landslides have brought challenges to developing countries undergoing urbanization. Rapid approaches to assess ground deformation are required when facing the challenge of insufficient geological survey methods. Additionally, it is indeed a challenge to map landslide-affected areas, especially precipitation-induced landslides, through optical remote sensing methods. This study applied SAR change detection methods to map the slope failure event of the San Jorge Kantutani landfill site in La Paz, Bolivia, which occurred in April 2019, and Multi-Temporal Synthetic Aperture Radar Interferometry (MTInSAR) methods to assess pre- and post-failure ground stability related to this event. We found that the amplitude information of high-resolution COSMO-SkyMed SAR imagery and its texture information can be very useful in landslide mapping, especially in situations in which optical images are not available because of complex meteorological conditions and the similar spectral characteristics between the original land cover and landslide deposits. The MTInSAR analyses found that there was already significant deformation of more than 50 mm/year along the slope direction over this site before the landslide, and such deformation could be clearly discriminated from the surrounding environment. After the landslide event and the remobilization of the landslide deposit, the slope still shows a deformation velocity of more than 30 mm/year. The SAR amplitude change detection and MTInSAR fully exploited the SAR data in landslide studies and were useful in back analyzing the occurred landslides; this could be a good method for monitoring the ground stability of La Paz or even on a national scale over the long term for reducing the catastrophic effects of geological hazards in this landslide-prone city. Full article

Shadows are a special distortion in synthetic aperture radar (SAR) imaging. They often hamper proper image understanding and target recognition but also offer useful information, and therefore, the statistical modeling of SAR image shadows is imperative. In this endeavor, we systematically deduced the statistical models of shadows in multimodal SAR images, including single-look intensity and amplitude images and multilook intensity and amplitude images in a real domain and complex domain, respectively. In particular, for the filtered SAR image shadow, we introduced the generalized extreme value (GEV) distribution to characterize its statistics. We carried out an experiment on shadows in a real SAR image and conducted chi-square goodness-of-fit tests on the deduced models. Furthermore, we compared the deduced statistical models of shadows with state-of-the-art statistical models of SAR imagery. Finally, suggestions are given for selecting the optimal statistical model of shadows in multimodal SAR images. Full article

Cross-correlation of image-pairs derived from both optical and synthetic aperture radar satellite imagery is the most common technique for measuring glacier flow velocity and quantifying the dynamics and discharge of glaciers. While the technique has been shown to be effective on polar ice sheets, the accuracy of satellite-derived velocities in temperate alpine regions is poorly constrained. Flow velocities were measured in situ using an RTK-GPS along four profiles on Taku, Matthes, Vaughan-Lewis, and Llewellyn Glaciers in southeast Alaska from 2016 through 2018. These GNSS-measured velocities were correlated against spatially coincident and contemporaneous satellite-derived velocity datasets, including both versions 1 and 2 of ITS_LIVE and velocities determined by offset tracking of SAR data in the Sentinel Application Platform (SNAP) and GAMMA (RETREAT dataset). Significant gaps in velocity maps derived from optical imagery (Landsat/Sentinel-2) were observed and determined to be due to low coherence rather than cloud contamination. Cross-correlation of SAR data (Sentinel-1) in SNAP and RETREAT achieved better accuracy compared to optical, although a strong dichotomy in performance was observed. SAR-derived velocities in the accumulation zone and transient snowline area showed overall poor correlation to GNSS-measured velocities that were likely due to significant shifts in the backscatter amplitude of the homogenous, snow-covered surface, although both SAR-derived SNAP and RETREAT velocities were anomalously accurate where GNSS velocities were below 0.10 m/day along the glacier margins. SNAP and RETREAT achieved the most accurate results in the study in the ablation zone of the Llewellyn Glacier where stable backscatter targets on the glacier surface (crevasses, supraglacial debris) facilitated high coherence in the cross-correlation procedure. SAR data are likely the most suitable for the derivation of satellite-derived velocities on temperate alpine glaciers, particularly in slow-moving and ablation zones, but should be subject to scrutiny for fast-flowing glaciers and those with an active hydrologic surface system. Full article

Circular synthetic aperture radar (CSAR) has the potential to form 3D images with single-pass single-channel radar data, which is very time-efficient. This article proposes a volumetric neural renderer that utilizes CSAR 2D amplitude images to reconstruct the 3D power distribution of the imaged scene. The innovations are two-fold: Firstly, we propose a new SAR amplitude image formation model that establishes a linear mapping relationship between multi-look amplitude-squared SAR images and a real-valued 4D (spatial location (x, y, z) and azimuth angle $\theta$) radar scattered field. Secondly, incorporating the proposed image formation model and SAR imaging geometry, we extend the neural radiance field (NeRF) methods to reconstruct the 4D radar scattered field using a set of 2D multi-aspect SAR images. Using real-world drone SAR data, we demonstrate our method for (1) creating realistic SAR imagery from arbitrary new viewpoints and (2) reconstructing high-precision 3D structures of the imaged scene. Full article

Interferometric coherence from SAR data is a tool used in a variety of Earth observation applications. In the context of crop monitoring, vegetation indices are commonly used to describe crop dynamics. The most frequently used vegetation indices based on radar data are constructed using the backscattered intensity at different polarimetric channels. As coherence is sensitive to the changes in the scene caused by vegetation and its evolution, it may potentially be used as an alternative tool in this context. The objective of this work is to evaluate the potential of using Sentinel-1 interferometric coherence for this purpose. The study area is an agricultural region in Sevilla, Spain, mainly covered by 18 different crops. Time series of different backscatter-based radar vegetation indices and the coherence amplitude for both VV and VH channels from Sentinel-1 were compared to the NDVI derived from Sentinel-2 imagery for a 5-year period, from 2017 to 2021. The correlations between the series were studied both during and outside the growing season of the crops. Additionally, the use of the ratio of the two coherences measured at both polarimetric channels was explored. The results show that the coherence is generally well correlated with the NDVI across all seasons. The ratio between coherences at each channel is a potential alternative to the separate channels when the analysis is not restricted to the growing season of the crop, as its year-long temporal evolution more closely resembles that of the NDVI. Coherence and backscatter can be used as complementary sources of information, as backscatter-based indices describe the evolution of certain crops better than coherence. Full article

Volcanic eruptions pose a great threat to humans. In this context, volcanic hazard and risk assessment constitute crucial issues with respect to mitigating the effects of volcanic activity and ensuring the health and safety of inhabitants. Lava flows directly affect communities living near active volcanoes. Nowadays, remote sensing advances make it possible to effectively monitor eruptive activity, providing immediate and accurate information concerning lava evolution. The current research focuses on the mapping of the surface deformation and the analysis of lava flow evolution occurred on the island of La Palma, during the recent (2021) eruptive phase of the volcano. Sentinel-1 data covering the island were collected throughout the entire eruptive period, i.e., September 2021 until January 2022. The processing was based on amplitude-based and phase-based detection methods, i.e., Synthetic Aperture Radar interferometry (InSAR) and offset tracking. In particular, ground deformation occurred on the island, while Line-Of-Sight (LOS) displacements were derived from Sentinel-1 interferograms. Moreover, the evolution of lava flow velocity was estimated using Sentinel-1 imagery along with offset tracking technique. The maximum lava flow velocity was calculated to be 2 m/day. It was proved that both approaches can provide rapid and useful information in emergencies, especially in inaccessible areas. Although offset tracking seems a quite promising technique for the mapping of lava flows, it still requires improvement. Full article

This article introduces exponentiated transmuted-inverted beta (ET-IB) distribution, supported by a continuous positive real line, as a synthetic aperture radar (SAR) imagery descriptor. It is an extension of the inverted beta distribution, an important texture model for SAR imagery. The considered distribution extension approach increases the flexibility of the baseline distribution, and is a new probabilistic model useful in SAR image applications. Besides introducing the new model, the maximum likelihood method is discussed for parameter estimation. Numerical experiments are performed to validate the use of the ET-IB distribution as a SAR amplitude image descriptor. Finally, three measured SAR images referring to forest, ocean, and urban regions are considered, and the performance of the proposed distribution is compared to distributions usually considered in this field. The proposed distribution outperforms the competitor models for modeling SAR images in terms of some selected goodness-of-fit measures. The results show that the ET-IB distribution is suitable as a SAR descriptor and can be used to develop image-processing tools in remote sensing applications. Full article

Mapping the outlines of glaciers has primarily relied on the interpretation of satellite optical images. However, the accurate delineation of glaciers in complex terrain mountain regions remains challenging, mainly because the supraglacial debris-covered ablation zones and snow-covered accumulation zones often exhibit the same spectral properties as their adjacent grounds in optical images. This study presents a novel approach by exploring both the satellite synthetic aperture radar (SAR) amplitude and interferometric coherence to map mountain glaciers. This method explores the deviation of the glacier surface signal in the SAR time series to distinguish glacier ice from the surrounding stable ground. To this end, we explored the classifying capabilities of two indices from a set of SAR images, SAR interferometric coherence and amplitude deviation index (ADI), to determine glacier boundary. We found that the two indices complement each other for mapping glaciers. A ratio map based on ADI and SAR coherence (ACR) was then derived, from which the glacier outline was automatically tracked using a specified threshold, followed by manual modification. We validated this approach on two typical valley glaciers, the debris-covered Hailuogou Glacier and debris-free Mozigou Glacier, in Mount Gongga in the southeastern Tibetan Plateau. The results show that the proposed ACR criteria can significantly enhance the contrast between glaciers and their surroundings. By comparing our results with manually delineated glacier outlines from high-resolution cloud-free satellite optical imagery, we found that the misclassification rate and difference rate for our results were 2.6% and 4.2%, respectively. The approach presented in this study can be easily adapted to map the outlines of mountain glaciers worldwide efficiently and is useful for inferring glacier boundary changes in a climate warming context. Full article

Multiple landslide events are common around the globe. They can cause severe damage to both human lives and infrastructures. Although a huge quantity of research has been shaped to address rapid mapping of landslides by optical Earth Observation (EO) data, various gaps and uncertainties are still present when dealing with cloud obscuration and 24/7 operativity. To address the issue, we explore the usage of SAR data over the eastern Iburi sub-prefecture of Hokkaido, Japan. In the area, about 8000 co-seismic landslides were triggered by an Mw 6.6 earthquake on 6 September 2018, at 03.08 local time (JST). In the following study, we modify a Deep Learning (DL) convolutional neural network (CNN) architecture suited for pixel-based classification purposes, the so-called Attention U-Net (Attn-U-Net) and we employ it to evaluate the potential of bi- and tri-temporal SAR amplitude data from the Sentinel-1 satellite and slope angle to map landslides even under thick cloud cover. Four different datasets, composed of two different band combinations per two satellite orbits (ascending and descending) are analyzed. Moreover, the impact of augmentations is evaluated independently for each dataset. The models’ predictions are compared against an accurate landslide inventory obtained by manual mapping on pre-and post-event PlanetScope imagery through F1-score and other common metrics. The best result was yielded by the augmented ascending tri-temporal SAR composite image (61% F1-score). Augmentations have a positive impact on the ascending Sentinel-1 orbit, while metrics decrease when augmentations are applied on descending path. Our findings demonstrate that combining SAR data with other data sources may help to map landslides quickly, even during storms and under deep cloud cover. However, further investigations and improvements are still needed, this being one of the first attempts in which the combination of SAR data and DL algorithms are employed for landslide mapping purposes. Full article
