In this study, the ballistic effectiveness of Kevlar 29 composites was analyzed by combining 400 and 460 GSM grammages with a polyurethane matrix. Plates measuring 300 mm × 250 mm were fabricated using hand lamination and compression techniques, with reinforcement designs consisting of 10, 14, and 18 layers of Kevlar 29 fabric oriented at a 90° angle. Ballistic tests were conducted following the parameters of the NIJ 0108.01 standard, applying five impacts with 9 mm FMJ and 22 (5.5 mm) caliber bullets. Both the composites and pure Kevlar were evaluated. Post-damage visual analysis was conducted on the front and back faces, as well as the interior of the composite, to identify delamination and fractures. The results show that .22 caliber bullets were captured at various stacking levels depending on the configuration, whereas 9 mm bullets penetrated all the plates. Localized fractures and delamination associated with the impacts were observed, highlighting the importance of stacking design and grammage in the material’s energy dissipation capacity. Full article

The aim of this work is to comparatively analyze, using numerical simulation, the impact behavior of aramid fabric. A layered panel was impacted by two projectiles specific to the NIJ protection level HG1. The protection level in this study is based on NIJ Standard 0123.00. This standard is used to establish protection levels. The two projectiles specific to the NIJ HG1 protection level are 9 mm Luger and .357 Mag FMJ. Law enforcement personnel use body armor designed to protect the torso. With the help of numerical simulation, the mechanisms of destruction of the aramid fabric on impact are identified. The protection performance is analyzed as a function of the influence of the number of layers and the projectile velocity variation. The fabric is modeled at the yarn level, with each yarn consisting of hundreds or even thousands of fibers. Simulations are performed at the yarn level, since fiber-level modeling is difficult to implement due to high computational resource requirements. The material properties for the yarn, as well as for the projectiles, are selected from the literature. The results show that only the 20-layer fabric panel impacted by the 9 mm Luger FMJ RN 9 mm FMJ RN projectile at 398 m/s meets the protection requirements of the NIJ standard (NIJ HG1 protection level). In contrast, panels impacted at 436 m/s, or those with fewer layers, show rapid stress wave propagation, severe deformation, and complete perforation, indicating insufficient energy dissipation. This study highlights the critical role of impact velocity, projectile geometry, and number of layers in determining ballistic resistance. These findings contribute to the development of more effective ballistic protective equipment, highlighting the need for optimized layer configurations and improved material properties to meet NIJ standards under different impact conditions. Full article

Ballistic helmets are individual pieces of armor equipment designed to protect a soldier’s head from projectiles and fragments. Although very common, these helmets are responsible for several casualties due to their significant back face deformation and low ballistic resistance to projectiles. Therefore, to enhance helmet performance, studies have focused on the development of new materials and new ballistic protection solutions. The purpose of this study was to develop and evaluate a new ballistic solution using thermoplastic-based matrices. The first matrix was based on high-density polyethylene (HDPE). The second matrix was based on HDPE modified with exfoliated montmorillonite (MMT). The main manufacturing processes of a thermoplastic-based ballistic helmet are presented, along with its ballistic performance, according to the National Institute of Justice (NIJ) standard 0106.01 and an investigation of its failure mechanisms via a non-destructive technique. All the helmets resulted in level III-A ballistic protection. The postimpact helmets were scanned to evaluate the back face deformation dimensions, which revealed that the global cone deformation was deeper in the HDPE than in the HDPE/MMT helmet. The failure analysis revealed an overall larger deformation area in the HDPE and HDPE/MMT helmet delamination zones in the regions with a large radius of curvature than in the zones with the lowest radius, which is in accordance with previous simulations reported in the literature. Full article

The development of Ballistic Protection Vests (BPVs) has gained significant attention, particularly focusing on the design of Ballistic Protection Soft Panels (BPSPs), which are crucial to the overall size and configuration of these vests. Despite their critical role, there is a noticeable lack of a standardized design method for surface area patterns of BPSPs in the existing literature. The findings indicate that the National Institute of Justice (NIJ) standard 0101.06 Ballistic Test Templates (BTTs) are only partially applicable to the design of BPSP patterns. While the NIJ standard 0101.06 provides a useful framework, it requires adaptation to meet the specific needs of regional body types and the practicalities of BPV manufacturing. This research aims to address this gap by assessing the suitability of NIJ BTTs for the design of BPSPs and BPVs and to develop a standardized pattern design methodology along with a method for calculating the surface area of the soft amour prior to its creation. Results have to be achieved ready for the production of BPSP patterns tailored to the body types of regional soldiers while adhering to relevant standards and soldier’s physical comfort, thereby saving time and resources for manufacturers and researchers. In this study, we evaluated the applicability of the NIJ standard 0101.06 BTT for configuring these templates into the cutting patterns of BPSPs. To achieve this, patterns for BPSPs were designed and the feasibility of using NIJ BTTs for their configuration was analyzed. The research process involved a comprehensive literature review, an analysis of the dimensions of existing BPV soft panels, and a comparison with NIJ standard 0101.06 BTT. The design and scaling of the panel patterns were executed using computer-aided design (CAD) systems and evaluated through both physical fitting on mannequins and virtual fitting using the Clo3D program. The developed pattern-making methodology includes size specifications tailored to regional covers, incorporating a coefficient K identified to calculate the BPSP surface area prior to design. This approach not only ensures better fitting for the physical comfort and protection of soldiers but also saves time and resources in the manufacturing process of BPSPs. The proposed design methodology offers a significant step forward in standardizing BPSP patterns, promising enhanced protection and efficiency in BPV manufacturing. Full article

The aim of this study is to analyze the ballistic impact behavior of a panel made of Twaron CT736 fabric with a 9 mm Full Metal Jacket (FMJ) projectile. Three shots are fired at different velocities at this panel. The ballistic impact test procedure was carried out in accordance with NIJ 010106. The NIJ-010106 standard is a document that specifies the minimum performance requirements that protection systems must meet to ensure performance. The 9 mm FMJ projectile is, according to NIJ 010106, in threat level II, but the impact velocity is in threat level IIIA. Analysis of macro-photographs of the impact of the Twaron CT736 laminated fabric panel with a 9 mm FMJ projectile involves a detailed examination of the images to gather information about the material performance and failure mechanisms at the macro- or even meso-level (fabric/layer, thread). In this paper, we analyze numerically and experimentally a panel consisting of 32 layers, made of a single material, on impact with a 9 mm FMJ projectile. The experimental results show that following impact of the panel with three projectiles, with velocities between 414 m/s and 428 m/s, partial penetration occurs, with a different number of layers destroyed, i.e., 15 layers in the case of the projectile velocity of 414 m/s, 20 layers of material in the case of the panel velocity of 422 m/s and 22 layers destroyed in the case of the projectile velocity of 428 m/s. Validation of the simulated model is achieved by two important criteria: the number of broken layers and the qualitative appearance. Four numerical models were simulated, of which three models validated the impact results of the three projectiles that impacted the panel. Partial penetration occurs in all four models, breaking the panel in the impact area, with only one exception, i.e., the number of layers destroyed, in which case the simulation did not validate the validation criterion. The performance of Twaron CT736 fabric is also given by the indentation depth values by two methods: according to NIJ 0101.06 and by 3D scanning. The NIJ 010106 standard specifies that a panel provides protection when the indentation depth values are less than 0.44 mm. Full article

This paper presents research on several factors influencing the stabbing behaviour of stratified panels made of aramid fabric Twaron^® SRM509 Teijin Aramid BV (Arnhem, The Netherlands). The inputs in the test campaign were the number of layers, the impact energy, and the sample size. Tests were performed on small samples (130 mm × 130 mm) on an Instron^® CEAST 9350 drop-tower impact system (Norwood, MA, USA) and on larger samples (400 mm × 400 mm) using a test installation with the same values of the impact energy. Knife type S1 was used, with the geometry recommended in NIJ Standard 0115.00 Stab Resistance of Body Armor SEM, and macro photography investigations revealed the failure mechanisms of panel, layers and fibres. A very important conclusion of this study regarding the stabbing performance of fabric Twaron^® SRM 509 in particular, but also in general for panels for body protection is that a research study could start on small size samples, with an accurately instrumented machine, in order to establish the influence of significant factors of stab resistance (energy level, number of layers in a panel, etc.), as these samples are less expensive and less time consuming, but the study should be continued to examine larger size samples. The obtained data are useful for the prototype. Full article

Arapaima scales possess a hierarchical structure capable of absorbing a considerable amount of energy before fracture. These natural dermal armors present significant potential in the sustainable development of cost-effective composites. This work aimed, for the first time, to analyze the impact resistance and ballistic performance of arapaima scale-reinforced epoxy composites and their potential application in multilayered armor systems (MAS). Composite plates were prepared with 20%, 30%, and 40 vol% of arapaima scales. Composite specimens were subjected to notched Izod impact and residual velocity stand-alone tests and their MAS through backface signature (BFS) tests, with their fracture surfaces studied using SEM. The Izod tests confirmed the effect of scales’ volume fraction on the energy absorbed by the composites, showing an increase with volume fraction. Residual velocity tests showed that composites with 30 vol% of scales resulted in the most significant improvement in absorbed energy. All MAS formulations presented BFS depths lower than the trauma limit specified by the NIJ standard. Fractographic analysis showed that the scales’ toughening mechanisms improved the composites’ energy absorption capacity. The experimental results substantiate the potential use of arapaima scales as a reinforcement agent in polymeric composites, with 30 vol% being the optimal volume fraction for energy-absorbing applications. Full article

The idea of flexible body armor has been around for many years. Initial development included shear thickening fluid (STF) as a backbone polymer to impregnate ballistic fibers such as Kevlar. At the core of the ballistic and spike resistance was the instantaneous rise in viscosity of STF during impact. Increase in viscosity was due to the hydroclustering of silica nanoparticles dispersed in polyethylene glycol (PEG) through a centrifuge and evaporation process. When STF composite was dry, hydroclustering was not possible due to absence of any fluidity in PEG. However, particles embedded within the polymer, covered the Kevlar fiber and offered some resistance to spike and ballistic penetration. The resistance was meagre and hence, the goal was to improve it further. This was achieved by creating chemical bonds between particles, and by strongly attaching particles to the fiber. PEG was replaced with silane (3-amino propyl trimethoxysilane), and a fixative cross-linker, Glutaraldehyde (Gluta), was added. Silane installed an amine functional group on the silica nanoparticle surface, and Gluta created strong bridges between distant pairs of amine groups. Amide functional groups present in Kevlar also interacted with Gluta and silane to form a secondary amine, allowing silica particles to attach to fiber. A network of amine bonding was also established across the particle-polymer-fiber system. In synthesizing the armor, silica nanoparticles were dispersed in a mixture of silane, ethanol, water, and Gluta, maintaining an appropriate ratio by weight, and using a sonication technique. Ethanol was used as a dispersion fluid and was evaporated later. Several layers of Kevlar fabric were then soaked with the admixture for about 24 h and dried in an oven. Armor composites were tested in a drop tower according to NIJ115 Standard using spikes. Kinetic energy at impact was calculated and normalized with the aerial density of the armor. NIJ tests revealed that normalized energy for 0-layer penetration increased from 10 J-cm²/g (STF composite) to 220 J-cm²/g for the new armor composite, indicating a 22-fold enhancement. SEM and FTIR studies confirmed that this high resistance to spike penetration was due to the formation of stronger C-N, C-H, and C=C-H stretches facilitated by the presence of silane and Gluta. Full article

As destructive power of firearms raises over the years, ballistic armors are in continuous need of enhancement. For soft armors, this improvement is invariably related to the increase of stacked layers of high-strength fiber fabrics, which potentially restrains wearer mobility. A different solution was created in the early 2000s, when a research work proposed a new treatment of the ballistic panels with non-Newtonian colloidal shear thickening fluid (STF), in view of weight decreasing with strength reinforcement and cost-effective production. Since then, databases reveal a surge in publications generally pointing to acceptable features under ballistic impact by exploring different conditions of the materials adopted. As a result, several works have not been covered in recent reviews for a wider discussion of their methodologies and results, which could be a barrier to a deeper understanding of the behavior of STF-impregnated fabrics. Therefore, the present work aims to overview the unexplored state-of-art on the effectiveness of STF addition to high-strength fabrics for ballistic applications to compile achievements regarding the ballistic strength of this novel material through different parameters. From the screened papers, SiO${}_2$, Polyethylene glycol (PEG) 200 and 400, and Aramid are extensively being incorporated into the STF/Fabric composites. Besides, parameters such as initial and residual velocity, energy absorbed, ballistic limit, and back face signature are common metrics for a comprehensive analysis of the ballistic performance of the material. The overview also points to a promising application of natural fiber fabrics and auxetic fabrics with STF fluids, as well as the demand for the adoption of new materials and more homogeneous ballistic test parameters. Finally, the work emphasizes that the ballistic application for STF-impregnated fabric based on NIJ standards is feasible for several conditions. Full article

The main objective of this study focuses on designing and testing body protection systems using advanced materials based on aramid fibers, for high impact speeds of up to 420 ± 10 m/s. Ballistic applications of aramid fiber-based composites mostly include soft body armors. The investigation of the failure mechanisms identifies issues of protective fabrics, major challenges and technological problems for efficient development of these systems. The authors present an investigation on the failure processes and destructive stages of a ballistic package made of successive layers of LFT SB1plus, a trade name for a multiaxial fabric by Twaron Laminated Fabric Technology (LFT), taking into account the particular test conditions from NIJ Standard-0101.06 Ballistic Resistance of Body Armor. The main parameter of interest was the backface signature (BFS), but also details of projectile arrest and SEM investigation could offer arguments for using this material for individual protection. For the reported tests, the maximum and minimum values for BFS were 12 mm and 24 mm, the mean value being 18.66 mm and the standard deviation being 3.8 mm. Full article

Since the mid-2000s, several studies were carried out regarding the development of ballistic resistant materials based on polymeric matrix composites reinforced with natural lignocellulosic fibers (NLFs). The results reported so far are promising and are often comparable to commonly used materials such as Kevlar^TM, especially when used as an intermediate layer in a multilayer armor system (MAS). However, the most suitable configuration for these polymer composites reinforced with NLFs when subjected to high strain rates still lacks investigation. This work aimed to evaluate four possible arrangements for epoxy matrix composite reinforced with a stiff Brazilian NLF, piassava fiber, regarding energy absorption, and ballistic efficiency. Performance was evaluated against the ballistic impact of high-energy 7.62 mm ammunition. Obtained results were statistically validated by means of analysis of variance (ANOVA) and Tukey’s honest test. Furthermore, the micromechanics associated with the failure of these composites were determined. Energy absorption of the same magnitude as Kevlar^TM and indentation depth below the limit predicted by NIJ standard were obtained for all conditions. Full article

In this paper, hybrid composite plates for ballistic protection were investigated experimentally and numerically, with a target to reduce the weight of currently used body armor inserts and, at the same time, satisfy the requirements of the National Institute of Justice’s (NIJ) ballistic protection standards. The current study has three phases to improve the ballistic plate’s energy absorption capability. The first phase is devoted to studying the effect of the material types, including three different fibers: carbon fiber, date palm fiber, and Kevlar fiber. The second phase is dedicated to studying the effect of hybridization within layers. The two previous phases’ results were analyzed to optimize the material based on the hybrid composite ballistic plate’s maximum energy absorption capability. The commercial finite element software package LS-DYNA was employed for numerical modeling and simulation. The hybrid composite ballistic plate could absorb more impact energy than the non-hybrid Kevlar plate with the same area density from the numerical simulation results. This study provides lighter-weight ballistic inserts with a high protection level, making movement easier for the wearer. The numerical results were verified by comparing results of a plate made of 40 layers of Kevlar with an actual ballistic test. The results indicated that the simulation results were conservative compared to the ballistic test. Full article

Multilayered armor systems (MAS) with a front ceramic layer backed by a relatively unknown Amazonian guaruman fiber-reinforced (Ischnosiphon koem) epoxy composites, as second layer, were for the first time ballistic tested against the threat of 7.62 mm rifle ammunition. The amount of 30 vol% guaruman fibers was investigated in three distinct configurations: (i) continuous aligned, (ii) 0–90° cross-laid, and (iii) short-cut randomly dispersed. Additionally, single-target ballistic tests were also carried out in the best MAS-performed composite with cross-laid guaruman fibers against .22 caliber ammunition. The results disclosed that all composites as MAS second layer attended the US NIJ standard with corresponding penetration depth of (i) 32.9, (ii) 27.5, and (iii) 29.6 mm smaller than the lethal limit of 44 mm in a clay witness simulating a personal body. However, the continuous aligned guaruman fiber composite lost structural integrity by delamination after the 7.62 projectile impact. By contrast, the composite with cross-laid guaruman fibers kept its integrity for subsequent shootings as recommended by the standard. The single-target tests indicated a relatively higher limit velocity for .22 caliber projectile perforation, 255 m/s, and absorbed energy of 106 J for the cross-laid guaruman fibers, which are superior to corresponding results for other less known natural fiber epoxy composites. Full article

The effects of the yarn composition system inside 3D woven high-performance textiles are not well investigated and understood against their final ballistic impact behaviour. The current study aims to examine the ballistic impact performances of armour panels made of different 3D woven fabric variants through postmortem observations. Four high-performance five-layer 3D woven fabric variants were engineered based on their different warp yarn compositions but similar area density. A 50 × 50 cm² armour system of each variant, which comprises eight nonbonded but aligned panels, namely, 3D-40-8/0 (or 8/0), 3D-40-8/4 (or 8/4), 3D-40-8/8 (or 8/8) and 3D-40-4/8 (or 4/8), were prepared and moulded to resemble female frontal morphology. The armour systems were then tested with nonperforation ballistic impacts according to the National Institute of Justice (NIJ) 0101.06 standard Level-IIIA. Two high-speed cameras were used to capture the event throughout the test. Nondestructive investigation (NDI) using optical microscopic and stereoscopic 3D digital images were employed for the analysis. The armour panels made of the 8/0 and 4/8 fabric variants were perforated, whereas the armour made of the 8/8 and 8/4 fabric variants showed no perforation. Besides, the armour made of the 8/4 fabric variant revealed higher local and global surface displacements than the other armours. The current research findings are useful for further engineering of 3D woven fabric for seamless women’s impact protective clothing. Full article

This study aims to develop a lightweight ballistic helmet based on nanocomposite with matrix of the copolymer of benzoxazine with an urethane prepolymer [poly(BA-a-co-PU)], at mass ratio 80/20, reinforced with aramid fabric and multi-walled carbon nanotubes (MWCNTs). This has a protection level II according to the National Institute of Justice (NIJ) 0106.01 standard. The effects of MWCNTs mass content in a range of 0 to 2 wt% on tensile, physical and ballistic impact properties of the nanocomposite were investigated. The results revealed that the introduction of MWCNTs enhanced the tensile strength and energy at break of the nanocomposite; the highest values were obtained at 0.25 wt%. In addition, the nanocomposite laminate with 20 plies of aramid fabric showed the lowest back face deformation of 8 mm which was much lower than that specified by the NIJ standard. According to Military Standard (MIL-STD) 662F, the simulation prediction revealed that the ballistic limit of the ballistic helmet nanocomposite was as high as 632 m s⁻¹. The developed laminates made of aramid fabric impregnated with poly(BA-a-co-PU) 80/20 containing 0.25 wt% MWCNTs showed great promise for use as a light weight and high-performance ballistic helmet. Full article
